DETAILS
SECTION A - TYPICAL SECTIONS
A1 - 450 EAVE
A2 - NO EAVE
A3 - DOUBLE STOREY - 450 EAVE
A4 - D/S - LIGHTWIEGHT - NO EAVE
DETAIL BOOK TABLE OF CONTENTS
A5 - DOWNPIPES NOT STEP AT BRICKWORK
A6 - TYPICAL WALL SECTION - 450 EAVE LINEA
A7 - 450 EAVE - CONDENSATION MANAGEMENT
SECTION B - FOOTING DETAILS
B1 - TYPICAL EDGE BEAM (310 SLAB)
B2 - TYPICAL EDGE BEAM (385 SLAB)
B3 - TYPICAL EDGE BEAM (460 SLAB)
B4 - STEPDOWN TO OUTDOOR LIVING (310 SLAB)
B5 - STEPDOWN TO OUTDOOR LIVING (385 SLAB)
B6 - STEPDOWN TO OUTDOOR LIVING (460 SLAB)
B7 - GARAGE FOOTING
B8 - HWS PAD DETAIL
B9 - REBATED THRESHOLD ENTRY
B10 - 86mm GARAGE STEPDOWN
B11 - 344mm GARAGE STEPDOWN
B12 - 514mm GARAGE STEPDOWN
B13 - RECESSED SLIDING DOOR - NO OUTDOOR LIVING
B14 - RECESSED SLIDING DOOR - LEVEL THRESHOLD
SECTION C - GENERAL DETAILS
C1 - ROOF / LIGHTWEIGHT CLADDING
C2 - DADO RAIL
C3 - BULKHEAD ABOVE O.H
C3.b - BULKHEAD ABOVE O.H WITH COFFERED CEILING
C4 - GUTTER ON BRICKWORK
C5 - PASTER LINED MDF BH
C6 - PLASTERBOARD EXPANSION JOINT
C7 - CANOPY FLASHING
C8 - PITCHED ROOF RIDGE VENTILATION
C9 - TYPICAL DOOR JAMB
C10 - TYPICAL PARAPET DETAIL
C11 - TYPICAL PARAPET WITH BOX GUTTER DETAIL
C12 - FEATURE BULKHEAD - COFFERED CEILING
C13 - BALCONY FLOOR WASTE DETAIL
C14 - SALES OFFICE SPLIT JAMB DETAIL
C15 - RETAINING WALL DETAIL - ≤400
C16 - RETAINING WALL DETAIL - 400-800
C17 - RAINHEAD DETAIL
C18 - BAL12.5 PORTICO PIER DETAIL
C19 - LAUNDRY CHUTE DETAIL
C20 - BALCONY FLOOR DETAIL
C21 - BALCONY WATERPROOFING DETAIL (INT WALL HEBEL)
C22 - BALCONY WATERPROOFING DETAIL (EXTERNAL FACE)
C23 - BALCONY WATERPROOFING DETAIL (INT WALL CLADDING)
C24 - BARN DOOR DETAILS
C25 - CONDENSATION MNAGEMENT - 0-10º SKILLION ROOF HIGH LEVEL VENTILATION
C26 - NCC RAMP 86MM SLAB STEPDOWN
C27 - NCC RAMP 172MM SLAB STEPDOWN
C28 - NCC STEP-FREE THRESHOLD
SECTION D - FACADE DETAILS
D1 - RAISED PORCH ABOVE INFILL
D2 - PIER DETAIL RENDERED BRICK BASE, EX. POST
D3 - REMOVED
D4 - HEBEL PIER
D5 - EXPOSED POST STIRRUP DETAIL
D6 - NOVA SUMP/DOWNPIPE
D7 - PROVINCIAL PIER DETAIL
D8 - PROVINCIAL BALCONY BRICK INFILL
D9 - NOVA - PORCH CANOPY EXTENSION
D10 - NOVA - PORCH ROOF PLAN
D11 - NOVA - REAR WALL DETAIL
D12 - BRIDGEHAMPTON - 'AIRE' 3-RAIL BALUSTRADE
SECTION E - WINDOW DETAILS
E1 - WINDOW WITH NO BOTTOM REVEAL
E2 - TYPICAL FACE BRICK SILL
E3 - TYPICAL RENDERED BRICK SILL
E4 - TYPICAL BRICKWORK ABOVE OPENING
E5 - BRICKWORK ABOVE OPENING - NO EAVE
E6 - INFILL ABOVE OPENING - 450 EAVE
E7 - INFILL ABOVE OPENING - NO EAVE
E8 - INFILL ABOVE OPENING - NO EAVE - 2590 CEILING
E9 - NO INFILL - 450 EAVE - 2440 CEILING
E10 - TRIMS TO INFILL
E11 - SQUARE SET WITH OVERHEAD CAB ABOVE
E12 - SQUARE SET SPLASHBACK WINDOW
E13 - SKYLIGHT SHAFT SECTION
E14 - SKYLIGHT CROSS SECTION
E15 - HEBEL WINDOW DETAILS
SECTION F - GARAGE DETAILS
F1a - GARAGE DOOR PARAPEt - TIMBER
F1b - GARAGE DOOR PARAPEt - STEEL
F2 - GARAGE DOOR SECTION - 450 EAVE - 2440 CEILING
F3 - GARAGE DOOR SECTION - BRICK ABOVE - 450 EAVE
F4 - GARAGE DOOR SECTION - FC INFILL - 450 EAVE
F5 - GARAGE DOOR SECTION - EPS
F6 - GARAGE DOOR PARAPET - BOX GUTTER
F7 - TRAY DECK ROOF OVER GARAGE
F8 - GARAGE STEPDOWN CEILING
F9 - GARAGE OFFSET VALLEY
SECTION G - OUTDOOR LIVING DETAILS
G1 - INFILL ABOVE OL OPENING - 2440 CEILING
G2 - INFILL ABOVE OL OPENING - 2590 CEILING
G3 - REMOVED
G4 - REMOVED
G5 - OL BEAM - WITH BH
G6 - OL BEAM
G7 - OL BEAM - ROOM ABOVE WITH BH
G8 - REMOVED
G9 - BOUTIQUE ENTERTAINER SLIDING DOOR DETAIL
G10 - OL BEAM - CONCEALED WITHIN FLOOR ABOVE
G11 - TILING TO OL FLOOR
SECTION H - WET AREA DETAILS
H1 - REMOVED
H2 - REMOVED
H3 - BATH HOB DETAILS (CLASSIC)
H4 - BATH HOB DETAILS (PREMIUM)
H5 - BATH HOB WATERSTOP
H6 - SHOWER BASE - WITH HOB
H7 - SHOWER BASE - 10mm RECESSED
H8 - SHOWER BASE - 5mm RECESSED NCC2022
H9 - REMOVED
H10 - SHOWER NICHE
H10.b - SHOWER NICHE - 600 WIDE
H11 - SHOWER NICHE - EXTERNAL WALL
H12 - 1200 HIGH TILED WALL
H13 - SHAVING CABINET
H14 - WALL MOUNTED BASIN MIXERS (ABOVE COUNTER & INSET
H15 - LAUNDRY CABINET CUTOUT
H16 - EXTENDED BENCH OVER BATH
H17 - SHOWER WINDOW DETAIL
H18 - BATH HOB WATERSTOP ALTERNATIVE SOLUTION
H19 - SHOWER HOB DETAIL LEVEL THRESHOLD
H20 - CLASSIC 1500 - ISLAND BATH CUTOUT
H21 - CLASSIC 1700 - ISLAND BATH CUTOUT
H22 - TYPICAL TILED SHOWER SEAT DETAIL
SECTION I - CLADDING DETAILS
I1 - AXON CLADDING DETAILS
I2 - FINE TEXTURE CLADDING DETAILS
I3 - EPS CLADDING DETAILS
I4 - LINEA CLADDING DETAILS
I5 - LINEA TO HARDIEFLEX DETAIL
I6 - NEWPORT CLADDING DETAILS
I7 - STRIA CLADDING DETAILS
SECTION J - STAIRCASE DETAILS
J1 - N/A
SECTION K - SITE
K1 - WATER TANK (POLY)
K2 - WATER TANK (STEEL)
K3 - GAS METER CLEARANCES
K4 - WATER TANK ROUGH IN
K5 - SERVICES RUN-IN LOCATIONS (AT METERING) 31/08/2024
UNDER EAVE WINDOW REVEAL HEAD HEIGHTS
2590MM = 2310MM
2740MM = 2460MM
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
GROUND FLOOR CEILING LEVEL
COLORBOND STEEL FASCIA
ROOF TRUSSES TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
CEILING INSULATION AS PER SPECIFICATIONS
TOP PLATE
4.5MM FC SHEET EAVE LINING 19mm Quad
TRIMMERS@ 1200 CTS
2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE
WALL TIES MAX 400MM SPACINGS (4 COURSES).
NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING
WEEPHOLE
GROUND FLOOR
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
TYPICAL WALL SECTION, 450 EAVE
SCALE 1:20
90x35 MGP10 EAVE DROPPER
INSULATION BATTS AS PER SPECIFICATION
BOTTOM PLATE
MDF SKIRTING BOARD
NOGGIN
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
GROUND FLOOR CEILING LEVEL
COLORBOND STEEL FASCIA
2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE
WALL TIES AS PER AS2699.1
WALL TIES MAX 400MM SPACINGS (4 COURSES).
NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING
WEEPHOLE
GROUND FLOOR
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
TYPICAL WALL SECTION, NO EAVE
SCALE 1:20
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
CEILING INSULATION AS PER SPECIFICATIONS
TOP PLATE
DETAIL:
INSULATION BATTS AS PER SPECIFICATION
BOTTOM PLATE
MDF SKIRTING BOARD
NOGGIN
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
FIRST FLOOR CEILING LEVEL
COLORBOND STEEL FASCIA
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
CEILING INSULATION AS PER SPECIFICATIONS
TOP PLATE
90x35 MGP10 EAVE DROPPER TRIMMERS@ 1200 CTS
35mm TOP HAT TO BE INSTALLED MAX 250MM FROM TOP AND BOTTOM OF PANEL, FIXINGS AS PER MANUFACTURER
REFER TO ELEVATION TO WALL CLADDING MATERIAL
NOTE:
PENETRATIONS THROUGH HEBEL CLADDING FOR SERVICES SHOULD BE NEATLY DRILLED AND THE JOINT SEALED WITH AN EXTERNAL GRADE ACOUSTIC AND/OR FIRE RATED PAINTABLE SEALANT
COLORBOND CAPPING AND FLASHING WIN MIN. 1:200 FALL
FIRST FLOOR
GROUND FLOOR CEILING LEVEL
2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE
WALL TIES AS PER AS2699.1
WALL TIES MAX 400MM SPACINGS (4 COURSES).
NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING
WEEPHOLE
GROUND FLOOR
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
SISALATION TO FRAME INSULATION BATTS AS PER SPECIFICATION
CHIPBOARRD FLOORING
UPPER FLOOR JOISTS AS PER SPECIFICATION
10mm PLASTER
NOGGING
BOTTOM PLATE
MDF SKIRTING BOARD
TYPICAL WALL SECTION - HEBEL (50mm), 450mm EAVE
SCALE 1:20
NOGGING
SCALE 1:20
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
FIRST FLOOR CEILING LEVEL
COLORBOND STEEL FASCIA
REFER TO ELEVATION TO WALL CLADDING MATERIAL
VERTICAL BATTENS
FIRST FLOOR
2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE
GROUND FLOOR CEILING LEVEL
PLASTER CORNICE
CEILING INSULATION AS PER SPECIFICATIONS
90x45 MGP10 TOP PLATE
INSULATION FOIL TO OUTSIDE OF BATTENS
INSULATION BATTS AS PER SPECIFICATION
NOGGING
CHIPBOARRD FLOORING
UPPER FLOOR JOISTS AS PER SPECIFICATION
WALL TIES MAX 600MM SPACINGS (7 COURSES).
NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
10mm PLASTER NOGGING
BREATHABLE SARKING INSTALLED OVER DAMP PROOF COURSE FLASHING
WEEPHOLE
GROUND FLOOR
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
90x45 MGP10 BOTTOM PLATE
MDF SKIRTING BOARD
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
CEILING LEVEL
ROOF TRUSSES @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
CEILING INSULATION AS PER SPECIFICATIONS
TOP PLATE
INSULATION FOIL TO OUTSIDE OF FRAME
INSULATION BATTS AS PER SPECIFICATION
10mm PLASTER
LINEA WEATHERBOARD ON TIMBER BATTENS
BREATHABLE SARKING INSTALLED OVER DAMP PROOF COURSE FLASHING
WALL TIES MAX 600MM SPACINGS (7 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
WEEPHOLE
FLOOR LEVEL
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
BOTTOM PLATE
MDF SKIRTING BOARD
WAFFLE POD SLAB TO ENGINEER'S DESIGN
TYPICAL WALL SECTION
SCALE 1:20
COR-VENT FIXED OVER FIRST BATTEN TO PERIMITER OF ROOF WHERE REQUIRED IN BUISHFIRE ZONES STAINLESS STEEL EMBER MESH WITH APERTURE LESS THAN 2.0MM MEETS COMPLIANCE WITH AS3959.
GROUND FLOOR CEILING LEVEL
COLORBOND STEEL FASCIA
4.5MM FC SHEET EAVE LINING
TRIMMERS@ 1200 CTS
SCALE 1:20
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH TOP PLATE
ROOF TRUSSES TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE CEILING INSULATION AS PER SPECIFICATIONS
19MM QUAD
90x35 MGP10 EAVE DROPPER
BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING
NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)
BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT
PLASTIC MEMBRANE TO BE TURNED OVER SLAB REBATE
BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER
WEEPHOLE GROUND FLOOR
NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)
BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
FOR 385mm HIGH SLAB SCALE 1:10
BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER
NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)
BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
GARAGE DOOR TO CLOSE ONTO
LINE OF REBATE BEYOND
PROVIDE GRADE BEHIND GARAGE REBATE
EXPANSION FOAM TO BE INSTALLED PRIOR TO DRIVEWAY INSTALLATION
CONCRETE SLAB AS PER ENGINEER'S DESIGN
SLAB MEMBRANE
BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT
PLASTIC MEMBRANE TURNED OVER SLAB REBATE
BREATHABLE SARKING INSTALLED OVER DAMP PROOF COURSE FLASHING
DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER
NOTE: CONCRETE PAD FOR HWS TO BE 100MM LOWER THAN FFL
NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)
WEEPHOLE GROUND FLOOR
CONCRETE PAD FOR HWS
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
TIMBER ENTRY FRAME CANTILEVERED OVER REBATE AND FIXED TO FRAMING MEMBER, MAX 5MM THRESHOLD
METAL ANGLE FOR SILL SUPPORT BOLTED TO SLAB
SRAY ON TERMITE APPLICATION
CONCRETE PAVING OVER INTEGRATED PORTICO SLAB, GRADED AT MAX 1:8
ENTRY DOOR FRAME REBATED 35MM
REBATED THRESHOLD ENTRY FOR 385mm HIGH SLAB SCALE 1:10
NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN
110X19 HARDWOOD PLATE
X19 KDHW TIMBER TOP TREAD
KDHW STAINED TIMBER TREADS
KDHW STAINED TIMBER RISERS
MDF SKIRTING BOARD MDF ARCHITRAVE
TO FORM BASE, TO BE GLUED TO CONCRETE SLAB BELOW
MDF ARCHITRAVE
NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN
110X19 HARDWOOD PLATE
140 X19 KDHW TIMBER TOP TREAD
290X45 KDHW STAINED TIMBER TREADS
140X19 KDHW STAINED TIMBER RISERS
MDF SKIRTING BOARD
140x45F17 TO FORM BASE, TO BE GLUED TO CONCRETE SLAB BELOW
NYLON
FLOORING TO BE LAID FLUSH, OR MAX. 5mm BENEATH TOP OF ALUMINIUM SILL
BRICKWORK BENEATH DOOR TO BE CUT ON EDGE TO FORM FLAT SILL
BREATHABLE SISALATION OVER LEAD FLASHING
LIGHTWEIGHT CLADDING FIXED TO BATTEN BEHIND
ACRYFLASH ROOF FLASHING REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
WALL INSULATION AS PER ENERGY RATE
BOTTOM PLATE
MDF SKIRTING BOARD
CHIPBOARD FLOORING FLOOR JOISTS
FULL TIMBER BLOCKING BOLTED TO STEEL BEAM WITH JOIST HANGER FOR JOIST FIXING
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
TIMBER BEAM FIXED TO STEEL WITH JOIST HANGER TO SUPPORT ROOF TRUSSES
PLASTERBOARD CEILING
BEAM AS PER ENGINEERS DESIGN
SCALE 1:20
PORTA 'VICTORIAN' DADO
PORTA
REFER TO INTERNAL ELEVATION FOR BULKHEAD HEIGHT
PLASTER CORNICE
FRAMING TO FORM BULKHEAD
40MM INFILL BY KITCHEN MANUFACTURER, TO MATCH CABINET COLOUR
KITCHEN OVERHEAD CUPBOARDS
WIDTH OF BULKHEAD TO ALIGN WITH ADJOINING WALL OR BENCH BELOW, WHICHEVER IS GREATER - REFER PLAN FOR EXTENT
REFER TO INTERNAL ELEVATIONS FOR CUPBOARD HEIGHTS FROM FLOOR LEVEL
OVERHEAD CUPBOARD BULKHEAD DETAIL
(IF REQUIRED)
SCALE 1:10
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL: SECTION:
PLASTER CORNICE
METAL CAGE BY PLASTERER
SQUARE SET CEILING
40MM INFILL BY KITCHEN MANUFACTURER
WIDTH OF BULKHEAD TO ALIGN WITH ADJOINING WALL OR AS PER DIMENSION NOMINATED ON INTERNAL ELEVATIONS
KITCHEN OVERHEAD CUPBOARDS
REFER TO INTERNAL ELEVATIONS FOR DETAILS OVERHEAD CUPBOARD BULKHEAD DETAIL SCALE 1:10
NOTE : ONLY AVAILABLE WITH 2740MM HIGH CEILINGS DETAIL:
ROOF PITCH & MATERIAL TO MATCH ELEVATIONS
GUTTER FIXED WITH A EXTERNAL GUTTER BRACKET "GP CLIP" AND SCREWED TO TRUSS
"Z" FLASHING OVER BATTERN TO BRICKWORK
A WALL MAY TERMINATE NOT MORE THAN 200mm MAX. FROM UNDERSIDE OF A NON-COMBUSTILBE ROOF COVERING. MUST BE SEALED WITH A NON-COMBUSTIBLE FASCIA, GUTTER OR FLASHING.
GARAGE ON BOUNDARY/GUTTER ON BRICKWORK
SCALE 1:20
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
(03) 9375 4632 www.orbithomes.com.au
BEAM TO ENGINEERS DESIGNS
FLASHING WITH FALL TO LOWER FLOOR KICK-OUT BELOW
18mm CHIPBOARD FLOORING BENEATH FLASHING, BATTEN AT UPPER FLOOR SIDE TO CREATE FALL @ MIN. 1°PITCH
RAFTERS AS PER ENGINEERING DESIGN
INSULATION PER ENERGY REPORT
10mm PLASTERBOARD LINING TO WALL AND CEILINGS
NOTE:
1. HIGH LEVEL VENTILATION SHOULD BE EVENLY DISTRIBUTED ALONG THE ROOF
2. WEATHERPROOFING OF SHEET ENDS TO BE MAINTAINED WHILE ALLOWING VENTILATION PATHWAY OF 5000mm²/m
ROOFING SHEETS TO BE UPTURNED AT EDGE BENEATH RIDGE CAPPING (REFER TO NOTE 2)
SARKING/ROOF BLANKET
20 MIN.
VENTILATION GAP BETWEEN SHEETS AT RIDGE
METAL RIDGE CAPPING (NOT SCRIBED)
METAL ROOF SHEETING AND PITCH AS PER PLANS
RIDGELINE VENTILATION - WITH SARKING
SCALE 1:20
20 MIN.
ROOFING SHEETS TO BE UPTURNED AT EDGE BENEATH RIDGE CAPPING (REFER TO NOTE 2)
VENTILATION GAP BETWEEN SHEETS AT RIDGE
METAL RIDGE CAPPING (NOT SCRIBED)
METAL ROOF SHEETING AND PITCH AS PER PLANS
RIDGELINE VENTILATION - WITHOUT SARKING
SCALE 1:20
(03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
COLORBOND FLASHING TO TOP
WEATHERBOARD CAPPING TO GRADE PARAPET FLASHING
FACE BRICKWORK
WALL TIES AS PER AS2699.1
WALL TIES MAX 400MM SPACINGS (4 COURSES).
NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
400 MAX HT
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
PLASTER CORNICE ROOF TRUSSES @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS
TYPICAL PARAPET DETAIL SCALE 1:20
SECTION:
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©
DETAIL:
COLORBOND FLASHING TO TOP OF PARAPET TO FALL BACK TO BOX GUTTER
WEATHERBOARD CAPPING TO GRADE PARAPET FLASHING
FACE BRICKWORK
WALL TIES AS PER AS2699.1
WALL TIES MAX 400MM SPACINGS (4 COURSES).
NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD
19MM YELLOW TONGUE FLOORING TO INSIDE FACE
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
TIMBER BLOCKING TO SUPPORT GUTTER BOARD
PLASTER CORNICE
REFER PLANS
SQUARE SET CEILING
METAL CAGE BY PLASTERER LASER LEVEL & BATTEN
PLASTER
SQUARE SET CEILING 160
FEATURE BULKHEAD - COFFERED CEILING (SQUARE SET)
SCALE 1:10
REFER PLANS
CORNICE
METAL CAGE BY PLASTERER
PLASTER
SQUARE SET CEILING CL 200
FEATURE BULKHEAD - COFFERED CEILING
SCALE 1:10
SECTION:
DETAIL:
MT
ROAD
VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
FLOOR DRAIN BASE INSERT
FLOOR TILES GROUT
SECONDARY COAT OF MEMBRANE ON TOP OF SCREED
MORTAR BED
WATERPROOF MEMBRANE
SCYON SECURA
NOTCH SECURA FLOOR AT FLANGE LOCATION
PUDDLE FLANGE UNDERNEATH
WATERPROOF MEMBRANE
BALCONY JOISTS
OUTLET TO DOWN PIPE
PORCH CEILING LINE
FLANGE FITTED OVER WASTE BELOW CEILING LINE
BALCONY FLOOR OVERFLOW POP DETAIL
SCALE 1:5
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
TIMBER SLEEPERS BUTT JOINTED ON CENTRE LINE
2 LAYERS OF 0.2mm POLYTHENE MEMBRANE TO BACK OF WALL FOR FULL HEIGHT. POLYTHENE MEMBRANE TO RUN DOWN BENEATH AG PIPE
GRANULAR COMPACTED FREE DRAINING MATERIAL OR NO FINES CONCRETE
100⌀ AG DRAIN WRAPPED IN GEOTEXTILE FABRIC. CONNECTED TO LEGAL POINT OF DISCHARGE.
15MPa CONCRETE FOOTING TO SOLDIERS INTO MIN. 100kPa BEARING CAPACITY SOIL. FOR MIN. FOOTING DEPTH REFER TO SCHEDULE
SIZE OF VERTICAL SOLDIERS AND MAX. CRS AS SPECIFIED IN TABLE
BUILDER TO PROVIDE A SAFE SOIL BATTER SLOPE DURING CONSTRUCTION (TO BE CONFIRMED WITH THE GEOTECHNICAL ENGINEER)
SPOON DRAIN (OR NATURAL SWALE)
N.S.L
NOTE: WALL DESIGNED FOR MAX SURCHARGE LOAD OF 5.0kPa
REFER TABLE
TYPICAL RETAINING WALL DETAIL - ≤ 400 HIGH
SCALE 1:20
TIMBER SLEEPER. REFER SCHEDULE.
WHERE STEEL POSTS SUPPORTS FENCE OVER WALL TO BE CONSTRUCTED VERTICALLY
BACKFILL WITH FREE DRAINAGE MATERIAL.
MOISTURE BARRIER TO BASE AND SIDES OF TRENCH EXCAVATION
40-50mm CRUSHED ROCK FILTER. 200mm COVER ABOVE AGI DRAIN
90 DIA. AGI DRAIN TO BE INSTALLED NO HIGHER THAN LOWER FINISHED SURFACE LEVEL WITH A 1:100 MIN. FALL WRAP DRAIN IN GEOTEXTILE FABRIC TO PREVENT CLOGGING
CRUSHED ROCK FILTER TO CONTINUE BETWEEN POSTS
STEEL POST. REFER SCHEDULE.
20 MPa MASS CONCRETE FOOTING. REFER SCHEDULE FOR FOUNDING DEPTH.
SLEEPER RETAINING WALL SCHEDULE - RETAINING CUT
185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS
RAKED RENDER TO TOP OF PIER
RENDERED 100MM EPS TO TOP OF BRICKWORK, WITH 18º FALL TO COMPLY WITH BAL REQUIREMENT
RENDER TO FACE OF BRICK PIER
PAVING IF SPECIFIED
FOOTINGS TO ENGINEERS DESIGN
185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS
RENDERED 100MM EPS TO TOP OF BRICKWORK WITH 18º FALL TO COMPLY WITH BAL REQUIREMENT
HOUSE FFL
RENDER TO FACE OF BRICK PIER
PAVING IF SPECIFIED FOOTINGS TO
2040H DOOR FLUSH PANEL HINGED AND LACHED DOOR WITH ARCHITRAVES AND DUMMY SET HANDLE
EXTERNAL WATERPROOFING TO BE IN ACCORDANCE WITH AS 4654.1 & 2
MINIMUM 1:100
75MM EPS SILL WITH TEXTURED RENDER ON BATTEN COLORBOND FLASHING 120 x 100
STEPDOWN TO BALCONY TO BE MINIMUM 50mm
WATERPROOFING MEMBRANE AND RETURNED UP WALLS 100mm IN ACCORDANCE WITH AS 4654.1 - 2012
BALCONY FLOOR DETAIL
20MM EPS BATTEN
EXTERNAL WATERPROOFING TO BE IN ACCORDANCE WITH AS 4654.1 & 2
RENDER FINISH APPLIED OVER WATERPROOFING MEMBRANE TO CLADDING
TILED SKIRT
TILED FLOORING
WATERPROOFING MEMBRANE BENEATH AND ABOVE SCREED, AND RETURNED UP WALLS AND OVER BALCONY EDGE MIN. 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2
TILE SCREED
19MM 'SCYON SECURA' FLOORING
STEPDOWN TO BALCONY TO BE MINIMUM 50mm FALL MINIMUM 1:100
RENDERED LIGHTWEIGHT CLADDING FIXED ON 24MM TOP HATS
STUD FRAME WITH SELECTED WALL BATTS
SELECTED SKIRTING
SELECTED FLOORING
COLORBOND FLASHING 120 x 100
NOTE: HEIGHT OF HANDRAIL AROUND
BALCONY TO BE 1000MM MIN ABOVE THE HIGHEST PART OF BALCONY FLOOR
19MM 'SCYON SECURA' FLOORING
BALCONY JOISTS
120MM X 100MM COLORBOND FLASHING
PLASTER LINING FIXED TO PORCH
BALCONY PORCH
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
WATERPROOFING MEMBRANE BENEATH AND ABOVE SCREED, AND RETURNED UP WALLS AND OVER BALCONY EDGE MIN. 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2
TILE SCREED TO FALL TOWARDS FLOOR WASTES IN THE CENTRE OF THE BALCONY FLOOR TILES TO BALCONY
RENDERED BLUEBOARD TO TOP AND INSIDE FACE OF NIB WALL
3NO. 90X35MM TRIMMERS FOR BALUSTRADE FIXING
RENDERED EPS DIRECT FIXED TO FACE OF BALCONY BEAM BALCONY JOIST LEVEL
2NO. 90 X 35MM PACKERS, ONE TO BE RIPPED DOWN TO SIZE
30mm DRIP EDGE
19 x 19mm TRIM
PORCH/BALCONY POST (REFER TO PLANS)
DATE ISSUED:
EXTERNAL WATERPROOFING TO BE IN ACCORDANCE WITH AS 4654.1 & 2
LINEA WEATHERBOARD CLADDING FIXED TO BATTEN
75MM EPS WALL CLADDING WITH TEXTURED RENDER FINISH OVER WATERPROOF MEMBRANE
TILED FLOORING
WATERPROOFING MEMBRANE BENEATH AND ABOVE SCREED, AND RETURNED UP WALLS AND OVER BALCONY EDGE MIN. 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2
TILE SCREED
19MM 'SCYON SECURA' FLOORING
STEPDOWN TO BALCONY TO BE MINIMUM 50mm
SCALE 1:10
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
BREATH SARKING TO STUD WALL
STUD FRAME WITH SELECTED WALL BATTS
SELECTED SKIRTING
SELECTED FLOORING
BEAM AS PER ENGINEERING
COLORBOND FLASHING 120 x 100
HANGING DOOR PANEL TRACK FACE MOUNT ROLLER
BUILDING UNDERLAY
BATTEN
SELECTED CLADDING
ALUMINUM FLASHING OVER FASCIA VENT
VENT SYSTEMS OVER FASCIA VENT - 62500N
VENT SYSTEMS - BV25 (>25000mm p/lm), 75mm FLASHING TAPE EACHSIDE WITH 30mm MESH CENTRE
TERMINATE UNDERLAY AT TOP OF PURLIN EXTRA 10mm REQUIRED FOR FIXING, OR FIX ROOFING AND FLASHING INDIVIDUALLY FOAM CLOSER BENEATH FLASHING
ALUMINIUM FLASHING DRESSED DOWN OR NOTCHED
REFER TO ELEVATIONS FOR ROOF MATERIAL AND PITCH ROOFING UNDERLAY
CONDENSATION MANAGEMENT
0-10º
SCALE 1:5
NOTE: STUD WALL TO BE ON
19MM STRUCTURAL PLYWOOD FLOORING TO ARCHITECTURAL SPECIFICATIONS. PAINTED "INTERGRAIN" NON SLIP FINISHING AS PER AS1428.
90X45 MGP10 NOGGING BETWEEN JOISTS
4NO. 90X45 MGP10 JOISTS @ 300 CTS AND AT EACH END CUT DEPTH TO SUIT FLOORING THICKNESS. 18MM LOSP COVERING TO EITHER SIDE
RAVEN THRESHOLD RP98 @ NO STEEPER THAN 1:8 TO RAMP TRANSITION (19x150mm)
104MM HIGH PINE STEP RAMP AT MAX 1:10 GRADIENT, MIN 1000MM WIDE
DESIGNED IN ACCORDANCE WITH AS1170.1
ADHESIVE FIXED TO SLAB AND CAULKED TO PERIMITER. JOISTS TO BE FIXED TO SLAB BY LIQUID NAILING OR SIMILAR TO MANUFACTURERS SPECIFICATIONS.
