EQUIPMENT INTRODUCTIONS
Demag
AC 80-4 All-terrain Crane The 110-ton class AC 80-4 has a main boom that is 196.9 ft. long and comes close to its lifting capacity with fully extended boom up to a radius of 98.4 ft. The unit has a line pull of 7.5 tons. Its reach can be expanded with a 21.3-ft. main boom extension that can be offset by 25° and 50° and has a capacity of 26.2 tons. An available 4.9-ft. runner has a capacity of 29.3 tons. The main boom can be lowered up to 3° below its horizontal position so the jibs can be installed quickly and safely. The unit features 19.5 tons of counterweight, a threesheave hook block on board, standard all-wheel steering and the IC-1 Plus control system. Power is provided by a 456-hp Mercedes-Benz Tier 4 Final engine.
Liebherr
Updated L 550 and L 556 XPower Wheel Loaders The 222-hp L 550 XPower loader has a 40,896-lb. operating weight, a 27,558-lb. tip load and a 4.45-cu.-yd. bucket capacity, while the 249-hp L 556 weighs 43,210 lbs., has a 30,314-lb. tip load and a 4.8-cu.-yd. bucket capacity. Standard power-split travel drive increases engine power. Increased working hydraulic performance enables dynamic lift and tip functions regardless of the size or weight of the working tool. Structural modifications to the lift arms enable higher breakout, holding and retrieval forces. The fully automatic LIKUFIX quick-coupler system is now available, along with a range of assistance systems including active personnel detection at the rear with a new braking assistant.
www.forconstructionpros.com/21343014
www.forconstructionpros.com/21244868
John Deere
SmartGrade 210G LC and 350G LC Excavators The SmartGrade grade control solution is now offered on the 210G LC and 350G LC excavators, with four grade management options to choose from, plus upgrade kits so customers can adopt technology at their own pace. Options available include SmartGrade, SmartGrade-Ready with 2D, 3D Grade Guidance and 2D Grade Guidance. The technology uses GNSS for accurate horizontal and vertical positioning of boom and bucket movements to a precise design target. The selectable bucket control feature automatically maintains a user-defined bucket angle throughout grading passes. Precision technology features include Virtual Front, over-dig protect and virtual fence technology.
www.forconstructionpros.com/21366838
Genie Komatsu
PC88MR-11 Excavator The 67.7-hp PC88MR-11 reduced tailswing excavator has an 18,739- to 19,224-lb. operating weight, a bucket digging force (SAE) of 11,982 lbs. and bucket capacity of .12 to .26 cu. yds. Standard high-flow auxiliary hydraulics with proportional joysticks provide precise attachment control. Six working modes tailor the machine to the tasks. A high-efficiency Tier 4 Final engine and viscous fan clutch work together to lower overall fuel consumption by up to 13%. The standard 7-ft. 7-in. grading blade with new moldboard profile allows for improved backfilling and light grading. A quiet, climate-controlled cab comes with air suspension seat, Bluetooth radio and high-resolution monitor with rear view camera.
GTH-1056 Telehandler The GTH-1056 has been purposefully designed to lower total cost of ownership by 10% while delivering 20% more lift capacity at max height. It has a sidemounted engine and stronger boom design that delivers a 10,000-lb. capacity. The unit is able to lift 5,000 lbs. at its maximum height of 56 ft. 7 in. and 3,000 lbs. at a maximum reach of 42 ft. It boasts a 30% stronger boom and chassis. The boom with mid-pivot point uses a single lift cylinder. This simpler configuration, combined with a wider, stiffer horsehead, efficiently transfers loads in applications imposing high stress on the boom, such as pipe handling or suspended loads.
www.forconstructionpros.com/21295398
www.forconstructionpros.com/21366856
