Removing and installing the power unit (engine 2.0 l) Withdrawal Open the hood. Disconnect the battery. Disconnect the connection with the mass withdrawal from the masses - loosen the nuts. Empty the climate installation. Connect the gas station. Connect the blue hose to the technology fitting the low-pressure small diameter. Connect the red hose to the fitting of high pressure technology of large diameter. NOTE Carefully read the instruction manual petrol station. Determine the amount of refrigerant recovered from the oil separator gas station. Remove the intermediate shaft steering column. To do this, the steering wheel in position rectilinear motion. Remove the ignition key and lock the steering wheel. Fig. 2.126. Bolt kreleniya intermediate shaft steering column: 1 - Bolt
Loosen the screw fastening (2.126). Remove the battery. Disconnect the positive lead from the positive terminal. Loosen the bolt mounting bracket and remove the battery. Fig. 2.127. Sensor wiring harness connector boost pressure: 1 connector
Unplug the wiring harness connector boost pressure sensor (2.127). Disconnect the upper wiring harness module cooling. Disconnect the wiring harness connector. Disconnect the relay from the bracket. Remove the battery support.