90X45 MGP10 TRIMMER BETWEEN PLATES AT THE RAMP LOCATION, NOMINAL FIXING. JOIST HANGERS OR SKEW NAILS AS PER MANUFACTURERS SPECIFICATIONS
110X18 HARDWOOD PLATE RAMPED THRESHOLD WITH A GRADIENT NO STEEPER THAN 1:8
SELECTED FLOOR COVERING
FL INSIDE DWELLING
90X35 MGP10 NOMINAL FIXING
SECTION:
DETAIL:
NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN
19MM STRUCTURAL PLYWOOD FLOORING TO ARCHITECTURAL SPECIFICATIONS. PAINTED "INTERGRAIN" NON SLIP FINISHING AS PER AS1428.
4NO. 190X45 MGP10 JOISTS @ 300 CTS AND AT EACH END CUT DEPTH TO SUIT FLOORING THICKNESS. 18MM LOSP COVERING EITHER SIDE.
45X90 MGP10 NOGGING BETWEEN JOISTS
RAVEN THRESHOLD RP138 NO STEEPER THAN 1:8 TO RAMP TRANSITION
90X45 MGP10 TRIMMER BETWEEN PLATES AT THE RAMP LOCATION, NOMINAL FIXING. JOIST HANGERS OR SKEW NAILS AS PER MANUFACTURERS SPECIFICATIONS
110X18 HARDWOOD PLATE RAMPED THRESHOLD WITH A GRADIENT NO STEEPER THAN 1:8
SELECTED FLOOR COVERING
FL INSIDE DWELLING
190MM HIGH PINE STEP RAMP AT MAX 1:10 GRADIENT, MIN 1000MM WIDE
DESIGNED IN ACCORDANCE WITH AS1170.1
ADHESIVE FIXED TO SLAB AND CAULKED TO PERIMITER. JOISTS TO BE FIXED TO SLAB BY LIQUID NAILING OR SIMILAR TO MANUFACTURERS SPECIFICATIONS.
TYPICAL GARAGE RAMP (172MM STEPDOWN)
SCALE 1:20
90X35 MGP10 NOMINAL FIXING
DOOR JAMB
'RAVEN RP77 (13x100mm) THRESHOLD PLATE WITH MIN. 1:8 GRADIENT SELECTED FLOOR COVERING
RENDER TO FACE OF BRICK PIER
SLAB
RENDER TO FACE OF BRICK PIER
SLAB AS PER ENGINEERS DESIGN
PORCH
135x135
185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS
RAKED RENDER TO TOP OF PIER
RENDERED 100MM EPS TO TOP OF BRICKWORK
135x135 Ex. POSTS
185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS RAKED RENDER TO TOP OF PIER
RENDERED 100MM EPS TO TOP OF BRICKWORK
STEEL COLUMN TO ENGINEER'S DESIGN CENTRED TO PIER
STEEL POST TO BE CLAD WITH LOSP TO PROVIDE A 120x120 TIMBER POT APPEARANCE
138x18 TIMBER TRIM AROUND BASE OF EXPOSED POST
RENDERED BLUEBOARD TO 'TOP OF 'HEBEL' PIER, RENDER TO FALL AWAY FROM CENTRE
'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS
24mm TOP HAT FOR FIXING OF PANEL, REFER TO MANUFACTURERS FOR FIXING REQUIREMENTS
STEEL COLUMN TO ENGINEER'S DESIGN CENTRED TO PIER
'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS
90x90 TIMBER SUPPORT POST TO HEIGHT OF 'HEBEL' CLADDING ONLY
TIMBER POST AS PER PLAN
CENTRE PIN POST STRIRRUP
ANCHOR BOLTS - TO BE INSTALLED PERPENDICULAR TO THE SLAB
INGRATED SLAB AS PER ENGINEER'S DESIGN
CONCRETE PAVING TO BE 50mm MIN FROM BOTTOM OF POST DETAIL:
HOUSE FFL
EXPOSED POST STIRRUP DETAIL SCALE 1:20
AXON CLADDING ON TIMBER BATTENS
ROOF TRUSSES AS PER TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER LINING TO UNDERSIDE OF PORCH
2º METAL DECK ROOF OVER PORCH
METAL FLASHING
CEILING LINE
RENDERED EPS
OVERFLOW WITH PICTURE FRAME CAPPING SUMP BOX GUTTER 100MM x 75MM DOWNPIPE PICTURE FRAME AROUND OVERFLOW POP
135 X 135 STAINED EXPOSED POST WITH METAL STIRRUP AT BOTTOM
AUSTRALIA Pty.Ltd.© ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
75MM RENDERED EPS CLADDING FIXED TO 35MM TIMBER BATTENS
STEEL COLUMN TO ENGINEER'S DESIGN
110X20 RENDERED MOULDING
590X590 FACE BRICK PIER
DETAIL:
110X20 RENDERED MOULDING
RENDERED BRICKWORK TO BALCONY SECTION
110X20RENDERED MOULDING
590X590 FACE BRICK PIER
STEEL COLUMN TO ENGINEER'S DESIGN
590X590 FACE BRICK PIER
110X20 RENDERED MOULDING
710X710 RENDERED BRICK TO BASE OF PIER
SECTION:
STEEL COLUMN TO ENGINEER'S DESIGN
RENDERED BRICKWORK TO
110X20 RENDERED MOULDING
590X590 FACE BRICK PIER
FACE BRICK INFILL TO BALCONY BETWEEN PIERS
PORCH INFILL - 3D VIEW
STEEL COLUMN TO ENGINEER'S DESIGN
RENDERED BRICKWORK TO
110X20 RENDERED MOULDING
590X590 FACE BRICK PIER
FACE BRICK INFILL TO BALCONY BETWEEN PIERS
- 3D
RENDERED EPS CLADDING TO INSIDE OF BALCONY
TIMBER FRAME TO BALCONY
DOUBLE BRICK TO PORCH INFILL BELOW BALCONY JOISTS
AXON CLADDING FIXED TO 35MM BATTENS
TRANSFER FLASHING OVER BRICK JUNCTION
OUTSIDE BRICK
PLASTER STUD WALL
NOVA - REAR WALL DETAIL
SCALE 1:10
SECTION:
COPYRIGHT
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD
ASCOT VALE. 3032
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
DATE ISSUED:
75x30mm TOP RAIL
OFFSET TOP RAIL WALL MOUNTING BRACKET
MOUNTING PLATE
45x45mm MID RAIL
65x16.5mm SLAT BALUSTERS
50x50x3.2mm 'AIRE' POST WITH WELDED BASE PLATE
TWO-PART DOMICAL BASE PLATE COVER
MOUNTING PLATE
45x45mm BOTTOM RAIL
OFFSET TOP RAIL WALL MOUNTING BRACKET
50x50x3.2mm 'AIRE' POST WITH WELDED BASE PLATE
MID RAIL MOUNTING PLATES
45x45mm MID RAIL
BOTTOM RAIL MOUNTING PLATES
TWO-PART DOMICAL BASE PLATE COVER
SLAT
45x45mm BOTTOM RAIL
DETAIL:
75x30mm
BENCHTOP
NOTE: WINDOW TO BE 865mm TO BOTTOM OF WINDOW REVEAL FLEXIBLE
ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
10mm CLEARANCE
BETWEEN FRAME AND SILL
TIMBER REVEAL
ARCHITRAVE AS PER SPECIFICATION
SILL BRICK
FLASHING AS PER WINDOW MANUFACTURER
PLASTER STUD WALL
WALL TIES
BRICK HEADER COURSE UNDER WINDOW
TIMBER REVEAL 10mm CLEARANCE BETWEEN FRAME AND SILL
ARCHITRAVE AS PER SPECIFICATION
FLASHING AS PER WINDOW MANUFACTURER
PLASTER STUD WALL WALL TIES
RENDERED BRICKWORK AS PER ELEVATIONS
OUTSIDE BRICK
SISALATION WRAP OVER BRICK FLASHING
WEEPHOLE WITH FLASHING
PLASTER STUD WALL
ARCHITRAVE AS PER SPECIFICATION
TIMBER REVEAL 15mm CLEARANCE
EA STEEL LINTEL
STEEL LINEL ANGLE TO COVER HOLES IN BRICK, IF REQUIRED TRIM REAR OF BRICK DETAIL: SECTION:
3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632
COLORBOND STEEL FASCIA
WEEPHOLE WITH FLASHING
HEAD HEIGHT
CEILING INSULATION AS PER SPECIFICATION
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS PLASTER CORNICE
TOP PLATE
LINTEL AS PER PLAN
STEEL LINTEL AND INFILL STRIP ATTACHED TO UNDERSIDE DOOR FRAME
BRICKWORK ABOVE OPENINGS (NO EAVE)
SCALE 1:20
90x35 MGP10 EAVE DROPPER
600 PLASTER CORNICE
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
CEILING INSULATION AS PER SPECIFICATION
LINTEL AS PER PLAN
COLORBOND STEEL FASCIA DPC WINDOW FLASHING
WEEPHOLE WITH FLASHING
EA STEEL LINTEL
STEEL LINTEL ANGLE TO COVER HOLES IN BRICK, IF REQUIRED TRIM REAR OF BRICK
CEILING HEIGHT WINDOW HEAD HEIGHT TOP PLATE ALUMINIUM WINDOW FRAME
BRICKWORK ABOVE OPENINGS (450 EAVE)
SCALE 1:20
TRIMMERS@ 1200 CTS DETAIL: SECTION:
90x35 MGP10 EAVE DROPPER
CEILING HEIGHT
COLORBOND STEEL FASCIA
WINDOW HEAD HEIGHT
4.5MM FC SHEET FIXED TO TIMBER BLOCKING
TRIMMERS@ 1200 CTS DETAIL:
SCALE 1:20
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
CEILING INSULATION AS PER SPECIFICATION
PLASTER CORNICE
TOP PLATE
LINTEL AS PER PLAN
DPC WINDOW FLASHING
ALUMINIUM WINDOW FRAME
CEILING HEIGHT
COLORBOND STEEL FASCIA
2110 WINDOW HEAD HEIGHT
4.5MM FC SHEET FIXED TO TIMBER BLOCKING
SCALE 1:20
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD
VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
CEILING INSULATION AS PER SPECIFICATION
PLASTER CORNICE
TOP PLATE
LINTEL AS PER PLAN
90 x 35 & 42 x 19 PINE DAR FRAMING WITH BLOCKING BEHIND
ALUMINIUM WINDOW FRAME
CEILING HEIGHT
COLORBOND STEEL FASCIA
2100 WINDOW HEAD HEIGHT
4.5MM FC SHEET FIXED TO TIMBER BLOCKING
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
CEILING INSULATION AS PER SPECIFICATION
PLASTER CORNICE
TOP PLATE
LINTEL AS PER PLAN
90 x 35 & 42 x 19 PINE DAR FRAMING WITH BLOCKING BEHIND
