Jumper and Connector Locations Mainboard Top View
Item
Description
Item
Description
PJ2
DC-in
CN1
LED connector
PJ1
Battery connector
CN17
USB connector
CN6
LCD connector
CN18
HDMI
CN5
Touchscreen connector
CN2
Keyboard connector
CN7
Bluetooth connector
CN3
Touchpad connector
CN8
Speaker connector
CN4
Card reader board connector
