VN5 PRICE AND SPECIFICATION


VN5 - FEATURES

1

FEATURES .

2

From its distinctive design and proven technology, to uncompromising safety standards and ease of use, an array

1

Strength Anodised aluminium monocoque body structure is strong and durable

2

Energy Regenerative braking reuses energy to preserve the charge in the drive battery

3

Resistance Sheet Moulded Composite (SMC) panels are resistant to dents and corrosion

4

Manoeuvrability helps negotiate narrow city streets

5

Technology Proven eCity technology with 489 km

3

**

6

5

4

pure electric range

6

Power Fast charging can replenish the battery from zero to 100 % in as little as 30 minutes ***

The values were determined according to the more realistic test procedure WLTP (Worldwide harmonised Light vehicles Test Procedure), which replaces the test procedure with

Fuel consumption and CO emissions CO efficiency band

WLTP * Energy consumption (weighted*, combined) with full battery emissions (weighted*, combined) Electric range (with full battery)

2

A+

0,8 litres/100 km and 23,6 kWh/100 km 19 g/km 102,7 km


TWI N R EAR D O O RS 6 0/40 ASYM M ETR I C

938 M M

8

8

7

9

1 ,128 M M 6 40 M M LOAD H EI G HT

7

Space The loadspace of up to 5,5 m 3 accommodates two Euro-3 pallets, which can be loaded from the side or rear

8

Access Side loading door with 1,128 mm aperture and rear 60/40 split door allow easy loading and unloading

9

10

11

12

Practicality

10

Capacity Up to 830 kg * gross payload & 735 kg * net payload, including up to 100 kg on the roof

11

Visibility LED lights are brighter and last longer than halogen

12

Versatility

3


VN5 - FEATURES

FEATURES . 13

Safety Full complement of passive safety systems and cutting-edge active driver assistance

14

Comfort Dual-zone climate control regulates cabin temperature, and the seat and steering wheel are fully adjustable

15

Design Ergonomic, quiet workspace with ample stowage

13 15

14

16

Flexibility and Save - always electrically driven

16

18

17

4

17

Stability The latest features including Autonomous Emergency Braking, ABS, Emergency Brake Assist and Electronic Stability Control

18

Intuition Controls are within easy reach and settings can be accessed via a large central touchscreen


VN5

PAINT COLOURS .

C

S

T

N A

R

L

IG

H

T

B

L

A

C

IG

H

A

R

T

S

K

Y

B

L

U

E

O

A

G

R

Y

*

S

T

O

R

M

G

R

E

Y

P

L H

C

L

E

U

N

T A

R

S

IL

V

E

R

U

P

E

L

O

R

E

IL

L

A

R

B

O

X

R

E

D

B

R

IS

T

O

L

B

L

U

E

A

L

P

IN

E

W

H

IT

E

O

C

E

A

N

B

L

U

E

D

K

5


VN5 - VARIANTS

VARIANTS .

49.910,00 €

(RETAIL PRICE, EXCL. VAT)

CONSTRUCTION Anodised aluminium construction Sheet Moulded Composite (SMC) panels EXTERIOR Alpine white body colour Satin black front & rear bumpers, D pillar covers, mirror covers & door handles Black steel wheels DRIVER COMFORT Two zone climate control (A/C) Bluetooth connectivity Two USB ports 9-inch (22,86 cm) touch screen Keyless start DAB+ 12V socket in the cab Automatic windscreen wipers Auto LED headlights with automatic adjustment LED daytime running lights LED cab lights Electrically adjusted & heated mirrors

6


3.980,00 €

6.177,60 €

(RETAIL PRICE, INCL. VAT+SRT)

CARGO RELATED FUNCTIONALITY

CHARGING 50 kW DC rapid charging

LED cargo light

11 kW AC fast charging Type 2/CCS combo charging port

Converter interface plug Cargo floor cover DRIVEABILITY Three driving modes (Pure EV, Smart & Save) Two-stage regenerative braking Hill hold Automatic electronic parking brake

FEATURES IN ADDITION TO BUSINESS

FEATURES IN ADDITION TO CITY

DRIVER COMFORT

EXTERIOR

Heated windscreen

Charcoal grey metallic paint

Additional storage under driver & passenger seats

Body coloured front & rear bumpers & D pillar covers

SAFETY

Silver steel wheels

Driver & passenger front & side airbags

DRIVEABILITY

Tyre Pressure Monitoring System (TPMS)

Front & rear parking sensors

Anti-lock Braking System (ABS) and Electronic Stability Control (ESC)

SAFETY

Autonomous Emergency Braking System (AEBS) for pedestrians, cyclists, city & interurban

(RETAIL PRICE, INCL. VAT+SRT)

DRIVER COMFORT Driver & passenger fully electrically

Safety pack

Satellite Navigation CARGO RELATED FUNCTIONALITY

Forward Collision Warning (FCW) with Vulnerable Road User (VRU) protection Cruise control Alarm

DRIVEABILITY CARGO RELATED FUNCTIONALITY Fully cladded cargo area 12V socket in cargo area

Rear view camera CHARGING 22 kW AC fast charging

7


TAILORED TO YOUR REQUIREMENTS.

