Knowledge Series: All Fluoroplastic Couplings, Expansion Joints, Bellows

DISCLAIMER While the FSA makes every reasonable attempt to ensure that the information contained in this document is accurate and curren t, the FSA, its officers, directors, volunteers, and authorized agents are not responsible for any errors or omissions contained therein nor are they responsible for any results obtained from the use of o r reliance upon its content. All information is provided “AS IS,” with no guarantee of completeness, accuracy, timeliness or of the results obtained, and without warranty of any kind, express or impl ied. In no event shall FSA or its officers, directors, volunteers, or authorized agents be liable to you or anyone else for any decision made or action taken in reliance on the information contained herein or for any for any consequential, indirect, special, or similar damages, even if advised of the possibility of such damages. The information contained in this document is for informational purposes only and does not constitute professional advice. It also includes references to certain standards that may change over time and should be interpreted only in light of particular circumstances. It is your sole resp onsibility to confirm the current state of any referred to standards. FSA reserves the right to modify or update the document content and to modify this Disclaimer at any time, effective upon posting of an up dated version of this Disclaimer.

© (April, 2023), Fluid Sealing Association. All Rights Reserved.

Introduction • A flexible Fluoroplastic pipe connector is a 2 or more-convolution expansion joint consisting of a member of FEP, PTFE or PFA. • Reinforced with metal rings and attached with ductile iron flanges.

• Designed to absorb movement and vibration in a piping system.

• This type of expansion joint has been used with highly corrosive medias, with glass or plastic piping or in heating, ventilating and air conditioning applications, where space is a premium.

Performance Characteristics: • Chemical Resistance: Molded or machined Fluoroplastic connectors are used in corrosive applications due to the inherent resistance of Fluoroplastic to a vast range of chemicals.

• Vibration Absorption: Fluoroplastic connectors are sometimes used in HVAC applications to absorb vibration and attenuate noise.

• Temperature Limits: Fluoroplastic connectors can withstand temperatures as high as 450°F and as low as - 100°F. Note: Temperatures of the system significantly affect the pressure rating of the connectors.

• Pressure Limits: Pressures vary widely depending upon system temperature. Consult each manufacturer for its specific pressure/temperature relationship.

Construction Details • Body: The body of the Fluoroplastic connectors are manufactured of 100% FEP, PTFE or PFA Fluoroplastic, which may be colored or opaque/clear depending upon the manufacturer.

• Reinforcing Rings: Metal reinforcing rings of stainless steel, Monel or other metals may be used to add strength between the convolutions.

• Flange: The flanges are normally manufactured of ductile iron, coated or plated with a rust inhibiting paint. Flanges of other materials are available upon request. The flanges are normally drilled with ANSI B16.5 150# tapped holes. Some manufacturers also provide drilling for glass pipe flange bolting.

• Control Rods: All connectors are supplied with factory set control rods. The control rods are set to prevent over- extension during operation.

• Stabilizing Rings: Some manufacturers offer styles of expansion joints with stabilizing rings to prevent squirm.

• Liners: Internal sleeves are sometimes available for abrasive or high velocity flow rate applications. Consult each manufacturer for information.

Types of Connectors • Coupling – 2 Convolute • Expansion Joint – 3 Convolute

• Bellows – 5 Convolute

6

Coupling • Coupling: A two-convolution connector designed for minimum movements.

7

Expansion Joint • Expansion Joint: A three-convolution connector designed for easy movement and ease of system installation

8

Bellows • Bellows: A five-convolution connector designed for maximum movements and vibration elimination

9

Manufacturing Details • Neutral Lengths: Installed Neutral Lengths vary from manufacturer to manufacturer. Consult each manufacturer for its standard neutral length.

• Movements: Axial, Lateral and Angular movements vary slightly by manufacturer. The figures listed in the previous tables are typical movements; consult each manufacturer’s literature for specific movements.

• Temperature/Pressure: The working pressure of various temperatures vary slightly by manufacturer. The figures listed in the previous tables are typical, consult each manufacturer’s literature for specific pressure ratings.

• Vacuum: 5 convolute bellows not usually recommended for vacuum service.

Installation and Maintenance • Installation: Since the connectors have a Fluoroplastic flare over the flange, no other sealing device, such as a gasket, is required. Remove protective flange covers only when ready to install.

Thread the installation bolts from the mating flange side and be sure bolts do not extend beyond the bellows flange. No nuts are required.

• Anchoring: Fluoroplastic connectors should always be installed in piping systems which are properly anchored and guided. The connectors should be protected from movements which are greater than that for which they are designed.

• Protective shields are recommended to protect personnel or adjacent equipment in the event of leakage or splash. Wrap around Protective Shields of Fluoroplastic or Fluoroplastic impregnated fiberglass are the most common types of protective shields.

• Protective Shields should be used on expansion joints in lines that carry high temperature or corrosive media.

• Contact the manufacturer for specific design details.

All Fluoroplastic Couplings, Expansion Joints, Bellows For additional technical information regarding Fluoroplastic Couplings, Expansion Joints, Bellows consult the Fluid Sealing Associations Technical Handbook for Expansion Joints Piping (https://www.fluidsealing.com/)
