Steering and Body Steering Post REMOVING NOTE: Perform steps 1-8 for both the brake and throttle cables.
1. Remove the handlebar pad. 2. Remove the C-clips securing the brake and throttle lever pins in the brake housing and throttle control; then remove the pins and levers.
ZR-108
4. Remove the C-clip securing the throttle cable in the throttle control; then remove the cable from the throttle control.
ZR-109 ZR-105
5. Cut the cable ties securing the cables to the steering post.
ZR-106
3. Disconnect the brake and throttle cables from the levers; then slide the cables out of the levers.
ZR-110
6. Using a sharp knife, cut the grip off the handlebar. 7. Using a solvent, clean the old adhesive from the handlebar. 8. Loosen the screw securing the emergency stop switch to the handlebar; then remove the stop switch. 9. Remove the two cap screws and lock nuts securing the upper steering post bearing retainer and supports; then remove the retainer and bearing.
ZR-107
48
