8. Turn the filter ONE FULL TURN ONLY after gasket contact. 9. Reconnect the cooler lines and tighten the fittings securely. 10. Replace the quantity of transmission fluid lost during the gasket replacement process. Refer to MT3190EN for fluid fill and check procedures.
6–6. REAR SEAL REPLACEMENT Use the following procedure for removal and installation of the output seal located in the rear cover of the transmission. Removal is usually required to repair a seal leak. a. Removal. WARNING: Chock wheels to prevent vehicle from moving when the driveline is disconnected. 1. Chock wheels to prevent vehicle movement. 2. If present, disconnect the parking brake apply linkage/cable from the parking brake apply lever. 3. Disconnect the vehicle driveline from the transmission output flange/yoke. Secure the driveline so that it does not interfere with the removal of parking brake components or the output flange/yoke. 4. Remove the bolt and sealing washer that attaches the output flange/yoke to the transmission output shaft. Remove the output flange/yoke. 5. Inspect the seal journal on the output flange/yoke. Replace the output flange/ yoke if scratches or machine type leading is present. Scratches or machine type leading can cause the seal to leak. Replace the output flange/yoke if light scoring cannot be removed using crocus cloth. 6. Obtain special tool J 24171-A and install the tip with a 90 degree hook onto the end of the slide-hammer. 7. Position the 90 degree hook behind the rear face of the seal outer case (see Figure 6–3). 8. Remove the rear seal using the slide-hammer.
