TRAILERS Products
Felling Low Pro Limited Eager Beaver 50 GSL-PT Paver Trailer The 50 GSL-PT has a 100,000-lb. load capacity and 122,700-lb. GVWR and is suited for loading rollers, pavers and milling machines. • Tapered four-beam, 16-in.-deep cambered I-beam mainframe and side rails • 10-in.-deep crossmembers pierced through the mainframe • 25,000-lb. axles with all-wheel ABS (4S3M) with spring brakes on all axles • Cush Air Ride suspension with 75,000-lb.-capacity air lift third axle
www.forconstructionpros.com/20979451
The Low Pro Limited deck-over tag trailer series includes the 22 1/2-ton FT-45-2 LP Limited tandem axle and the 25-ton FT-50-3 LP Limited triple axle. • 20-, 22- and 24-ft. available deck lengths for the tandem axle and 24- and 26-ft. deck lengths offered for the triple axle • Constructed with an 8-in. channel side rail (flange in) with 4-in. Jr. I-beam crossmembers pierced through the heavy-duty, engineered, fabricated 16-in. mainframe • 6-ft.-long double incline beavertail provides 12° and 6° load angles for safe loading/unloading of tracked equipment • 6’ x 20” spring-assist ramps with 5” x 3” self-cleaning angle construction or apitong inlay
www.forconstructionpros.com/21198119
CornPro Power I-Series Flatbed Trailers The heavy-duty Power I-Series flatbed trailer features a 10-in. I-beam frame and is capable of payloads from 11,000 to over 16,000 lbs. • Includes a 102-in. width, treated and kiln-dried pine decking and spring-assist ramps • Heavy-duty 4-sq.-in. jack and 2 5/16-in. coupler • Features Dexter spring axles, all-axle electric brakes and rubber-mounted LED lighting • Various tilt, hydraulic and length options available
www.forconstructionpros.com/21126110
XL Specialized Power Tail Trailer
Talbert Tag-A-Long AC Series
The XL Power Tail trailer features a hydraulic tail with a load angle of only 10° to easily load lifts, rollers, forklifts and paving equipment. • Comes in a 48-ft. length with 30-ft. 4-in. main deck or 53-ft. length with 35-ft. 4-in. main deck, both offering a 36-in. loaded deck height • Rated at 80,000 lbs. overall and 50,000 lbs. concentrated in 10 ft., plus features a 25,000-lb. tail lifting capacity for loads centered on the main platform • Tail features an 8-ft. 8-in. platform ramp and 60-in. flip tail, as well as lug-style hinges that keep hinge points clean as it prevents debris from accumulating • 9-ft. hydraulic pop-up ramp connects the deck to the gooseneck
The 10- to 25-ton Tag-A-Long Austin Carry-All Series (AC Series) trailers feature durable construction and a low 7° load angle to transport small- to mid-size equipment. • Dual-axle AC-10 offers a 10-ton, 20,000lb. capacity; 24-ft. deck length; 5-ft. 5-in. self-cleaning, spring-assisted rear ramps and 32.25-in. loaded deck height • AC-20 provides a 20-ton, 40,000-lb. capacity within the same deck dimension and loaded deck height • AC3-25 has a 29-ft. deck and a 25-ton, 50,000- lb. capacity with a 32.75-in. loaded deck height • AC-20ART and AC3-25ART include an air ramp and/or air tilt for loading of low-clearance equipment
www.forconstructionpros.com/21126279
www.forconstructionpros.com/21138130
Fontaine Heavy-Haul 55PVR Trailer The Heavy-Haul 55PVR features a low front approach angle suited for ground hugging pavers and a removable center bogie section to accommodate excavators. • Low 9° front ramp at the deck • 16° deck-to-bogie transition ramps • Handles 55 tons in 16 ft. or 50 tons in 12 ft. • Three or four axles close coupled • Four-point lift system • Equipped with a versatile hydraulic removable gooseneck
www.forconstructionpros.com/21307296
Air-Tow E-16 XL Extra Large Enclosed Trailers The 10,000-lb.-capacity E-16 XL is the largest enclosed trailer in the Air-Tow line of ground-level loading trailers and comes preloaded with many features. • Lowers flat to the ground for safe loading and unloading and transport of any type of equipment • 75-in. deck width and a length of 15 ft. 9 in. • 838 cu. ft. of total storage space includes a 15-in., 36-cu.-ft. shelf at front of enclosure that is easily accessible from inside and via a passenger side compartment door • Standard self-locking roll-up door, two LED interior lights and a 3/8-in. plywood interior lining
SAF-TITE
Unsurpassed strength at an incredible value WWW.PREMIER-MFG.COM
www.forconstructionpros.com/21118796
