D E TA I L S G U I D E

DETAIL BOOK TABLE OF CONTENTS SECTION A - TYPICAL SECTIONS A1 - 450 EAVE A2 - NO EAVE A3 - DOUBLE STOREY - 450 EAVE A4 - D/S - LIGHTWIEGHT - NO EAVE A5 - DOWNPIPES NOT STEP AT BRICKWORK A6 - TYPICAL WALL SECTION - 450 EAVE LINEA A7 - 450 EAVE - CONDENSATION MANAGEMENT

E8 - INFILL ABOVE OPENING - NO EAVE - 2590 CEILING E9 - NO INFILL - 450 EAVE - 2440 CEILING E10 - TRIMS TO INFILL E11 - SQUARE SET WITH OVERHEAD CAB ABOVE E12 - SKYLIGHT SHAFT SECTION E13 - SKYLIGHT CROSS SECTION E14 - HEBEL WINDOW DETAILS E15 - BOUTIQUE WINDOW CAULKING AGAINST LINEA TRIM

SECTION B - FOOTING DETAILS B1 - TYPICAL EDGE BEAM (310 SLAB) B2 - TYPICAL EDGE BEAM (385 SLAB) B3 - TYPICAL EDGE BEAM (460 SLAB) B4 - STEPDOWN TO OUTDOOR LIVING (310 SLAB) B5 - STEPDOWN TO OUTDOOR LIVING (385 SLAB) B6 - STEPDOWN TO OUTDOOR LIVING (460 SLAB) B7 - GARAGE FOOTING B8 - HWS PAD DETAIL B9 - REBATED THRESHOLD ENTRY B10 - 86mm GARAGE STEPDOWN B11 - 344mm GARAGE STEPDOWN B12 - 514mm GARAGE STEPDOWN B13 - RECESSED SLIDING DOOR - NO OUTDOOR LIVING B14 - RECESSED SLIDING DOOR - LEVEL THRESHOLD

SECTION F - GARAGE DETAILS F1a - GARAGE DOOR PARAPET - TIMBER F1b - GARAGE DOOR PARAPET - STEEL F2 - GARAGE DOOR SECTION - 450 EAVE - 2440 CEILING F3 - GARAGE DOOR SECTION - BRICK ABOVE - 450 EAVE F4 - GARAGE DOOR SECTION - FC INFILL - 450 EAVE F5 - GARAGE DOOR SECTION - EPS F6 - GARAGE DOOR PARAPET - BOX GUTTER F7 - TRAY DECK ROOF OVER GARAGE F8 - GARAGE STEPDOWN CEILING F9 - GARAGE OFFSET VALLEY

SECTION D - FACADE DETAILS D1 - RAISED PORCH ABOVE INFILL D2 - BRICK PIER - RENDERED EPS CAPPING & PART. EXPOSED POST D3 - BRICK PIER - RENDERED FEAT. MOULDING & PART. EXPOSED POST D4 - HEBEL PIER D5 - EXPOSED POST STIRRUP DETAIL D6 - PROVINCIAL PIER DETAIL D7 - PROVINCIAL BALCONY BRICK INFILL D8 - NOVA SUMP/DOWNPIPE D9 - NOVA - PORCH CANOPY EXTENSION D10 - NOVA - PORCH ROOF PLAN D11 - NOVA - REAR WALL DETAIL D12 - NOVA - ROOF PARTITION WALL DETAIL D13 - BRIDGEHAMPTON - 'AIRE' 3-RAIL BALUSTRADE D14 - EXT. WALL TILING >2.7M (UNDER EAVE WALL TILING) D15 - EXTERNAL WALL TILING >2.7M (EXPOSED WALLTILING) D16 - "MODERN" EXTERNAL WALL TILING >2.7M - UNDER EAVE TILING D17 - "OTWAY" CORNER SUMP DETAIL

SECTION H - WET AREA DETAILS H1 - REMOVED H2 - REMOVED H3 - BATH HOB DETAILS (CLASSIC) H4 - BATH HOB DETAILS (PREMIUM) H5 - BATH HOB WATERSTOP H6 - SHOWER BASE - WITH HOB H7 - SHOWER BASE - 10mm RECESSED H8 - SHOWER BASE - 5mm RECESSED NCC2022 H9 - REMOVED H10 - SHOWER NICHE H10.b - SHOWER NICHE - 600 WIDE H11 - SHOWER NICHE - EXTERNAL WALL H12 - 1200 HIGH TILED WALL H13 - SHAVING CABINET H14 - WALL MOUNTED BASIN MIXERS (ABOVE COUNTER & INSET H15 - LAUNDRY CABINET CUTOUT H16 - EXTENDED BENCH OVER BATH H17 - SHOWER WINDOW DETAIL H18 - BATH HOB WATERSTOP ALTERNATIVE SOLUTION H19 - SHOWER HOB DETAIL LEVEL THRESHOLD H22 - TYPICAL TILED SHOWER SEAT DETAIL H23 - BUTT JOINTED CEILING FULL HEIGHT TILE SECTION I - CLADDING DETAILS I0 - FEATURE MOULDINGS CROSS REFERENCE TABLE I1 - AXON CLADDING DETAILS I2 - FINE TEXTURE CLADDING DETAILS I3 - EPS CLADDING DETAILS I4 - LINEA CLADDING DETAILS I5 - LINEA TO HARDIEFLEX DETAIL I6 - NEWPORT CLADDING DETAILS I7 - STRIA CLADDING DETAILS I8 - HARDIE FLEX CLADDING DETAILS I9 - MATRIX CLADDING DETAILS I10 - OBLIQUE CLADDING DETAILS I11 - 'INSTYLE CLASSIC' SHIPLAP DETAILS I12 - PERMATIMBER CLADDING DETAILS I13 - NATIONAL TILES 'NATURA' STONE EXTERNAL CLADDING I14 - 'DECOBATTEN' 40mm BATTEN CLADDING SECTION J - STAIRCASE DETAILS J1 - GENERAL STAIRCASE DETAILS SECTION K - SITE K1 - WATER TANK (POLY) K2 - WATER TANK (STEEL) K3 - GAS METER CLEARANCES K4 - WATER TANK ROUGH IN K5 - SERVICES RUN-IN LOCATIONS (AT METERING)

SECTION E - WINDOW DETAILS E1 - WINDOW WITH NO BOTTOM REVEAL E2 - TYPICAL FACE BRICK SILL E3 - TYPICAL RENDERED BRICK SILL E4 - TYPICAL BRICKWORK ABOVE OPENING E5 - BRICKWORK ABOVE OPENING - NO EAVE E6 - INFILL ABOVE OPENING - 450 EAVE E7 - INFILL ABOVE OPENING - NO EAVE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

TABLE OF CONTENTS

DATE ISSUED:

20/08/2026

0 - TOC SHEET:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SECTION C - GENERAL DETAILS C1 - ROOF / LIGHTWEIGHT CLADDING C2 - DADO RAIL C3 - BULKHEAD ABOVE O.H C3.b - BULKHEAD ABOVE O.H WITH COFFERED CEILING C4 - GUTTER ON BRICKWORK C5 - PLASTER LINED MDF BULKHEAD C6 - PLASTERBOARD EXPANSION JOINT C7 - CANOPY FLASHING C8 - PITCHED ROOF RIDGE VENTILATION C9 - TYPICAL DOOR JAMB C10 - TYPICAL PARAPET DETAIL C11 - TYPICAL PARAPET WITH BOX GUTTER DETAIL C12 - FEATURE BULKHEAD - COFFERED CEILING C13 - BALCONY FLOOR WASTE DETAIL C14 - SALES OFFICE SPLIT JAMB DETAIL C15 - RETAINING WALL DETAIL - ≤400 C16 - RETAINING WALL DETAIL - 400-800 C17 - RAINHEAD DETAIL C18 - BAL12.5 PORTICO PIER DETAIL C19 - LAUNDRY CHUTE DETAIL C20 - BALCONY FLOOR DETAIL C21 - BALCONY WATERPROOFING DETAIL (INT WALL HEBEL) C22 - BALCONY WATERPROOFING DETAIL (EXTERNAL FACE) C23 - BALCONY WATERPROOFING DETAIL (INT WALL CLADDING) C24 - BARN DOOR DETAILS C25 - CONDENSATION MANAGEMENT - 0-10º SKILLION ROOF HIGH LEVEL VENTILATION C26 - NCC RAMP 86MM SLAB STEPDOWN C27 - NCC RAMP 172MM SLAB STEPDOWN C28 - NCC STEP-FREE THRESHOLD C29 - BRICK PIER RAKED RENDER CAPPING C30 - DROPPED CEILING OVER KITCHEN ISLAND C31 - INTERNAL ARCHED PLASTER OPENINGS C32 - WINDOW FALL GUARD - 3 RAIL C35 - FEATURE WALL PANEL A C36 - FEATURE WALL PANEL B C37 - FEATURE WALL PANEL C C38 - STONE CLADDING A (INSTALLATION) C39 - STONE CLADDING B (HALF HEIGHT PIER C40 - HEATING & COOLING - LINEAR GRILL BULKHEADS C41 - TRAY DECK OVER GARAGE

SECTION G - OUTDOOR LIVING DETAILS G1 - INFILL ABOVE OL OPENING G2 - BRICKWORK ABOVE OL OPENING G3 - REMOVED G4 - REMOVED G5 - OL BEAM - WITH BH G6 - OL BEAM G7 - OL BEAM - ROOM ABOVE WITH BH G8 - REMOVED G9 - BOUTIQUE ENTERTAINER SLIDING DOOR DETAIL G10 - OL BEAM - CONCEALED WITHIN FLOOR ABOVE G11 - TILING TO OL FLOOR

UNDER EAVE WINDOW REVEAL HEAD HEIGHTS 2590MM = 2310MM 2740MM = 2460MM REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

600 450

ROOF TRUSSES TRUSS MANUFACTURERS SPECIFICATIONS

GROUND FLOOR CEILING LEVEL

90x35 MGP10 EAVE DROPPER

PLASTER CORNICE

CEILING INSULATION AS PER SPECIFICATIONS

COLORBOND STEEL FASCIA

4.5MM FC SHEET EAVE LINING

19mm TRIM

TOP PLATE

TRIMMERS@ 1200 CTS

2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING

NOGGIN

WALL TIES MAX 400MM SPACINGS (4 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD INSULATION BATTS AS PER SPECIFICATION

BOTTOM PLATE

MDF SKIRTING BOARD GROUND FLOOR

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

A1 - TYPICAL WALL SECTION, 450 EAVE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

A - TYPICAL SECTIONS

DETAIL:

TYPICAL WALL SECTION 450 EAVE (NCC2025)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

GROUND FLOOR CEILING LEVEL COLORBOND STEEL FASCIA PLASTER CORNICE

CEILING INSULATION AS PER SPECIFICATIONS TOP PLATE

2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING

WALL TIES AS PER AS2699.1

WALL TIES MAX 400MM SPACINGS (4 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD

NOGGIN

INSULATION BATTS AS PER SPECIFICATION

BOTTOM PLATE

MDF SKIRTING BOARD GROUND FLOOR

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

A2 - TYPICAL WALL SECTION, NO EAVE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

A - TYPICAL SECTIONS

DETAIL:

SHEET:

TYPICAL WALL SECTION - NO A2 EAVE (NCC2025) AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

535

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

FIRST FLOOR CEILING LEVEL

70X35 CASTELLATED STRUCTURAL BATTEN

PLASTER CORNICE

CEILING INSULATION AS PER SPECIFICATIONS

COLORBOND FASCIA

TOP PLATE

NCC2025 PART10.8 VENTILATED WALL CAVITY ACHIEVING MINIMUM FREE AREA OF NOT LESS THAN 1000MM2/M DISCHARGING TO ATMOSPHERE VIA VENTILATED ROOF SPACE

SISALATION TO OUTSIDE FRAME

25MM TOP HAT TO BE INSTALLED MAX 250MM FROM TOP AND BOTTOM OF PANEL, FIXINGS AS PER MANUFACTURER

INSULATION BATTS AS PER SPECIFICATION

75MM EPS WALL CLADDING

NCC2025 MIN 10MM AIR GAP FROM BASE OF CLADDING TO TRANSFER FLASHING ACHEIVING A MINIMUM FREE AREA VENTILATION OF NOT LESS THAN 1000MM2/M

NCC2025 TRANSFER FLASHING TO BE MIN 1MM OFF FACE BRICK ACHEIVING MINIMUM FREE AREA VENTILATION OF NOT LESS THAN 1000MM2/M

CHIPBOARRD FLOORING

COLORBOND CAPPING AND FLASHING WIN MIN. 1:200 FALL FIRST FLOOR

Min

UPPER FLOOR JOISTS AS PER SPECIFICATION

1mm

GROUND FLOOR CEILING LEVEL

2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE WALL TIES MAX 400MM SPACINGS (4 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD

10mm PLASTER

WALL TIES AS PER AS2699.1

NCC2025 PART 10.8 VENTILATED WALL CAVITY ACHIEVING MINIMUM FREE AREA OF NOT LESS THAN 1000MM2/M

NOGGING

WEEP HOLES INSTALLED AT EVERY SECOND BRICK

BOTTOM PLATE

SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING MDF SKIRTING BOARD GROUND FLOOR

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES

A3 - TYPICAL WALL SECTION EPS (75mm), 450mm EAVE (NCC2025) SCALE 1:20

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

A - TYPICAL SECTIONS

TYPICAL WALL SECTION DOUBLE STOREY - 450 EAVE AMENDMENT AMM #: TYPE: (NCC2025) DRAWN:

SHEET:

A3 DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

FIRST FLOOR CEILING LEVEL COLORBOND STEEL FASCIA PLASTER CORNICE

NCC2025 PART10.8 VENTILATED WALL CAVITY ACHIEVING MINIMUM FREE AREA OF NOT LESS THAN 1000MM2/M DISCHARGING TO ATMOSPHERE VIA VENTILATED ROOF SPACE

CEILING INSULATION AS PER SPECIFICATIONS 90x45 MGP10 TOP PLATE

REFER TO ELEVATION TO WALL CLADDING MATERIAL

INSULATION FOIL TO OUTSIDE OF BATTENS INSULATION BATTS AS PER SPECIFICATION

VERTICAL BATTENS NOGGING

NCC2025 MIN. 10MM AIR GAP FROM BASE OF CLADDING TO TRANSFER FLASHING ACHEIVING A MINIMUM FREE AREA VENTILATION OF NOT LESS THAN 1000MM2/M CHIPBOARRD FLOORING

FIRST FLOOR

NCC2025 TRANSFER FLASHING TO BE MIN 1MM OFF FACE BRICK ACHEIVING MINIMUM FREE AREA VENTILATION OF NOT LESS THAN 1000MM2/M GROUND FLOOR CEILING LEVEL

Min

UPPER FLOOR JOISTS AS PER SPECIFICATION

1mm

2NO. WALL TIES AT TOP WITHIN 300MM MAX OF TOP BRICK COURSE BREATHABLE SARKING INSTALLED OVER DAMP PROOF COURSE FLASHING 10mm PLASTER

WALL TIES MAX 600MM SPACINGS (7 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD

NCC2025 PART 10.8 VENTILATED WALL CAVITY ACHIEVING MINIMUM FREE AREA OF NOT LESS THAN 1000MM2/M

NOGGING

WEEP HOLES INSTALLED AT EVERY SECOND BRICK

90x45 MGP10 BOTTOM PLATE

MDF SKIRTING BOARD GROUND FLOOR

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER

A4 - TYPICAL WALL SECTION (NCC2025) SCALE 1:20 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

A - TYPICAL SECTIONS

TYPICAL WALL SECTION DOUBLE STOREY - NO EAVE AMENDMENT AMM #: TYPE: (NCC2025) DRAWN:

SHEET:

A4 DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

FIRST FLOOR CEILING LEVEL COLORBOND STEEL FASCIA

DOWNPIPE FIXED TO POP

14 8

.0 45

APPROX 450 TRANSITION FIRST FLOOR

FIRST CLIP

GROUND FLOOR CEILING LEVEL

A5 - DETAIL DOWNPIPES NOT STEP AT BRICKWORK

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

A - TYPICAL SECTIONS

DETAIL:

DOWNPIPES NOT STEP AT BRICKWORK

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

ROOF TRUSSES @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS

490 REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH CEILING LEVEL

CEILING INSULATION AS PER SPECIFICATIONS PLASTER CORNICE 19MM TRIM

TOP PLATE

INSULATION FOIL TO OUTSIDE OF FRAME INSULATION BATTS AS PER SPECIFICATION LINEA WEATHERBOARD ON TIMBER BATTENS

10mm PLASTER

BREATHABLE SARKING INSTALLED OVER DAMP PROOF COURSE FLASHING

WALL TIES MAX 600MM SPACINGS (7 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD

NOGGING

BOTTOM PLATE MDF SKIRTING BOARD

WAFFLE POD SLAB TO ENGINEER'S DESIGN

FLOOR LEVEL

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES PLASTIC MEMBRANE TURNED OVER SLAB REBATE

A6 - TYPICAL WALL SECTION (LINEA CLADDING - 450 EAVE)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

A - TYPICAL SECTIONS

TYPICAL WALL SECTION 450 EAVE LINEA (NCC2025)

DATE ISSUED:

SHEET:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

COR-VENT FIXED OVER FIRST BATTEN TO PERIMITER OF ROOF WHERE REQUIRED IN BUISHFIRE ZONES STAINLESS STEEL EMBER MESH WITH APERTURE LESS THAN 2.0MM MEETS COMPLIANCE WITH AS3959.

