Arctic Cat Snowmobile Crossfire 700 Efi Illustrated Parts Manual

Page 21

2006 Crossfire 700 EFI

HEADLIGHT, INSTRUMENTS, AND WIRING ASSEMBLIES 0740-314

1 2 3 4 5 6 7 8 9 10

1686-281 1 Harness, Main 1686-255 1 Harness, Hood 0123-788 AR Cable Tie - 8 in. 0609-694 1 Lens/Reflector - Headlight - Right (inc. 5-6) 0609-695 1 Lens/Reflector - Headlight - Left (inc. 5-6) 0609-251 2 Bulb, Headlight 0609-693 2 Bulb, Headlight 1623-025 2 Insert 0623-360 2 Spring, Adjuster 1623-024 2 Screw, Adjuster 1623-137 2 Clip, Hairpin

11 1623-272 1623-273 12 0620-300 13 0620-281 14 0620-280 15 0617-501 16 8047-366 17 0630-182 18 1686-160 19 0123-811

2 2 1 1 4 2 1 1 1 2

Clip - Right Clip - Left Tachometer/Speedometer (inc. 13-14) Bracket, Retaining Nut w/Washer Foam, Hood/Headlight Nut, Lock Regulator, Voltage Harness, Extension - Taillight Cable Tie - 4 in.

19
