AFTON CHEMICAL THE GREASE PORTFOLIO
Multi-functional Componentry
• Formulation simplicity, meaning fewer blend errors
• Inventory rationalization
• Bulk savings versus drums
The Afton Chemical Grease Portfolio
Multi-functional Componentry
Multi-functional componentry is a building block approach that combines several performance attributes into a single product. This is an efficient and increasingly popular way to streamline your grease portfolio. The right system can save time and money while maintaining flexibility in creating a full grease product line – from core to enhanced performance.
Building Blocks
Building blocks offer a flexible approach to constructing your finished grease formulation. Starting with an appropriate foundation – from core to enhanced –additional performance can be “dialed in” to meet the goals of your custom grease needs.
Grease Additive Composition Examples
HiTEC® 552H
Robust EP/AW with enhanced oxidation and rust protection
HiTEC® 553
Ashless economic EP/ AW with oxidation and rust protection
HiTEC® 552
Reliable ZDDP-based multi-functional core with improved AW
HiTEC® 343G
Ashless sulfur/phosphorus multi-functional core with increased EP
HiTEC® 321G
Ashless sulfur/phosphorus multi-functional core
2
P E R F O R M A N C E 100% 80% 60% 40% 20% 0% CORE ENHANCED Grease A Grease B Grease C Grease D HiTEC® 552 EP/AW RI AO
High Performance Additives
• Maximum flexibility
• Customized speciality formulations
• Top treat performance enhancement
High Performance Additives
High performance additives are traditionally used by grease formulators to add individual performance characteristics to their finished greases, maintaining maximum flexibility and uniqueness of formulations.
Anti-wear (AW) and Extreme Pressure (EP) Additives
AW characteristics and protection against EP regimes are important performance characteristics that need to be incorporated in greases for various applications. Afton offers many different options for the formulator seeking to strike the right balance between structural stability, surface activity, performance and cost.
Corrosion Inhibition (CI)
Corrosion inhibition is critical in many grease applications. From testing in salt spray to Emcor dynamic bearings to yellow metal protection, Afton has a wide range of options to allow maximum synergy while minimizing the impact on thickener structure and other important performance criteria.
High Temperature
Grease manufacturers need special additives to meet the unique demands of applications for which heat is a critical variable. Afton offers a range of chemistry designed to meet the stringent needs of your individual grease formulations. From increasing oxidation resistance to improving structural stability at high temperatures, these components can help you meet the distinctive challenges of grease formulating.
Multi-functional Componentry
ENHANCED PERFORMANCE
Robust performance package, provides excellent fortification against corrosion and oxidation combined with EP and AW protection. This system can be used to produce high temperature, multipurpose greases such as those used in chassis and wheel bearings.
Ashless economic performance package, provides good protection against EP and AW while also providing oxidation and corrosion resistance necessary in a fullyformulated, multipurpose grease suitable for use at higher temperatures.
These enhanced performance packages offer an efficient and convenient approach to streamlining grease formulations. The right system can save time and money while maintaining your flexibility and providing targeted performance.
Product Recommended Treat Rate % wt. (1) Function EP AW CI AO
HiTEC® 552H 3-4
HiTEC® 553 3-4
4
(1) Optimized treat rate can be a function of specific thickener system
Good Better Best
HiTEC® 552H
CORE PERFORMANCE
HiTEC® 552 1-2
HiTEC® 343G 1-2
HiTEC® 321G 1-2
Reliable ZDDP-containing additive core, combines EP and AW performance with basic rust protection and antioxidancy.
Multi-functional Componentry
• Formulation simplicity, meaning fewer blend errors
• Inventory rationalization
• Bulk savings versus drums
Ashless cost-effective sulfur/phosphorus core, provides an increased EP boost along with protection from wear, yellow metal and steel corrosion.
Ashless cost-effective sulfur/phosphorus core, combines EP/AW, yellow metal and steel corrosion inhibitors.
These core performance systems can be used by themselves in a variety of multipurpose greases that require basic EP/AW and corrosion protection. Or they can be boosted for higher performance with the appropriate additive selection to add, improve, or strengthen specific performance attributes.
5
HiTEC® 552
HiTEC® 321G
HiTEC® 343G
Product Recommended Treat Rate % wt. (1) Function EP AW CI AO
Good Better Best
High Performance Additives
Anti-wear (AW) and Extreme Pressure (EP) Additives
| Zinc DialkylDithioPhosphate
(ZDDP)
ZDDP is an effective and cost efficient way for a grease formulator to reduce wear and oxidation in a wide range of grease formulations.
HiTEC® 7197G (C4/C5/C8)
HiTEC® 55450 (C3/C4/C8)
HiTEC® 7169 (C3/C6)
Excellent AW protection combined with antioxidancy.
Wider functional temperature range for protection by degradation of ZDDP.
Provides AW and oxidation protection at lower temperatures.
