Reliability Versatility User friendly interfaces Industrial grade components
ADDITIONAL RESOURCES Literature available: (call or download from the web) Web link: www.jrclancy.com/controlsystems
SceneControl® 5200 and 5200P
SceneControl® 5100
The SceneControl 5200 console can serve as a main controller for small to mid-sized productions like high school and college musicals and as a secondary controller for larger productions. It networks easily with other SceneControl consoles.
When you need accurate, repeatable positioning for battens that raise and lower equipment or curtains, you need the SceneControl 5100 controller. Set up to eight presets – soft upper, soft lower, and six intermediate targets – and run your motorized hoist with the knowledge that it will always return to the right place.
The 5200 and 5200P consoles provide programming for an unlimited number of cues. The 10.1" (25 cm) graphic touchscreen display shows the operator the position of each batten and all of the targets, so you’re never in the dark about elements in motion.
FEATURES
SceneControl® 5200 Rack or Wall Mount Controller
SceneControl® 5200P Hand-Held Pendant Controller
• Control up to 24 axes • Change the speed of an axis in motion • Start/stop an axis multiple times within a cue, or send to multiple targets • Create motion profiles based on time or speed • Emergency stop system can be upgraded to SIL3 rating • Illuminated STOP/GO hard-wired buttons for precise motion initiation • Hold-to-run function requires the operator to be at the controller when scenery is moving • Displays data in units of feet/inches, decimal feet, meter or as a percentage • Multi-Language capability supports English and two other languages
The SceneControl 5100 controller is the perfect pendant device for equipment that needs to return to the same position every time. Use this single-axis preset controller for fixed or variable speed scenery battens, house curtains, a backdrop or cyclorama that always trims at the same level.
FEATURES
• 2 40 x 180 backlit graphic LCD display with touch-screen capability for quick programming •C hoose 1, 4 or 8 axes •P ortable pendant allows operator to view batten movement from any point backstage with proper receptacle locations •P osition, target, and status on color display •E mergency stop operator • P assword protection to allow access only to authorized users • L oad sensing capability •A utomatic alarms if an error or fault is detected • I lluminated GO button •H old-to-run function requires the operator to be at the controller when scenery is moving •O ptional storage case
