BC town chooses MBBR‑DAF system for its wastewater plant upgrade

L

adysmith, British Columbia, on the western coast of Canada, is home to nearly 8,000 people and has a history of coal mining, forestry, rail and marine industry. An existing primary plant provided treatment to the town’s wastewater before discharging to Ladysmith Harbour. The town needed an upgraded wastewater treatment system that would minimize its biological and separation footprint, while also meeting the new lower proposed effluent limits of 15 mg/L for both BOD and TSS on an average monthly basis. World Water Works’ Ideal MBBR-DAF technology was selected for the upgrade. It combines moving bed biofilm reactor (MBBR) technology and dissolved air flotation (DAF) technology to provide high removal rates of BOD and TSS. The MBBR reactor degrades organic matter, resulting in BOD removal, and the DAF component separates biomass and solids from the water. This dual system allowed the town to have the highest possible removal rates of BOD and TSS, with the lowest possible plant footprint.

The system combines moving bed biofilm reactor technology and dissolved air flotation technology.

Another bonus to the MBBR system is its adaptability for system upgrades. World Water Works’ phased approach meant the system was up and running efficiently with improvements that met the community’s immediate needs, but left room for the town to add denitrification and nitrification processes, should they choose to in the future. The new 10 MLD system is designed to service a population of 17,000 and will treat the town’s wastewater for at least the next 20 years. The Ideal MBBRDAF system provided advanced secondary treatment for the existing wastewa-

ter treatment plant. The system drastically reduced BOD and TSS amounts released into Ladysmith Harbour. With these improvements, the Town of Ladysmith was able to minimize its ecological footprint and, during the system’s performance test, met an average of 8 mg/L BOD and 11 mg/L TSS. World Water Works completed work on Ladysmith’s Ideal MBBR-DAF system in the summer of 2016. For more information, visit www.worldwaterworks.com

Resilient & Sustainable Solutions Climate change and associated extreme weather events have a significant impact on our natural and built environment. Associated Engineering’s Climate Science and Modelling Subject Matter Experts help our clients by interpreting climate information, using climate model output, or developing specific climate analyses that allow us to develop solutions that support sustainable and resilient communities. Associated Engineering provides consulting services in planning, engineering, landscape architecture, environmental science, project management, and asset management. We specialize in the water, infrastructure, environmental, transportation, energy, and building sectors. Our holistic approach considers climate change impacts to create sustainable and resilient solutions.

www.ae.ca