SECONDARY ALCOHOLS PRIMARY ALCOHOLS
Zinc complexity - all zincs aren’t created equal
• ZDDP requires partial decomposition to deposit Zn, P and S on the metal surface.
• The type, branching and chain length of the alcohol used can affect performance in several ways.
ZDDPs made from secondary alcohols decompose more easily than those made from primary alcohols providing anti-wear protection at lower temperatures.
Antioxidant (and EP) performance requires that sulfur be “released”; this process is made more difficult in ZDDPs made with longer alcohols.
• Branching of the alcohol groups will also affect the stability of the ZDDP in both positive and negative ways further complicating formulation challenges.
Type of Alcohol Primary Primary/Secondary Secondary AW Activation Temperature Thermal Stability Alchol Chain Length Long Short Available Sulfur (AO/EP) Thermal Stability 6
High Performance Additives
• Maximum flexibility
Customized speciality formulations
Top treat performance enhancement
| Ashless Anti-wear (AW)
Ashless anti-wear chemistry can be an effective aid in reducing scuffing or fretting wear.
833
Amine sulfurized phosphite –Excellent EP and AW protection particularly in reducing fretting wear.
| Sulfur Extreme Pressure (EP) Sources
Different sulfur-based chemistries are important for giving grease formulations added protection under EP conditions.
HiTEC® 312G
High sulfur content with controlled ac tivity; often used in combination with ZDDP AW
HiTEC® 7188
Excellent AO combined with low activity sulfur for EP
7 0 0.5 1 1.5 2 40 20 0
WEAR, MG
FRETTING WEAR – ASTM D4170
TREAT RATE OF HiTEC® 833, % wt.
ACTIVE SULFUR %TOTAL SULFUR % 32% 28% 2% 12% HiTEC®
High Performance Additives Continued
Corrosion Inhibition (CI)
| Rust Inhibitors
Protection against rust attack on ferrous parts is critical in many grease applications. From static to salt spray to dynamic bearings, Afton has a full slate of corrosion inhibitors designed to cost-effectively enhance your grease’s performance in these critical areas while maintaining grease stability, extreme pressure and wear protection.
• Succinate ester
HiTEC® 559
• Acidic inhibitor, used at low treat, good synergy with other CIs.
HiTEC® 538
• Poly ester succinimide
• Neutral inhibitor, good rust protection and friction reduction, synergistic
HiTEC® 614
• Low TBN calcium sulfonate
• Excellent in protecting against corrosive/ humid conditions such as ASTM B117 salt fog test
Formulating with rust inhibitors
Why don’t all additives behave the same?
Synergy
To meet the demands of severely corrosive conditions (such as 3% NaCl), individual rust inhibitors can offer some protection at higher treat rates. However, synergistic combinations can often be identified that can lower overall treat rate and cost.
Thickener Interaction
The complexities inherent in grease formulating include variations in grease thickener chemistry and manufacturing conditions which can have an enormous impact on additive effectiveness – especially with regard to interactions with polar additives such as rust inhibitors.
8
| Yellow Metal Protection
Well-formulated grease products should not be chemically aggressive to parts containing yellow metals.
High Performance Additives
• Maximum flexibility
• Customized speciality formulations
• Top treat performance enhancement
Ashless alkyl thiadiazole is an excellent sulfur scavenger and metal passivator when used in greases at low treat rates. It also contributes to EP properties and antioxidancy especially at higher concentrations.
High Temperature
From increasing oxidation resistance to improving structural stability under thermal stress, these additives can help you gain specific performance benefits that will help you meet the unique challenges of developing a high temperature grease formulation.