SARKING OVER ROOF BATTEN & COR-VENT CL

600 450

ROOF TRUSSES TRUSS MANUFACTURERS SPECIFICATIONS

GROUND FLOOR CEILING LEVEL

PLASTER CORNICE

CEILING INSULATION AS PER SPECIFICATIONS TOP PLATE 19MM QUAD

COLORBOND STEEL FASCIA

90x35 MGP10 EAVE DROPPER

4.5MM FC SHEET EAVE LINING TRIMMERS@ 1200 CTS

A7 - TYPICAL 450 EAVE - CONDENSATION MANAGEMENT (COR-VENT)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

A - TYPICAL SECTIONS

TYPICAL WALL SECTION 450 EAVE CONDENSATION

DATE ISSUED:

SHEET:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING

120

PLASTIC MEMBRANE TO BE TURNED OVER SLAB REBATE

310

190

BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT

NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)

GROUND FLOOR

B1 - TYPICAL EDGE BEAM 310mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

B - FOOTING DETAILS

TYPICAL EDGE BEAM SECTION (310mm)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER

WEEPHOLE

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

195

300

BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT

385

190

NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)

GROUND FLOOR

B2 - TYPICAL EDGE BEAM 385mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

B - FOOTING DETAILS

TYPICAL EDGE BEAM SECTION (385mm)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

BREATHABLE SISALATION INSTALLED OVER DAMP PROOF COURSE FLASHING DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

150

460

BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT

310

NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED)

WEEPHOLE GROUND FLOOR

B3 - TYPICAL EDGE BEAM 460mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

B - FOOTING DETAILS

TYPICAL EDGE BEAM SECTION (460mm)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES

WEEPHOLE

PLAIN CONCRETE SLAB FINISH TO EXTERNAL AREA

225

310

190

FL INSIDE DWELLING

B4 - TYPICAL O.LIVING FOR 310mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

B - FOOTING DETAILS

DETAIL:

STEPDOWN TO OUTDOOR LIVING SLAB (310mm)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WEEPHOLE

PLAIN CONCRETE SLAB FINISH TO EXTERNAL AREA

300

385

190

FL INSIDE DWELLING

B5 - TYPICAL O.LIVING FOR 385mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

B - FOOTING DETAILS

DETAIL:

STEPDOWN TO OUTDOOR LIVING SLAB (385mm)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES

WEEPHOLE

PLAIN CONCRETE SLAB FINISH TO EXTERNAL AREA

460

375

FL INSIDE DWELLING

B6 - TYPICAL O.LIVING FOR 460mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

B - FOOTING DETAILS

DETAIL:

STEPDOWN TO OUTDOOR LIVING SLAB (460mm)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

GARAGE DOOR TO CLOSE ONTO DRIVEWAY

LINE OF REBATE BEYOND

30 MIN.

150

20 MIN.

FINISHED DRIVEWAY LEVEL TO BE 50mm BELOW GARAGE FL

PROVIDE GRADE BEHIND GARAGE REBATE

230 305

SLAB MEMBRANE

EXPANSION FOAM TO BE INSTALLED PRIOR TO DRIVEWAY INSTALLATION CONCRETE SLAB AS PER ENGINEER'S DESIGN

B7 - GARAGE FOOTING DETAIL SECTION VIEW SCALE 1:10

230

GARAGE DOOR WIDTH AS PER PLAN

REBATE

BRICK 110 120 75

230

REBATE

GARAGE REBATE INCREASED AROUND GARAGE DOOR AS DIMENSIONED. PROVIDE GRADE BEHIND GARAGE REBATE AS SHOWN IN SECTION VIEW

B7 - GARAGE FOOTING DETAIL PLAN VIEW SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

B - FOOTING DETAILS

GARAGE FOOTING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

50mm REBATE FROM FINISHED SLAB LEVEL

BREATHABLE SARKING INSTALLED OVER DAMP PROOF COURSE FLASHING DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WITH TERMITE BARRIER NOTE: CONCRETE PAD FOR HWS TO BE 100MM LOWER THAN FFL NOTE: MIN. 75MM BETWEEN BOTTOM OF WEEPHOLE AND ANY PAVING (IF REQUESTED) WEEPHOLE DWELLING FLOOR

85 300

CONCRETE PAD FOR HWS

100

GROUND FLOOR

600

PLASTIC MEMBRANE TURNED OVER SLAB REBATE

385

BACKFILL AGAINST SLAB TO MATCH REBATE HEIGHT

150

B8 - HWS PAD DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

B - FOOTING DETAILS

HWS PAD DETAIL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

TIMBER ENTRY FRAME CANTILEVERED OVER REBATE AND FIXED TO FRAMING MEMBER, MAX 5MM THRESHOLD

METAL ANGLE FOR SILL SUPPORT BOLTED TO SLAB

ENTRY DOOR FRAME REBATED 35MM

SRAY ON TERMITE APPLICATION CONCRETE PAVING OVER INTEGRATED PORTICO SLAB, GRADED AT MAX 1:8

FL INSIDE DWELLING WITH SELECTED FLOOR COVERING

300

385

190

110

B9 - REBATED THRESHOLD ENTRY FOR 385mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

B - FOOTING DETAILS

DETAIL:

REBATED THRESHOLD ENTRY (385mm)

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

PLASTERBOARD

NOTCH OUT BOTOM PLATE TO CLEAR SLAB

SUPPORTING NOGGIN AS REQUIRED

70MM BOTTOM PLATE

FL INSIDE DWELLING

FL INSIDE GARAGE

B10 - TYPICAL GARAGE 86mm STEPDOWN

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

B - FOOTING DETAILS

GARAGE STEPDOWN (86mm)

DATE ISSUED:

SHEET:

B10

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

PLASTER CORNICE

MDF ARCHITRAVE

0 22

140

2590

0 80

NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN

140 X19 KDHW TIMBER TOP TREAD

110X19 HARDWOOD PLATE

290X45 KDHW STAINED TIMBER TREADS 140X19 KDHW STAINED TIMBER RISERS

MDF SKIRTING BOARD

140x45F17 TO FORM BASE, TO BE GLUED TO CONCRETE SLAB BELOW

B11 - GARAGE STEPDOWN 344MM

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

B - FOOTING DETAILS

GARAGE STEPDOWN (344mm)

DATE ISSUED:

SHEET:

B11

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

PLASTER CORNICE

MDF ARCHITRAVE

2590

0 80

0 22

140

0 44

NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN

140 X19 KDHW TIMBER TOP TREAD

110X19 HARDWOOD PLATE

290X45 KDHW STAINED TIMBER TREADS 140X19 KDHW STAINED TIMBER RISERS

MDF SKIRTING BOARD

B12 - GARAGE STEPDOWN 514MM

140x45F17 TO FORM BASE, TO BE GLUED TO CONCRETE SLAB BELOW

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

B - FOOTING DETAILS

GARAGE STEPDOWN (514mm)

DATE ISSUED:

SHEET:

B12

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

INTERNAL

EXTERNAL

NYLON PACKERS AS REQUIRED TO SUIT DOOR OPENING HEIGHT

BRICKWORK BEYOND FLASHING

FLOORING TO BE LAID FLUSH, OR MAX. 5mm BENEATH TOP OF ALUMINIUM SILL

REC.

127

MDF REVEAL TO BE CUT DOWN ON-SITE TO SUIT FLOOR COVERING LEVEL

REBATE

BRICKWORK BENEATH DOOR TO BE CUT ON EDGE TO FORM FLAT SILL

SLAB EDGE RECESS TO SUIT SLIDING DOOR

150

REC. REBATE

B13 - RECESSED SLIDING DOOR - NO OUTDOOR LIVING

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

B - FOOTING DETAILS

RECESSED SLIDING DOOR ENTERTAINER

DATE ISSUED:

SHEET:

B13

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

DOOR FRAME CANTILEVERED OVER REBATE AND FIXED TO FRAMING MEMBER, MAX 5MM THRESHOLD

DOOR FRAME REBATED 50MM

100mm WIDE STORMTECH 100TiTDiS THRESHOLD DRAIN

DOOR PACKING

CONCRETE PAVING

FL INSIDE DWELLING WITH SELECTED FLOOR COVERING

110

85 385

150

300

140

1:40 FALL IN PAVING

METAL ANGLE FOR SILL SUPPORT BOLTED TO SLAB

B14 - RECESSED SLIDING DOOR LEVEL THRESHOLD

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

B - FOOTING DETAILS

RECESSED SLIDING DOOR LEVEL THRESHOLD

DATE ISSUED:

SHEET:

B14

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

BREATHABLE SISALATION OVER LEAD FLASHING LIGHTWEIGHT CLADDING FIXED TO BATTEN BEHIND ACRYFLASH ROOF FLASHING

WALL INSULATION AS PER ENERGY RATE

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

BOTTOM PLATE MDF SKIRTING BOARD CHIPBOARD FLOORING FLOOR JOISTS

FULL TIMBER BLOCKING BOLTED TO STEEL BEAM WITH JOIST HANGER FOR JOIST FIXING

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

PLASTERBOARD CEILING BEAM AS PER ENGINEERS DESIGN

TIMBER BEAM FIXED TO STEEL WITH JOIST HANGER TO SUPPORT ROOF TRUSSES

C1 - ROOF/LIGHTWEIGHT CLAD DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

ROOF/LIGHTWEIGHT CLADDING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

NOGGING ON EDGE

PORTA 'VICTORIAN' DADO RAIL

JAMES HARDIE 'HARDIEGROOVE' DADO DIRECT FIX TO FRAME

1000

160

JAMES HARDIE 'HARDIEGROOVE' DADO DIRECT FIX TO FRAME

SKIRTING BOARD TO OUTSIDE OF DADO

C2 - ENTRY DADO PLAN VIEW

SECTION VIEW

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL SHEET:

ENTRY DADO

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

REFER TO INTERNAL ELEVATION FOR BULKHEAD HEIGHT

HEIGHT

PLASTER CORNICE FRAMING TO FORM BULKHEAD

WIDTH OF BULKHEAD TO ALIGN WITH ADJOINING WALL OR BENCH BELOW, WHICHEVER IS GREATER - REFER PLAN FOR EXTENT

40MM INFILL BY KITCHEN MANUFACTURER, TO MATCH CABINET COLOUR KITCHEN OVERHEAD CUPBOARDS

REFER TO INTERNAL ELEVATIONS FOR CUPBOARD HEIGHTS FROM FLOOR LEVEL

C3 - OVERHEAD CUPBOARD BULKHEAD DETAIL (IF REQUIRED)

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

C - GENERAL

DETAIL:

BULKHEAD ABOVE O.H

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

REFER TO INTERNAL ELEVATIONS FOR DETAILS

HEIGHT

METAL CAGE BY PLASTERER

200

PLASTER CORNICE

SQUARE SET CEILING 40

40MM INFILL BY KITCHEN MANUFACTURER

WIDTH OF BULKHEAD TO ALIGN WITH ADJOINING WALL OR AS PER DIMENSION NOMINATED ON INTERNAL ELEVATIONS KITCHEN OVERHEAD CUPBOARDS

NOTE : ONLY AVAILABLE WITH 2740MM HIGH CEILINGS NOTE : COFFERED CEILING HEIGHT TO MATCH BULKHEAD (200MM)

C3.b - OVERHEAD CUPBOARD BULKHEAD DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

BULKHEAD ABOVE O.H WITH COFFERED CEILING

SHEET:

C3.b

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

ROOF PITCH & MATERIAL TO MATCH ELEVATIONS GUTTER FIXED WITH A EXTERNAL GUTTER BRACKET "GP CLIP" AND SCREWED TO TRUSS

"Z" FLASHING OVER BATTERN TO BRICKWORK

A WALL MAY TERMINATE NOT MORE THAN 200mm MAX. FROM UNDERSIDE OF A NON-COMBUSTILBE ROOF COVERING. MUST BE SEALED WITH A NON-COMBUSTIBLE FASCIA, GUTTER OR FLASHING.

160

150

FLASHING DIMENSIONS C4 - GARAGE ON BOUNDARY/GUTTER ON BRICKWORK

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

GUTTER ON BRICKWORK

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

NOM

REFER TO INTERNAL ELEVATIONS FOR CUPBOARD HEIGHTS FROM FLOOR LEVEL

MDF BULKHEAD BY KITCHEN MANUFACTURER LINED WITH 10mm PLASTER 10mm PLASTERBOARD

OVERHEAD CUPBOARD

C5 - TYPICAL OVERHEAD CUPBOARD BULKHEAD DETAIL TO LAUNDRY

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

TYPICAL PLASTER LINED MDF BH TO LAUNDRY

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

DETAIL:

PLASTERBOARD EXPANSION JOINT

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

800mm MAX. BEAM TO ENGINEERS DESIGNS

FLASHING WITH FALL TO LOWER FLOOR KICK-OUT BELOW 18mm CHIPBOARD FLOORING BENEATH FLASHING, BATTEN AT UPPER FLOOR SIDE TO CREATE FALL @ MIN. 1°PITCH

3° PITCH

RAFTERS AS PER ENGINEERING DESIGN INSULATION PER ENERGY REPORT

10mm PLASTERBOARD LINING TO WALL AND CEILINGS

C7 - CANOPY FLASHING DETAILS

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

CANOPY FLASHING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

NOTE: 1. HIGH LEVEL VENTILATION SHOULD BE EVENLY DISTRIBUTED ALONG THE ROOF 2. WEATHERPROOFING OF SHEET ENDS TO BE MAINTAINED WHILE ALLOWING VENTILATION PATHWAY OF 5000mm²/m

Ridge Ventilation Notes SCALE 1 : 20

20 MIN.

VENTILATION GAP BETWEEN SHEETS AT RIDGE

ROOFING SHEETS TO BE UPTURNED AT EDGE BENEATH RIDGE CAPPING (REFER TO NOTE 2)

METAL RIDGE CAPPING (NOT SCRIBED) METAL ROOF SHEETING AND PITCH AS PER PLANS

SARKING/ROOF BLANKET

C8 - RIDGELINE VENTILATION - WITH SARKING SCALE 1:20

20 MIN.

VENTILATION GAP BETWEEN SHEETS AT RIDGE

ROOFING SHEETS TO BE UPTURNED AT EDGE BENEATH RIDGE CAPPING (REFER TO NOTE 2)

METAL RIDGE CAPPING (NOT SCRIBED) METAL ROOF SHEETING AND PITCH AS PER PLANS

C8 - RIDGELINE VENTILATION - WITHOUT SARKING

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

PITCHED ROOF RIDGE VENTILATION

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

2/90X35 STUDS

10MM PACKER

10MM PLASTER

110x18MM MDF JAMB 30x12MM DOOR STOP DOOR 67MM ARCHITRAVE

C9 - TYPICAL DOOR JAMB DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

TYPICAL DOOR JAMB

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

COLORBOND FLASHING TO TOP

BALTIC PINE WEATHERBOARD CAPPING FIXED OVER PARTICAL BOARD FLOORING TO GRADE BACK TO ROOF

MIN. 1:200 FALL

400 MAX HT

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

ROOF TRUSSES @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS

FACE BRICKWORK

WALL TIES AS PER AS2699.1

WALL TIES MAX 400MM SPACINGS (4 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD

PLASTER CORNICE

C10 - TYPICAL PARAPET DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

TYPICAL PARAPET

SHEET:

C10

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

COLORBOND FLASHING TO TOP OF PARAPET TO FALL BACK TO BOX GUTTER

19MM YELLOW TONGUE FLOORING TO INSIDE FACE MIN. 1:200 FALL

BALTIC PINE WEATHERBOARD CAPPING FIXED OVER PARTICAL BOARD FLOORING TO GRADE BACK TO ROOF

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

300 150

150

. MIN

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS FACE BRICKWORK

WALL TIES AS PER AS2699.1

WALL TIES MAX 400MM SPACINGS (4 COURSES). NOTE: AT INTERSECTING WALLS THE NUMBER OF TIES PROVIDED IS TO BE DOUBLED, I.E. EITHER SIDE OF STUD

TIMBER BLOCKING TO SUPPORT GUTTER BOARD PLASTER CORNICE

C11 - TYPICAL PARAPET WITH BOX GUTTER DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

SHEET:

TYPICAL PARAPET WITH BOX C11 GUTTER AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER PLANS

SQUARE SET CEILING METAL CAGE BY PLASTERER

160

LASER LEVEL & BATTEN

PLASTER SQUARE SET CEILING

C12 - FEATURE BULKHEAD - COFFERED CEILING (SQUARE SET) SCALE 1:10

CORNICE METAL CAGE BY PLASTERER

200

REFER PLANS

PLASTER SQUARE SET CEILING

C12 - FEATURE BULKHEAD - COFFERED CEILING

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

FEATURE BH - COFFERED CEILING

SHEET:

C12

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

90 HOLE TO SECURA FLOOR DRAIN BASE INSERT GROUT FLOOR TILES

SECONDARY COAT OF MEMBRANE ON TOP OF SCREED MORTAR BED WATERPROOF MEMBRANE

SCYON SECURA

NOTCH SECURA FLOOR AT FLANGE LOCATION PUDDLE FLANGE UNDERNEATH WATERPROOF MEMBRANE

BALCONY JOISTS

OUTLET TO DOWN PIPE

PORCH CEILING LINE

FLANGE FITTED OVER WASTE BELOW CEILING LINE

C13 - BALCONY FLOOR OVERFLOW POP DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

BALCONY FLOOR WASTE

SHEET:

C13

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

STUDS FRAMING 10MM PLASTER

SALES OFFICE SIDE MDF SPLIT JAMB PLASTERED OVER

DOOR

MDF DOOR STOP

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

SALES OFFICE - SPLIT JAMB DETAIL

SHEET:

C14

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

C14 - SALES OFFICE SPLIT JAMB DETAIL SCALE 1:5

SITE BOUNDARY

SIZE OF VERTICAL SOLDIERS AND MAX. CRS AS SPECIFIED IN TABLE

TIMBER SLEEPERS BUTT JOINTED ON CENTRE LINE

BUILDER TO PROVIDE A SAFE SOIL BATTER SLOPE DURING CONSTRUCTION (TO BE CONFIRMED WITH THE GEOTECHNICAL ENGINEER)

SPOON DRAIN (OR NATURAL SWALE) N.S.L

2 LAYERS OF 0.2mm POLYTHENE MEMBRANE TO BACK OF WALL FOR FULL HEIGHT. POLYTHENE MEMBRANE TO RUN DOWN BENEATH AG PIPE

REFER TABLE "H"

N.S.L

100⌀ AG DRAIN WRAPPED IN GEOTEXTILE FABRIC. CONNECTED TO LEGAL POINT OF DISCHARGE.

NOTE: WALL DESIGNED FOR MAX SURCHARGE LOAD OF 5.0kPa

100

15MPa CONCRETE FOOTING TO SOLDIERS INTO MIN. 100kPa BEARING CAPACITY SOIL. FOR MIN. FOOTING DEPTH REFER TO SCHEDULE

REFER TABLE "D"

GRANULAR COMPACTED FREE DRAINING MATERIAL OR NO FINES CONCRETE

REFER TABLE "W"

C15 - TYPICAL RETAINING WALL DETAIL - ≤ 400 HIGH SCALE 1:20

SOLDIER PILE AND SLEEPER RETAINING WALL TABLE RETAINING WALL HEIGHT 'H' (mm)

≤400

SOLDIER PILE SIZE MAX. SPACING OF SLEEPER SIZE FOOTING DEPTH FOOTING WIDTH AND GRADE SOLDIER POST (mm) AND GRADE 'D' (mm) 'W' (mm) 100x200 H4 TREATED F7 KD PINE 75x200 H4 TREATED F7 1800 1100 450⌀ OR 100 UC 15 KD PINE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

RETAINING WALL 0-400

SHEET:

C15

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

ALL STEEL WORK TO BE HOT DIP GALVANIZED

WHERE STEEL POSTS SUPPORTS FENCE OVER WALL TO BE CONSTRUCTED VERTICALLY

TIMBER SLEEPER. REFER SCHEDULE.

MOISTURE BARRIER TO BASE AND SIDES OF TRENCH EXCAVATION

VERTICAL OR OPTIONAL 5°

REFER TABLE "H"

BACKFILL WITH FREE DRAINAGE MATERIAL.

200

40-50mm CRUSHED ROCK FILTER. 200mm COVER ABOVE AGI DRAIN 90 DIA. AGI DRAIN TO BE INSTALLED NO HIGHER THAN LOWER FINISHED SURFACE LEVEL WITH A 1:100 MIN. FALL WRAP DRAIN IN GEOTEXTILE FABRIC TO PREVENT CLOGGING

REFER TABLE "D"

CRUSHED ROCK FILTER TO CONTINUE BETWEEN POSTS STEEL POST. REFER SCHEDULE.

