Chapter 1
System Specifications Features This computer was designed with the user in mind. Here are just a few of its many features:
Performance T
Intel® Pentium® M processor at 1.3 ~ 1.7 GHz or higher
T
Intel 855PM Chipset
T
Memory upgradeable up to 2GB with 2 slots
T
Internal removable optical drive (AcerMedia bay)
T
High-capacity, Enhanced-IDE hard disk
T
Li-Ion main battery pack
T
Power management system with ACPI (Advanced Configuration Power Interface)
T
14.1” or 15.0” Thin-Film Transistor (TFT) displaying at 1024x768 XGA resolution or 15.0” Thin-Film Transistor (TFT) displaying at 1400x1050 SXGA+ resolution
T
ATI Mobility Radeon 9700 with 64MB of external DDR video RAM, supporting Microsoft-DirextX9.0
T
3D graphics engine
T
Simultaneous LCD and CRT display support
T
S-video for output to a television or display device that supports S-video input
T
DualViewTM display support
Display
Multimedia T
16-bit high-fidelity AC’97 Codec stereo audio
T
Built-in dual speakers
T
High-speed optical drive (AcerMedia bay)
Connectivity T
High-speed fax/data modem port
T
Ethernet/Fast Ethernet port
T
Fast infrared wireless communication
T
Three USB 2.0 (Universal Serial Bus) ports (Two in rear and one on left)
T
IEEE 1394 port
T
InviLink 802.11b/g wireless LAN (manufacturing optional)
T
Bluetooth ready (manufacturing optional)
Expansion
Chapter 1
T
One type II CardBus PC Card slot
T
Upgradeable memory
1
