Grafton Designer Inclusions

Page 1


Inclusions Designer

Grafton

+ Owned and operated by a local builder

+ Backed by the support of an International network and brand with over 35 years experience

+ Fixed price building contract

+ Complimentary site consultation with our new home consultant and the local builder

+ Protectant termite perimeter & penetrations barrier (slab)

+ Termite treated timber flooring system (two storey / bearers & joist construction)

+ Fully treated frames & trusses. Wall frame – 90 x 35mm at 450mm stud centres

+ Standard BASIX requirements, assessments & reports.

+ Builder’s internal house clean - all construction debris removed

+ 6 year structural guarantee with 12 week maintenance period

+ Austral add-a-line wall mount clothesline BASIX

+ 5,000ltr rainwater tank connected to; toilets, laundry cold water & 1 garden tap

+ Dedicated LED lighting

+ 4kW Solar PV system

+ Tap & Fixture ratings; toilets = 4 star, kitchen/laundry/bathroom taps = 4 star, shower

+ R4.1 ceiling batts, including anticon blanket, ceiling batts not included to porch & alfresco ceiling

+ R2.0 external wall batts & sisalation

Construction

+ All development application fees and water meter cost for single residential dwelling

+ Fully painted inside and out with ‘Wattyl - Ultra Premium’ paint, 3 coats

+ All construction to Australian Standards (AS) & local government requirements

+ Professional drafting included

+ Construction site fencing as required

+ Home Building Compensation Fund (HBCF) - (formally known as Home Owner Warranty (HOW)), construction & liability insurance included

+ Engineer’s site and soil report including foundation, slab design and wind loading

Exterior

+ PGH bricks, from our large choice of bricks in our Group One range

+ Tiles to Porch & Alfresco floors including riser (slab only). Cushion edge tiles, laid in square pattern, purchase price of $33/sqm inc. GST

+ Colorbond roofing with 1 Whirlybird (Roof Vent)

+ Powder coated aluminium windows & sliding doors including locks & fly screens

+ Colorbond fascia and gutter

+ Two external garden taps

+ Auto lift sectional panel garage door with 2 remotes and 1 wall mounted controller

+ Stormwater, underground power & sewer connection to 6m allowance

+ Any cladding shown is Hardies Primeline cladding in standard plank design

+ Site Works to 500mm fall, and slab designed to suit “S” class site

+ 5000 ltr round poly water tank including rainpro pump

+ Up to 25 degree roof pitch 600mm wide eaves

+ Alfresco ceiling is plasterboard mounted to steel battens

+ External timber posts are 135sq laminated Spotted Gum

+ Complimentary “Milkcan” house numbers mounted to front wall or post

Interior

+ 2550mm internal ceiling height

+ Walls 10mm plasterboard

+ 90mm cove cornice throughout

+ All ceilings 10mm plasterboard is fixed to steel battens

+ R4.1 Insulation Batts to ceiling (Note: excludes alfresco/Porch ceiling)

+ Garage walls plaster lined and painted

+ Decorative timber skirtings and architraves (68 x 18mm) to windows & doors

+ Robes full melamine carcass, including top shelf hanging rail and bank of 4 shelves to 600mm wide

+ Walk in Robe includes top shelf, 2 banks of 4 shelves to 600mm wide and a hanging rail

Design

+ Personal in house design & colour selection process

+ Architecturally designed floor plans & styled exteriors

+ Large range of quality, optional upgrades & alternative products

+ Choice of flooring; Tiles by Colortile, Vinyl Planks by Andersens, Carpet by Andersens (select range), your quote will detail your floor selection per area Kitchen

+ Fully laminated European designed cupboards with 20mm Stone Benchtops (silica free) & stainless steel “C” pull door handles and soft close hinges and 1 set of 3 drawers

+ Overhead cupboard to concealed rangehood/splashback (under overhead cupboards)

+ Tiled splashback up to 650mm high. Cushion edge tiles, laid in square pattern, purchase price of $33/sqm inc. GST

+ Smeg stainless steel dishwasher (DWA6214S4)

+ Raymor Projix Double Bowl Universal mount sink (Top Mounted) with fold up over sink drainer

+ Tapware - Alder Gooseneck hob mixer

+ Pantry as per the plan with four shelves

+ We will itemise the lineal metres of 900mm breakfast bar, 600mm bench and overhead cupboards included in the quote Select from Option 1 or Option 2 for oven and cookware:

+ Option 1 - SMEG Classic Thermoseal oven 60cm Vapour clean in stainless steel (SFA63M3TVX), 60cm concealed rangehood ducted to eave, Smeg Ceramic cooktop (SE464TD) or Smeg Gas cooktop (CIR66XS3)

+ Option 2 -Smeg upright 90cm freestanding gas cooker 5 burner (FS9010XS-1), 90cm concealed rangehood ducted to eave Bathroom

+ All wet areas are recessed into the slab design (if applicable)

+ Vanities made by kitchen supplier - include 1 set of 3 drawers

+ Semi-Framed Shower Screens clear glass with pivot doors

+ Vito Bertoni Eco Dual Shower rails, round or square rail (round head only)

+ Aris edge mirror full length of vanity top to 900mm high

+ Choice of Alder tapware.

+ Alder Alto Double towel Rail 750mm in Chrome

+ Alder Alto Toilet Roll Holder & Towel Ring

+ Tiled Wall Niche to both the Bathroom and Ensuite Showers

+ Tiles to Bathroom/Ensuite floor, shower recess up to 2200mm high and remaining walls up to 1200mm high. Cushion edge tiles, laid in square pattern, purchase price of $33/sqm inc. GST. Smart tile floor wastes where applicable

+ Tiles to WC floor, wall behind toilet up to 1200mm high and skirting to remaining walls. Cushion edge tiles, laid in square pattern, purchase price of $33/sqm inc. GST

+ Raymor, Alpha Back to wall freestanding Bath 1700mm with Bamboo Caddy

+ Raymor, Atlanta II Back To Wall Suite - White vitreous china pan & slimline China dual flush cistern and soft close seat

Choice of 3 Basin styles

+ Arto 9048B Square Drop in Basin

+ Fienza REBA Above Counter Basin

+ Raymor Amethyst II Counter Top Basin

Laundry

+ All wet areas are recessed into the slab design (if applicable)

+ Raymor Projix 45ltr stainless steel drop in tub in cabinetry (Laminate benchtop only, no drawers)

+ Alder Vito Bertoni Milano Pull Out Mixer

+ Tiles to floor, skirting & 600mm splashback, laid in square pattern (tiles @ $33.00sqm inc. GST)

Electrical

+ Electrical layout consultation

+ Power points – all doubles, 2 TV point and 1 phone point

+ TV antenna & booster

+ NBN Fibre Provision

+ Smoke Detectors to Australian Standards

+ Recessed LED emergency light in kitchen

+ Lighting – white LED Down Lights

+ 2 Bulb fan/heat/light to each bathroom

+ Your quote will detail the quantity of light points and power points allocated

+ 4Kw Solar PV System

+ 26L Vulcan Instant Gas Hot Water system

Doors

+ Wideline Aluminium Atrium Entry Door up to 1200mm wide (including weather seal)

+ Gainsborough Contemporary Tri-lock (Double Cylinder) (chrome or satin)

+ Choice of Hume Accent Range doors or smooth ready coat doors to all internal doors (inc. linen) up to 870mm wide

+ Choice of Hume Accent Range smartrobe doors for all built in robes

+ Garage internal door includes weather seal as required

+ Gainsborough Lever door furniture, in chrome or satin

+ White air cushion stops to hinged doors