150

20 MPa MASS CONCRETE FOOTING. REFER SCHEDULE FOR FOUNDING DEPTH.

REFER TABLE "W"

C16 - TYPICAL RETAINING WALL DETAIL - 400 - 800 HIGH SCALE 1:20

SLEEPER RETAINING WALL SCHEDULE - RETAINING FILL MAX. RETAINING WALL HEIGHT 'H' (mm)

UPRIGHT SIZE

MAX. SPACING OF SLEEPER SIZE UPRIGHT (mm) AND GRADE

PIER DEPTH PIER SIZE 'D' (mm) 'W' (mm)

DEPTH INTO ROCK

400

100 UC 14.8 (H.D GALV.)

2400

200x75 F5

1300

450⌀

N/A

600

100 UC 14.8 (H.D GALV.)

2400

200x75 F5

1500

450⌀

N/A

800

100 UC 14.8 (H.D GALV.)

1200

200x75 F5

1400

450⌀

N/A

SLEEPER RETAINING WALL SCHEDULE - RETAINING CUT UPRIGHT SIZE

MAX. SPACING OF SLEEPER SIZE UPRIGHT (mm) AND GRADE

400

100 UC 14.8 (H.D GALV.)

2400

200x75 F5

800

450⌀

N/A

600

100 UC 14.8 (H.D GALV.)

2400

200x75 F5

700

450⌀

N/A

800

100 UC 14.8 (H.D GALV.)

1200

200x75 F5

700

450⌀

N/A

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

DEPTH INTO ROCK

SECTION:

C - GENERAL

DETAIL:

RETAINING WALL 400 - 800

SHEET:

C16

AMENDMENT AMM #:

PIER DEPTH PIER SIZE 'D' (mm) 'W' (mm)

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

MAX. RETAINING WALL HEIGHT 'H' (mm)

FLAT BOTTOM RAIN HEAD WITH NED KELLY OVERFLOW

DOWNPIPE

AVAILABLE SIZES (mm) LENGTH

WIDTH

DEPTH

380

225

275

450

250

300

C17 - RAINHEAD DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

RAINHEAD DETAIL

SHEET:

C17

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS RAKED RENDER TO TOP OF PIER

TIMBER POST

RENDERED 100MM EPS TO TOP OF BRICKWORK, WITH 18º FALL TO COMPLY WITH BAL REQUIREMENT

700

18º FALL

RENDER TO FACE OF BRICK PIER

PAVING IF SPECIFIED

HOUSE FFL FOOTINGS TO ENGINEERS DESIGN

C18.1 - BAL 12.5 PORTICO PIER DETAIL (SOUTHAMPTON FACADE) SCALE 1:20

10MM 'ABLEFLEX' AROUND POST

NOM.

RAKED RENDER CAPPING TO TOP OF PIER AT MIN. 3° FALL TOWARDS OUTSIDE EDGES. NOTE: 18 DEGREE FALL REQUIRED IN BUSHFIRE ZONES CAVITY TO BE FILLED AND PACKED WITH EXPANDING FOAM

4.5mm FC SHEET LINING BELOW SECOND LAST BRICK COURSE, EMBEDDED INTO MORTAR BY MIN. 25mm TIMBER POST WITHIN PIER, AS PER ENGINEERING FACE/RENDER BRICKWORK TO PIER, AS PER PLANS

SCALE 1:20

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

BAL 12.5 PORTICO PIER DETAIL

SHEET:

C18

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

C18.2 - BRICK PIER WITH RAKED RENDER CAPPING

500

OPEN TO BELOW

400

DOOR

PLASTER FRONT PLASTER BALUSTRADE 1050MM FROM FFL

2040H DOOR FLUSH PANEL HINGED AND LACHED DOOR WITH ARCHITRAVES AND DUMMY SET HANDLE

C19 - LAUNDRY CHUTE SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

LAUNDRY CHUTE

DATE ISSUED:

C - GENERAL SHEET:

C19

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

1050

16MM MELAMINE CHUTE TO GROUND FLOOR

DOOR/WINDOW REVEAL

FC SHEET INFILL FIXED TO FRAME

TILED SKIRTING OVER WATERPROOF MEMBRANE CAULKED TO SUIT

190

COLORBOND FLASHING 120x100

EXTERNAL WATERPROOFING TO BE IN ACCORDANCE WITH AS 4654.1 & 2

EXTENT OF RENDERED EXTERNAL WALL CLADDING FRENCH DOOR FRAME INC 165MM REVEAL 90X45MM PINE PACKER

FALL MINIMUM 1:100

100 WATERPROOFING MEMBRANE AND RETURNED UP WALLS 100mm IN ACCORDANCE WITH AS 4654.1 - 2012

STEPDOWN TO BALCONY TO BE MINIMUM 50mm

90 165

C20 - BALCONY FLOOR DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

BALCONY FLOOR DETAIL

SHEET:

C20

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

BALCONY

DWELLING

EXTERNAL WATERPROOFING TO BE IN ACCORDANCE WITH AS 4654.1 & 2

RENDER FINISH APPLIED OVER WATERPROOFING MEMBRANE TO CLADDING

RENDERED LIGHTWEIGHT CLADDING FIXED ON 24MM TOP HATS

TILED SKIRT

STUD FRAME WITH SELECTED WALL BATTS

TILED FLOORING

SELECTED SKIRTING

WATERPROOFING MEMBRANE BENEATH AND ABOVE SCREED, AND RETURNED UP WALLS AND OVER BALCONY EDGE MIN. 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2

FALL MINIMUM 1:100

100

TILE SCREED

SELECTED FLOORING

BEAM AS PER ENGINEERING COLORBOND FLASHING 120 x 100

19MM 'SCYON SECURA' FLOORING

STEPDOWN TO BALCONY TO BE MINIMUM 50mm

C21 - BALCONY WATERPROOFING DETAIL - DWELLING WALL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

C - GENERAL

BALCONY WATERPROOFING (INTERNAL WALL - HEBEL)

DATE ISSUED:

SHEET:

C21

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

NOTE: HEIGHT OF HANDRAIL AROUND BALCONY TO BE 1000MM MIN ABOVE THE HIGHEST PART OF BALCONY FLOOR

FLOOR TILES TO BALCONY

WATERPROOFING MEMBRANE BENEATH AND ABOVE SCREED, AND RETURNED UP WALLS AND OVER BALCONY EDGE MIN. 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2

BALCONY

TILE SCREED TO FALL TOWARDS FLOOR WASTES IN THE CENTRE OF THE BALCONY 19MM 'SCYON SECURA' FLOORING

RENDERED BLUEBOARD TO TOP AND INSIDE FACE OF NIB WALL

140

3NO. 90X35MM TRIMMERS FOR BALUSTRADE FIXING

125

120MM X 100MM COLORBOND FLASHING

BALCONY JOIST LEVEL

NOM.

BALCONY JOISTS

2NO. 90 X 35MM PACKERS, ONE TO BE RIPPED DOWN TO SIZE RENDERED EPS DIRECT FIXED TO FACE OF BALCONY BEAM

PLASTER LINING FIXED TO PORCH 30mm DRIP EDGE 19 x 19mm TRIM

PORCH

PORCH/BALCONY POST (REFER TO PLANS)

C22 - BALCONY WATERPROOFING DETAIL - EXTERNAL FACE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

C - GENERAL

BALCONY WATERPROOFING DETAILS (EXTERNAL FACE)

DATE ISSUED:

SHEET:

C22

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

BALCONY

DWELLING

EXTERNAL WATERPROOFING TO BE IN ACCORDANCE WITH AS 4654.1 & 2

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

LINEA WEATHERBOARD CLADDING FIXED TO BATTEN

BREATH SARKING TO STUD WALL

75MM EPS WALL CLADDING WITH TEXTURED RENDER FINISH OVER WATERPROOF MEMBRANE

STUD FRAME WITH SELECTED WALL BATTS

TILED FLOORING

SELECTED SKIRTING

WATERPROOFING MEMBRANE BENEATH AND ABOVE SCREED, AND RETURNED UP WALLS AND OVER BALCONY EDGE MIN. 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2

FALL MINIMUM 1:100

SELECTED FLOORING

BEAM AS PER ENGINEERING

TILE SCREED

COLORBOND FLASHING 120 x 100

19MM 'SCYON SECURA' FLOORING

STEPDOWN TO BALCONY TO BE MINIMUM 50mm

C23 - BALCONY WATERPROOFING DETAIL - DWELLING WALL (WEATHERBOARD CLADDING)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

C - GENERAL

BALCONY WATERPROOFING (INT WALL - CLADDING)

DATE ISSUED:

SHEET:

C23

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

LINTEL SUPPORT FOR BARN DOOR TRACK 90X18 SOLID TIMBER MOUNTING BOARD

TRACK

105

CENTERLINE OF TRACK

FACE MOUNT ROLLER

HANGING DOOR PANEL

SQUARE SET TO OPENING

DOOR PANEL

67x18 ARCHITRAVE

GROOVED BOTTOM RAIL

FLOOR MOUNTED DOOR GUIDE

FFL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

C - GENERAL

BARN DOOR DETAILS

DATE ISSUED:

SHEET:

C24

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

C24 - BARN DOOR SECTION SCALE 1:5

BUILDING UNDERLAY BATTEN SELECTED CLADDING

ALUMINUM FLASHING OVER FASCIA VENT VENT SYSTEMS OVER FASCIA VENT - 62500N

VENT SYSTEMS - BV25 (>25000mm p/lm), 75mm FLASHING TAPE EACHSIDE WITH 30mm MESH CENTRE TERMINATE UNDERLAY AT TOP OF PURLIN

EXTRA 10mm REQUIRED FOR FIXING, OR FIX ROOFING AND FLASHING INDIVIDUALLY 100

FOAM CLOSER BENEATH FLASHING

40 MIN.

ALUMINIUM FLASHING DRESSED DOWN OR NOTCHED REFER TO ELEVATIONS FOR ROOF MATERIAL AND PITCH ROOFING UNDERLAY

25 MIN.

C25 - CONDENSATION MANAGEMENT 0-10º SKILLION ROOF HIGH LEVEL VENTILATION

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

0-10º SKILLION ROOF HIGH LEVEL VENTILATION

SHEET:

C25

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN 90X45 MGP10 TRIMMER BETWEEN PLATES AT THE RAMP LOCATION, NOMINAL FIXING. JOIST HANGERS OR SKEW NAILS AS PER MANUFACTURERS SPECIFICATIONS

PLASTERBOARD

19MM STRUCTURAL PLYWOOD FLOORING TO ARCHITECTURAL SPECIFICATIONS. PAINTED BLACK "INTERGRAIN" NON SLIP FINISHING AS PER AS1428. 90X45 MGP10 NOGGING BETWEEN JOISTS

110X18 HARDWOOD PLATE RAMPED THRESHOLD WITH A GRADIENT NO STEEPER THAN 1:8

4NO. 90X45 MGP10 JOISTS @ 300 CTS AND AT EACH END CUT DEPTH TO SUIT FLOORING THICKNESS. 18MM LOSP COVERING TO EITHER SIDE

RAVEN THRESHOLD RP98 @ NO STEEPER THAN 1:8 TO RAMP TRANSITION (19x150mm)

SELECTED FLOOR COVERING

FL INSIDE DWELLING

90X35 MGP10 NOMINAL FIXING

FL INSIDE GARAGE

1040 104MM HIGH PINE STEP RAMP AT MAX 1:10 GRADIENT, MIN 1000MM WIDE DESIGNED IN ACCORDANCE WITH AS1170.1 ADHESIVE FIXED TO SLAB AND CAULKED TO PERIMITER. JOISTS TO BE FIXED TO SLAB BY LIQUID NAILING OR SIMILAR TO MANUFACTURERS SPECIFICATIONS.

C26 - TYPICAL GARAGE RAMP (86MM STEPDOWN)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

SHEET:

NCC RAMP 86MM STEPDOWN C26 AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

NOTE: STUD WALL TO BE ON LOW SIDE OF STEPDOWN PLASTERBOARD

19MM STRUCTURAL PLYWOOD FLOORING TO ARCHITECTURAL SPECIFICATIONS. PAINTED BLACK "INTERGRAIN" NON SLIP FINISHING AS PER AS1428.

90X45 MGP10 TRIMMER BETWEEN PLATES AT THE RAMP LOCATION, NOMINAL FIXING. JOIST HANGERS OR SKEW NAILS AS PER MANUFACTURERS SPECIFICATIONS

110X18 HARDWOOD PLATE RAMPED THRESHOLD WITH A GRADIENT NO STEEPER THAN 1:8

4NO. 190X45 MGP10 JOISTS @ 300 CTS AND AT EACH END CUT DEPTH TO SUIT FLOORING THICKNESS. 18MM LOSP COVERING EITHER SIDE.

45X90 MGP10 NOGGING BETWEEN JOISTS

SELECTED FLOOR COVERING

FL INSIDE DWELLING

172

190

RAVEN THRESHOLD RP138 NO STEEPER THAN 1:8 TO RAMP TRANSITION

FL INSIDE GARAGE

90X35 MGP10 NOMINAL FIXING

1900 190MM HIGH PINE STEP RAMP AT MAX 1:10 GRADIENT, MIN 1000MM WIDE DESIGNED IN ACCORDANCE WITH AS1170.1 ADHESIVE FIXED TO SLAB AND CAULKED TO PERIMITER. JOISTS TO BE FIXED TO SLAB BY LIQUID NAILING OR SIMILAR TO MANUFACTURERS SPECIFICATIONS.

C27 - TYPICAL GARAGE RAMP (172MM STEPDOWN)

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

NCC RAMP 172MM STEPDOWN

SHEET:

C27

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

GARAGE

DWELLING

DOOR JAMB

HUME INSULATOR DOOR SYSTEM INCLUDING NCC COMPLIANT SILL PLATE WITH MIN. 1:8 GRADIENT SELECTED FLOOR COVERING FFL INSIDE GARAGE

FFL INSIDE DWELLING

C28 - STEP FREE THRESHOLD (GARAGE INTERNAL ACCESS)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

SHEET:

NCC STEP FREE THRESHOLD C28 AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

NOM.

10MM 'ABLEFLEX' AROUND POST

RAKED RENDER CAPPING TO TOP OF PIER AT MIN. 3° FALL TOWARDS OUTSIDE EDGES. NOTE: 18 DEGREE FALL REQUIRED IN BUSHFIRE ZONES CAVITY TO BE FILLED AND PACKED WITH EXPANDING FOAM

4.5mm FC SHEET LINING BELOW SECOND LAST BRICK COURSE, EMBEDDED INTO MORTAR BY MIN. 25mm TIMBER POST WITHIN PIER, AS PER ENGINEERING FACE/RENDER BRICKWORK TO PIER, AS PER PLANS

C29 - BRICK PIER WITH RAKED RENDER CAPPING

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

BRICK PIER RAKED RENDER CAPPING

SHEET:

C29

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

100

200

120

100

LED STRIP LIGHTING TO CORNER (IF APPLICABLE) 1000

1200

PRE-FAB STEEL FRAME

C30 - DROPPED CEILING OVER KITCHEN ISLAND

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

DROPPED CEILING OVER KITCHEN ISLAND

SHEET:

C30

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

1020

HATCHING DENOTES MDF SHEET RADIUS FORM CUT DOWN AND FIXED TO BLOCKING ON EITHER FACE OF OPENING CEILING LEVEL

EQ. EQ. N GG. OGG.N EQ O N . . O CL G G C G CL L G O . N

90x45mm BLOCKING TO STUD FRAME, FOR FIXING OF MDF RADIUS FORMS

PLASTERBOARD LINING FIXED OVER NOGGINGS AND MDF VOID FORM

EQ. G. NOG

EQ. NOG G.

FRA

510 S DIU RA ME

510

70x35mm MGP10 TIMBER NOGGINGS BETWEEN RADIUS FORMS, AT MAX 450mm CENTRES

130

OVERALL STUD OPENING

INTERNAL TIMBER STUD WALL FRAMING

C31.1 - 1020mm (FRAME) PASSAGE WIDTH SCALE 1:25

EQ. EQ. ING NOGGING EQ NOGG CL . N Q . E CL OG NG CL GI GI G NG NO

0 101 DIUS RA ME A FR

130 1010

INTERNAL TIMBER STUD WALL FRAMING

400 G OGGIN

400 NOGG ING EQ N . CL OG GI NG

70x35mm MGP10 TIMBER NOGGINGS BETWEEN RADIUS FORMS, AT MAX 450mm CENTRES

HATCHING DENOTES MDF SHEET RADIUS FORM CUT DOWN AND FIXED TO BLOCKING ON EITHER FACE OF OPENING

N . EQ ING CL GG NO

90x45mm BLOCKING TO STUD FRAME, FOR FIXING OF MDF RADIUS FORMS

CEILING LEVEL

350

FRAME-OUT

350

FRAME-OUT

350 PLASTERBOARD LINING FIXED OVER NOGGINGS AND MDF VOID FORM

2020 OVERALL STUD OPENING

350

FRAME-OUT

90x45mm FRAME-OUT SECTIONS TO CORNERS OF STUD FRAME, FOR FIXING OF MDF RADIUS FORMS

C31.2 -2020mm (FRAME) PASSAGE WIDTH SCALE 1:25

3020 810

PLASTERBOARD LINING FIXED OVER NOGGINGS AND MDF VOID FORM

EQ . CL NOG

LC NO

G G

12 5 FRA 8 ME RA DIU

130

HATCHING DENOTES MDF SHEET RADIUS FORM CUT DOWN AND FIXED TO BLOCKING ON EITHER FACE OF OPENING

. IN G

0 126 IUS AD ER M A FR

FRAME-OUT

450 EQ . GIN G

450 GING

450 NOGG ING

CL NOG

NOG . EQ C ING L GG NO

GI NG

G NO

N G CL IN G

EQ. NOGGIN G

C31.3 - 3020mm (FRAME) PASSAGE WIDTH SCALE 1:25 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

INTERNAL PLASTER ARCHES SCALEORBIT 1 : 25 COPYRIGHT HOMES AUSTRALIA Pty.Ltd.©

DETAIL BOOK

SECTION:

C - GENERAL

DETAIL:

SHEET:

INTERNAL ARCHED PLASTER C31 OPENINGS AMENDMENT

AMM #:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

1330

EQ. . GGING CL O N Q E ING CL G OG

INTERNAL TIMBER STUD WALL FRAMING

450 FRAME-OUT

CEILING LEVEL

70x35mm MGP10 TIMBER NOGGINGS BETWEEN RADIUS FORMS, AT MAX 450mm CENTRES

90x45mm BLOCKING TO STUD FRAME, FOR FIXING OF MDF RADIUS FORMS

810

450

450 FRAME-OUT

FRAME-OUT

90x45mm FRAME-OUT SECTIONS TO CORNERS OF STUD FRAME, FOR FIXING OF MDF RADIUS FORMS

OVERALL STUD OPENING 500

MAX 600MM 450

450MM - 500MM SPACING BTW FALL GUARD RAILS

450

NO GAP GREATER THAN 600MM FROM TOP OF WINDOW TRIMMER TO HIGHEST FALL GUARD RAIL

FIRST RAIL TO START 450MM OFF WINDOW SILL TRIMMER

300

NOMINAL WINDOW OPENING HEIGHT

FALL GUARD FIXED TO INSIDE OF STUD FRAME

NOMINAL WINDOW OPENING WIDTH

C32 - WINDOW FALL GUARD SPACING (3 RAIL)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

