10 Pro Tips for Mastering BIM Projects with Navisworks

Tips to Help You Succeed

01 Create a Project Setup:

Define a clear project structure with appropriate levels of detail and classification.

Establish naming conventions for models and views to maintain consistency.

Import models from various BIM authoring tools (e.g., Revit, ArchiCAD, Tekla) into Navisworks. Link models to maintain synchronization with changes in the original files.

02

Import and Link Models:

03 Manage Model Coordination:

Use Navisworks' clash detection tools to identify and resolve conflicts between models. Implement a clash resolution process involving relevant stakeholders.

Create custom views for specific purposes (e.g., construction, maintenance, facility management).

Use filters to isolate and focus on specific elements or systems. Create and Manage Views:

05 Leverage Timelining and Animation:

Create timelines to visualize the construction sequence and identify potential scheduling conflicts.

Use animations to simulate the movement of objects or systems over time.

06

Utilize Measurement Tools:

Measure distances, areas, and volumes to verify design intent and quantities.

Use section and elevation views to analyze model geometry.

Integrate with Other Tools: 07

Connect Navisworks with other software (e.g., project management tools, cost estimation software) for comprehensive project management.

Customize Interface and Settings: 08

Tailor Navisworks to your preferences and workflow by customizing toolbars, keyboard shortcuts, and settings.

09 Explore Advanced Features:

Experiment with advanced features such as point clouds, reality capture, and BIM 360 integration.

10 Stay Updated:

Keep up with the latest Navisworks releases and best practices to maximize its benefits.

Elevate your BIM projects with Navisworks. Start implementing these tips today to streamline collaboration, enhance visualization, and achieve project success.
