VENKATESH RESIDENCE

from Internship Portfolio by Vaishnavi S (Triple O Studio, 2022)

by Vaishnavi S

VENKATESH RESIDENCE

augmenting a shell, tailor-made for the inhabitants, making a house- a home

First floor Plan

MOTHER'S

@ 1' from true ceiling (till beam bottom)

AREA : 100 SQFT

12" thickness gypsum board false ceiling @ 9" from true ceiling (till beam bottom)

FINISH - Wood Finish

AREA : 110 SQFT

12" thickness gypsum board false ceiling @ 6" from true ceiling

AREA : 215 SQFT

12" thickness gypsum board false ceiling @ 1' from true ceiling

FINISH - Jute Finish

AREA : 140 SQFT

Fan F01 drawing is the sole property of 'Triple O studio' and cannot be reproduced in any form or on any other site apart from that specified, retained or copied without the express consent of the architects.

4" thk concrete slab as seating finished with 1" oxide finish of selected texture and shade

3/4" thk BWR plywood as shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as skirting finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as frame finished with 1mm laminate of selected texture and shade

3/4" thk BWR plywood as stopper finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

All dimensions are in millimeters unless mentioned. This drawing is the sole property of 'Triple O studio' and cannot be reproduced in any form or on any other site apart from that specified, retained or copied without the express consent of the architects.

9" thk brick wall finished with 12 mm cement plaster and paint of selected shade

3/4" thk BWR plywood as handleless shutter as specified

1 2" thk BWR plywood as backing finished with 5mm veneer of selected texture and shade existing concrete slab covered with 3mm thk BWR plywood as facia finished with 5mm veneer of selected texture and shade

25mm dia brass knob for further detail

3 4" thk BWR plywood as frame finished with 5mm veneer selected texture and shade

3 4 " thk BWR plywood as shutter finished with 5mm veneer of selected texture and shade

3mm thk cane fibre woven on 1"wide frame support

3 4 " thk BWR plywood as skirting finished with 5mm veneer of selected texture and shade

3 4 " thk BWR plywood as shutter finished with 5mm veneer of selected texture and shade

3mm thk cane fibre woven on 1"wide frame support

3 4 " thk BWR plywood as skirting finished with 5mm veneer of selected texture and shade

25mm dia brass knob for further detail

1 2 " thk BWR plywood as backing finished with 5mm veneer selected texture and shade

3 4 " thk BWR plywood as shutter finished with 5mm veneer selected texture and shade

3 4 " thk BWR plywood as shutter finished with 5mm veneer of selected texture and shade

3mm thk cane fibre woven on 1" wide frame support

FCL±9'-7"

1/2" thk BWR plywood as ledge finished with 5mm veneer of selected texture and shade

25mm dia CHS- MS section of 3 mm thickness in powder coated black finish

1/2" plywoods as frame finished with 5mm veneer of selected texture and shade

1/4" solid wood beading 1" wide as wooden paneling of selected texture and shade

FFL±0'-0"

1/2" thk BWR plywood as backing finished with 5mm veneer of selected texture and shade

3/4" thk BWR plywood as frame finished with 5mm veneer of selected texture and shade

6mm thk clear glass of selected shade and texture

25mm dia CHS- solid rod with screw thread

2" deep fisher nutt for anchoring

1/2" thk BWR plywood as handleless pullout drawer finished with 5mm veneer of selected texture and shade

1 2" UPVC/ plastic glass holder

1/2" thk BWR plywood as ledge finished with 5mm veneer of selected texture and shade

25mm dia CHS- MS section of 3 mm thickness in powder coated black finish

1/2" plywood as facia finished with 5mm veneer of selected texture and shade

FFL±0'-0"

25mm dia CHS- solid rod with screw thread milling to match the nutt groves scale job architect drawn checked by

11 MAR 2022

Plan TRIPLE O STUDIO Vaishnavi 2'-9" D Ground Floor date Venkatesh Residence Display Unit- GF 104ID_FS_GF04 R01

Sarojini Ar. Tahaer Zoyab

1/2" thk BWR plywoods as ledge finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

50mm CHS- MS section of 3 mm thickness in powder coated black finish

3/4" thk BWR plywood as frame finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

50mm CHS- MS section of 3 mm thickness in powder coated black finish

1/2" thk BWR plywoods as ledge finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

50mm CHS- MS section of 3 mm thickness in powder coated black finish

Key Plan

Ground Floor

1/2" thk BWR plywoods as ledge finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

50mm CHS- MS section of 3 mm thickness in powder coated black finish

Drawer

1/2" thk BWR plywood as backing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as partition finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

Triple O

3/4" thk BWR plywood as shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

FFL±0'-0"

Ground Floor

50mm CHS- MS section of 3 mm thickness in powder coated black finish

3/4" thk BWR plywood as shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

1/2" thk BWR plywood as backing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as frame finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

50mm CHS- MS section of 3 mm thickness in powder coated black finish

FFL±0'-0" FCL±6'-2"

3 4" thk 1'*1' wide plywood frame for the mirror

25mm thk oxide finish as dado of selected texture and shade

3/4" thk BWR plywood as frame finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

1/2" thk BWR plywood as backing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as handleless shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

1/2" thk BWR plywood as backing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as frame finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

TRIPLE G 1:10

Ground Floor

Key Plan STUDIO Vaishnavi drawn checked by 11 MAR 2022 date architect Sarojini Ar. Tahaer Zoyab scale job Venkatesh Residence VanityUnit-GF 104ID_FS_GF09R01

1/2" thk BWR plywood as backing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as boxing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

3/4" thk BWR plywood as shutter finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

1" thk granite slab as ledge of selected texture and shade

4" thk concrete slab as counter top with 1" granite topping of selected texture and shade

3/4" thk BWR plywood as partition finished with 1mm laminate and 2mm edge winding tape of selected texture and shade

1/2" thk BWR plywood as backing finished with 1mm laminate and 2mm edge winding tape of selected texture and shade