SHEET:

WINDOW FALL GUARD 3 RAIL C32 AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:25

5 SQUARE SET CEILING

LAMINEX SURROUND PANELLING FIXED TO PLASTER

SCALLOP 22.5 / 45 / 135

90x18MM MDF TRIM

SKIRTING TO BUTT INTO MDF

C35 - FEATURE WALL PANEL - A SECTION VIEW SQUARE SET CEILING

DEMI ROUND 20 / 40

SCALE 1:10 180

SELECTED CORNICE

200

SQUARE SET CEILING

FRENCH STRIPE

LAMINEX SURROUND PANELLING FIXED TO PLASTER

90x18MM MDF TRIM

SKIRTING TO BUTT INTO MDF

SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

FEATURE WALL PANEL - A

SHEET:

C35

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

BATTEN 40, 75, 100, 300

C35 - FEATURE WALL PANEL - A SECTION VIEW CORNICE & BULKHEAD CEILING

5 SQUARE SET CEILING

LAMINEX SURROUND PANELLING FIXED TO PLASTER

CAULKING TO GAPS

CLASSIC VJ 100 / 200

SKIRTING OVER FEATURE WALL PANELLING

C36 - FEATURE WALL PANEL - B SECTION VIEW SQUARE SET CEILING SCALE 1:10 5

HERITAGE 150

SELECTED CORNICE CAULKING TO GAPS

LAMINEX SURROUND PANELLING FIXED TO PLASTER

CAULKING TO GAPS

C36 - FEATURE WALL PANEL - B SECTION VIEW CORNICED CEILING SCALE 1:10 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

FEATURE WALL PANEL - B

SHEET:

C36

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SKIRTING OVER FEATURE WALL PANELLING

5 SQUARE SET CEILING

70X35mm BATTENS FIXED HORIZONTALLY OVER FRAME

FEATURE WALL PANELLING FIXED TO BATTENS

ARCHITECTURAL PANEL

90x18MM MDF TRIM

SKIRTING TO BUTT INTO MDF

C37 - FEATURE WALL PANEL - C SECTION VIEW SQUARE SET CEILING SCALE 1:10 180

SELECTED CORNICE

200

FEATURE WALL PANELLING FIXED TO BATTENS 70X35mm BATTENS FIXED HORIZONTALLY OVER FRAME

90x18MM MDF TRIM

C37 - FEATURE WALL PANEL - C SECTION VIEW CORNICE & BULKHEAD CEILING SCALE 1:10 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

FEATURE WALL PANEL- C

SHEET:

C37

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SKIRTING TO BUTT INTO MDF

DETAILED STONE FIXING (NOT TO SCALE)

NATURA MOSAIC STONE FACINGS FIXED OVER PROPRIETARY BACKING SHEET

BASE COMMONS BRICKWORK

TWO PART MAPEI ULTRALITE S2 ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 12MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE) AS PER MANUFACTURERS RECOMENDATIONS

MAPEI PLANITOP SMOOTH & REPAIR R4 SUBSTRATE TO CREATE FLAT AND LEVEL SURFACE FOR STONE FIXING

NOTE: 100% ADHESIVE COVERAGE TO REAR BACKING OF STONE SHEET AND SUBSTRATE

ARDEX WJ 50 WIDE JOINT GROUT BETWEEN STONE FACINGS

MAPEI PRIMER G OVER SUBSTRATE

C38.1 - NATURA STONE WALL CLADDING GROUTED INSTALLATION

DETAILED STONE FIXING (NOT TO SCALE)

NATURA MOSAIC STONE FACINGS FIXED OVER PROPRIETARY BACKING MESH

BASE COMMONS BRICKWORK

TWO PART MAPEI ULTRALITE S2 ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 12MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE) AS PER MANUFACTURERS RECOMENDATIONS

MAPEI PLANITOP SMOOTH & REPAIR R4 RENDER SUBSTRATE TO CREATE FLAT AND LEVEL SURFACE FOR STONE FIXING

NOTE: 100% ADHESIVE COVERAGE TO REAR BACKING OF STONE SHEET AND SUBSTRATE

STONE FACINGS TO BE TIGHT FITTED NO GROUT IN BETWEEN SPACINGS

MAPEI PRIMER G OVER SUBSTRATE

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

C - GENERAL

STONE CLADDING A (ENGAGED PIER)

SHEET:

C38

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

C38.2 - NATURA STONE WALL CLADDING TIGHT JOINT INSTALLATION

185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS

TIMBER POST

RAKED RENDER TO TOP OF PIER RENDERED 100MM EPS TO TOP OF BRICKWORK

700

STONE FACINGS TO FACE OF BRICK PIER

PAVING IF SPECIFIED

HOUSE FFL FOOTINGS TO ENGINEERS DESIGN

C39 - STONE CLADDING B (HALF HEIGHT PIER)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

STONE CLADDING B (HALF HEIGHT PIER)

SHEET:

C39

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

DUCT EXCLUSION ZONE. NO SERVICES, PLUMBING, BRACING, BLOCKING, STRONG BACKS ETC TO IMPEDE DUCKWORK

300

300 CL

100

DUCT TO BE ROUGHED IN & TAPED TO THE TOP FACE OF BOOT

LINEAR GRILL FACING/OUTLET LINEAR GRILL BOOT FRAMING TO FORM BULKHEAD KITCHEN OVERHEAD CUPBOARDS

C40 - HVAC - LINEAR GRILL IN BULKHEAD DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

C - GENERAL

DETAIL:

HVAC - LINEAR GRILL IN BULKHEAD

SHEET:

C40

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

ROOF PITCH MATERIAL AS NOTED ON ELEVATIONS

600 TO FRAME

450

PORCH PITCHING LEVEL

ROOF TRUSSES AS PER TRUSS MANUFACTURERS SPECIFICATIONS

SELECTED COLORBOND FASCIA AND GUTTER

360

PLASTER CORNICE

RENDERED EPS CLADDING DIRECT FIXED TO FRAMING BETWEEN PIERS

LINTEL AS PER PLAN

50 50

BOTTOM OF CLADDING 50mm DRIP EDGE

DPC ABOVE WINDOW SELECTED ARCHITRAVE

PLASTERBOARD TO CEILING

RENDERED EPS CLADDING FIXED TO FRAMING ABOVE WINDOW TO FINISH FLUSHED WITH BRICK RENDER

ALUMINIUM WINDOW FRAME

D1.1 - RAISED PORCH INFILL DETAIL SCALE 1:20

ROOF PITCH MATERIAL AS NOTED ON ELEVATIONS

600 TO FRAME

450

PORCH PITCHING LEVEL

ROOF TRUSSES AS PER TRUSS MANUFACTURERS SPECIFICATIONS

SELECTED COLORBOND FASCIA AND GUTTER

PLASTER CORNICE

NOM.

50 RENDERED EPS DIRECT FIX TO FRAME

LINTEL AS PER PLAN

BOTTOM OF CLADDING PLASTERBOARD TO CEILING 4.5MM PAINTED FC SHEET

QUIRK

DPC ABOVE WINDOW SELECTED ARCHITRAVE ALUMINIUM WINDOW FRAME

138 X 18 LOSP

D1.2 - RAISED PORCH INFILL DETAIL - DEEPER BEAM SCALE 1:20 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

RAISED PORCH ABOVE INFILL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

RENDERED EPS CLADDING FIXED TO FRAMING ABOVE WINDOW TO FINISH FLUSHED WITH BRICK RENDER

135x135 Ex. POSTS 185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS RAKED RENDER TO TOP OF PIER RENDERED 100MM EPS TO TOP OF BRICKWORK

700

EPS TO BE CUT AROUND DOWNPIPE WHERE APPLICABLE

RENDER TO FACE OF BRICK PIER SLAB AS PER ENGINEERS DESIGN

190

HOUSE FFL

D2.1 - PORCH PIER DETAIL (INTEGRATED SLAB) SINGLE POST SCALE 1:20 135x135 Ex. POSTS 185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS RAKED RENDER TO TOP OF PIER

700

RENDERED 100MM EPS TO TOP OF BRICKWORK

RENDER TO FACE OF BRICK PIER SLAB AS PER ENGINEERS DESIGN

D2.2 - PORCH PIER DETAIL (INTEGRATED SLAB) - DOUBLE POST

SCALE 1:20

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

BRICK PIER & EPS CAPPING W. EX. POST

AMM #: 01 COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

AMENDMENT TYPE: SINGLE POST DET. ADDED

DRAWN: MRO

SHEET:

D2 DATE: 31.07.23

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

190

HOUSE FFL

185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS

RAKED RENDER CAPPING TO TOP OF PIER AT MIN. 3° FALL TOWARDS OUTSIDE EDGES. NOTE: 18 DEGREE FALL REQUIRED IN BUSHFIRE ZONES

10MM 'ABLEFLEX' AROUND POST

4.5mm FC SHEET LINING BELOW SECOND LAST BRICK COURSE, EMBEDDED INTO MORTAR BY MIN. 25mm CAVITY TO BE FILLED AND PACKED WITH EXPANDING FOAM

NOM.

FACE/RENDER BRICKWORK TO PIER, AS PER PLANS

REFER TO PLANS

MOULDING TO BE NOTCHED AROUND DOWNPIPE, WHERE APPLICABLE

RENDERED FEATURE MOULDINGS TO TOP OF PIER, AS PER PLANS

SLAB AS PER ENGINEERING DESIGN

190

HOUSE FFL

PARTIALLY EXPOSED TIMBER POST TO PIER, AS PER PLANS/ENGINEERING

D3.1 - PORCH PIER DETAIL (INTEGRATED SLAB) - SINGLE POST WITH FEATURE MOULDING TO TOP EDGE SCALE 1:20 185x18 TIMBER TRIMS TO TOP OF PIER AROUND POSTS

RAKED RENDER CAPPING TO TOP OF PIER AT MIN. 3° FALL TOWARDS OUTSIDE EDGES. NOTE: 18 DEGREE FALL REQUIRED IN BUSHFIRE ZONES

10MM 'ABLEFLEX' AROUND POST

MOULDING TO BE NOTCHED AROUND DOWNPIPE, WHERE APPLICABLE

RENDERED FEATURE MOULDINGS TO TOP OF PIER, AS PER PLANS

70x35mm TIMBER BLOCKING TO INSIDE OF POST, TO SUPPORT FC SHEET

REFER TO PLANS

4.5mm FC SHEET LINING BELOW SECOND LAST BRICK COURSE, EMBEDDED INTO MORTAR BY MIN. 25mm

NOM.

FACE/RENDER BRICKWORK TO PIER, AS PER PLANS SLAB AS PER ENGINEERING DESIGN

190

HOUSE FFL

PARTIALLY EXPOSED TIMBER POSTS TO PIER, AS PER PLANS/ENGINEERING

D3.2 - PORCH PIER DETAIL (INTEGRATED SLAB) - SINGLE POST WITH FEATURE MOULDING TO TOP EDGE SCALE 1:20 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

BRICK PIER & FEAT. MOULDING W. EX. POST

AMM #: 01 COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

AMENDMENT TYPE: SINGLE POST DET. ADDED

DRAWN: MRO

SHEET:

D3 DATE: 31.07.23

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

CAVITY TO BE FILLED AND PACKED WITH EXPANDING FOAM

STEEL COLUMN TO ENGINEER'S DESIGN CENTRED TO PIER

STEEL POST TO BE CLAD WITH LOSP TO PROVIDE A 120x120 TIMBER POT APPEARANCE

138x18 TIMBER TRIM AROUND BASE OF EXPOSED POST

RENDERED BLUEBOARD TO 'TOP OF 'HEBEL' PIER, RENDER TO FALL AWAY FROM CENTRE

'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS

24mm TOP HAT FOR FIXING OF PANEL, REFER TO MANUFACTURERS FOR FIXING REQUIREMENTS

STEEL COLUMN TO ENGINEER'S DESIGN CENTRED TO PIER

'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS

90x90 TIMBER SUPPORT POST TO HEIGHT OF 'HEBEL' CLADDING ONLY

D4 - HEBEL PIER DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

D - FACADES SHEET:

HEBEL PIER

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

TIMBER POST AS PER PLAN CENTRE PIN POST STRIRRUP

HOUSE FFL 190

ANCHOR BOLTS - TO BE INSTALLED PERPENDICULAR TO THE SLAB

INGRATED SLAB AS PER ENGINEER'S DESIGN

CONCRETE PAVING TO BE 50mm MIN FROM BOTTOM OF POST

D5 - EXPOSED POST STIRRUP DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

EXPOSED POST STIRRUP DETAIL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

0 39

39 0 75MM RENDERED EPS CLADDING FIXED TO 35MM TIMBER BATTENS STEEL COLUMN TO ENGINEER'S DESIGN

110X20 RENDERED MOULDING

590X590 FACE BRICK PIER

110X20 RENDERED MOULDING

RENDERED BRICKWORK TO BALCONY SECTION

110X20RENDERED MOULDING

590X590 FACE BRICK PIER

STEEL COLUMN TO ENGINEER'S DESIGN

590X590 FACE BRICK PIER

110X20 RENDERED MOULDING

710X710 RENDERED BRICK TO BASE OF PIER

D6 - PORCH PIER - 3D VIEW

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

PROVINCIAL PIER DETAIL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

STEEL COLUMN TO ENGINEER'S DESIGN

RENDERED EPS CLADDING TO INSIDE OF BALCONY

RENDERED BRICKWORK TO BALCONY SECTION

TIMBER FRAME TO BALCONY

110X20 RENDERED MOULDING

590X590 FACE BRICK PIER

FACE BRICK INFILL TO BALCONY BETWEEN PIERS

D7.1 - PORCH INFILL - 3D VIEW

(CUT THROUGH ABOVE FLOOR JOISTS) SCALE 1:20

STEEL COLUMN TO ENGINEER'S DESIGN RENDERED BRICKWORK TO BALCONY SECTION

DOUBLE BRICK TO PORCH INFILL BELOW BALCONY JOISTS

110X20 RENDERED MOULDING

590X590 FACE BRICK PIER

FACE BRICK INFILL TO BALCONY BETWEEN PIERS

D7.2 - PORCH INFILL - 3D VIEW

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

SHEET:

PROVINCIAL BALCONY BRICK D7 INFILL DETAIL AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

(CUT THROUGH BELOW FLOOR JOISTS) SCALE 1:20

AXON CLADDING ON TIMBER BATTENS

OVERFLOW WITH PICTURE FRAME CAPPING

ROOF TRUSSES AS PER TRUSS MANUFACTURERS SPECIFICATIONS

BOX GUTTER

2º METAL DECK ROOF OVER PORCH

PICTURE FRAME AROUND OVERFLOW POP

METAL FLASHING

SUMP

CEILING LINE RENDERED EPS

PLASTER LINING TO UNDERSIDE OF PORCH

100MM x 75MM DOWNPIPE

135 X 135 STAINED EXPOSED POST WITH METAL STIRRUP AT BOTTOM

D8 - NOVA SUMP/DOWNPIPE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

NOVA (a) SUMP/DOWNPIPE

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

185

480

RENDERED 100MM EPS CLADDING FIXED TO FRAMED OUT WALL

310

170

ALUMINIUM FLASHING TO TOP OF BUILDOUT

D9 - NOVA - PORCH EXTENSION

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

D - FACADES

DETAIL:

NOVA (a) PORCH EXTENSION

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

2° METAL DECK ROOF

BOX GUTTER SUMP FALL REFER PLAN

140

140 215

REFER PLAN

185

METAL FLASHING TO TOP OF PARAPET

D10 - NOVA - PORCH ROOF PLAN

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES SHEET:

NOVA (a) PORCH ROOF PLAN D10

DATE ISSUED:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:50

AXON CLADDING FIXED TO 35MM BATTENS TRANSFER FLASHING OVER BRICK JUNCTION

OUTSIDE BRICK PLASTER STUD WALL

D11 - NOVA - REAR WALL DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES

NOVA (a) REAR WALL

DATE ISSUED:

SHEET:

D11

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

75x30mm TOP RAIL

OFFSET TOP RAIL WALL MOUNTING BRACKET MOUNTING PLATE 45x45mm MID RAIL 65x16.5mm SLAT BALUSTERS

50x50x3.2mm 'AIRE' POST WITH WELDED BASE PLATE

TWO-PART DOMICAL BASE PLATE COVER MOUNTING PLATE

45x45mm BOTTOM RAIL

SECTION VIEW SCALE 1:10 MID RAIL MOUNTING PLATES

50x50x3.2mm 'AIRE' POST WITH WELDED BASE PLATE

45x45mm MID RAIL

75x30mm TOP RAIL

OFFSET TOP RAIL WALL MOUNTING BRACKET

1000 MIN.

BOTTOM RAIL MOUNTING PLATES

65x16.5mm SLAT BALUSTERS

TWO-PART DOMICAL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES

BRIDGEHAMPTON - 'AIRE' 3-RAIL BALUSTRADE

DATE ISSUED:

SHEET:

D13

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

45x45mm BOTTOM RAIL

BASE PLATE COVER ELEVATION VIEW D13 - BRIDGEHAMPTON BALUSTRADE DETAIL SCALE 1:10

TOP OF EXPOSED PIERS TO BE TILED WITH TILE TRIM TO PERIMITER

SELECTED WALL TILES TO TOP OF PIER

CHROME TILE TRIM EDGE STRIP TO PERIMITER FALL

STAINLESS STEEL HANDRAIL @ MIN 1m HIGH FROM FINISHED FL OF BALCONY

600 X 600MM WALL TILING FIXED USING MIN 15MM PROPRIETARY MAPEI ULTRALITE S2 TILE ADHESIVE AS PER AS3958

BALCONY JOISTS EPS CLADDING TO FACE OF BALCONY

PLASTER SHEET LINING FIXED TO 90x35 TIMBER DROPPERS FLOOR TILES TO BALCONY TO FALL TO BALCONY FLOOR DRAIN. SECURA FLOORING BENEATH WITH WATERPROOFING MEMBRANE AND RETURNED UP WALLS 100MM, IN ACCORDANCE WITH AS4654.1 AND AS4654.2

ALUMINIUM TILE TRIM 15X8MM SCREWED INTO BRICKWORK AT 600MM CENTRES NOTE: TILE TRIM FROM FIRST TILE 2.7M OFF NATURAL GROUND. NOTE: TRIM FIXED TO BRICKWORK 70MM FROM EACH END. TRIM TO FULL LENGTH OF TILED APPLICATION TO BE GROUTED OVER.

