TABLE OF CONTENTS
SECTION 1
GENERAL INFORMATION
INTRODUCTION - This manual covers the operation, lubrication and maintenance of the Marion Model 151-M Ward-Leonard Electric Shovel. The information, measurements and specifications herein are Marion Power Shovel Company Engineering Standards and must be strictly adhered to in all maintenance and repair of the machine.
Power excavating equipment is subjected to tremendous stresses and shock loads. These loads and stresses have been thoroughly studied and considered in the design and building of Marion Equipment. Marion Shovels are designed to provide a reserve of power and strength and with good care and maintenance will provide the owner with many years of excellent service.
PARTS - Parts books have been furnished for this machine which list all parts by group numbers with item and part numbers for your specific machine. When ordering parts, always give the serial number and type of machine, item and part number and group or repair list number. This will assist the Parts Department in filling your order promptly.
The serial number of the machine can be found on the name plate attached to the left side of the ballast box. If the serial number is not available, the machine may be identified if the names of previous owners can be furnished.
Right and left hand parts of the upper frame can be determined by looking from the rear of the machine toward the front. Right and left hand parts of the lower frame can be determined by standing at the rear (crawler drive end) and looking forward.
The parts books furnished with this machine contain all the necessary information for properly ordering parts. Order carefully so that the proper parts and quantities can be furnished. Wrong parts, ordered by mistake, which are returned to the company are subject to a rehandling charge.
NOTE: Do not order parts from this manual. Use the parts books furnished with the machine.
STANDARD WARRANTY - Marion Power Shovel Company guarantees the equipment manufactured by it to be free from defects in material and workmanship under normal use and service, its obligation under this warranty being limited to making good at its factory any part or parts thereof manufactured by it which shall, within six (6) months after delivery to buyer, be returned to it, with transportation prepaid, and which its examination shall disclose to its satisfaction to have been thus defective, this warranty being expressly in lieu of all other warranties, expressed or implied and of all other obligations or liabilities on Marion Power Shovel Company's part.