Code

Feature

LCL01

Delete side loading door

LCL02

One side loading door

VN5 is available in three generously equipped variants to meet

Retail price (excl. VAT)

Retail price (incl. VAT+ SRT)

BUSINESS

VN5 - VARIANTS

POA

POA

O S

Two side loading doors

795,00 € 1.065,57 €

O

Metallic/pearlescent paint

890,00 €

1.193,14 €

O

420,00 €

562,80 €

O

795,00 € 1.065,57 €

O

532,00 €

712,88 €

O

1.002,00 € 1.343,22 €

O

Alpine white Solid paint

Choose the variants to suit you and personalise the vehicle with

Body coloured front & rear bumpers & D pillar covers Heated windscreen

S

DAB+ radio VB02

VP02

Satellite Navigation1

S

Geofence ready

168,00 €

225,12 €

O

Parking sensors - rear

398,00 €

532,78 €

O

Parking sensors - front (must be combined with VP02)

398,00 €

532,78 €

O

Rear view camera

477,00 €

638,59 €

O

Additional storage under driver’s seat

129,00 €

172,86 €

O

Additional storage under passenger’s seat

129,00 €

172,86 €

O

Delete bulkhead

POA

POA

Bulkhead

O S S

56,00 €

LTD08

75,04 €

Standard driver seat including - Seat height - electric adjustment - Pneumatic lumbar support - Forward & aft - manual adjustment - Backrest angle - manual adjustment

- Seat height - electric adjustment - Pneumatic lumbar support - Forward & aft - electric adjustment - Backrest angle - electric adjustment - Tilt - electric adjustment (always combined with LNJ02 – luxury heated driver seat) 1

8

O

S

476,00 €

637,84 €

O


Feature

NP07

No passenger seat

LNJ01

Standard passenger seat including - Seat height - electric adjustment - Pneumatic lumbar support - Forward & aft - manual adjustment - Backrest angle - manual adjustment - Fixed headrest

LNJ02

Luxury heated passenger seat including - Seat height - electric adjustment - Pneumatic lumbar support - Forward & aft - electric adjustment - Backrest angle - electric adjustment - Tilt - electric adjustment - Cushion length extension – manual - Fixed headrest

Retail price (incl. VAT+ SRT)

BUSINESS

Code

Retail price (excl. VAT) POA

POA

O

S

476,00 €

637,84 €

O

(always combined with LNI02 – luxury heated driver seat) CS04

H8 AGM 95Ah 850 CCA 12V battery

213,00 €

285,15 €

O

CZ02

CHAdeMO charging port

532,00 €

712,88 €

O

3101

11 kW AC fast charging

3102

22 kW AC fast charging

LCC02

Type 2 mode 3 fast charging cable (32A 5m)

LSW01

Black steel wheels

LSW02

Silver steel wheels

LSW03

Alloy wheels

LWF04

Full size black steel spare wheel (price includes LRQ04 – toolkit)

168,00 €

225,12 €

LWF05

Full size silver steel spare wheel (price includes LRQ04 – toolkit)

168,00 €

225,12 €

LWF03

Full size alloy spare wheel (price includes LRQ04 – toolkit)

LRQ03

Toolkit - no spare wheel

S

LRQ04

Toolkit - spare wheel (always combined with LWF04, LWF05 or LWF03)

O

0206

12V socket in cargo area

POA

POA

O

0206

Driver front & thorax airbags

S

NP08

Passenger front & thorax airbags

S

POA

POA

O S

*

LFT01

1.064,00 € 1.425,76 €

S O

263,00 €

352,42 €

O

S

POA

POA

O

POA

POA

O

POA

POA

O O O

LFT03

Floor cover

LRD01+LQC01+LUL01+LUR01

Delete cargo area cladding

POA

POA

S

LRD02+LQC02+LUL02+LUR03

Fully cladded cargo area

POA

POA

O

9


VN5

O PTIO N PACKS . BUSINESS Retail price

(incl. VAT+SRT)

759,00 €

1.017,06 € • •

Lane Departure Warning

Driver & passenger curtain airbags

BUSINESS Retail price

(incl. VAT+SRT)

1.876,00 € 2.513,84 € Front & rear parking sensors Rear view camera

• • •

H8 AGM 95Ah 850 CCA 12V battery

CHAdeMO charging port

Type 2 mode 3 fast charging cable (32A 5 m)

10

-


BUSINESS

BUSINESS

Retail price

Retail price

(incl. VAT+SRT)

(incl. VAT+SRT)

1.338,00 €

2.296,00 € 3.076,64 €

1.792,92 €

Heated windscreen

Front & rear parking sensors

Additional storage under driver & passenger seats

Heated windscreen Driver & passenger fully electrically adjusted Additional storage under driver & passenger seats Satellite Navigation

• • • •

BUSINESS

BUSINESS

Retail price

Retail price

2.744,00 € 3.676,96 €

5.012,00 € 6.716,08 €

(incl. VAT+SRT)

(incl. VAT+SRT)