DETAILED TILE FIXING (NOT TO SCALE)

BAGGED RENDERED FINISH SUBSTRATE UNDER WALL TILING

TWO PART MAPEI ULTRALITE S2 TILE ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE)

ARDEX MULTIPRIME WATER BASED PRIMER OVER RENDER SUBSTRATE

D14 - DOUBLE STOREY EXPOSED PIER FINISH - EXTERNAL WALL TILING ABOVE 2.7M HEIGHT (URBAN COASTAL FACADE) NOTE: EXTERNAL WALL TILES NOT TO BE FIXED OVER AAC OR FOAM EXTERNAL WALL CLADDING SYSTEMS. MECHANICAL FIXING MUST BE APPLIED AT WORKING HEIGHTS OVER 2.7M NGL. TILE SIZE NOT TO EXCEED 600 X 600MM

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES

EXTERNAL WALL TILING ABOVE 2.7M - EXPOSED DATE ISSUED: TILING

SHEET:

D14

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

WALL TILING FIXED USING MIN 15MM PROPRIETARY MAPEI ULTRALITE S2 TILE ADHESIVE AS PER AS3958

BASE COMMONS BRICKWORK

135X135MM PAINTED LOSP POST 190X19MM PAINTED LOSP TRIM TO BASE OF POST, CAULKED TO SUIT

RENDERED FINISH TO TOP OF PIER CAVITY FILLED WITH EXPANDING FOAM FC SHEET LINING AT SECOND LAST BRICK COURSE 120X30MM EPS MOULDING AROUND PIER BASE COMMONS BRICKWORK BAGGED FINISH SUBSTRATE WOODEN TROWEL FINISH (SMOOTH)

SINGLE COAT OF ARDEX MULTIPRIME WATER BASED PRIMER OVER RENDERED SUBSTRATE

TWO PART MAPEI ULTRALITE S2 TILE ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE)

FIRST FLOOR

DETAILED TILE FIXING (NOT TO SCALE)

WALL TILING FIXED USING MIN 15MM PROPRIETARY MAPEI ULTRALITE S2 TILE ADHESIVE AS PER AS3958

BASE COMMONS BRICKWORK

BAGGED RENDERED FINISH SUBSTRATE UNDER WALL TILING

ARDEX MULTIPRIME WATER BASED PRIMER OVER RENDER SUBSTRATE

TWO PART MAPEI ULTRALITE S2 TILE ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE)

NOTE: EXTERNAL WALL TILES NOT TO BE FIXED OVER AAC OR FOAM EXTERNAL WALL CLADDING SYSTEMS. MECHANICAL FIXING MUST BE APPLIED AT WORKING HEIGHTS OVER 2.7M NGL. TILE SIZE NOT TO EXCEED 600 X 600MM

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES

EXTERNAL WALL TILING ABOVE 2.7M - UNDER EAVE DATE ISSUED: TILING

SHEET:

D15

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

D15 - DOUBLE STOREY PIER FINISH - EXTERNAL WALL TILING ABOVE 2.7M HEIGHT (BRIDGEHAMPTON FACADE)

POST AS PER PLAN RENDERED FINISH TO TOP OF PIER CAVITY FILLED WITH EXPANDING FOAM FC SHEET LINING AT SECOND LAST BRICK COURSE CHROME TILE TRIM EDGE STRIP TO PERIMITER

BASE COMMONS BRICKWORK BAGGED FINISH SUBSTRATE WOODEN TROWEL FINISH (SMOOTH)

SINGLE COAT OF ARDEX MULTIPRIME WATER BASED PRIMER OVER RENDERED SUBSTRATE

TWO PART MAPEI ULTRALITE S2 TILE ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE)

FIRST FLOOR

DETAILED TILE FIXING (NOT TO SCALE)

WALL TILING FIXED USING MIN 15MM PROPRIETARY MAPEI ULTRALITE S2 TILE ADHESIVE AS PER AS3958

BASE COMMONS BRICKWORK

BAGGED RENDERED FINISH SUBSTRATE UNDER WALL TILING

ARDEX MULTIPRIME WATER BASED PRIMER OVER RENDER SUBSTRATE

TWO PART MAPEI ULTRALITE S2 TILE ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE)

D16 - DOUBLE STOREY PIER FINISH - EXTERNAL WALL TILING ABOVE 2.7M HEIGHT (MODERN FACADE)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES

EXTERNAL WALL TILING ABOVE 2.7M - UNDER EAVE DATE ISSUED: TILING MODERN

SHEET:

D16

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

NOTE: EXTERNAL WALL TILES NOT TO BE FIXED OVER AAC OR FOAM EXTERNAL WALL CLADDING SYSTEMS. MECHANICAL FIXING MUST BE APPLIED AT WORKING HEIGHTS OVER 2.7M NGL. TILE SIZE NOT TO EXCEED 600 X 600MM

200x65mm SIDE OVERFLOW THROUGH GARAGE PARAPET

BOX GUTTER TO GARAGE, AS PER PLANS

30 0

25 MIN.

BOX GUTTER TO PORCH, AS PER PLANS

150

0 60 40 0

0 90

0 30

WASTE DIRECTED TO VOID BELOW, AS PER PLANS

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

D - FACADES

OTWAY/MONA CORNER SUMP DETAIL

DATE ISSUED:

SHEET:

D17

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

D17 - OTWAY/MONA FACADE - CORNER SUMP DETAIL SCALE 1:20

ARCHITRAVES BUTT INTO STONE BENCHTOP

BENCHTOP TO RUN INTO BOUTIQUE FRAME FLEXIBLE PVC SILL FLAP 10mm FROM WINDOW TO BRICK SILL BRICK

200MM PLY BRACE SUPPORT

FLEXIBLE PVC FLASHING FIN

BASE CUPBOARD CARCUS

WEEP HOLE

E1 - STONE BENCHTOP OVER WINDOW REVEAL NOTE: WINDOW TO BE SET AT 885MM TO UNDERSIDE OF BOTTOM REVEAL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

KIT SPLASHBACK WINDOW (ARCHITRAVES)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

10mm CLEARANCE BETWEEN FRAME AND SILL TIMBER REVEAL

ARCHITRAVE AS PER SPECIFICATION SILL BRICK

FLASHING AS PER WINDOW MANUFACTURER

PLASTER STUD WALL

WALL TIES

E2 - TYPICAL FACE BRICK SILL DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

TYPICAL FACE BRICK SILL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

BRICK HEADER COURSE UNDER WINDOW 10mm CLEARANCE BETWEEN FRAME AND SILL TIMBER REVEAL

ARCHITRAVE AS PER SPECIFICATION

FALL

FLASHING AS PER WINDOW MANUFACTURER

PLASTER STUD WALL WALL TIES

RENDERED BRICKWORK AS PER ELEVATIONS

E3 - TYPICAL RENDERED BRICK SILL DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

TYPICAL RENDERED BRICK SILL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

OUTSIDE BRICK PLASTER STUD WALL

SISALATION WRAP OVER BRICK FLASHING

WEEPHOLE WITH FLASHING

ARCHITRAVE AS PER SPECIFICATION

15mm CLEARANCE TIMBER REVEAL

EA STEEL LINTEL

STEEL LINEL ANGLE TO COVER HOLES IN BRICK, IF REQUIRED TRIM REAR OF BRICK

E4 - TYPICAL BRICKWORK ABOVE OPENING DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

SHEET:

TYPICAL BRICKWORK ABOVE E4 OPENING AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

CEILING INSULATION AS PER SPECIFICATION PLASTER CORNICE

COLORBOND STEEL FASCIA WEEPHOLE WITH FLASHING

TOP PLATE LINTEL AS PER PLAN

HEAD HEIGHT

STEEL LINTEL AND INFILL STRIP ATTACHED TO UNDERSIDE DOOR FRAME

E5.1 - BRICKWORK ABOVE OPENINGS (NO EAVE) SCALE 1:20

90x35 MGP10 EAVE DROPPER

600 ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

TRIMMERS@ 1200 CTS CEILING HEIGHT

CEILING INSULATION AS PER SPECIFICATION PLASTER CORNICE TOP PLATE COLORBOND STEEL FASCIA WEEPHOLE WITH FLASHING

LINTEL AS PER PLAN DPC WINDOW FLASHING

WINDOW HEAD HEIGHT EA STEEL LINTEL

STEEL LINTEL ANGLE TO COVER HOLES IN BRICK, IF REQUIRED TRIM REAR OF BRICK

ALUMINIUM WINDOW FRAME

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

E - WINDOWS

BRICKWORK ABOVE OPENING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

E5.2 - BRICKWORK ABOVE OPENINGS (450 EAVE) SCALE 1:20

90x35 MGP10 EAVE DROPPER

TRIMMERS@ 1200 CTS

600 ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS CEILING HEIGHT

490

CEILING INSULATION AS PER SPECIFICATION PLASTER CORNICE

COLORBOND STEEL FASCIA

WINDOW HEAD HEIGHT

NOM. INFILL

TOP PLATE LINTEL AS PER PLAN DPC WINDOW FLASHING

4.5MM FC SHEET FIXED TO TIMBER BLOCKING ALUMINIUM WINDOW FRAME

E6 - INFILL ABOVE OPENINGS (450 EAVE)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

INFILL ABOVE OPENING - 450 EAVE

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS CEILING HEIGHT

2110 WINDOW HEAD HEIGHT

234 INFILL

COLORBOND STEEL FASCIA

4.5MM FC SHEET FIXED TO TIMBER BLOCKING

CEILING INSULATION AS PER SPECIFICATION PLASTER CORNICE TOP PLATE LINTEL AS PER PLAN

90 x 35 & 42 x 19 PINE DAR FRAMING WITH BLOCKING BEHIND ALUMINIUM WINDOW FRAME

E7 - INFILL ABOVE OPENINGS (NO EAVE)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

INFILL ABOVE OPENING - NO EAVE (2440 CL)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS CEILING HEIGHT

384 INFILL

COLORBOND STEEL FASCIA

2100 WINDOW HEAD HEIGHT

4.5MM FC SHEET FIXED TO TIMBER BLOCKING

CEILING INSULATION AS PER SPECIFICATION PLASTER CORNICE TOP PLATE LINTEL AS PER PLAN

90 x 35 & 42 x 19 PINE DAR FRAMING WITH BLOCKING BEHIND ALUMINIUM WINDOW FRAME

E8 - INFILL ABOVE OPENINGS (NO EAVE)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

INFILL ABOVE OPENING - NO EAVE - 2590 CEILING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

90x35 MGP10 EAVE DROPPER TRIMMERS@ 1200 CTS

537 ROOF TRUSSES CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS CEILING HEIGHT CEILING INSULATION AS PER SPECIFICATION PLASTER CORNICE COLORBOND STEEL FASCIA

TOP PLATE LINTEL AS PER PLAN

4.5MM FC SHEET FIXED TO TIMBER BLOCKING

90X35 & 42X19 PINE DAR FRAMING WITH BLOCKING BEHIND ALUMINIUM WINDOW FRAME

E9 - NO INFILL ABOVE OPENINGS (450 EAVE) Note: Required Window head heights under eave 2590mm ceilings - 2310mm head height 2740mm ceilings - 2460mm head height

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

NO INFILL - 450 EAVE- 2440 CEILING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

19 x 19mm QUAD

4.5mm FC SHEET INFILL ABOVE WINDOW

WINDOW

E10 - TRIMS TO INFILLS

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

E - WINDOWS

TRIMS TO INFILLS

SHEET:

E10

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

OVERHEAD CUPBOARD CARCASS

FLEXIBLE PVC SILL FLAP 10mm FROM WINDOW TO BRICK

200MM PLY BRACE SUPPORT TO UNDERSIDE OF WINDOW

865MM TO BOTTOM REVEAL

BENCHTOP TO RUN OVER BOTTOM REVEAL INTO ALUMINIUM WINDOW FRAME

SILL BRICK

WEEP HOLE

BASE CUPBOARD CARCUS

TILE ANGLE TO EXTEND UP TO OVERHEAD CABINET

1625MM WINDOW HEAD HEIGHT

STEEL LINEL ANGLE TO COVER HOLES IN BRICK, IF REQUIRED TRIM REAR OF BRICK

TILED SIDE REVEALS (OVER PLASTER)

905MM TO TOP OF BENCHTOP

760MM WINDOW OVER REVEALS

SQUARE SET PLASTERED WINDOW HEADER NOTE: DOUBLE PLASTER SHEETING TO TOP OF REVEAL (CONSISTENT SURROUNDS)

OUTSIDE BRICK

E11 - 720MM HIGH BOUTIQUE WINDOW OFFSET REVEALS WITH OVERHEAD CABINET ABOVE

SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

E - WINDOWS

DETAIL:

KIT SPLASHBACK WINDOW (OFFSET REVEALS)

SHEET:

E11

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

NOTE: WINDOW TO BE SET AT 865MM TO UNDERSIDE OF BOTTOM REVEAL

60150 mm

HEAD FLASHING

VAPOR BARRIER

SILL FLASHING

BLOCKING AS REQUIRED INSULATE CAREFULLY AROUND SKYLIGHT

BATTENS

OU TS IDE FR AM EH EIG HT

TILES

UNDERLAYMENT

VERTICAL CROSS SECTION SCALE 1:20

SUPPORT BATTEN INSULATION

PLASTER CEILING

DECK SEAL

MIDDLE GUTTER

30-60mm

TILES

30-60mm UNDERLAYMENT

BATTENS

FLASHING GUTTER UNDERLAYMENT

OUTSIDE FRAME WIDTH

PACKING TRUSSES

100 FRAME TO FRAME SPACING

PLASTER CEILING VAPOR BARRIER

HORIZONTAL CROSS SECTION E12 - SKYLIGHT SECTION ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

E - WINDOWS

SKYLIGHT SECTION

DATE ISSUED:

SHEET:

E12

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

VELUX SKYLIGHT REFER TO DETAILS

REFER TO ELEVATIONS FOR ROOF MATERIAL AND PITCH

SKYLIGHT SHAFT SQUARE TO ROOF

SKYLIGHT SHAFT PLUMB TO ROOF

PITCHED CEILING @ 12.5DEG

E13 - SKYLIGHT SHAFT SECTION

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

E - WINDOWS

SKYLIGHT SHAFT

DATE ISSUED:

SHEET:

E13

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

INTERNAL LINING

BITUMEN TAPE AROUND WINDOW BREATHABLE SARKING TO OUTSIDE OF FRAME 34mm TOP HAT FOR FIXING OF PANEL, FIXING AS PER MANUFACTURER 'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS

WINDOW JAMB WITH TRIM SCALE 1:5

34mm TOP HAT FOR FIXING OF PANEL, FIXING AS PER MANUFACTURER

BITUMEN TAPE AROUND WINDOW NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

O/A DEPTH

CAULKING AROUND WINDOW RUBBER

MIN 15° FALL

50MM 'HEBEL POWER PANEL', COATING SYSTEM AS MANUFACTURERS SPECIFICATIONS

BREATHABLE SARKING TO OUTSIDE OF FRAME

E14 - HEBEL WINDOW SILL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

E - WINDOWS

TYPICAL HEBEL SILL

SHEET:

E14

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

BREATHABLE SARKING TO STUD WALL BEHIND BATTEN LINEA WEATHERBOARD CLADDING FIXED TO BATTEN 90 X 35 TIMBER BATTEN STARTER STRIP 90x42mm LOSP TRIM

CORROSION RESISTANT FLASHING NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

FLEXIBLE PVC SILL FLAP 10mm FROM WINDOW TO BRICK CAULKED AROUND WEEP HOLES TO SUIT. NOTE: WEEPHOLES NOT TO BE CAULKED

WINDOW FLASHING TO RETURN DOWN FRAME OVER SARKING WRAP 90x42mm LOSP TRIM BREATHABLE SARKING BEHIND BATTEN

LINEA WEATHERBOARD CLADDING FIXED TO BATTEN

E15 - BOUTIQUE WINDOW CAULKING (LINEA)

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

E - WINDOWS

BOUTIQUE WINDOW CAULKING (LINEA)

SHEET:

E15

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

COLORBOND FLASHING TO TOP

BALTIC PINE WEATHERBOARD CAPPING FIXED OVER PARTICAL BOARD FLOORING TO GRADE BACK TO ROOF

3 DEG FALL

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

ORANGE TONGUE 19MM SHEET FLOORING

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

FACE BRICKWORK CEILING LEVEL

PLASTER CORNICE

BATTEN @600 CENTERS AND PLASTER LINED TO REAR BEAM BEAM & LINTEL AS PER ENGINEERING DESIGN BRICK LINTEL AS PER ENG. DESIGN

19x120 LSOP TRIM

F1a - GARAGE DOOR PARAPET SECTION (TIMBER BEAM)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE DOOR PARAPET SECTION (TIMBER BEAM)

SHEET:

F1a

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

COLORBOND FLASHING TO TOP

BALTIC PINE WEATHERBOARD CAPPING FIXED OVER PARTICAL BOARD FLOORING TO GRADE BACK TO ROOF

3DEG FALL

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

FACE BRICKWORK CEILING LEVEL

PLASTER CORNICE

BEAM AS PER ENGINEERING DESIGN BATTEN @600 CENTERS AND PLASTER LINED TO REAR BEAM BRICK LINTEL AS PER ENG. DESIGN

F1b - GARAGE DOOR PARAPET SECTION (PFC LINTEL)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

F - GARAGE

GARAGE DOOR PARAPET SECTION (STEEL BEAM)

DATE ISSUED:

SHEET:

F1b

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

90x35 MGP10 EAVE DROPPER ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

TRIMMERS@ 1200 CTS

CEILING HEIGHT

PLASTER CORNICE

COLORBOND STEEL FASCIA

BEAM AS SPECIFIED ON PLAN

4.5mm FC SHEET, ABOVE DOOR FIXED WITH CEMENT SHEETS NAILS

QUIRK

PLASTER LINED TO REAR LVL

90x18 LOSP TRIM BELOW LVL 42x42 LOSP TRIM

F2 - GARAGE DOOR SECTION (NO INFILL)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE DOOR SECTION 450 EAVE - NO INFILL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

90x35 MGP10 EAVE DROPPER TRIMMERS@ 1200 CTS CEILING HEIGHT

PLASTER CORNICE

COLORBOND STEEL FASCIA WITH DRIP EDGE

BEAM AS PER ENGINEER'S SPECIFICATION

19X19mm QUAD

118X18 LOSP TRIM

REFER TO PLAN FOR GARAGE DOOR HEIGHT

STEEL ANGLE AS PER ENGINEERS DRAWINGS

F3 - BRICKWORK ABOVE GARAGE DOOR SECTION

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE DOOR SECTION BRICK ABOVE - 450 EAVE

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH

90x35 MGP10 EAVE DROPPER TRIMMERS@ 1200 CTS

ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

CEILING HEIGHT

PLASTER CORNICE

COLORBOND STEEL FASCIA WITH DRIP EDGE

BEAM AS PER ENGINEER'S SPECIFICATIONS

19X19mm QUAD

REFER TO PLAN FOR GARAGE DOOR HEIGHT

118X18 LOSP TRIM

4.5mm FC SHEET, ABOVE DOOR FIXED WITH CEMENT SHEETS NAILS

F4 - GARAGE DOOR SECTION 450 EAVE - FC INFILL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE DOOR SECTION FC INFILL - 450 EAVE

