General description Description A30 "Cebis MFT" terminal module.
Y335-2 Ratio under torque solenoid valve.
A57-1 "TR1" transmission module.
Y335-3 Ratio under torque solenoid valve.
A57-2 "TR2" transmission module.
Y339-1 Range solenoid valve "A".
A100 "MFA" multifunction armrest module.
Y339-2 Range solenoid valve "B".
A101 Dashboard and "DBD" CAN network communication module. Y339-3 Range solenoid valve "C". A124 Display module of the "DSP" gearbox.
Y339-4 Range solenoid valve "D".
R73 Clutch pedal switch.
Z153-1 Range "A" engaged contact.
S171 Revershift lever.
Z153-2 Range "B" engaged contact.
Y327 Forward drive solenoid valve.
Z153-3 Range "C" engaged contact.
Y328 Reverse drive solenoid.
Z153-4 Range "D" engaged contact.
Y335-1 Ratio under torque solenoid valve.
Z150 Slow range contact.
Module control law
110 l/min
Piston (B) (bar) 60 l/min
110 l/min
Y335-2 (ampere)
60 l/min
Y335-3 (ampere)
Piston (A) (bar)
Y335-1 (ampere)
Ratio
Ratio
"Hexashift" Piston (C) (bar) 60 l/min
110 l/min
1
0,58
0,8
20
18,5
0
0
0
0,7
20
18,5
2
0,690
0
0
0
0
0
0
0,7
20
18,5
3
0,83
0,8
20
18,5
0
0
0
0
0
0
4
1
0
0
0
0
0
0
0
0
0
5
1,16
0,8
20
18,5
0,7
20
18,5
0
0
0
6
1,40
0
0
0
0,7
20
18,5
0
0
0
"REVERSHIFT" Direction of motion
Ratio
Forwards
1
Reverse
1
B1.6
Y327 (ampere)
Piston (D) (bar) 60 l/min
110 l/min
0 à 0,8
0 à 21
0 à 19,5
0
0
0
Arion 640-510 – 12.2008 – GB
Y328 (ampere)
Piston (E) (bar) 60 l/min
110 l/min
0
0
0
0 à 0,8
0 à 21
0 à 19,5