Metallic/pearlescent/solid paint

Silver steel wheels Body coloured front & rear bumpers & D pillar covers

Front & rear parking sensors

Metallic/pearlescent/solid paint Body coloured front & rear bumpers & D pillar covers

Front & rear parking sensors

Rear view camera Driver & passenger fully electrically

Additional storage under driver & passenger seats

Silver steel wheels

Satellite Navigation

• 11


VN5 - DIMENSIONS

PRICE LIST. Basic Recommended Retail Price (excl. VAT)

49.910,00

12

ETT

4.991,00

VAT(24% )

Total Recommended Retail Price (incl. VAT+SRT)

11.978,00

66.879,00


2.083 mm

1.990 mm

1.574 mm

CARGO WIDTH

2.447 mm

1.622 mm

ON FLOOR

2.315 mm

1.945 mm

1.373 mm

1.253 mm APERTURE WIDTH

938 mm

1.199 mm

1.272 mm

1.109 mm WHEEL ARCHES 640 mm

150 mm

1.128 mm

1.637 mm 906 mm

3.386 mm

941 mm

5.233 mm

13


VN5

TECHNICAL DATA . ECONOMY AND EMISSIONS Energy consumption (weighted *, combined) with full battery

WLTP * 8

23,6

emissions (weighted *, combined) Pure EV (electric-only) range Pure EV range (City)

19 g/km 102,7 km 132,5 km 410 km 513 km 543 km

Total range Total range (City) 8,8 PERFORMANCE

EXTERIOR DIMENSIONS Length

Height (unladen) Height (fully laden) Wheelbase Front overhang Rear overhang Front track Rear track

5,233 mm 2,083 mm 1,945 mm 1,990 mm 1,932 mm 3,386 mm 941 mm 906 mm 1,622 mm 1,637 mm 150 mm

Acceleration 128 km/h

LOADSPACE DIMENSIONS Length

WEIGHTS

3

Kerb weight Mass in running order **

***

***

Business: 2,070-2,201 kg City: 2,070-2,204 kg Ultima: 2,122-2,222 kg Business: 2,165-2,296 kg City: 2,165-2,299 kg Ultima: 2,217-2,317 kg 2,900 kg 2,900 kg 1,500 kg 1,500 kg Business: 604-735 City: 601-735 Ultima:583-683 Business: 699-830 City: 696-830 Ultima: 678-778 100 kg

Width between wheel arches Height Side load door entry width Side load door entry height Rear door entry width Rear load door entry height

3

1,574 mm 1,109 mm 1,373 mm 938-1,128 mm 1,199 mm 1,253 mm 1,272 mm 640 mm

DRIVE MOTOR Driven wheels Peak power Peak torque

***The payload includes the weight of the driver

14

2,447 mm

Rear 110 kW 250 Nm 11,500 rpm


DRIVE BATTERY Drive battery type Gross storage capacity Total number of cells

WHEELS & TYRES 3-string Lithium ion 31 kWh 288

Wheel size Tyre size Rolling resistance Tyre Noise emissions

7J X 17 215/60/R17 C 107 T 8,99 N/kN 72 dB

CHARGING On-board charging AC On-board charging DC Optimum charging time @ 50 kW (0-100 %) Optimum charging time @ 50 kW (0-80 %) Optimum charging time @ 22 kW (0-100 %) Optimum charging time @ 11 kW (0-100 %) Optimum charging time @ 7 kW (0-100 %)

11 or 22 kW 50 kW 30 minutes 25 minutes 75 minutes 140 minutes 225 minutes

RANGE-EXTENDER Fuel type

Cubic capacity Power Electrical output Peak torque Fuel tank capacity (usable)

Petrol (95-RON up to E10) Direct injection, turbo-charged 1,477 cm3 67 kW 60 kW 160 Nm

Braking aids

Power steering type

Electrical Hydraulic Power Assisted Steering (EHPS)

Steering ratio Turning Circle (kerb to kerb) Turning Circle (wall to wall) WARRANTY Standard vehicle warranty (distance) Standard vehicle warranty (time) Standard battery warranty (distance) Standard battery warranty (time)

240,000 km 5 years 240,000 km 8 years

SERVICE INTERVAL Service interval (distance) Service interval (time)

40,000 km 1 year

SUSPENSION Front

BRAKES Braking system

STEERING

ventilated discs ABS, Electronic Stability Control and Emergency Brake Assist

Rear

anti-roll bar Double-insulated 5-link with transverse composite leaf spring

15


VN5 - WARRANTY

DRIVE WITH CO NFI DEN CE. LEVC has a nationwide network of authorised dealers and repair centres, who hold

Our goal is to give drivers a high standard of service with speed, convenience, and the

16


WARRANTY. *

vehicle warranty

STAN DARD WARRANTY 5 years/240,000 km

8 years/240,000 km

17


made to ensure that the contents of this publication are accurate and up-to-date at the time of going to press (June

ED JUNE 2021

LEVC Greece

263, Sygrou Avenue 171 22, Nea Smirni Athens, Greece +30 210 94 24 493 E info@levcgreece.gr