ALUMINIUM WINDOW FRAME
TRIMMERS@ 1200 CTS
CEILING HEIGHT
COLORBOND STEEL FASCIA
4.5MM FC SHEET FIXED TO TIMBER BLOCKING
90x35 MGP10 EAVE DROPPER
ROOF TRUSSES CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS
CEILING INSULATION AS PER SPECIFICATION
PLASTER CORNICE
TOP PLATE
LINTEL AS PER PLAN
90X35 & 42X19 PINE DAR FRAMING WITH BLOCKING BEHIND
ALUMINIUM WINDOW FRAME
NO INFILL ABOVE OPENINGS (450 EAVE)
Note: Required Window head heights under eave
2590mm ceilings - 2310mm head height
2740mm ceilings - 2460mm head height
SCALE 1:20
SECTION:
AUSTRALIA Pty.Ltd.© ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
OVERHEAD CUPBOARD CARCASS
TILE ANGLE TO RUN UP TO OVERHEAD CL30
SQUARE SET PLASTER, PAINTED, NO TILE OR NO ANGLE
TILED SQUARE SET REVEAL (OVER PLASTER)
BENCHTOP TO RUN INTO BOUTIQUE FRAME
200MM PLY BRACE SUPPORT
BASE CUPBOARD CARCUS
NOTE: WINDOW TO BE 865mm TO BOTTOM OF WINDOW REVEAL
STEEL LINEL ANGLE TO COVER HOLES IN BRICK, IF REQUIRED TRIM REAR OF BRICK
FLEXIBLE PVC SILL FLAP 10mm FROM WINDOW TO BRICK
SILL BRICK
FLEXIBLE PVC FLASHING FIN
HOLE
720MM HIGH BOUTIQUE OFFSET PLASTER REVEAL WINDOW WITH OVERHEAD CABINET ABOVE (BOTTOM REVEAL)
SCALE 1:10
PLASTERED SQUARE SET REVEAL INCLUDING PLASTER ANGLE
TILES OVER PLASTER. TILE ANGLE INSTALLED OVER PLASTER TO PICK UP REVEAL RETURN
PLASTER SQUARE SET OVERHEAD REVEAL AGAINST BOUTIQUE FRAME, NO TILES
TILE ANGLE TO CORNER JUNCTION
WALL TILES RETURNED OVER SQUARE SET PLASTER RETURNING INTO BOUTIQUE FRAME
STONE BENCHTOP RETURNS INTO WINDOW, NO BOTTOM REVEAL
VAPOR BARRIER
BLOCKING AS REQUIRED
INSULATE CAREFULLY AROUND SKYLIGHT
HEAD FLASHING
UNDERLAYMENT 60-150mm
OUTSIDEFRAMEHEIGHT
VERTICAL CROSS SECTION
SCALE 1:20
DECK SEAL
TILES
BATTENS
30-60mm
SUPPORT BATTEN
INSULATION
PLASTER CEILING
SILL FLASHING
BATTENS TILES
OUTSIDE FRAME WIDTH
PACKING TRUSSES
MIDDLE GUTTER
UNDERLAYMENT
30-60mm
FLASHING GUTTER
UNDERLAYMENT
OUTSIDE FRAME WIDTH
100 FRAME TO FRAME SPACING
HORIZONTAL CROSS SECTION
SCALE 1:20
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©
PLASTER CEILING
VAPOR BARRIER
SECTION:
DETAIL:
DATE ISSUED:
REFER TO ELEVATIONS FOR ROOF MATERIAL AND PITCH
SKYLIGHT SECTION
SCALE 1:20
COPYRIGHT
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
SKYLIGHT REFER TO DETAILS
PITCHED CEILING @ 12.5DEG
DETAIL: SECTION:
VELUX
INTERNAL LINING
BITUMEN TAPE AROUND WINDOW
BREATHABLE SARKING TO OUTSIDE OF FRAME
34mm TOP HAT FOR FIXING OF PANEL, FIXING AS PER MANUFACTURER
'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS
WINDOW JAMB WITH TRIM
SCALE 1:5
34mm TOP HAT FOR FIXING OF PANEL, FIXING AS PER MANUFACTURER
BITUMEN TAPE AROUND WINDOW
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
O/A DEPTH
CAULKING AROUND WINDOW RUBBER
MIN 15° FALL
50MM 'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS
BREATHABLE SARKING TO OUTSIDE OF FRAME
HEBEL WINDOW SILL
SCALE 1:5
HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL: SECTION:
COLORBOND FLASHING TO TOP
FACE BRICKWORK
CEILING LEVEL
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
ORANGE TONGUE 19MM SHEET FLOORING
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
BATTEN @600 CENTERS AND PLASTER LINED TO REAR BEAM
BEAM & LINTEL AS PER ENGINEERING DESIGN
19x120 LSOP TRIM
BRICK LINTEL AS PER ENG. DESIGN
GARAGE DOOR PARAPET SECTION
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
COLORBOND FLASHING TO TOP
FACE BRICKWORK
CEILING LEVEL
BRICK LINTEL AS PER ENG. DESIGN
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD
VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
ORANGE TONGUE 19MM SHEET FLOORING
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
BEAM AS PER ENGINEERING DESIGN
BATTEN @600 CENTERS AND PLASTER LINED TO REAR BEAM
3DEG FALL
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
90x35 MGP10 EAVE DROPPER TRIMMERS@ 1200 CTS
CEILING HEIGHT
COLORBOND STEEL FASCIA
4.5mm FC SHEET, ABOVE DOOR FIXED WITH CEMENT SHEETS NAILS
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE BEAM AS SPECIFIED ON PLAN
PLASTER LINED TO REAR LVL
QUIRK
90x18 LOSP TRIM BELOW LVL 42x42 LOSP TRIM
GARAGE DOOR SECTION (NO INFILL)
SCALE 1:20
DETAIL:
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
90x35 MGP10 EAVE DROPPER TRIMMERS@ 1200 CTS
CEILING HEIGHT
COLORBOND STEEL FASCIA WITH DRIP EDGE
19X19mm QUAD
REFER TO PLAN FOR GARAGE DOOR HEIGHT
BRICKWORK ABOVE
GARAGE DOOR SECTION
SCALE 1:20
DETAIL:
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
BEAM AS PER ENGINEER'S SPECIFICATION
118X18 LOSP TRIM
STEEL ANGLE AS PER ENGINEERS DRAWINGS
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
90x35 MGP10 EAVE DROPPER
TRIMMERS@ 1200 CTS
CEILING HEIGHT
COLORBOND STEEL FASCIA WITH DRIP EDGE
19X19mm QUAD
REFER TO PLAN FOR GARAGE DOOR HEIGHT
4.5mm FC SHEET, ABOVE DOOR FIXED WITH CEMENT SHEETS NAILS
GARAGE DOOR SECTION
SCALE 1:20
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTER CORNICE
BEAM AS PER ENGINEER'S SPECIFICATIONS
118X18 LOSP TRIM
LINEA WEATHERBOARD 35MM BATTEN COLORBOND FLASHING OVER BRICK/EPS JUNCTION
FIRST FLOOR LEVEL
75MM EPS CLADDING INSTALLED TO MANUFACTURER'S DESIGN AND SPECIFICATION
GROUND FLOOR CEILING HEIGHT
2/90MM X 35MM TIMBER BATTENS
GARAGE DOOR HEIGHT 2400mm
HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
CHIPBOARD FLOORING
FLOOR JOISTS
PLASTER CORNICE
300 PFC AS PER ENGINEERING DESIGN
BATTEN @600 CENTERS AND PLASTER LINED TO REAR BEAM
138x18 LOSP TRIM
COLORBOND STEEL FASCIA
90X45 CEILING JOISTS @ 600 CENTRES TRAY DECK ROOF @ 2° PITCH
90X45 RAFTERS @ 600 CENTRES
BEAM AS PER ENG. DESIGN
MDF SKIRTING BOARD
CHIPBOARD FLOORING
FLOOR JOISTS
FLASHING
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
ROOF RAFTERS @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS
FIRST FLOOR GROUND CEILING
PLASTERBOARD CEILING
TIMBER BEAM FIXED TO STEEL WITH JOIST HANGER TO SUPPORT ROOF RAFTERS
CEILING TO GARAGE
SCALE 1:20
GARAGE CEILING
STEEL BEAM AS PER ENGINEERS DESIGN
MDF SKIRTING BOARD
CHIPBOARD FLOORING
FLOOR JOISTS
FLASHING
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
ROOF RAFTERS @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS
FIRST FLOOR GROUND CEILING
PLASTERBOARD CEILING
TIMBER BEAM FIXED TO STEEL WITH JOIST HANGER TO SUPPORT ROOF RAFTERS
DROPPED CEILING AS PER ROOF MANUFACTURER SPECIFICATIONS
GARAGE CEILING DROPPED CEILING
STEEL BEAM AS PER ENGINEERS DESIGN
DROPPED CEILING TO GARAGE
SCALE 1:20
ORBIT HOMES AUSTRALIA PTY. LTD.
DETAIL:
SECTION:
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au AMENDMENT
COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©
TRUSS ROOF TO BE CONSTRUCTED SO THAT THE OUTER EDGE OF THE VALLEY GUTTER INERSECTS WITH THE CORNER OF THE CLADDING
EXTERNAL CORNER
TRUSS ROOF TO BE CONSTRUCTED SO THAT THE OUTER EDGE OF THE VALLEY GUTTER INERSECTS WITH THE CORNER OF THE BRICKWORK
10mm PLASTERBOARD LINING
90 x 35 CEILING BATTENS @450 CTRS
PLASTER CORNICE 19X19mm QUAD
4.5mm FC SHEET FIXED TO BLOCKING ABOVE WINDOW
CEILING LEVEL
LINTEL AS PER PLAN WINDOW HEADER
NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS
NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT
OUTDOOR LIVING/WINDOW
DETAIL WITH INFILL SCALE 1:20
HOMES AUSTRALIA PTY. LTD.
MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
10mm PLASTERBOARD LINING
90 x 35 CEILING BATTENS @450 CTRS
19X19mm QUAD
STEEL LINTEL AS PER ENGINEERS DESIGN WINDOW HEADER PLASTER CORNICE
CEILING LEVEL
INSTALL ALUMINUM INFILL IF REQUIRED
NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS
NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT
SCALE 1:20
DETAIL:
MT ALEXANDER ROAD
VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
CEILING LEVEL
COLORBOND STEEL FASCIA WITH DRIP EDGE
PAINTED FC SHEET
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
10MM PLASTERBOARD LINING
REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH
CEILING LEVEL
COLORBOND STEEL FASCIA
19X19mm QUAD
4.5mm FC SHEET NOTE: NO PVC JOINERS BETWEEN SHEETS
BEAM AS SPECIFIED ON PLAN
90x18mm LOSP TIMBER TRIM TO BOTTOM
ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS
PLASTERBOARD TO CEILING
90 x 35 CEILING BATTENS @450 CTRS 19mm QUAD
FC SHEET ENDS AT SAME LEVEL ON BOTH SIDES WITH QUIRK
NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS
NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT
OUTDOOR LIVING BEAM CLADDING DETAIL
SCALE 1:20
FLOOR LEVEL
BEAM AS PER ENGINEERS DRAWING 25MM TOP HAT BATTENS
CEILING LEVEL
CHIPBOARD FLOORING FLOOR JOISTS
PLASTERBOARD TO CEILING FIXED 90x35 CEILING BATTENS @450 CTRS
19X19mm QUAD
470X1070 BRICK PIER WITH 115X115 T.PINE POST WITHIN
10mm PLASTERBOARD LINING
CEILING LEVEL
90 x 35 CEILING BATTENS @450 CTRS
19X19mm QUAD
STEEL LINTEL AS PER ENGINEERS DESIGN WINDOW HEADER PLASTER CORNICE
35mm BATTENS TO INSIDE TO CREATE A 125mm THICK FRAME, INSTALLED AT INTERNAL LOCK-UP STAGE DPC FLASHING
INSTALL ALUMINUM INFILL IF REQUIRED
NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS
NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT
EPS CLADDING FIXED OVER 35mm TOP HAT BATTENS
FLOOR LEVEL
STRUCTURAL BEAM (REFER TO ENGINEERING)
CEILING LEVEL
DRIP EDGE
PLASTER TERMINATING 6MM SHORT OF HEBEL CLADDING 90X35 BATTEN
CHIPBOARD FLOORING SUBSTRATE FLOOR JOISTS
PLASTERBOARD TO CEILING FIXED OVER 90x35 CEILING BATTENS @450 CTRS
18X18MM QUAD
SCALE 1:20
*ALWAYS REFER TO INSTALLATION INSTRUCTIONS PROVIDED WITH THE BA TH TO ENSURE CURRENT INSTALLATION REQUIREMENTSADVISE OFFICE IF DETAILS IN BATH DO NOT MATCH THIS DETAIL INSTALLATION
SPOUT LOCATION TO BE CTR OF BATH UNLESS NOTED OTHERWISE ON PLANS SUPPORT BATTEN AT WASTE END OF BATH TO BE CUT EITHER SIDE OF WASTE PIPE
REPER WATER STOP DETAIL FOR PERIMETER OF BATH RIM
MIN. REFER TO WATERSTOP DETAIL
BRICK AND MORTAR PACKING TO SUPPORT BATH. ENSURE BATH RIM IS LEVEL.
SMARTPAN TO BE SEALED AS PER MANUFACTURER'S SPECIFICATIONS
HOB FRAMING TO BE 90X35 MGP10 HOB TO BE LINED WITH "VILLABOARD" TOP OF HOB TO BE WATERPROOFED
*ALWAYS REFER TO INSTALLATION INSTRUCTIONS PROVIDED WITH THE BA TH TO ENSURE CURRENT INSTALLATION REQUIREMENTSADVISE OFFICE IF DETAILS IN BATH DO NOT MATCH THIS DETAIL INSTALLATION
SUPPORT BATTEN AT WASTE END OF BATH TO BE CUT EITHER SIDE OF WASTE PIPE
INSTALL WATER BAR AROUND BATH INSERT CUTOUT. WATERPROOF UP TO WATER BAR
HOLE IN RUBBER SEAL CUT 10MM SMALLER THAN OUTLET AND GLUED IN PLACE
ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
BRICK AND MORTAR PACKING TO SUPPORT BATH. ENSURE BATH RIM IS LEVEL.
40MM FLANGE CUT INTO PVC LID. SMARTPAN TO BE SEALED AND GLUED INTO POSITION AS PER MANUFACTURER'S SPECIFICATIONS
• HOB FRAMING TO BE 90X35 MGP10 HOB TO BE LINED WITH "VILLABOARD" TOP OF HOB TO BE WATERPROOFED
•
SHOWER SCREEN POSITIONED ON TOP OF HOB
TILED 75x75mm HOB TO PERIMETER OF SHOWER
SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1:200 MIN FALL METAL ANGLE STRIP SHOWER
INTERNAL MEMBRANE OVER FLOOR SHEETING
SCALE 1:5
HOB DETAIL
OUTSIDE SHOWER COMPARTMENT
SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1:200 MIN FALL
SILL-LESS NOTHRESHOLD SHOWER SCREEN OVER OPENING 5
SHOWER SCREEN FRAME RAISED WITH PROPRIETARY PACKER AND SEALED
WATERPROOF MEMBRANE DIRECT TO SLAB AND OVER WATERSTOP
WATERSTOP SET 5MM ABOVE FLOOR TILE SET INTO PROPRIETARY SHOWER SCREEN CHANNEL
SHOWER HOB DETAIL - NCC2022 LEVEL THRESHOLD
SCALE 1:2
NOTE: A SHOWER WITHIN 200MM OF WET AREA OPENING/DOORWAY TO INCLUDE A VERTICAL WATERSTOP WHERE THE SHOWER ABUTS TEH WALL
DETAIL:
SELECTED TILES TO
NICHE CENTERED TO SHOWER WALL
SELECTED WALL TILES TO THE SHOWER
SELECTED WALL TILES TO THE INSIDE FACE AND INSIDE EDGES OF THE NICHE
CHROME EDGE STRIP AROUND NICHE 3MM PACKER REQUIRED TO REAR OF BASE SHEET TO CREATE FALL
CHROME EDGE STRIP AROUND NICHE
WATERPROOFING BOARD TO WET AREAS
WATERPROOFING ON BOARD BEHIND GROUT
GROUT
SELECTED WALL TILES
SELECTED WALL TILES TO THE SHOWER
SELECTED WALL TILES TO THE INSIDE FACE AND INSIDE EDGES OF THE NICHE
CHROME EDGE STRIP AROUND NICHE 3MM PACKER REQUIRED TO REAR OF BASE SHEET TO CREATE FALL
WATERPROOFING BOARD TO WET AREAS
WATERPROOFING ON BOARD BEHIND GROUT
GROUT
SELECTED WALL TILES
SELECTED
NICHE CENTERED TO SHOWER WALL
SELECTED WALL TILES TO THE SHOWER
SELECTED WALL TILES TO THE INSIDE FACE AND INSIDE EDGES OF THE NICHE
CHROME EDGE STRIP AROUND NICHE 3MM PACKER REQUIRED TO REAR OF BASE SHEET TO CREATE FALL
OUTER LAYER OF VILLABOARD
PLYBOARD TO EXTERNAL
INNER LAYER OF WATERPROOF BOARD GLUED TO OUTER PLYBOARD
WATERPROOFING ON BOARD BEHIND GROUT OUTER LAYER OF PLYBOARD FIXED TO STUD.
GROUT
SELECTED WALL TILES
SHOWER SCREEN POSITIONED ON TOP OF ANGLE CHROME EDGE STRIP CORNER UPPER
SELECTED WALL TILES
SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1: 200 MIN FALL. SHOWER
SCALE 1:10
END OF WALL STUDS THROUGH TO FLOOR JOISTS FOR SOLID FIXING. PROVIDE INTERMEDIATE BLOCKING WHERE REQUIRED.
END OF WALL STUDS THROUGH TO FLOOR JOISTS FOR SOLID FIXING.
INTERMEDIATE BLOCKING WHERE REQUIRED.