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

LINEA WEATHERBOARD 35MM BATTEN COLORBOND FLASHING OVER BRICK/EPS JUNCTION CHIPBOARD FLOORING FLOOR JOISTS

FIRST FLOOR LEVEL 75MM EPS CLADDING INSTALLED TO MANUFACTURER'S DESIGN AND SPECIFICATION

GROUND FLOOR CEILING HEIGHT 2/90MM X 35MM TIMBER BATTENS

PLASTER CORNICE 300 PFC AS PER ENGINEERING DESIGN

GARAGE DOOR HEIGHT 2400mm

BATTEN @600 CENTERS AND PLASTER LINED TO REAR BEAM 138x18 LOSP TRIM

DRIP EDGE

F5 - EPS CLADDING ABOVE GARAGE DOOR SECTION

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE DOOR SECTION 100MM EPS BO - 2740H

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

COLORBOND FLASHING TO TOP OF PARAPET TO FALL BACK TO BOX GUTTER BALTIC PINE WEATHERBOARD CAPPING FIXED OVER PARTICAL BOARD FLOORING TO GRADE BACK TO ROOF TOP OF PARAPET

350

360

620

RAINWATER HEAD

GROUND FLOOR CEILING 10mm PLASTERBOARD LINING

LINE OF 90mm POP AND PIPE INTO RAINHEAD

90 x 35 CEILING BATTENS @450 CTRS SUMP WHEN REQUIRED BOX GUTTER ON 70x35 TRIMMERS

F6 - GARAGE DOOR PARAPET - BOX GUTTER DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE DOOR PARAPET BOX GUTTER DETAIL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATION TO WALL CLADDING MATERIAL TRAY DECK ROOF @ 2° PITCH

150 MIN.

ALUMINIUM FLASHING

BOTTOM PLATE

NOM. TRUSS HEEL

CHIPBOARRD FLOORING

UPPER FLOOR JOISTS AS PER SPECIFICATION GROUND FLOOR CEILING LEVEL PLASTER CORNICE

BEAM AS PER ENG. DESIGN

ROOF TRUSSES TO MANUFACTURERS SPECIFICATIONS

TOP PLATE

COLORBOND STEEL FASCIA

GARAGE

TRAY DECK ROOF OVER GARAGE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

TRAY DECK ROOF

DATE ISSUED:

F - GARAGE SHEET:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

MDF SKIRTING BOARD CHIPBOARD FLOORING FLOOR JOISTS

FIRST FLOOR

FLASHING

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH ROOF RAFTERS @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS GROUND CEILING

GARAGE CEILING

PLASTERBOARD CEILING

TIMBER BEAM FIXED TO STEEL WITH JOIST HANGER TO SUPPORT ROOF RAFTERS STEEL BEAM AS PER ENGINEERS DESIGN

CEILING TO GARAGE SCALE 1:20

MDF SKIRTING BOARD CHIPBOARD FLOORING FLOOR JOISTS

FIRST FLOOR

FLASHING

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH ROOF RAFTERS @ 600 CTRS TO TRUSS MANUFACTURERS SPECIFICATIONS

DROPPED CEILING

DROPPED CEILING AS PER ROOF MANUFACTURER SPECIFICATIONS

GROUND CEILING

PLASTERBOARD CEILING

GARAGE CEILING

TIMBER BEAM FIXED TO STEEL WITH JOIST HANGER TO SUPPORT ROOF RAFTERS STEEL BEAM AS PER ENGINEERS DESIGN

SCALE 1:20

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

F - GARAGE

GARAGE STEPDOWN CEILING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

DROPPED CEILING TO GARAGE

TYPICAL VALLEY GUTTER SECTION

35 21 5 5

MIN REQ FLOW WIDTH

R TE EN C LI E N O

FIRST FLOOR CLADDING

F LL VA EY G

14010 200

ER TT U

TRUSS ROOF TO BE CONSTRUCTED SO THAT THE OUTER EDGE OF THE VALLEY GUTTER INERSECTS WITH THE CORNER OF THE CLADDING

TYPICAL DOUBLE SOAKER FLASHING DISHARGING TO FASCIA GUTTER

F9a - EXTERNAL CORNER SCALE 1:5

TYPICAL VALLEY GUTTER SECTION

35 21 5 5

MIN REQ FLOW WIDTH

R TE EN C LI E N

FIRST FLOOR CLADDING NOT FOWL MINIMUM FLOW WIDTH OF VALLEY GUTTER

O F LL VA EY G

BRICKWORK

14010 200

ER TT U

TRUSS ROOF TO BE CONSTRUCTED SO THAT THE OUTER EDGE OF THE VALLEY GUTTER INERSECTS WITH THE CORNER OF THE BRICKWORK

TYPICAL DOUBLE SOAKER FLASHING DISHARGING TO FASCIA GUTTER

SCALE 1:5

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

F - GARAGE

DETAIL:

GARAGE OFFSET VALLEY

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

F9b - EXTERNAL CORNER BRICK

10mm PLASTERBOARD LINING

CEILING LEVEL

PLASTER CORNICE LINTEL AS PER PLAN

90 x 35 CEILING BATTENS @450 CTRS

WINDOW HEADER

19X19mm QUAD

4.5mm FC SHEET FIXED TO BLOCKING ABOVE WINDOW

NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS

NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT

G1 - OUTDOOR LIVING/WINDOW DETAIL WITH INFILL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

G - OUTDOOR LIVING

DETAIL:

INFILL ABOVE O.L OPENING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

10mm PLASTERBOARD LINING

CEILING LEVEL

PLASTER CORNICE

90 x 35 CEILING BATTENS @450 CTRS 19X19mm QUAD

WINDOW/DOOR HEADER

STEEL LINTEL AS PER ENGINEERS DESIGN

INSTALL ALUMINUM INFILL IF REQUIRED

NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS

NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT

G2 - BRICKWORK ABOVE OUTDOOR LIVING/OPENING DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

G - OUTDOOR LIVING

DETAIL:

BRICKWORK ABOVE O.L OPENING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

CEILING LEVEL

300

COLORBOND STEEL FASCIA WITH DRIP EDGE BEAM AS PER ENG.

10MM PLASTERBOARD LINING

PAINTED FC SHEET

DRIP EDGE

19X19mm QUAD PVC EXTERNAL ANGLES

G5 - OUTDOOR LIVING DETAIL WITH 300mm BULKHEAD

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

G - OUTDOOR LIVING

DETAIL:

OUTDOOR LIVING DETAIL WITH 300mm BULKHEAD

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

REFER TO ELEVATIONS FOR ROOF MATERIALS AND PITCH ROOF TRUSSES TO TRUSS MANUFACTURERS SPECIFICATIONS

COLORBOND STEEL FASCIA

CEILING LEVEL

19x19mm QUAD TO CONTINUE AROUND BULKHEAD 4.5mm FC SHEET NOTE: NO PVC JOINERS BETWEEN SHEETS

'WR' PLASTERBOARD LINING TO CEILING FIXED OVER 90x35mm BATTENS @ MAX. 450mm CTRS 19x19mm QUAD

BEAM AS SPECIFIED ON PLAN

90x18mm LOSP TIMBER TRIM TO BOTTOM

FC SHEET ENDS AT SAME LEVEL ON BOTH SIDES, WITH QUIRK

NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS

NOTE: CEILING TO BE PAINTED WITH EXTERIOR GRADE PAINT NOTE: ALL JUNCTIONS TO BE CAULKED WITH A SUITABLE EXTERIOR GRADE SEALANT

G6 - OUTDOOR LIVING BEAM CLADDING DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

G - OUTDOOR LIVING

O.L BEAM CLADDING

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

HEBEL CLADDING CHIPBOARD FLOORING

25MM TOP HAT BATTENS

FLOOR JOISTS

FLOOR LEVEL

BEAM AS PER ENGINEERS DRAWING CEILING LEVEL

PLASTERBOARD TO CEILING FIXED 90x35 CEILING BATTENS @450 CTRS 19X19mm QUAD

DRIP EDGE FC SHEET

90X18 LOSP

470X1070 BRICK PIER WITH 115X115 T.PINE POST WITHIN

G7 - O.L BEAM - ROOM ABOVE HEBEL CLADDING

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

G - OUTDOOR LIVING

DETAIL:

O.L BEAM - ROOM ABOVE

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

10mm PLASTERBOARD LINING

CEILING LEVEL

PLASTER CORNICE

90 x 35 CEILING BATTENS @450 CTRS

35mm BATTENS TO INSIDE TO CREATE A 125mm THICK FRAME, INSTALLED AT INTERNAL LOCK-UP STAGE

19X19mm QUAD

DPC FLASHING WINDOW HEADER

STEEL LINTEL AS PER ENGINEERS DESIGN

INSTALL ALUMINUM INFILL IF REQUIRED

NOTE: PLASTERER TO REMOVE RECESS FROM PLASTER SHEETS TO PERIMETER & KEEP MAX 5mm GAP TO EXTERNAL WALLS & BEAMS

NOTE: CEILING TO BE PAINTED WITH EXTERNAL GRADE PAINT

G9 - BOUTIQUE ENTERTAINER SLIDING DOOR OUTDOOR LIVING/WINDOW DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

G - OUTDOOR LIVING

DETAIL:

BOUTIQUE ENTERTAINER SLIDING DOOR DETAIL

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

PARTICLEBOARD FLOORING SUBSTRATE

RENDERED 75mm EPS CLADDING FIXED OVER 25mm BATTENS AS PER ELEVATIONS

FLOOR JOISTS

FF FLOOR LEVEL

BEAM AS PER ENGINEERING DESIGN TIMBER FRAME BLOCKING BENEATH BEAM

GF CEILING LEVEL

PLASTERBOARD TO CEILING FIXED OVER 90x35 CEILING BATTENS @450 CTRS

6mm CLEARANCE FROM PLASTERBOARD TO RENDER FINISH

19x19mm QUAD

G10 - OUTDOOR LIVING DETAIL (BUILD OVER) BEAM WITHIN FLOOR SPACE

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

G - OUTDOOR LIVING

DETAIL:

O.L BEAM - CONCEALED WITHIN FLOOR ABOVE

SHEET:

G10

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

DAMP PROOF FLASHING TO CONTINUE UP 2 COURSES WEEPHOLE TILE OVER PAVING

CONCRETE SCREED APPLIED OVER SLAB AND GRADED AWAY FROM DWELLING AT MIN. 1:100

300

385

190

FL INSIDE DWELLING

G11 - TILING OVER O.LIVING FOR 385mm HIGH SLAB

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

G - OUTDOOR LIVING

TILING TO O.L FLOOR

SHEET:

G11

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

AMM #:

TYPE:

DETAIL BOOK

BATH HOB DETAILS (CLASSIC)

DRAWN:

H3 - BATH HOB & TAP DETAIL

HOB FRAMING TO BE 90X35 MGP10 HOB TO BE LINED WITH "VILLABOARD" TOP OF HOB TO BE WATERPROOFED

SCALE 1:20

FLOOR STRUCTURE

BRICK AND MORTAR PACKING TO SUPPORT BATH. ENSURE BATH RIM IS LEVEL.

550 HOB HEIGHT

SECTION:

H - WET AREAS

SHEET:

AMENDMENT

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

70mm MIN. REFER TO WATERSTOP DETAIL

REPER WATER STOP DETAIL FOR PERIMETER OF BATH RIM

176

• • •

FLOOR STRUCTURE

900 HOB WIDTH

SMARTPAN TO BE SEALED AS PER MANUFACTURER'S SPECIFICATIONS

SUPPORT BATTEN AT WASTE END OF BATH TO BE CUT EITHER SIDE OF WASTE PIPE

SPOUT LOCATION TO BE CTR OF BATH UNLESS NOTED OTHERWISE ON PLANS

*ALWAYS REFER TO INSTALLATION INSTRUCTIONS PROVIDED WITH THE BATH TO ENSURE CURRENT INSTALLATION REQUIREMENTS - ADVISE OFFICE IF DETAILS IN BATH DO NOT MATCH THIS DETAIL

INSTALLATION DETAILS CAROMA LUNA "FOUR TILE FLANGE" BATH

133

750 TIMBER AND SPOUT HEIGHT

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

AMM #:

TYPE:

750

TIMBER AND SPOUT HEIGHT

DETAIL BOOK

SCALE 1:20

H4 - BATH HOB & TAP DETAIL GROUND FLOOR - SMART PAN

HOB FRAMING TO BE 90X35 MGP10 HOB TO BE LINED WITH "VILLABOARD" TOP OF HOB TO BE WATERPROOFED

40MM FLANGE CUT INTO PVC LID. SMARTPAN TO BE SEALED AND GLUED INTO POSITION AS PER MANUFACTURER'S SPECIFICATIONS

INSTALL WATER BAR AROUND BATH INSERT CUTOUT. WATERPROOF UP TO WATER BAR

176

SECTION:

H - WET AREAS

BATH HOB DETAIL (PREMIUM)

DRAWN:

SHEET:

AMENDMENT

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

550

BRICK AND MORTAR PACKING TO SUPPORT BATH. ENSURE BATH RIM IS LEVEL.

HOB HEIGHT

• • •

SLAB

HOB WIDTH

900

HOLE IN RUBBER SEAL CUT 10MM SMALLER THAN OUTLET AND GLUED IN PLACE

SUPPORT BATTEN AT WASTE END OF BATH TO BE CUT EITHER SIDE OF WASTE PIPE

*ALWAYS REFER TO INSTALLATION INSTRUCTIONS PROVIDED WITH THE BATH TO ENSURE CURRENT INSTALLATION REQUIREMENTS - ADVISE OFFICE IF DETAILS IN BATH DO NOT MATCH THIS DETAIL

INSTALLATION DETAILS CAROMA LUNA "ISLAND" BATH

133

SHOWER

OUTSIDE

SHOWER SCREEN POSITIONED ON TOP OF HOB TILED 75x75mm HOB TO PERIMETER OF SHOWER

SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1:200 MIN FALL METAL ANGLE STRIP

INTERNAL MEMBRANE OVER FLOOR SHEETING

H6 - SHOWER BASE WITH HOB DETAIL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

SHOWER BASE - WITH HOB

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

SHOWER

OUTSIDE

SHOWER SCREEN

INTERNAL MEMBRANE OVER FLOOR SHEETING

SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1:200 MIN FALL

METAL ANGLE

H7 - SHOWER HOB DETAIL - 10MM RECESSED

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

SHEET:

SHOWER HOB DETAIL - 10MM H7 RECESSED AMENDMENT

AMM #: COPYRIGHT ORBIT HOMES AUSTRALIA Pty.Ltd.©

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

SHOWER COMPARTMENT

OUTSIDE SILL-LESS NOTHRESHOLD SHOWER SCREEN OVER OPENING

SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1:80 MIN FALL

SHOWER SCREEN FRAME RAISED WITH PROPRIETARY PACKER AND SEALED

WATERSTOP SET 5MM ABOVE FLOOR TILE SET INTO PROPRIETARY SHOWER SCREEN CHANNEL

WATERPROOF MEMBRANE DIRECT TO SLAB AND OVER WATERSTOP

H8 - SHOWER HOB DETAIL - NCC2022 LEVEL 5mm THRESHOLD SCALE 1:2

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

H - WET AREAS

SHOWER HOB DETAIL NCC2022 LEVEL 5mm DATE ISSUED: THRESHOLD

SHEET:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

NOTE: A SHOWER WITHIN 200MM OF WET AREA OPENING/DOORWAY TO INCLUDE A VERTICAL WATERSTOP WHERE THE SHOWER ABUTS THE WALL

400 NOMINAL NICHE SIZE

SELECTED WALL TILES TO THE SHOWER

400

SELECTED WALL TILES TO THE INSIDE FACE AND INSIDE EDGES OF THE NICHE

CHROME EDGE STRIP AROUND NICHE

1200

3MM PACKER REQUIRED TO REAR OF BASE SHEET TO CREATE FALL

ELEVATION NICHE CENTERED TO SHOWER WALL

430 BETWEEN STUDS 400 NOMINAL NICHE SIZE

FALL

CHROME EDGE STRIP AROUND NICHE

WATERPROOFING BOARD TO WET AREAS

SELECTED TILES TO SHOWER NICHE

PLAN

WATERPROOFING ON BOARD BEHIND GROUT

H10 - TYPICAL TILED SHOWER NICHE

GROUT

SCALE 1:1

SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SECTION:

H - WET AREAS

SHOWER NICHE

SHEET:

H10

AMENDMENT AMM #:

SELECTED WALL TILES

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

600 NOMINAL NICHE SIZE

SELECTED WALL TILES TO THE SHOWER

400

SELECTED WALL TILES TO THE INSIDE FACE AND INSIDE EDGES OF THE NICHE

CHROME EDGE STRIP AROUND NICHE

1200

3MM PACKER REQUIRED TO REAR OF BASE SHEET TO CREATE FALL

ELEVATION NICHE CENTERED TO SHOWER WALL U.N.O

630 BETWEEN STUDS 15

600

FALL

CHROME EDGE STRIP AROUND NICHE

WATERPROOFING BOARD TO WET AREAS

SELECTED TILES TO SHOWER NICHE

WATERPROOFING ON BOARD BEHIND GROUT

PLAN

H10b - TYPICAL TILED SHOWER NICHE 600w SCALE 1:10

SCALE 1:1

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

SECTION:

H - WET AREAS

DETAIL:

SHOWER NICHE 600 WIDE

SHEET:

H10.b

AMENDMENT AMM #:

SELECTED WALL TILES

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

GROUT

400 NOMINAL NICHE SIZE

SELECTED WALL TILES TO THE SHOWER

400

SELECTED WALL TILES TO THE INSIDE FACE AND INSIDE EDGES OF THE NICHE

CHROME EDGE STRIP AROUND NICHE

3MM PACKER REQUIRED TO REAR OF BASE SHEET TO CREATE FALL

1200

OUTER LAYER OF VILLABOARD FIXED TO STUD

ELEVATION

NICHE CENTERED TO SHOWER WALL

NOM BETWEEN STUDS 15

NOMINAL NICHE SIZE

PLYBOARD TO EXTERNAL

FALL

OUTER LAYER OF PLYBOARD FIXED TO STUD.

CHROME EDGE STRIP AROUND NICHE 1

INNER LAYER OF WATERPROOF BOARD GLUED TO OUTER PLYBOARD

SELECTED TILES TO SHOWER NICHE

WATERPROOFING ON BOARD BEHIND GROUT

PLAN

SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

GROUT

SCALE 1:1

DETAIL BOOK

SECTION:

H - WET AREAS

DETAIL:

SHOWER NICHE (EXTERNAL BRICKWORK)

SHEET:

H11

AMENDMENT AMM #:

SELECTED WALL TILES

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

H11 - TYPICAL TILED SHOWER NICHE (EXT BRICKWORK)

SHOWER SCREEN POSITIONED ON TOP OF ANGLE

CHROME EDGE STRIP CORNER

SELECTED WALL TILES

END OF WALL STUDS THROUGH TO FLOOR JOISTS FOR SOLID FIXING.

SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1: 200 MIN FALL.

UPPER FLOOR LEVEL

INTERMEDIATE BLOCKING WHERE REQUIRED.

END OF WALL STUDS THROUGH TO FLOOR JOISTS FOR SOLID FIXING. PROVIDE INTERMEDIATE BLOCKING WHERE REQUIRED.

FLOOR JOISTS

DETAIL C

DETAIL D

H12 - SHOWER HALF WALL DETAIL - 180MM

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

H - WET AREAS

1200 TILED WALL

SHEET:

H12

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

PLASTER

6MM TILES ABOVE VANITY BENCH

5mm MIRROR FIXED ON CABINET DOOR

100

OVERALL

5 163 84 16

SHAVING CABINET

CARCASE 124

PLASTER

NOTE: • VOID WIDTH = DOOR WIDTH + 20mm • VOID HEIGHT = DOOR HEIGHT + 10mm

H13a - SHAVING CABINET - RECESSED DETAIL

SHAVING CABINET

PLAN 5mm MIRROR FIXED ON CABINET DOOR

SCALE 1:10

BUILD THEVOID ENSURING IT IS AT LEAST 10MM BELOW THE TOP OF TILES. 10

PLASTER

124

OVERALL

CARCASE

100

SHAVING CABINET

5 3 16 84 16

6MM TILES ABOVE VANITY BENCH

SIDE ELEVATION

5mm MIRROR FIXED ON CABINET DOOR

H13b SHAVING CABINET - WALL HUNG DETAIL SCALE 1:10

PLASTER

6MM TILES ABOVE VANITY BENCH

5mm MIRROR FIXED ON CABINET DOOR

OVERALL

SHAVING CABINET

124

5 163 84 16

33mm BACKING BOARD BEHIND MIRROR

NOTE: • VOID WIDTH = DOOR WIDTH + 20mm • VOID HEIGHT = DOOR HEIGHT + 10mm

H13c - SHAVING CABINET - RECESSED DETAIL WITH FIXED TO SIDE SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

H - WET AREAS

SHAVING CABINET

SHEET:

H13

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

PLAN

H14a - WALL MOUNTED MIXER INSET BASIN

H14b - WALL MOUNTED MIXER ABOVE COUNTER BASIN

SCALE 1:20

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

WALL MOUNTED MIXER BASIN

SHEET:

H14

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

1050

1100

TRI TEC VALVE FOR MIXER & FUTURE WM CONNECTION WHEN LOCATED INSIDE CABINET, GPO TO BE POSITIONED ABOVE WM STOPS ON CUTOUT SIDE FOR FUTURE WM CONNECTION

TRI TEC VALVE FOR MIXER & FUTURE WM CONNECTION

80MM DIA. CUT OUT TO WM SIDE OF CARCASS

300

550

WHERE REQUIRED RECYCLED WATER POINT LOCATED INSIDE CABINET

600

550

450

905

CABINET MID-SHELF TO BE LOCATED BELOW WATER POINTS AND GPO

100

H15 - LAUNDRY CABINET WM HOSE CUTOUT (RELOCATED STOPS) - FRONT & SIDE ELEVATION

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

H - WET AREAS

DETAIL:

LAUNDRY CABINET WM HOSE

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

H15

AMENDMENT AMM #: 01

SECTION:

TYPE:

DRAWN:

DATE:

RW TAP LOCATION

30/08/23

MRO

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

560

STONE VANITY BENCHTOP 500 2020

50MM X 19MM PACKERS

260

SILICON JOINT SELECTED TILES OVER WR BOARD APRON WATERPROOFING BEHIND

550

850

BATH HOB FRAME

H16 - EXTENDED BENCHTOP OVER BATH HOB

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

EXTENDED BENCH OVER BATH

SHEET:

H16

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

CEILING HEIGHT

TILE HEIGHT IN SHOWER COMPARTMENT TO BE RAISED TO MEET WINDOW HEAD

514MM HIGH PLASTERED OFFSET FIXED WINDOW WITH TILED REVEALS TILE TRIM AT JUNCTIONS

SILL SET AT A MINIMUM OF 1800MM FFL

H17 - WINDOW TO SHOWER COMPARTMENT (450 EAVE) Note: Required Window head heights under eave 2590mm ceilings - 2310mm head height 2740mm ceilings - 2460mm head height

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

SHOWER WINDOW DETAIL

SHEET:

H17

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:20

BATH TO SIT DIRECTLY ONTO BATH HOB - BATH TO BE INSTALLED AS PER MANUFACTURES SPECIFICATIONS

WATERPROOF SEALANT AT JUNCTION OF TILES AND BATH RIM. SEALANT TO BE PLACED AFTER TILING

70 MIN.

SELECTED TILES

WATERPROOF MEMBRANE TO ENTIRE TOP OF BATH HOB - BATH INSTALLATION TO OCCUR AFTER WATERPROOFING WATERPROOF SEALANT AT JUNCTION OF BATH AND BATH HOB - BATH RIM TO ACT AS WATER STOP. SEALANT TO BE PLACED PRIOR TO TILING VILLABOARD UNDERLAY

TIMBER FRAME FOR BATH HOB

AS PER WET AREA CONSTRUCTION - BATH INSTALLATION WATER STOP REPORT "PBS 289 17" STUART McCLENNAN

H18a - BATH HOB WATERSTOP ALTERNATIVE SOLUTION DETAIL NOT TO SCALE 70 MIN.

WATERPROOF SEALANT AT JUNCTION OF TILES AND BATH RIM. SEALANT TO BE PLACED AFTER TILING BATH TO SIT DIRECTLY ONTO BATH HOB - BATH TO BE INSTALLED AS PER MANUFACTURES SPECIFICATIONS

WATERPROOF SEALANT AT JUNCTION OF BATH AND BATH HOB - BATH RIM TO ACT AS WATER STOP. SEALANT TO BE PLACED PRIOR TO TILING VILLABOARD UNDERLAY SELECTED TILES

WATERPROOF MEMBRANE TO ENTIRE TOP OF BATH HOB - BATH INSTALLATION TO OCCUR AFTER WATERPROOFING TIMBER FRAME FOR BATH HOB

H18b - BATH HOB WATERSTOP AT WALL JUNCTION ALTERNATIVE SOLUTION DETAIL NOT TO SCALE ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

BATH HOB WATERSTOP ALTERNATIVE SOLUTION

SHEET:

H18

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

AS PER WET AREA CONSTRUCTION - BATH INSTALLATION WATER STOP REPORT "PBS 289 17" STUART McCLENNAN

SHOWER

OUTSIDE

SILL-LESS NO-THRESHOLD SHOWER SCREEN OVER OPENING

CAPPING ANGLE OR D MOULD OVER WATER STOP. MAX 5MM THRESHOLD FLOOR TILES SCREEDED TOWARDS WASTE (1:200 MIN FALL)

WATERSTOP ANGLE UNDER SHOWER SCREEN WATERPROOFING OVER

WATERPROOF MEMBRANE UNDER AND OVER SCREED

H19 - SHOWER DETAIL - LEVEL THRESHOLD

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

H - WET AREAS

SHOWER HOB DETAIL LEVEL THRESHOLD

DATE ISSUED:

SHEET:

H19

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

1525 BATH OVERALL 30

1465 CUTOUT OVERALL 200

919

200

900

HOB WIDTH

145 200 200 145

690 CUTOUT OVERALL 30

750 BATH OVERALL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

CLASSIC 1500 - ISLAND BATH CUTOUT

SHEET:

H20

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

H20 - ISLAND BATH CUTOUT - CLASSIC 1500

1698 BATH OVERALL 30

1638 CUTOUT OVERALL 200

1088

200

900

HOB WIDTH

146 200 200 146

692 CUTOUT OVERALL 30

752 BATH OVERALL

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

H - WET AREAS

DETAIL:

CLASSIC 1700 - ISLAND BATH CUTOUT

SHEET:

H21

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

H21 - ISLAND BATH CUTOUT - CLASSIC 1700

SELECTED WALL TILES TO THE SHOWER 10MM PACKER REQUIRED TO REAR OF SECURA FLOORING TO CREATE FALL SECURA FLOORING TO SUPPORT VILLABOARD AND TILES SELECTED WALL TILES TO FACE AND TOP OF SEAT FALL

METAL EDGE STRIP

450

350

SELECTED TILED FLOOR WITH SCREEDED FALL TOWARDS WASTE 1:200 MIN FALL

50mm STEPDOWN IN FLOOR JOISTS AND IN CONRETE SLAB AS PER ENGINEERING

SECURA FLOORING

GROUT

H22 - TYPICAL TILED SHOWER SEAT DETAIL

WATERPROOFING TO VILLABOARD

SELECTED WALL TILES

6MM VILLABOARD TO WET AREAS FALL

SCALE 1:10

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

H - WET AREAS

TILED SHOWER SEAT

SHEET:

H22

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:1

BUTT JOINTED CEILING JUNCTION TO FULL HEIGHT WALL TILING. NOTE: NOT TO BE STOPPED UP BY PLASTERER

3-5MM GAP

LASER BATTENING AS PER PLAN

WALL PLASTER SHEETING

FULL HEIGHT TILE FIXED OVER WET AREA PLASTERBOARD. WATERPROOFING AS PER AS3740

SECTION VIEW H23 - SQ SET CEILING - FULL HEIGHT TILES

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

H - WET AREAS

DETAIL:

SQ SET CEILING - FULL HEIGHT TILE

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

H23

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:10

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

DETAIL:

FEATURE MOULDINGS CROSS REFERENCE TABLE

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

INTERNAL LINING STUD WALL

NAIL FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. 2.8x40mm FIBRE CEMENT NAIL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING 42x42mm LOSP CAULKING TO JUNCTION

AXON CLADDING FIXED TO BATTEN

BREATHABLE SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5

INTERNAL LINING STUD WALL

BREATHABLE SARKING TO STUD WALL

NAIL FOR BATTEN FIXING

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

CUT BOARDS TO FINISH 2mm OF TIMBER TRIM

AXON CLADDING FIXED TO BATTEN 90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

42x18mm LOSP

2.8x40mm FIBRE CEMENT NAIL CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

SCALE 1:5

I1A - AXON CLADDING - FIXING DETAILS ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

SECTION:

I - CLADDING

DETAIL:

AXON CLADDING - FIXING DETAILS

SHEET:

I1A

AMENDMENT AMM #:

AXON CLADDING

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

EXTERNAL CORNER

BREATH SARKING TO STUD WALL AXON CLADDING FIXED TO BATTEN 90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX. VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT 42x42mm LOSP

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE WINDOW HEADER FLASHING

O/A DEPTH NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

A&L FLASHING TO WINDOW 42x42mm LOSP

AXON CLADDING FIXED TO BATTEN

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING INTERNAL LINING

NAIL FOR BATTEN FIXING

90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL

AXON CLADDING 42x42mm LOSP

WINDOW JAMB WITH TRIM SCALE 1:5

AXON CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

AXON CLADDING - WINDOW DETAILS

SHEET:

I1B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I1B - AXON CLADDING - WINDOW DETAILS

BREATHABLE SARKING TO STUD WALL

AXON CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

42x42mm LOSP

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

WINDOW HEADER FLASHING

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm FACTORY FITTED PACKING

FACTORY FITTED PACKING

BRICK SILL

BRICK HEADER COURSE UNDER WINDOW

FALL

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

SECONDARY FLASHING AS PER WINDOW MANUFACTURER BRICK FLASHING

WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

SCALE 1:5

WINDOW ABOVE BRICKWORK

SCALE 1:5

AXON CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

AXON CLADDING - WINDOW / BRICK SILL

SHEET:

I1C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I1C - AXON CLADDING - WINDOW / BRICK SILL

JAMES HARDIE AXON CLADDING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX CAULKING TO JUNCTION

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. CAULKING TO JUNCTION

MIN. 1DEG FALL

HEADER COURSE

BREATHABLE SARKING TO OUTSIDE STUD FRAME DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

WEEPHOLE

STUD WALL

UP TO 1M MAX

DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

RENDERED BRICKWORK

UP TO 1M MAX

BREATHABLE SARKING TO OUTSIDE STUD FRAME

HEADER COURSE

HORIZONTAL BRICK JUNCTION (EXPOSED BRICKWORK)

HORIZONTAL BRICK JUNCTION (RENDERED BRICKWORK)

SCALE 1:5

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

BREATHABLE SARKING TO STUD WALL INTERNAL LINING

STUD WALL

FLASHING

AXON CLADDING CAULKING TO JUNCTION

42x42mm LOSP TO CORNER CAULKING TO JUNCTION EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION

I1D - AXON CLADDING - BRICK JUNCTION DETAILS ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

SECTION:

I - CLADDING

DETAIL:

AXON CLADDING - BRICK JUNCTION DETAILS

SHEET:

I1D

AMENDMENT AMM #:

AXON CLADDING

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

50MM HEBEL FIRST FLOOR CLADDING

UPTURN FLASHING AGAINST FIRST FLOOR CLADDING 42x42mm LOSP TO CORNER TO STEP BACK AT MATERIAL TRANSITION

TRANSFER FLASHING OVER BRICK

CAULKING TO JUNCTION

AXON CLADDING FIXED TO BATTEN

50MM HEBEL FIRST FLOOR CLADDING

35MM TOPHAT BATTEN TRANSFER FLASHING OVER BRICK

UPTURN FLASHING AGAINST FIRST FLOOR CLADDING

CAULKING TO INTERNAL CORNER

INTERNAL LINING STUD WALL

BREATHABLE SARKING TO STUD WALL

75X75 COLORBOND CORNER FLASHING

AXON CLADDING FIXED TO BATTEN

42x18mm LOSP

90 x 45 MGP10 TIMBER BATTENS @600CTRS MAX.

I1E - AXON CLADDING/BRICK EXTERNAL CORNER

AXON CLADDING

SCALE 1:5

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK DETAIL:

SECTION:

I - CLADDING

AXON/BRICK FIRST FLOOR (ULTRA MODERN FACADE)

DATE ISSUED:

SHEET:

I1E

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

INTERNAL LINING STUD WALL

NAIL FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. 2.8x40mm FIBRE CEMENT NAIL

JAMES HARDIE 75X75 COLORBOND CORNER FLASING 42x42mm LOSP

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT EASYTEX CLADDING FIXED TO BATTEN

BREATHABLE SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5 INTERNAL LINING

STUD WALL

CLADDING FIXED TO BATTEN

NAIL FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX. 2.8x40mm FIBRE CEMENT NAIL

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

BREATHABLE SARKING TO STUD WALL JAMES HARDIE 75X75 COLORBOND CORNER FLASING

42x18mm LOSP

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

EXTERNAL CORNER SCALE 1:5

FINE TEXTURE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

FINE TEXTURE CLADDING FIXING DETAILS

SHEET:

I2A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I2A - FINE TEXTURE CLADDING - FIXING DETAILS

BREATH SARKING TO STUD WALL CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX. VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT 42x42mm LOSP

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE WINDOW HEADER FLASHING

O/A DEPTH NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

A&L FLASHING TO WINDOW 42x42mm LOSP

EASYTEX CLADDING FIXED TO BATTEN

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING INTERNAL LINING

NAIL FOR BATTEN FIXING

90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL CLADDING ON BATTENS 42x42mm LOSP

CAULKING TO JUNCTION

WINDOW JAMB WITH TRIM SCALE 1:5

FINE TEXTURE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

FINE TEXTURE CLADDING WINDOW DETAILS

SHEET:

I2B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I2B - FINE TEXTURE CLADDING - WINDOW DETAILS

BREATH SARKING TO STUD WALL

CLADDING FIXED TO BATTEN

EASYTEX CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

42x42mm LOSP

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

WINDOW HEADER FLASHING

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm FACTORY FITTED PACKING

FACTORY FITTED PACKING

BRICK HEADER COURSE UNDER WINDOW

FALL

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

SECONDARY FLASHING AS PER WINDOW MANUFACTURER BRICK FLASHING

WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

FINE TEXTURE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

FINE TEXTURE CLADDING WINDOW / BRICK SILL

SHEET:

I2C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I2C - FINE TEXTURE CLADDING - WINDOW / BRICK SILL

34MM TOP HAT BATTENS.

BREATHABLE SARKING TO OUTSIDE OF BATTEN 50MM HEBEL CLADDING

METAL FLASHING @ 3 DEGREES ON MORTAR BED

MASONRY WALL

STUD WALL

HORIZONTAL BRICK JUNCTION SCALE 1:5

90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL

INTERNAL LINING STUD WALL

FLASHING

EASYTEX CLADDING CAULKING TO JUNCTION

42x42mm LOSP TO CORNER CAULKING TO JUNCTION EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION I2D - FINE TEXTURE CLADDING - BRICK JUNCTION DETAIL FINE TEXTURE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

FINE TEXTURE CLADDING BRICK JUNCTION DETAIL

SHEET:

I2D

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

INTERNAL LINING STUD WALL

10-8x100mm SCREWS WITH WASHERS

BREATHABLE SARKING BEHIND EPS PANEL

3MM EXPANSION GAP SEALED PRIOR TO RENDER

RENDERED EPS PANEL

BREATHABLE SARKING BEHIND EPS PANEL

INTERNAL CORNER SCALE 1:5 INTERNAL LINING

STUD WALL

10-8X100mm SCREWS WITH WASHERS

RENDERED EPS PANEL

BREATHABLE SARKING BEHIND EPS PANEL

PVC EXTERNAL CORNER BEAD 3MM EXPANSION GAP SEALED PRIOR TO RENDER

EXTERNAL CORNER SCALE 1:5

EPS CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

EPS CLADDING - FIXING DETAILS

SHEET:

I3A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I3A - EPS CLADDING - FIXING DETAILS

BREATH SARKING TO STUD WALL RENDERED EPS CLADDING VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING

10-8x100mm SCREWS WITH WASHERS PVC REVEAL BEAD

SEALANT BEAD ACROSS GAP

O/A DEPTH

NOTE: ENSURE WINDOW WEEP HOLE IS NOT BLOCKED SEALANT BEAD ACROSS GAP

EXTERNAL CORNER BEAD 15º FALL ON SILL RENDERED EPS CLADDING

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING INTERNAL LINING

BREATHABLE SARKING BEHIND EPS PANEL

RENDERED EPS CLADDING

SEALANT BEAD ACROSS GAP

PVC REVEAL BEAD

WINDOW JAMB WITH TRIM SCALE 1:5

EPS CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

EPS CLADDING - WINDOW DETAILS

SHEET:

I3B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I3B - EPS CLADDING - WINDOW DETAILS

BREATH SARKING TO STUD WALL

RENDERED EPS CLADDING

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

10-8x100mm SCREWS WITH WASHERS

PVC REVEAL BEAD

O/A DEPTH

FACTORY FITTED PACKING

BRICK HEADER COURSE UNDER WINDOW

FALL

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

SECONDARY FLASHING AS PER WINDOW MANUFACTURER BRICK FLASHING

WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

EPS CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

EPS CLADDING - WINDOW / BRICK SILL

SHEET:

I3C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I3C - EPS CLADDING - WINDOW / BRICK SILL

