STORAGE AND PRE-SEASON PREPARATION
WARNING Because fuel and oil are flammable, have an authorized Sea-Doo dealer inspect the fuel and oil systems integrity as specified in the periodic inspection chart.
Storage It is recommended that the craft be serviced by an authorized Sea-Doo dealer for storage but the following operations can be performed by you with a minimum of tools. CAUTION: Do not run the engine during the storage period.
Craft Rinsing Thoroughly rinse craft’s hull with fresh water. Propulsion System Lubricant in jet pump reservoir should be drained and reservoir cleaned. Refill with SEA-DOO synthetic polyolester oil (75W90 GL5 type C gear lube) or equivalent. Refer to an authorized SeaDoo dealer for this operation. CAUTION: Use only SEA-DOO jet pump oil or equivalent synthetic gear oil, otherwise component service life could be reduced. Do not mix oil brands or types. IMPELLER SHAFT RESERVOIR
Engine Draining Check engine drain hose. Make sure there is no sand or other particles in it and that it is not obstructed so that water can exit the engine. Clean hose and fitting as necessary. CAUTION: Water in engine drain hose should be free to flow out, otherwise water could be trapped in engine. Should water freeze in engine, severe damage will occur. Check engine drain hose for obstructions.
MODEL
CAPACITY (mL)
LRV
115
Grease lubrication point(s) of propulsion system as explained in MAINTENANCE section. Fuel System SEA-DOO fuel stabilizer (or equivalent), can be added in fuel tank to prevent fuel deterioration and carburetor gumming. Follow manufacturer’s instructions for proper use. CAUTION: Fuel stabilizer should be added prior to engine lubrication to ensure carburetor protection against varnish deposits.
WARNING F02E05Y
TYPICAL 1. Engine drain hose
52
1
Fuel is flammable and explosive under certain conditions. Always work in a well ventilated area. Always wipe off any fuel spillage from the craft. Always turn the fuel valve to OFF position when storing the craft.