WALL MOUNTED MIXERINSET BASIN
SCALE 1:20
HOMES AUSTRALIA Pty.Ltd.© ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
WALL MOUNTED MIXERABOVE COUNTER BASIN
SCALE 1:20
TRI TEC VALVE FOR MIXER & FUTURE WM CONNECTION
TRI TEC VALVE FOR MIXER & FUTURE WM CONNECTION
WHEN LOCATED INSIDE CABINET, GPO TO BE POSITIONED ABOVE WM STOPS ON CUTOUT SIDE FOR FUTURE WM CONNECTION
CABINET MID-SHELF TO BE LOCATED BELOW WATER POINTS AND GPO
WHERE REQUIRED RECYCLED WATER POINT LOCATED INSIDE CABINET
80MM DIA. CUT OUT TO WM SIDE OF CARCASS
LAUNDRY CABINET WM HOSE CUTOUT (RELOCATED STOPS) - FRONT & SIDE ELEVATION
SCALE 1:20
HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
514MM HIGH PLASTERED OFFSET FIXED WINDOW WITH TILED REVEALS
SILL SET AT A MINIMUM OF 1800MM FFL
Note: Required Window head heights under eave
2590mm ceilings - 2310mm head height 2740mm ceilings - 2460mm head height
SCALE 1:20
BATH TO SIT DIRECTLY ONTO BATH
HOB - BATH TO BE INSTALLED AS PER
MANUFACTURES SPECIFICATIONS
WATERPROOF SEALANT AT JUNCTION OF TILES AND BATH RIM. SEALANT TO BE PLACED AFTER TILING
SELECTED TILES
WATERPROOF MEMBRANE TO ENTIRE TOP OF BATH HOB - BATH INSTALLATION TO OCCUR AFTER WATERPROOFING
WATERPROOF SEALANT AT JUNCTION OF BATH AND BATH HOB - BATH RIM TO ACT AS WATER STOP. SEALANT TO BE PLACED PRIOR TO TILING
VILLABOARD UNDERLAY
TIMBER FRAME FOR BATH HOB
AS PER WET AREA CONSTRUCTION - BATH INSTALLATION
STOP REPORT "PBS 289 17" STUART McCLENNAN
BATH HOB WATERSTOP
NOT TO SCALE
WATERPROOF SEALANT AT JUNCTION OF TILES AND BATH RIM. SEALANT TO BE PLACED AFTER TILING
BATH TO SIT DIRECTLY ONTO BATH HOB - BATH TO BE INSTALLED AS PER MANUFACTURES SPECIFICATIONS
WATERPROOF SEALANT AT JUNCTION OF BATH AND BATH HOB - BATH RIM TO ACT AS WATER STOP. SEALANT TO BE PLACED PRIOR TO TILING
VILLABOARD UNDERLAY
SELECTED TILES
WATERPROOF MEMBRANE TO ENTIRE TOP OF BATH HOB - BATH INSTALLATION TO OCCUR AFTER WATERPROOFING
TIMBER FRAME FOR BATH HOB AS PER WET AREA CONSTRUCTION - BATH INSTALLATION WATER STOP REPORT "PBS 289 17" STUART McCLENNAN
CAPPING ANGLE OR D MOULD OVER WATER STOP. MAX 5MM THRESHOLD
FLOOR TILES SCREEDED TOWARDS WASTE (1:200 MIN FALL)
WATERPROOF MEMBRANE UNDER AND OVER SCREED
WATERSTOP ANGLE UNDER SHOWER SCREEN WATERPROOFING OVER SILL-LESS NO-THRESHOLD SHOWER SCREEN OVER OPENING 5
INTERNAL LINING
STUD WALL
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
NAIL FOR BATTEN FIXING
2.8x40mm FIBRE CEMENT NAIL
JAMES HARDIE 75X75 COLORBOND CORNER FLASING
42x42mm LOSP
CAULKING TO JUNCTION
AXON CLADDING FIXED TO BATTEN
BREATHABLE SARKING TO STUD WALL
INTERNAL CORNER SCALE 1:5
BREATHABLE SARKING TO STUD WALL
NAIL FOR BATTEN FIXING
JAMES HARDIE 75X75 COLORBOND CORNER FLASHING
CUT BOARDS TO FINISH 2mm OF TIMBER TRIM
42x18mm LOSP
STUD WALL
INTERNAL LINING DETAIL:
AXON CLADDING FIXED TO BATTEN
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
2.8x40mm FIBRE CEMENT NAIL
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
BREATH SARKING TO STUD WALL
AXON CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
A&L FLASHING TO WINDOW
42x42mm LOSP
AXON CLADDING FIXED TO BATTEN
O/A DEPTH
WINDOW HEAD & SILL WITH TRIM SCALE 1:5
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
INTERNAL LINING
NAIL FOR BATTEN FIXING
BREATHABLE SARKING TO STUD WALL
AXON CLADDING
90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX. 42x42mm LOSP
WINDOW JAMB WITH TRIM
SCALE 1:5
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
BREATHABLE SARKING TO STUD WALL
AXON CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER
BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES;
70mm STUD - 143mm
90mm STUD - 163mm
FACTORY FITTED PACKING
DEPTH
BREATHABLE SARKING TO STUD WALL
AXON CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm O/A DEPTH
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE
BETWEEN FRAME AND SILL BRICK SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
WEEPHOLE ON BRICK
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
BRICK FLASHING WEEPHOLE ON BRICK
WINDOW ABOVE RENDERED BRICKWORK
SCALE 1:5
WINDOW ABOVE BRICKWORK
SCALE 1:5
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
BREATHABLE SARKING TO STUD WALL
AXON CLADDING
CAULKING TO JUNCTION
HEADER COURSE
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
BREATHABLE SARKING TO WALL STUD
AXON CLADDING CAULKING TO JUNCTION
RENDERED MASONRY WALL
HEADER COURSE
STUD WALL
HORIZONTAL BRICK JUNCTION
SCALE 1:5
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
BREATHABLE SARKING TO STUD WALL
INTERNAL LINING
HORIZONTAL BRICK JUNCTION
SCALE 1:5
STUD WALL FLASHING
AXON CLADDING
CAULKING TO JUNCTION
42x42mm LOSP TO CORNER
3 CAULKING TO JUNCTION
EXTERNAL BRICKWORK
SCALE 1:5
50MM HEBEL FIRST FLOOR CLADDING
TRANSFER FLASHING OVER BRICK
UPTURN FLASHING AGAINST FIRST FLOOR CLADDING
CAULKING TO INTERNAL CORNER
75X75 COLORBOND CORNER FLASHING BREATHABLE SARKING TO STUD WALL
42x18mm LOSP
SCALE 1:5
50MM HEBEL FIRST FLOOR CLADDING
TRANSFER FLASHING OVER BRICK
35MM TOPHAT BATTEN
UPTURN FLASHING AGAINST FIRST FLOOR CLADDING
42x42mm LOSP TO CORNER TO STEP BACK AT MATERIAL TRANSITION
CAULKING TO JUNCTION
INTERNAL LINING
STUD WALL
AXON CLADDING FIXED TO BATTEN
90 x 45 MGP10 TIMBER BATTENS @600CTRS MAX.
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
AXON CLADDING FIXED TO BATTEN
INTERNAL LINING
STUD WALL
NAIL FOR BATTEN FIXING
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
2.8x40mm FIBRE CEMENT NAIL
JAMES HARDIE 75X75 COLORBOND CORNER FLASING 42x42mm LOSP
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
EASYTEX CLADDING FIXED TO BATTEN
BREATHABLE SARKING TO STUD WALL
INTERNAL CORNER SCALE
1:5
INTERNAL LINING
STUD WALL
NAIL FOR BATTEN FIXING
CLADDING FIXED TO BATTEN
90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX.
2.8x40mm FIBRE CEMENT NAIL
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
LOSP
BREATHABLE SARKING TO STUD WALL
JAMES HARDIE 75X75 COLORBOND CORNER FLASING
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
EXTERNAL CORNER
SCALE 1:5
HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
42x18mm
BREATH SARKING TO STUD WALL
CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
A&L FLASHING TO WINDOW
42x42mm LOSP
EASYTEX CLADDING FIXED TO BATTEN
WINDOW HEAD & SILL WITH TRIM
SCALE 1:5
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
INTERNAL LINING
NAIL FOR BATTEN FIXING
90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX.
BREATHABLE SARKING TO STUD WALL
CLADDING ON BATTENS
42x42mm LOSP
WINDOW JAMB WITH TRIM
SCALE 1:5
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
ORBIT HOMES AUSTRALIA Pty.Ltd.©
CAULKING TO JUNCTION
BREATH SARKING TO STUD WALL
CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
WEEPHOLE ON BRICK
O/A DEPTH
EASYTEX CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
BREATH SARKING TO STUD WALL VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm O/A DEPTH
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
BRICK FLASHING
WEEPHOLE ON BRICK
WINDOW ABOVE RENDERED BRICKWORK
SCALE 1:5
WINDOW ABOVE BRICKWORK
SCALE 1:5
34MM TOP HAT BATTENS.
BREATHABLE SARKING TO OUTSIDE OF BATTEN
50MM HEBEL CLADDING
METAL FLASHING @ 3 DEGREES ON MORTAR BED
MASONRY WALL
STUD WALL 28 10 15
HORIZONTAL BRICK JUNCTION
SCALE 1:5
90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX.
BREATHABLE SARKING TO STUD WALL
INTERNAL LINING STUD WALL
EASYTEX CLADDING
CAULKING TO JUNCTION
42x42mm LOSP TO CORNER
CAULKING TO JUNCTION
EXTERNAL BRICKWORK
VERTICAL BRICK JUNCTION
SCALE 1:5
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
DETAIL:
STUD WALL
10-8x100mm SCREWS WITH WASHERS INTERNAL LINING
BREATHABLE SARKING BEHIND EPS PANEL
3MM EXPANSION GAP SEALED PRIOR TO RENDER
RENDERED EPS PANEL
BREATHABLE SARKING BEHIND EPS PANEL
INTERNAL CORNER
SCALE 1:5
INTERNAL LINING
STUD WALL
10-8X100mm SCREWS WITH WASHERS
RENDERED EPS PANEL
BREATHABLE SARKING BEHIND EPS PANEL
PVC EXTERNAL CORNER BEAD
3MM EXPANSION GAP SEALED PRIOR TO RENDER
EXTERNAL CORNER
SCALE 1:5
ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
Pty.Ltd.©
SECTION:
DETAIL:
BREATH SARKING TO STUD WALL
RENDERED EPS CLADDING
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
10-8x100mm SCREWS WITH WASHERS
SEALANT BEAD ACROSS GAP
NOTE: ENSURE WINDOW WEEP HOLE IS NOT BLOCKED
SEALANT BEAD ACROSS GAP
EXTERNAL CORNER BEAD 15º FALL ON SILL
RENDERED EPS CLADDING
WINDOW HEAD & SILL WITH TRIM
SCALE 1:5
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
INTERNAL LINING
SEALANT BEAD ACROSS GAP PVC REVEAL BEAD
BREATHABLE SARKING BEHIND EPS PANEL
RENDERED EPS CLADDING PVC REVEAL BEAD
WINDOW JAMB WITH TRIM
SCALE 1:5
BREATH SARKING TO STUD WALL
RENDERED EPS CLADDING
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
10-8x100mm SCREWS WITH WASHERS
PVC REVEAL BEAD
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
BREATH SARKING TO STUD WALL
RENDERED EPS CLADDING
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
10-8x100mm SCREWS WITH WASHERS
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
PVC REVEAL BEAD WEEPHOLE ON BRICK
BRICK FLASHING WEEPHOLE ON BRICK
BREATHABLE SARKING
BEHIND EPS PANEL
RENDERED EPS CLADDING
PVC RENDER STARTER BEAD
PARGED TEXTURE
RENDER FINISH WITH SLOPING SURFACE
CLOSED CELL
POLYETHYLENE COMPRESSIBLE BACKING ROD INCLUDING EXTERNAL GRADE CAULKING SEALANT FALL
HEADER COURSE
MASONRY WALL
STUD WALL
HORIZONTAL BRICK JUNCTION
SCALE 1:5
BREATHABLE SARKING BEHIND EPS PANEL
INTERNAL LINING STUD WALL
RENDERED EPS PANEL
10-8x100mm SCREWS WITH WASHERS
SEAL CONTROL JOINT BETWEEN REVEAL BEAD AND BRICKWORK + VCUT INTO RENDER AND SEAL BEFORE PAINTING
EXTERNAL BRICKWORK
VERTICAL BRICK JUNCTION
SCALE 1:5
BREATHABLE SARKING TO WALL STUD
45MM TIMBER BATTENS
SEALANT
100MM EPS CLADDING TEXTURED COATING
SEAL CONTROL JOINT
BETWEEN REVEAL BEAD AND BRICKWORK + VCUT INTO RENDER AND SEAL BEFORE PAINTING
BACKING ROD
HEADER COURSE
MASONRY WALL
STUD WALL
FLUSHED WITH BRICK - HORIZONTAL JUNCTION SCALE
BREATHABLE SARKING TO STUD WALL
INTERNAL LINING STUD WALL
45mm TIMBER BATTENS
RENDERED EPS PANEL
SEAL CONTROL JOINT
BETWEEN REVEAL BEAD AND BRICKWORK + VCUT INTO RENDER AND SEAL BEFORE PAINTING 8-10mm GAP
EXTERNAL BRICKWORK EPS
SCALE 1:5
1:5
INTERNAL LINING
STUD WALL
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
JAMES HARDIE 75X75 COLORBOND CORNER FLASING
2.8x40mm FIBRE CEMENT NAIL
LINEA WEATHERBOARD CLADDING
45 x 42mm LOSP TRIM
BREATHABLE SARKING TO STUD WALL
INTERNAL CORNER
SCALE 1:5
BREATHABLE SARKING TO STUD WALL
JAMES HARDIE 75X75 COLORBOND CORNER FLASHING DETAIL:
LOSP TRIM
INTERNAL LINING
STUD WALL
90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.
