Downhole
Essential flow control solutions for drilling and measurements, rotary steerable and smart completion control systems.
We keep operations flowing.TM
Gilmore has developed adaptable and modular technologies that go beyond standard applications for servere and critical service, safety systems, high flow and high shock.
Flow control success is essential
Building on the Gilmore pedigree in wireline tool sampling valves and the proven line of drilling control valves with over a half century of experience, we have engineered a reliable line of downhole solutions for a variety of tool applications in drilling and measurements, rotary steerable and smart completions.
When failure is not an option
Withstanding the rigors of high pressure and high temperature conditions that accompany geomechanics challenges, wellbore instability, vibration and torque are imperative to internal components managing hydraulic fluid flow. It is both operationally and business critical that these components do not fail.
Seal-in dependability
Utilizing Gilmore’s patented dual direction shear seal technologies, our line of flow control solutions push the envelope of higher pressures and temperatures while successfully operating in both clean and corrosive, debris laden fluids tested to date.
Agility to customize
Valve suites can be tailored to client specifications to meet the demands of current in-service tools in addition to those under development. We welcome the opportunity to be involved in the new product development process from the beginning through to successful deployment.
2-Way/2-Position
Cartridge Flex Valve
Ap Product features and benefits
• Debris laden fluids such as drilling muds and formation fluids
• Severe service materials available to NACE MR0175/ISO 15156 2015
• 2-Way/2-Position Cartridge Valve
• 3-Way/2-Position Cartridge Valve
• 4-Way/2-Position Cartridge and Manifold Pilot Valve
• Cartridge Regulator
• Pressures up to 15,000 psi supply
• Temperatures up to 350°F
• Cv range from .02-1.4 plication experience:
We keep operations flowing.TM
3-Way/2-Position Cartridge Flex Valve
Application experience:
• Wireline Sampling
• High Pressure High Temperature
• Safety Instrumentation Systems
• Workover Systems
• Running Tools
4-Way/2-Position Manifold Pilot Valve
• Completions Tools
• Chemical Injection
• Hydraulic Control Systems
Cartridge Regulator
