Pin
Wire
mm²
Designation
Tip
State
12
075-5
1.0
+ APC front tool power socket (5 A)
J289
B
13
236-5
0.5
D+ alternator
J004
2
14
188-5
0.5
Step working light command
J004
24
15
074-5
1.0
+ APC rear tool power socket (5 A)
J072
82
16
M161-5
2.5
Ground of front tool power socket 1
J289
J
17
M162-5
2.5
Ground of front tool power socket 2
J289
S
18
M130-5
2.5
Ground of rear tool power socket 1
J072
31
19
M131-5
2.5
Ground of rear tool power socket 2
J072
31
J063 Connector - Hexashift Transmission harness / V21-1 base plate
Pin
Wire
mm²
Designation
1
217-9
0,75
Reverser relay command
J003
36
2
631-9
0.75
J1939 CAN H powertrain (to transmission)
J158
2
3
508-9
0,75
Reverser engaged
J003
3
4
346-9
0.5
J1939 CAN H powertrain (to engine)
J003
39
5
349-9
0.5
J1939 CAN L powertrain (to engine)
J003
38
6
630-9
0.75
J1939 CAN L powertrain (to transmission)
J158
1
7
052-9
0,75
+ APC end of travel
N002
8
066-9
1.0
+ APC hydraulic pressure (rear axle)
J201
1
9
088-9
0,75
+ APC engine speed at gearbox entry
J305
3
10
M033-9
1
Range solenoid valve earth
N001
11
M061-9
0,75
Ground of braking solenoid valve (cuna, pneumatic, high pressure)
J306
D
11
M070-9
0,75
Ground of park lock
J094
6
12
M058-9
0,75
Ground of high pressure oil filter
J087
2
12
M079-9
1
Ground of hydraulic pressure (gearbox)
J202
2
13
M100-9
0,75
Ground of dephased engine speed
J083
2
14
M101-9
0,75
Ground of rear power take-off speed
J084
2
15
M027-9
0,75
Differential solenoid valve earth
J088
2
16
M021-9
0,75
Ground of 4 wheel drive solenoid valve
J089
2
17
M034-9
0,75
Ground of rear power take-off solenoid valve
J086
2
18
M065-9
0,75
Ground of reverter under torque module speed
J145
2
19
M099-9
0,75
Ground of engine speed at gearbox entry
J305
1
20
M102-9
0,75
Tractor speed earth
J082
2
21
M028-9
0,75
Ground of rear power take-off brake solenoid valve
J085
2