LINEA WEATHERBOARD CLADDING FIXED TO BATTEN
2.8x40mm FIBRE CEMENT NAIL
EXTERNAL CORNER
SCALE 1:5
90x42
BREATH SARKING TO STUD WALL
LINEA WEATHERBOARD CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
STARTER STRIP
CORROSION RESISTANT FLASHING
90x42mm LOSP TRIM
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
CAULKING
A&L FLASHING TO WINDOW
90x42mm LOSP TRIM
LINEA WEATHERBOARD CLADDING FIXED TO BATTEN
WINDOW HEAD & SILL WITH TRIM
SCALE 1:5
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
INTERNAL LINING
BREATHABLE SARKING TO STUD WALL
90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX.
'LINEA' WEATHERBOARD CLADDING
90x42 LOSP TRIM
WINDOW JAMB WITH TRIM
SCALE 1:5
CAULKING
BREATH
LINEA
90
VISCOURSE
CORROSION
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
BREATH SARKING TO STUD WALL
LINEA
90
VISCOURSE
CORROSION
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
90x42mm
BREATHABLE SARKING
90
90 x 35 MGP10
BREATHABLE SARKING TO STUD WALL
INTERNAL LINING
HEADER
'LINEA' WEATHERBOARD CLADDING
CAULKING TO JUNCTION
42x42mm LOSP TRIM
EXTERNAL BRICKWORK
VERTICAL BRICK JUNCTION
SCALE
BREATHABLE SARKING TO STUD WALL
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
LINEA
HEADER COURSE
RENDERED MASONRY WALL
STUD WALL
HARDIEFLEX CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
90x18mm LOSP TRIM
CAULKING TO JUNCTION
BREATH SARKING TO STUD WALL
LINEA WEATHERBOARD CLADDING FIXED TO BATTEN
VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632
BREATHABLE SARKING TO
INTERNAL LINING
STUD WALL
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
NAIL FOR BATTEN FIXING
JAMES HARDIE 75X75 COLORBOND CORNER FLASING
2.8x40mm FIBRE CEMENT NAIL
CAULKING TO JUNCTIONS
42x42 LOSP TRIM TO INTERNAL CORNER
'NEWPORT' WEATHERBOARD CLADDING
BREATHABLE SARKING TO STUD WALL
INTERNAL CORNER
SCALE 1:5
JAMES HARDIE 75X75 COLORBOND CORNER FLASHING
CAULKING TO JUNCTION
90x42 LOSP CORNER TRIM
NOTE: HANG CORNER STOP OUT BY 40mm
INTERNAL LINING
STUD WALL
90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.
'NEWPORT' WEATHERBOARD CLADDING FIXED TO BATTEN
2.8x40mm FIBRE CEMENT NAIL
CAULKING TO JUNCTION
EXTERNAL CORNER
SCALE 1:5
BREATH SARKING TO STUD WALL
'NEWPORT' WEATHERBOARD CLADDING
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
90x42mm LOSP TRIM
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CORROSION RESISTANT FLASHING
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES;
70mm STUD - 143mm
90mm STUD - 163mm
CONTINUOUS BEAD OF SEALANT
A&L FLASHING TO WINDOW
90x42mm LOSP TRIM
90x35mm MGP10 TIMBER BATTENS @ 600 CTRS MAX.
BREATHABLE SARKING TO STUD WALL
WINDOW HEAD & SILL WITH TRIM SCALE 1:5
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
'NEWPORT' WEATHERBOARD CLADDING INTERNAL LINING
'NEWPORT' WEATHERBOARD CLADDING
CAULKING TO JUNCTION
90x42 LOSP TRIM
WINDOW JAMB WITH TRIM
SCALE 1:5
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
Pty.Ltd.©
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
SECTION:
DETAIL:
BREATH SARKING TO STUD WALL
'NEWPORT' WEATHERBOARD CLADDING
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
LOSP TRIM
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
CORROSION RESISTANT FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm
90mm STUD - 163mm
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
BRICK FLASHING
WEEPHOLE ON BRICK
SCALE 1:5
BREATH SARKING TO STUD WALL
'NEWPORT' WEATHERBOARD CLADDING
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
90x42mm LOSP TRIM
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
CORROSION RESISTANT FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
FACTORY FITTED PACKING
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
WEEPHOLE ON BRICK
BRICK FLASHING
BRICK HEADER COURSE UNDER WINDOW WINDOW ABOVE BRICKWORK
SCALE 1:5
90x42mm
90
BREATHABLE SARKING TO STUD WALL
2.8x40mm FIBRE CEMENT NAIL
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
BREATHABLE SARKING TO STUD WALL
INTERNAL LINING STUD WALL
HEADER COURSE
'NEWPORT' WEATHERBOARD CLADDING CAULKING TO JUNCTION
42x42mm LOSP TRIM
EXTERNAL BRICKWORK
VERTICAL BRICK JUNCTION
90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX.
BREATHABLE SARKING TO STUD WALL
2.8x40mm FIBRE CEMENT NAIL
RENDERED
INTERNAL LINING
STUD WALL
BREATHABLE SARKING TO STUD WALL
JAMES HARDIE 75X75 COLORBOND CORNER FLASHING
90x42 LOSP CORNER TRIMS
90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.
'STRIA' WEATHERBOARD CLADDING FIXED TO BATTEN
2.8x40mm FIBRE CEMENT NAIL
CAULKING TO JUNCTION
EXTERNAL CORNER
SCALE 1:5
STUD WALL
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
2.8x40mm FIBRE CEMENT NAIL
JAMES HARDIE 75X75 COLORBOND CORNER FLASING
INTERNAL LINING 42x42mm LOSP TO CORNER
APPLY CONTINUOUS BEAD OF JAMES HARDIE SEALANT TO INTERNAL CORNERS
STRIA CLADDING FIXED TO BATTEN
BREATH SARKING TO STUD WALL
INTERNAL CORNER
SCALE 1:5
BREATH SARKING TO OUTSIDE OF BATTEN
STRIA CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING WITH BITUMEN TAPE
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP TRIM
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
A&L FLASHING TO WINDOW
42x42mm LOSP TRIM
STRIA CLADDING FIXED TO BATTEN
WINDOW HEAD & SILL WITH TRIM
SCALE 1:5
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING
INTERNAL LINING
NAIL FOR BATTEN FIXING
90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX.
BREATHABLE SARKING TO STUD WALL
STRIA CLADDING
42x42mm LOSP TRIM
WINDOW JAMB WITH TRIM
SCALE 1:5
ORBIT HOMES AUSTRALIA PTY. LTD.
286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
SECTION:
DETAIL:
CAULKING
BREATH SARKING TO STUD WALL
STRIA CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT
42x42mm LOSP TRIM
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
FACTORY FITTED PACKING
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
BRICK FLASHING
WEEPHOLE ON BRICK
BRICK HEADER COURSE UNDER WINDOW WINDOW ABOVE RENDERED BRICKWORK SCALE 1:5
BREATH SARKING TO STUD WALL
STRIA CLADDING FIXED TO BATTEN
90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.
VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER
CONTINUOUS BEAD OF JAMES
LOSP TRIM
NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE
WINDOW HEADER FLASHING
NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm
FACTORY FITTED PACKING
BRICK HEADER COURSE UNDER WINDOW
10mm CLEARANCE BETWEEN FRAME AND SILL
SECONDARY FLASHING AS PER WINDOW MANUFACTURER
WEEPHOLE ON BRICK
BRICK FLASHING WINDOW ABOVE BRICKWORK SCALE 1:5
42x42mm
HARDIE JOINT SEALANT
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
BREATHABLE SARKING TO STUD WALL
STRIA CLADDING
CAULKING TO JUNCTION
90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.
BREATH SARKING TO STUD WALL
INTERNAL LINING
STUD WALL
HEADER COURSE
STRIA CLADDING FIXED TO BATTEN
CAULKING TO JUNCTION 42x42mm LOSP TO CORNER
EXTERNAL BRICKWORK
VERTICAL BRICK JUNCTION
SCALE 1:5
90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.
BREATHABLE SARKING TO STUD WALL
STRIA CLADDING
CAULKING TO JUNCTION
HEADER COURSE
RENDERED MASONRY WALL
STUD WALL
HORIZONTAL BRICK JUNCTION
SCALE 1:5
HORIZONTAL BRICK JUNCTION
SCALE 1:5
SCALE 1:10
TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au
INLET FROM DOWNPIPE 100MM PVC
NOTE: INLET SIDE MAY BE INTERCHANGEABLE
2NO. WATER POINTS FOR MAINS BACKUP
EXTERNAL GPO FOR PUMP CONNECTION
TANK ON SLAB (900MM WIDE) 100MM ABOVE HOUSE REBATE
OVERFLOW TO STORMWATER
STEEL WATER TANK SETUP - SUBMERSIBLE PUMP
(2000L SLIMLINE) - W 700MM X L 1700MM X H 1860MM SCALE 1:25
Slimline with Submersible Pump 1150W x 2600L x 1860H
CLEARANCE FROM ANY DOOR, OPENABLE WINDOW, MECHANICAL
ROUGH IN SLIMLINE AND MODLINE TANK
LINTEL ABOVE METER BOX
ELECTRICAL RUN-IN TO HOME
ELECTRICAL METER BOX (LOCATION AS PER PLANS)
ELECTRICAL RUN-IN TO METER BOX
MIN. CLEARANCE FROM GAS METER TO BOTTOM OF METER BOX
GAS METER (LOCATION AS PER PLANS)
GAS SERVICE INLET TO HOME (RHS OF ELECTRICAL METERING) TO ENTER FRAME ABOVE BOTTOM PLATE
GAS RUN-IN TO METER
