Pin
Wire
mm²
Designation
Tip
State
10
195-1
1.0
Front screen washer control
P299
17
11
373-1
0.5
Front windscreen washer pump
P004
33
12
121-1
1.5
Left indicators supply (by comodo)
P297
4
13
180-1
2.0
+ APC windscreen wiper/washer control
P299
1
14
133-1
1.0
+ APC cigar lighter
J113
3
14
871-1
0.5
+ APC event counter
J342
1
15
028-1
1.0
+ APC fixed stop wiper motor
P299
20
16
135-1
1.0
Windscr. wiper eng. park. pos.
P299
4
17
076-1
1.0
+ APC cab tool power socket
J115
1
19
161-1
1.0
Fixed stop command
P299
18
20
194-1
1.0
Intermittent control
P299
3
J034 Connector - Cab bottom harness - manual air conditioning / V21-2 base plate
Pin
Wire
mm²
Designation
1
M075-1
3.0
Ground of V21-2 1 base plate
J293
1
2
M076-1
3.0
Ground of V21-2 2 base plate
J292
1
10
214-1
0.5
Recirculating controls
P296
6
13
080-1
1.5
+ APC recirculation controls
P296
20
15
215-1
0.5
Cab + APC relay command
P297
7
16
385-1
0.5
Recirculation +
P296
9
18
119-1
1.5
Right indicator supply (by comodo)
P297
5
19
386-1
0.5
Recirculation -
P296
5
20
228-1
0.5
Air conditioning compressor
P004
26
21
118-1
1.5
Right indicators supply (by warning lights button)
J112
5
