Chapter 1
System Specifications Features This computer was designed with the user in mind. Here are just a few of its many features:
Performance T
Intel® Pentium M processor at 1.4~ 1.8 GMHz or higher with uPGA478 socket
T
Intel 855GME + Intel ICH4-M
T
1MB L2 cache or 2MB L2 cache, 400MHz FSB, supporting Enhanced Intel SpeedStep® technology
T
30GB and up Enhanced-IDE hard disk drive
T
512KB Flash BIOS ROM
Memory T
256MB of DDR333 memory, upgradeable to 2GB with dual SODIMM modules
T
0MB DDR RAM on board
Two 256MB of DDR333 SODIMM (200-pin/2.5V/1.25V) connector,upgradeable to 2GB with dual SODIMM modules NOTE: (Small Outline-DIMM) A DIMM module with a thinner profile due to the use of TSOP chip packages. SODIMMs are commonly used in laptop computers T
The pic of SODIMM as showing : (copyright from Techweb)
Display
Chapter 1
T
Thin-Film Transistor (TFT) liquid-crystal display (LCD) displaying 32-bit high true colour up to 16.7 million colours at 1280x800 eXtended Graphics Array (WXGA) resolution
T
The 15.4” display panel provides a large viewing area for maximum efficiency and ease-of-use
T
16:10 viewing ratio, 185 nits or higher
T
Console display for Arcade media playback status
T
Intel® Extreme Graphics Technology (for Aspire 2010 use only)
T
ATI Radeon 9700 with 64MB DDR VGA Memory (for model with Discrete VGA only)
T
ATI Radeon 9700 with 128MB DDR VGA Memory (for model with Aspire 2020 only)
T
Supports simultaneous display on external LCD or CRT
T
One LED console display for multimedia status (for Aspire 2020 only)
T
S-video for output to a television or display device that supports S-video input
T
DualViewTM support
T
External resolution/refresh rate T
2040x1536:75/70/66/60 Hz
T
1920x1440: 85/75/60 Hz
1