Syngergistic antioxidant combination
• Designed to extend grease life in high temperature applications by providing resistance against oxidation, and protecting grease stability
• Can be used to boost antioxidant capability of multifunctional componentry
Boronated succinimide dispersants
• Gives antiwear protection and extreme pressure performance
• Mitigates the effects of deposits due to oxidation
• Provides the structural benefits of a PIB thickener
• Can deliver dropping point enhancement in some thickener systems
HiTEC® 55562 HiTEC® 4313 HiTEC® 6379
HiTEC® 648
ASTM D4048 – Detection of Copper Corrosion from Lubricating Grease
0.0% 0.15% 0.25%
Typical treat rate of HiTEC® 4313
Afton Chemical Grease Portfolio Summary
1 = Primary function
2 = Secondary function
10
Function Product Description Treat rate, % wt. Anti-wear (AW) Extreme Pressure (EP) Rust Inhibitors Yellow Metal Protection Friction Modifiers Enhanced Multi-functional Componentry HiTEC® 552H Robust EP/AW package with increased oxidation and rust protection 1.0 - 6.0 1 1 1 1 HiTEC® 553 Ashless economic EP/AW package with oxidation and rust protection 1.0 - 6.0 1 1 1 1 Core Multi-functional Componentry HiTEC® 552 Reliable ZDDP-based core 0.5 - 5.0 1 1 1 1 HiTEC® 343G Ashless sulfur/phosphorus core 0.5 - 5.0 1 1 1 1 HiTEC® 321G Ashless sulfur/phosphorus core 0.5 - 5.0 1 1 1 1 Extreme Pressure (EP) & Anti-wear (AW) HiTEC® 55450 Primary/secondary ZDDP 0.5 - 2.0 1 HiTEC® 7169 Secondary ZDDP 0.5 - 2.0 1 HiTEC® 7197G Primary ZDDP 0.5 - 2.0 1 HiTEC® 833 Amine sulfurized phosphite 0.1 - 2.0 1 2 HiTEC® 312G Sulfurized Isobutylene 0.5 - 4.0 1 HiTEC® 7188 Sulfurized olefin 0.5 - 4.0 1 Corrosion Inhibitors (CI) HiTEC® 559 Succinate ester 0.1 - 2.0 1 HiTEC® 538 Neutral ashless 0.2 - 4.0 1 2 HiTEC® 614 Calcium sulfonate (30 TBN) 0.5 - 5.0 2 1 HiTEC® 4313 Thiadiazole 0.05 - 4.0 2 1 Friction Modifiers HiTEC® 301 Ashless phosphorus-based 0.1 - 5.0 2 1 Polymers HiTEC® 5825H Solid olefin copolymer (25 SSI) 0.1 - 1.0 HiTEC® 5748 Liquid olefin copolymer (25 SSI) 1 - 10 HiTEC® 5850B Solid olefin copolymer (50 SSI) 0.1 - 1.0 HiTEC® 5751 Liquid olefin copolymer (50 SSI) 1 - 10 HiTEC® 151 High MW PIB tackifier 0.5 - 5.0 HiTEC® 152 High MW PIB tackifier 0.5 - 5.0 High Temperature HiTEC® 55562 Phenolic/amine anti-oxidant mix 0.1 - 3.0 HiTEC® 637 Boronated dispersant 0.5 - 5.0 2 2 HiTEC® 648 Boronated dispersant 0.5 - 5.0 2 2 Thickener HiTEC® 557 300 TBN calcium sulfonate 2 2
11 Structural Modifiers Antioxidant (AO) Complexing Agent S P Zn N Ca B Ba Flash Point, °C (min) Density @ 15.6°C Viscosity @ 40°C, cSt Viscosity @ 100°C, cSt 1 12.1 1.8 2.0 0.6 - - - 100 1.02 72 7.5 1 25.6 0.8 - 0.9 - - - 86 1.04 51 6.3 2 22.9 3.5 4.0 0.1 - - - 100 1.08 90 9.0 36.1 1.2 - 0.8 - - - 76 1.08 74 9.0 30.7 2.0 - 1.0 - - - 62 1.06 60 8.4 2 17.8 8.4 9.2 - - - - 145 1.12 230 11.8 2 17.1 8.2 9.0 - - - - 110 1.11 170 9.5 2 16.7 8.0 9.0 - - - - 110 1.12 175 11.0 6.3 6.2 - 3.2 - - - 62 0.95 60 12.0 46 (32) (C) - - - - - - 80 1.14 59 8.0 2 12 (2) (C) - - - - - - 150 0.89 15- - - - - - - 85 1.00 970 23.0 - - - 0.6 - - - 150 0.94 195 21.0 2.3 - - - 2.6 - - 150 0.94 400 16.0 2 35 - - 6.4 - - - 130 1.12 340 13.6 1.2 3.2 - 1.3 - - - 85 0.93 70 (d) 9.5 1 - - - - - - - - 0.86 -1 - - - - - - - 155 0.87 15000 1140 1 - - - - - - - - 0.86 -1 - - - - - - - 135 0.86 15000 1240 1 - - - - - - - 175 0.87 1200 1 - - - - - - - 180 0.88 - 2850 1 - - - 1.17 - - - 121 0.94 20 3.0 1 1 - 0.7 - 1.7 - 1.0 - 150 0.96 12500 400 1 1 - - - 1.4 - 1.3 - 150 0.94 12000 400 1.7 - - - 11.9 - - 150 1.13 275 30.0
(C) Active sulfur (ASTM D1662) (D) Solid at room temperature
As your Grease Solution Provider, Afton Chemical can tailor solutions for your grease plant to maximize the number of greases that use a common foundation. With our multi-functional componentry and additives, we can help you build greases for standard and premium tier applications.
For more information about our total capabilities and to access our Microbotz® Grease Guide, please go to https://www.aftonchemical.com/products/ industrial-additives/grease/
Multi-functional Componentry
• Formulation simplicity, meaning fewer blend errors
• Inventory rationalization
• Bulk savings versus drums
High Performance Additives
• Maximum flexibility
• Customized speciality formulations
• Top treat performance enhancement
