MAINTENANCE
WARNING Only perform procedures as detailed in this guide. It is recommended that the assistance of an authorized Sea-Doo dealer be periodically obtained on other components/systems not covered in this guide. Unless otherwise specified, engine should not be running and the safety lanyard should be removed from its switch for all maintenance procedures.
Use SEA-DOO synthetic grease or equivalent and lubricate PTO flywheel, see MAINTENANCE Periodic Inspection Chart. Proceed as follows: Remove seat(s) to expose engine compartment. PTO Flywheel Remove the wing nuts, washers and pull out PTO flywheel guard.
2
3
2
1. PTO flywheel 2. Grease fitting 3. PTO flywheel boot
Reinstall and secure PTO flywheel guard. Anticorrosion Protection Throttle/Choke Cables Lubricate the throttle and choke cables with BOMBARDIER LUBE lubricant or equivalent every 25 hours (or every 10 hours in salt water use). Electrical Connections As necessary, apply dielectric grease on battery posts and all exposed cable connectors. CAUTION: Do not lubricate connectors of the Multi-Purpose Electronic Module.
1
TYPICAL 1. Flywheel guard 2. Wing nuts
Using a grease gun, carefully lubricate PTO flywheel at grease fitting until PTO flywheel boot begins to expand.
46
1
F01I0BZ
Lubrication
F01I0AY
CAUTION: Immediately stop lubricating as soon as PTO flywheel boot begins to expand to prevent damage or slipping.
Additional Lubrication BOMBARDIER LUBE lubricant or equivalent will help prevent corrosion and maintain proper operation of moving mechanisms. Lubrication of the following items should be performed every 50 hours in fresh water use but every 10 hours in salt water use.
