Jumper and Connector Locations Top View
Item
Description
JP1
CRT
JP2
Parallel Port
JP3
TV-Out Connector
JP4
RJ11/45 Connector
JP5
1394 Connector
JP6/7/8
USB Connector
JP9
Modem Connector
JP11
PCMCIA Connector
JP12/13
AGP Connector
JP15
FAN Connector
JP16
MDC Connector
JP17
System Connector
JP18
R-SPK Connector
JP19
L-SPK Connector
JP20
T/P Connector
JP21
KB Connector
JP22
SO-DIMM1 Connector
JP23
CD-ROM Connector
JP25
HDD Connector
JP32
Cardreader Connector
