J034 Connector - Cab bottom harness - Automatic A/C / V21-2 base plate
Pin
Wire
mm²
Designation
Tip
State
1
M075-1
3.0
Ground of V21-2 1 base plate
J293
1
2
M076-1
3.0
Ground of V21-2 2 base plate
J292
1
13
080-1
1.5
+ APC ventilation (automatic A/C)
P296
20
14
638-01
0.5
+ APC left panel sensor
P296
20
15
215-1
0.5
Cab + APC relay command
P297
7
18
119-1
1.5
Right indicator supply (by comodo)
P297
5
21
118-1
1.5
Right indicators supply (by warning lights button)
J112
5
J035 Connector - Cab bottom harness / V21-2 base plate (Up to No.A0901559)
F2.32
Pin
Wire
mm²
Designation
1
398-1
0.5
Sensor reference
J007
4
2
143-1
0.5
Hood grid temperature sensor reference (climate control)
P004
17
3
802-1
0.5
A/C caisson sensors reference
P296
21
4
608-1
0.5
Dashboard (vizor) temperature sensor reference
P296
18
5
443-1
0.5
Left panel temperature sensor reference
J107
1
6
508-1
0.5
Reverser engaged
P298
17
7
637-1
0.5
Line L (to dashboard)
P298
15
10
358-1
0.5
Line K (to dashboard)
P298
10
11
708-1
0.5
Line K (to V21-3)
J007
5
20
556-1
1.5
Warning lights button
J112
6
Axion 810-850 – 09.2009 – GB
Tip
State
