General Functions of the Interface
Basic Screen Layout of the Hydraulic User Interface Program
1900 SRM 1561 Displays the settings for the electric/hydraulic valves.
A list of screen icons appear along the left margin of each screen and when clicked on serve as shortcuts to other screens within the program. See Figure 6.
6. Diagnostic Screen
Following is a brief description of each of these screens:
7. Active Errors Screen
1. Truck Configuration Screen Contains all basic truck configuration settings and provides access to the All Parameters screen. 2. Installed Features Screen Enables/disables available software-enabled options or standard features. 3. Calibration Screen Calibrates the joystick/levers following replacement or failure, or after replacing a hydraulic controller. See also Calibration. 4. Flow Settings Screen Adjusts flow demands for lifting/tilting and all auxiliary functions. 5. Valve Settings Screen
14
Displays the most common hydraulic controller signals and allows users to quickly identify problems or issues.
Provides an overview of actual active errors and provides access to the error history screen. 8. Active Errors Indicator Takes users to the Active Errors Screen. The box to the left of the icon displays the number of active errors. 9. Truck Serial Number Displays the truck serial number that is programmed in the hydraulic controller. 10. Upload Parameters Button Refreshes the parameters displayed on the active screen. 11. Download Parameters Button Saves the parameters displayed on the active screen.
