2006 Crossfire 700 EFI
COOLING ASSEMBLY 0740-776
1 2 3 4 5 6 7 8 9 10 11 12 13 14
3706-345 1 Heat Exchanger - Rear (inc. 2-3) 0623-582 1 Insert 0617-509 1 Foam, Tunnel/Heat Exchanger 8060-706 12 Rivet 1623-349 7 Clamp, Hose 0610-552 3 Hose, Coolant 3606-564 2 Protector, Hose - Rear 8060-504 AR Rivet 8060-508 AR Rivet 3606-518 1 Heat Exchanger - Right 3606-519 1 Heat Exchanger - Left 3606-565 1 Protector, Hose - Front 1623-229 2 Clamp, Hose 0610-625 1 Hose, Coolant Tank/Engine 1623-322 2 Clamp, Hose
15 16 17 18 19 20 21 22 23 24 25 26 27
2706-791 1 Tank, Coolant 0610-553 1 Hose, Coolant Tank/Right Heat Exchanger 2611-758 1 Decal, Fill Level - Coolant Tank 0610-016 AR Hose, Vent - 25 ft 0610-015 AR Hose, Vent - 100 ft 0606-268 1 Cap, Filler Neck 0124-045 1 Clamp, Hose 0610-538 AR Hose, Coolant - 25 ft 0623-063 1 Clamp, Hose 0123-788 1 Cable Tie - 7.5 in. 1623-350 1 Clamp, Hose 0610-626 1 Hose, Coolant - Engine/Front Heat Exchanger 1619-038 1 Protector, Hose - 7 in. 4606-102 1 Pad, Support - Coolant Tank
27
