Curing and thermal behavior of epoxy resins of hexafluoro - bisphenol –A and bisphenol-A been reported in the literature by several methods[20-24]. But the expression used by Dharwadkar and Kharkhanawala for the calculation of activation energy is independent of sample size and heating rate. Ea100θ ln ln = +C (1 − a )−1 RTi2 (T f − Ti )
(1)
where α, fraction reacted; Ti, the temperature of inception of reaction; Tf, temperature at the point of inflection on the thermogram; θ = (T-Ts) (where T is the temperature under consideration and Ts is the maximum temperature); C, −1 constant; R, gas constant. A plot of ln ln (1 − a ) versus θ gave a straight line was equal to m=
100 Ea
RTI 2 (T f −Ti )
(2)
From this equation, Ea was calculated.
Activation energies of decomposition (Ea) were calculated by using Equations 1 and 2 and the values of E have been summarized in Table 2. On comparing the activation energies of decomposition reaction of EFN and EBN novolac epoxy resins cured with DDM/ DDS/ IMAM curing agents respectively, the following trend was observed for activation energies [(EFN / EBN) + IMAM ] > [(EFN / EBN) + DDM ] > [(EFN / EBN) + DDS]. These results also substantiate the fact that the presence of fluorinated groups in the curing agent IMAM have also contributed towards the improvement of thermal stability of both the cured epoxy resins. From Table 2 it was also observed that the cured samples having high Rw value showed higher activation energy which led to the increase in their thermal stability.
4. Conclusions EFN and EBN novolac epoxy resins were synthesized, which were then thermally cured with aromatic amines (DDM, DDS) and synthesized aromatic imide-amine (IMAM) curing agents. The investigation of curing behavior of cured epoxy resins revealed that IMAM was found to be the least reactive curing agent towards both EFN and EBN as compared to their counterparts DDM and DDS. This was attributed to the electronic effects, high molecular weight and physical properties of IMAM curing agent. The experimental results for the thermal degradation demonstrated that the major weight loss for all the samples occurred in the temperature range of 300-600°C. Both the EFN and EBN samples cured with IMAM exhibited higher thermal stability probably due to the solid state aromatization reactions which may lead to the formation of cross-links between the carbonyl and trapped or unreacted amino groups. The presence of CF3 groups in IMAM may also have played its role in the enhancement of thermal stability of such cured resins. The EFN cured resins were found to be more heat resistant as compared to their corresponding EBN resins. This was owing to the ease of oxirane ring opening due to the presence of CF3 groups in EFN that might have been a good ignition for Polímeros, 26(1), 11-20, 2016
the formation of better crosslinked network structure than EBN cured resins.
5. References 1. Lee, G. S., Lee, Y. C., & Gong, M. S. (2001). Prepration of epoxy resins containing ether ether sulfone unit and thermal properties. Bulletin of Korean Chemical Society, 22(12), 13931396. 2. Romao, B. M. V., Diniz, M. F., Azevedo, M. F. P., Lourenco, V. L., Pardini, L. C., Dutra, R. C. L., & Burel, F. (2006). Characterization of the curing agents used in epoxy resins with TG/FT-IR technique. Polímeros: Ciencia e Technologia, 16(2), 94-98. http://dx.doi.org/10.1590/S0104-14282006000200007. 3. Paluvai, N. R., Mohanty, S., & Nayak, S. K. (2014). Synthesis and modification of epoxy resins and their composites: A review. Polymer-Plastics Technology and Engineering, 53(16), 17231758. http://dx.doi.org/10.1080/03602559.2014.919658. 4. Tao, Z., Yang, S., Ge, Z., Chen, J., & Fan, L. (2007). Synthesis and properties of novel fluorinated epoxy resins based on 1,1-bis(4-glycidyllesterphenyl)-1-(3′-trifuoromethylphenyl)2,2,2-trifluoroethane. European Polymer Journal, 43(2), 550-560. http://dx.doi.org/10.1016/j.eurpolymj.2006.10.030. 5. Vinicius, P., Bluma, S. G., & Raquel, M. S. (2013). Influence of the polyhedral oligomeric silsesquioxane n-phenylaminopropyposs in the thermal stability and the glass transition temperature of epoxy resin. Polímeros: Ciencia e Technologia, 23(3), 331-338. http://dx.doi.org/10.4322/polimeros.2013.039. 6. Alhousami, M. H. M., Al-Kamali, A. S. N., & Athawale, A. A. (2014). Synthesis and characterization of novel sulphanilamide/ epoxy resin modified polyester for thermal stability and impact strength. Open Journal of Polymer Chemistry, 4(4), 115-127. http://dx.doi.org/10.4236/ojpchem.2014.44013. 7. Dixit, V., Nagpal, A. K., & Singhal, R. (2010). Synthesis and characterization of phenoxy modified epoxy blends. Malaysian Polymer Journal, 5(2), 69-83. Retrieved in 20 December 2014, from http://www.fkkksa.utm.my/mpj 8. Oliveira, A., Backer, C. M., & Amico, S. C. (2015). Evaluation of the characteristics of an epoxy resin with diffrent degassing agents. Polímeros: Ciência e Tecnologia, 25(2), 186-191. http:// dx.doi.org/10.1590/0104-1428.1661. 9. Yu, M., Feng, B., Xie, W., Fang, L., Li, H., Liu, L., Ren, M., Sun, J., Zhang, J., & Hu, H. (2015). The modification of a terafunctional epoxy and its curing reaction. Materials, 8(6), 3671-3684. http://dx.doi.org/10.3390/ma8063671. 10. Ge, Z., Tao, Z., LiuJ., Fan, J., & Yang, S. (2007). Synthesis and charaterization of novel trifunctional fluorine containing epoxy resins based on 1,1,1-Tris(2,3-epoxypropoxyphenyl)2,2,2-trifluoroethane. Polymer Journal, 39(11), 1135-1142. http://dx.doi.org/ 10.1295/polymj.PJ2007096. 11. Cheng, J., Li, J., & Zhang, J. Y. (2009). Curing behavior and thermal properties of trifunctional epoxy resin cured by 4, 4′-diaminodiphenyl sulfone. Express Polymer Letters, 3(8), 501-509. http://dx.doi.org/10.3144/expresspolymlett.2009.62. 12. Heo, G. Y., & Park, S. J. (2009). Effect of substituted trifluoromethyl groups on thermal and mechanical properties of fluorine containing epoxy resin. Macromolecular Research, 17(11), 870-873. http://dx.doi.org/10.1007/BF03218628. 13. Meenakshi, K. S., Pradeep, E., Sudhan, J., & Kumar, S. A. (2012). Development and characterization of new phosphorus based flame retardant tetraglycidyl epoxy nanocomposites for aerospace application. Bulletin of Materials Science, 35(2), 129-136. http://dx.doi.org/10.1007/s12034-012-0271-0. 14. Liu, J. G., He, M. H., Li, Z. X., Qian, Z. G., Wang, F. S., & Yang, S. Y. (2002). Synthesis and characterization of organosoluble polyimides with trifluoro-substituted benzene in the side chain. 19
