J033 Connector - Cab bottom harness - manual air conditioning / V21-2 base plate
Pin
Wire
mm²
Designation
Tip
State
1
093-1
1.5
+ AVC warning lights button
J112
2
2
095-1
1.0
+ AVC key contact
P297
1
3
070-1
2.5
+ APC base plate (V21-1 supply) 1
P004
1
4
030-1
1.5
+ APC warning lights button
J112
8
5
072-1
3.0
+ APC V21-3 base plate
J008
2
6
071-1
2.5
+ APC base plate (V21-1 supply) 2
P004
3
10
195-1
1.0
Front screen washer control
P299
17
11
373-1
0.5
Front windscreen washer pump
P004
33
12
121-1
1.5
Left indicators supply (by comodo)
P297
4
13
180-1
2.0
+ APC windscreen wiper/washer control
P299
1
14
133-1
1.0
+ APC cigar lighter
J113
3
14
871-1
0.5
+ APC event counter
J342
1
15
028-1
1.0
+ APC fixed stop wiper motor
P299
20
16
135-1
1.0
Windscr. wiper eng. park. pos.
P299
4
17
076-1
1.0
+ APC cab tool power socket
J115
1
19
161-1
1.0
Fixed stop command
P299
18
20
194-1
1.0
Intermittent control
P299
3
J033 Connector - Cab bottom harness - Automatic A/C / V21-2 base plate
F2.30
Pin
Wire
mm²
Designation
1
093-1
1.5
+ AVC warning lights button
J112
2
2
095-1
1.0
+ AVC key contact
P297
1
3
070-1
2.5
+ APC base plate (V21-1 supply) 1
P004
1
4
030-1
1.5
+ APC warning lights button
J112
8
5
072-1
3.0
+ APC V21-3 base plate
J008
2
6
071-1
2.5
+ APC base plate (V21-1 supply) 2
P004
3
7
021-1
2.0
+ AVC ventilation (automatic A/C) 1
P296
8
8
022-1
2.0
+ AVC ventilation (automatic A/C) 2
P296
12
