Bevel gear and differential Exploded view of differential case 20.22
34 38 35 36
32 44
39 43
29 28 27 42 41 30 37 36
31 40
34 35
33 451msm0b
Fig. 26
Description 27 Disc.
33 Differential housing.
39 Sun gear.
28 Backplate.
34 Screw.
40 Tapered washer.
29 Disc.
35 Locking tab.
41 Spider.
30 Half-shaft.
36 Castellated nut.
42 Pin.
31 Planet gear.
37 Bearing.
43 Cover.
32 Pin.
38 Screw.
44 Tapered roller bearing.