BREATHABLE SARKING BEHIND EPS PANEL RENDERED EPS CLADDING PVC RENDER STARTER BEAD PARGED TEXTURE RENDER FINISH WITH SLOPING SURFACE CLOSED CELL POLYETHYLENE COMPRESSIBLE BACKING ROD INCLUDING EXTERNAL GRADE CAULKING SEALANT

FALL

HEADER COURSE MASONRY WALL

STUD WALL

HORIZONTAL BRICK JUNCTION SCALE 1:5

BREATHABLE SARKING BEHIND EPS PANEL

INTERNAL LINING STUD WALL

RENDERED EPS PANEL

10-8x100mm SCREWS WITH WASHERS SEAL CONTROL JOINT BETWEEN REVEAL BEAD AND BRICKWORK + VCUT INTO RENDER AND SEAL BEFORE PAINTING EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION SCALE 1:5

EPS CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

EPS CLADDING / BRICK JUNCTION DETAILS

SHEET:

I3D

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I3D - EPS CLADDING / BRICK JUNCTION DETAILS

BREATHABLE SARKING TO WALL STUD 45MM TIMBER BATTENS 100MM EPS CLADDING SEALANT TEXTURED COATING

SEAL CONTROL JOINT BETWEEN REVEAL BEAD AND BRICKWORK + VCUT INTO RENDER AND SEAL BEFORE PAINTING BACKING ROD 8-10mm GAP HEADER COURSE MASONRY WALL

STUD WALL

EPS FLUSHED WITH BRICK - HORIZONTAL JUNCTION SCALE 1:5

BREATHABLE SARKING TO STUD WALL

INTERNAL LINING STUD WALL

45mm TIMBER BATTENS

RENDERED EPS PANEL SEAL CONTROL JOINT BETWEEN REVEAL BEAD AND BRICKWORK + VCUT INTO RENDER AND SEAL BEFORE PAINTING EXTERNAL BRICKWORK

EPS FLUSHED WITH BRICK - VERTICAL JUNCTION

SCALE 1:5

EPS CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

EPS CLADDING FLUSHED WITH BRICK JUNCTION

SHEET:

I3E

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I3E - EPS CLADDING FLUSHED WITH BRICK JUNCTION

INTERNAL LINING

STUD WALL

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. JAMES HARDIE 75X75 COLORBOND CORNER FLASING 2.8x40mm FIBRE CEMENT NAIL

LINEA WEATHERBOARD CLADDING

45 x 42mm LOSP TRIM

BREATHABLE SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5

INTERNAL LINING STUD WALL

BREATHABLE SARKING TO STUD WALL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

90x42 LOSP TRIM

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX. LINEA WEATHERBOARD CLADDING FIXED TO BATTEN 2.8x40mm FIBRE CEMENT NAIL

EXTERNAL CORNER SCALE 1:5

LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

LINEA CLADDING - FIXING DETAILS

SHEET:

I4A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I4A - LINEA CLADDING - FIXING DETAILS

BREATH SARKING TO STUD WALL

LINEA WEATHERBOARD CLADDING FIXED TO BATTEN 90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX. STARTER STRIP

CORROSION RESISTANT FLASHING 90x42mm LOSP TRIM

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

WINDOW RUBBER OVER TRIM CAULKED TO SUIT

WINDOW FLASHING TO RETURN DOWN FRAME OVER SISILATION WRAP 90x42mm LOSP TRIM

LINEA WEATHERBOARD CLADDING FIXED TO BATTEN

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING INTERNAL LINING

90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL

'LINEA' WEATHERBOARD CLADDING

CAULKING

90x42 LOSP TRIM

WINDOW JAMB WITH TRIM I4B - LINEA CLADDING - WINDOW DETAILS LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

LINEA CLADDING - WINDOW DETAILS

SHEET:

I4B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

BREATH SARKING TO STUD WALL

LINEA WEATHERBOARD CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

STARTER STRIP

90x42mm LOSP TRIM

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE CORROSION RESISTANT FLASHING

CORROSION RESISTANT FLASHING

FACTORY FITTED PACKING

BRICK HEADER COURSE UNDER WINDOW

BRICK HEADER COURSE UNDER WINDOW 10mm CLEARANCE BETWEEN FRAME AND SILL

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

FALL

BRICK FLASHING

WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

LINEA CLADDING - WINDOW/ BRICK SILL

SHEET:

I4C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I4C - LINEA CLADDING - WINDOW/ BRICK SILL

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.

VERTICAL BRICK JUNCTION SCALE 1:5

BREATHABLE SARKING TO STUD WALL

INTERNAL LINING STUD WALL

'LINEA' WEATHERBOARD CLADDING CAULKING TO JUNCTION 42x42mm LOSP TRIM

LINEA WEATHERBOARD FIXED WITH 40x2.8mm FIBRE CEMENT NAIL FASTENED TO EACH BATTEN @ 90° TO FACE (FINISH FLUSH)

STARTER STRIP

CAULKING TO JUNCTION

MIN. 1DEG FALL

HEADER COURSE

RENDERED BRICKWORK

DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

WEEPHOLE

STUD WALL

HORIZONTAL BRICK JUNCTION (EXPOSED BRICKWORK)

HORIZONTAL BRICK JUNCTION (RENDERED BRICKWORK)

SCALE 1:5

LINEA CLADDING

I4D - LINEA CLADDING - BRICK JUNCTION DETAILS ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

LINEA CLADDING - BRICK JUNCTION DETAILS

SHEET:

I4D

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

BREATHABLE SARKING TO OUTSIDE STUD FRAME

UP TO 1M MAX

DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

HEADER COURSE

UP TO 1M MAX

BREATHABLE SARKING TO OUTSIDE STUD FRAME

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

30mm LAP 15

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

LAP 15

EXTERNAL BRICKWORK

HARDIEFLEX CLADDING FIXED TO BATTEN 90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

90x18mm LOSP TRIM

CAULKING TO JUNCTION

BREATH SARKING TO STUD WALL

30mm LAP

LINEA WEATHERBOARD CLADDING FIXED TO BATTEN

I5 - LINEA TO HARDIEFLEX TRANSFER

LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

I - CLADDING

DETAIL:

LINEA TO HARDIEFLEX DETAIL

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

INTERNAL LINING STUD WALL

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. NAIL FOR BATTEN FIXING

JAMES HARDIE 75X75 COLORBOND CORNER FLASING 2.8x40mm FIBRE CEMENT NAIL CAULKING TO JUNCTIONS

42x42 LOSP TRIM TO INTERNAL CORNER 'NEWPORT' WEATHERBOARD CLADDING

BREATHABLE SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5

INTERNAL LINING STUD WALL

BREATHABLE SARKING TO STUD WALL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING CAULKING TO JUNCTION

90x42 LOSP CORNER TRIM NOTE: HANG CORNER STOP OUT BY 40mm

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX. 'NEWPORT' WEATHERBOARD CLADDING FIXED TO BATTEN

2.8x40mm FIBRE CEMENT NAIL CAULKING TO JUNCTION

EXTERNAL CORNER SCALE 1:5

LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

I - CLADDING

DETAIL:

NEWPORT CLADDING FIXING DETAILS

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

I6A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I6A - NEWPORT CLADDING - FIXING DETAILS

BREATH SARKING TO STUD WALL 'NEWPORT' WEATHERBOARD CLADDING

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

90x42mm LOSP TRIM

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER CORROSION RESISTANT FLASHING

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

CONTINUOUS BEAD OF SEALANT A&L FLASHING TO WINDOW 90x42mm LOSP TRIM

'NEWPORT' WEATHERBOARD CLADDING

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING INTERNAL LINING

90x35mm MGP10 TIMBER BATTENS @ 600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL

'NEWPORT' WEATHERBOARD CLADDING

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

CAULKING TO JUNCTION 90x42 LOSP TRIM

WINDOW JAMB WITH TRIM SCALE 1:5

LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

I - CLADDING

DETAIL:

NEWPORT CLADDING WINDOW DETAILS

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

I6B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I6B - NEWPORT CLADDING - WINDOW DETAILS

BREATH SARKING TO STUD WALL

'NEWPORT' WEATHERBOARD CLADDING

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

90x42mm LOSP TRIM

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

CORROSION RESISTANT FLASHING

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FACTORY FITTED PACKING

BRICK HEADER COURSE UNDER WINDOW

FALL

10mm CLEARANCE BETWEEN FRAME AND SILL

FALL

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

BRICK FLASHING

WEEPHOLE ON BRICK

WEEPHOLE ON BRICK BRICK FLASHING

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

LINEA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

I - CLADDING

DETAIL:

NEWPORT CLADDING WINDOW / BRICK SILL

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SHEET:

I6C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I6C - NEWPORT CLADDING - WINDOW / BRICK SILL

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

BREATHABLE SARKING TO STUD WALL

INTERNAL LINING STUD WALL

FLASHING

'NEWPORT' WEATHERBOARD CLADDING CAULKING TO JUNCTION 42x42mm LOSP TRIM EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION SCALE 1:5

'NEWPORT' WEATHERBOARD CLADDING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

CAULKING TO JUNCTION

MIN. 1DEG FALL

HEADER COURSE

BREATHABLE SARKING TO OUTSIDE STUD FRAME DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

WEEPHOLE CL

WEEPHOLE

UP TO 1M MAX

STUD WALL

HORIZONTAL BRICK JUNCTION (EXPOSED BRICKWORK)

HORIZONTAL BRICK JUNCTION (RENDERED BRICKWORK)

SCALE 1:5

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

SECTION:

I - CLADDING

DETAIL:

NEWPORT CLADDING BRICK JUNCTION DETAILS

SHEET:

I6D

AMENDMENT AMM #:

NEWPORT CLADDING

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

RENDERED BRICKWORK

UP TO 1M MAX

BREATHABLE SARKING TO OUTSIDE STUD FRAME

HEADER COURSE

INTERNAL LINING STUD WALL

BREATHABLE SARKING TO STUD WALL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

90x42 LOSP CORNER TRIMS

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX. 'STRIA' WEATHERBOARD CLADDING FIXED TO BATTEN 2.8x40mm FIBRE CEMENT NAIL CAULKING TO JUNCTION

EXTERNAL CORNER SCALE 1:5 INTERNAL LINING STUD WALL

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

2.8x40mm FIBRE CEMENT NAIL

JAMES HARDIE 75X75 COLORBOND CORNER FLASING

42x42mm LOSP TO CORNER APPLY CONTINUOUS BEAD OF JAMES HARDIE SEALANT TO INTERNAL CORNERS

STRIA CLADDING FIXED TO BATTEN BREATH SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5

STRIA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

STRIA CLADDING - FIXING DETAILS

SHEET:

I7A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I7A - STRIA CLADDING - FIXING DETAILS

BREATH SARKING TO OUTSIDE OF BATTEN

STRIA CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX. VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING WITH BITUMEN TAPE

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT 42x42mm LOSP TRIM

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE WINDOW HEADER FLASHING

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

A&L FLASHING TO WINDOW 42x42mm LOSP TRIM STRIA CLADDING FIXED TO BATTEN

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING INTERNAL LINING

NAIL FOR BATTEN FIXING

90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX. BREATHABLE SARKING TO STUD WALL

STRIA CLADDING 42x42mm LOSP TRIM CAULKING

WINDOW JAMB WITH TRIM SCALE 1:5

STRIA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

STRIA CLADDING - WINDOW DETAILS

SHEET:

I7B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I7B - STRIA CLADDING - WINDOW DETAILS

BREATH SARKING TO STUD WALL

STRIA CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

42x42mm LOSP TRIM

NOM. 6mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

WINDOW HEADER FLASHING

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FACTORY FITTED PACKING

BRICK HEADER COURSE UNDER WINDOW

FALL

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

BRICK FLASHING

WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

STRIA CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

SHEET:

STRIA CLADDING - WINDOW / I7C BRICK SILL AMENDMENT

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I7C - STRIA CLADDING - WINDOW / BRICK SILL

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.

VERTICAL BRICK JUNCTION

BREATH SARKING TO STUD WALL

SCALE 1:5

INTERNAL LINING

STUD WALL

FLASHING

STRIA CLADDING FIXED TO BATTEN CAULKING TO JUNCTION

42x42mm LOSP TO CORNER EXTERNAL BRICKWORK

JAMES HARDIE STRIA CLADDING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

CAULKING TO JUNCTION

MIN. 1DEG FALL

BREATHABLE SARKING TO OUTSIDE STUD FRAME

RENDERED BRICKWORK

DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

BREATHABLE SARKING TO OUTSIDE STUD FRAME DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

WEEPHOLE

STUD WALL

HORIZONTAL BRICK JUNCTION (EXPOSED BRICKWORK)

HORIZONTAL BRICK JUNCTION (RENDERED BRICKWORK)

SCALE 1:5

I7D - STRIA CLADDING - BRICK JUNCTION DETAILS ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

SECTION:

I - CLADDING

DETAIL:

STRIA CLADDING - BRICK JUNCTION DETAILS

SHEET:

I7D

AMENDMENT AMM #:

STRIA CLADDING

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

HEADER COURSE

UP TO 1M MAX

HEADER COURSE

UP TO 1M MAX

MIN. 1DEG FALL

INTERNAL LINING STUD WALL

NAIL FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. 2.8x40mm FIBRE CEMENT NAIL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING 42x42mm LOSP

'HARDIEFLEX' CLADDING FIXED TO BATTEN

BREATHABLE SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5

STUD WALL INTERNAL LINING

'HARDIEFLEX' CLADDING FIXED TO BATTENS

NAIL FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX. 2.8x40mm FIBRE CEMENT NAIL

42x18mm LOSP

BREATHABLE SARKING TO STUD WALL JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

EXTERNAL CORNER SCALE 1:5

HARDIE FLEX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

HARDIE FLEX CLADDING FIXING DETAILS

SHEET:

I8A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I8A - HARDIE FLEX CLADDING - FIXING DETAILS

BREATHABLE SARKING TO STUD WALL HARDIEFLEX CLADDING FIXED TO BATTEN 90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX. VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

42x42mm LOSP TRIM FIXED THROUGH CLADDING TO BATTEN

O/A DEPTH NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FLEXIBLE PVC SILL FLAP

FLASHING OVER BREATHABLE SARKING TO STUD WALL

42x42mm LOSP TRIM FIXED THROUGH CLADDING TO BATTEN

INTERNAL LINING

HARDIEFLEX CLADDING FIXED TO BATTEN

STUD WALL

WINDOW HEAD & SILL WITH TRIM SCALE 1:5

INTERNAL LINING

METAL FLASHING

STUD WALL

NAIL FOR BATTEN FIXING

90x35mm MGP10 TIMBER BATTENS @600 CTRS MAX. BREATHABLE SARKING TO STUD WALL HARDIEFLEX CLADDING FIXED TO BATTEN 42x42mm LOSP TRIM FIXED THROUGH CLADDING TO BATTEN

CONTINUOUS BEAD OF HARDIE JOINT SEALANT TO JUNCTION

WINDOW JAMB WITH TRIM SCALE 1:5

HARDIE FLEX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

HARDIE FLEX CLADDING WINDOW DETAILS

SHEET:

I8B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I8B - HARDIE FLEX CLADDING - WINDOW DETAILS

HARDIEFLEX CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

42x42mm LOSP TRIM FIXED THROUGH CLADDING TO BATTEN

BREATHABLE SARKING TO STUD WALL

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FACTORY FITTED PACKING

BRICK HEADER COURSE UNDER WINDOW

FALL

FLEXIBLE PVC SILL FLAP

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

SECONDARY FLASHING AS PER WINDOW MANUFACTURER BRICK FLASHING

WEEPHOLE TO BRICKWORK, AS REQUIRED

RENDERED BRICKWORK STUD WALL

STUD WALL

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

HARDIE FLEX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

HARDIE FLEX CLADDING WINDOW / BRICK SILL

SHEET:

I8C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I8C - HARDIE FLEX CLADDING - WINDOW / BRICK SILL

BREATHABLE SARKING TO STUD WALL 90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX.

'HARDIEFLEX' CLADDING FIXED TO BATTENS 2.8x40mm FIBRE CEMENT NAIL

HARDIE JOINT SEALANT TO JUNCTION

INTERNAL LINING

STUD WALL

FALL

BRICK FLASHING HEADER COURSE

25 WEEPHOLE TO BRICKWORK, AS REQUIRED

EXTERNAL BRICKWORK

HORIZONTAL BRICK JUNCTION SCALE 1:5

90 x 35 MGP10 TIMBER BATTENS @600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL

INTERNAL LINING STUD WALL

FLASHING

HARDIEFLEX CLADDING FIXED TO BATTENS 42x42mm LOSP TRIM FIXED THROUGH CLADDING TO BATTEN EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION I8D - HARDIE FLEX CLADDING BRICK JUNCTION DETAILS ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

SECTION:

I - CLADDING

DETAIL:

HARDIE FLEX CLADDING BRICK JUNCTION DETAILS

SHEET:

I8D

AMENDMENT AMM #:

HARDIE FLEX CLADDING

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

INTERNAL LINING STUD WALL

BREATHABLE SARKING TO STUD WALL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

2.8x40mm FIBRE CEMENT NAIL WITH CONTINUOUS BEAD OF HARDIE JOINT SEALANT BEHIND CLADDING

HARDIE JOINT SEALANT TO JUNCTION

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX. HARDIE MATRIX CLADDING FIXED TO BATTENS

EXTERNAL CORNER SCALE 1:5

INTERNAL LINING STUD WALL

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX. APPLY CONTINUOUS BEAD OF JAMES HARDIE SEALANT TO INTERNAL CORNERS OF BATTENS STUD WALL

2.8x40mm FIBRE CEMENT NAIL WITH CONTINUOUS BEAD OF HARDIE JOINT SEALANT BEHIND CLADDING

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

HARDIE MATRIX CLADDING FIXED TO BATTEN BREATHABLE SARKING TO STUD WALL

INTERNAL CORNER SCALE 1:5

MATRIX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

MATRIX CLADDING - FIXING DETAILS

SHEET:

I9A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I9A - MATRIX CLADDING - FIXING DETAILS

BREATHABLE SARKING TO STUD WALL HARDIE MATRIX CLADDING FIXED TO BATTEN 90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX. VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

42x42mm LOSP TRIM, FIXED THROUGH CLADDING TO BATTEN

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

PVC SILL FLAP

HARDIE MATRIX CLADDING FIXED TO BATTEN

WINDOW HEAD & SILL SCALE 1:5 INTERNAL LINING STUD WALL

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

BREATHABLE SARKING TO STUD WALL

FLASHING TO WINDOW, TO LAP BATTEN

HARDIE MATRIX CLADDING FIXED TO BATTEN

HARDIE JOINT SEALANT TO JUNCTION

WINDOW JAMB SCALE 1:5

MATRIX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

MATRIX CLADDING WINDOW DETAILS

SHEET:

I9B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I9B - MATRIX CLADDING - WINDOW DETAILS

HARDIE MATRIX CLADDING FIXED TO BATTEN

90 X 35 MGP10 TIMBER BATTEN @600 CTRS MAX.

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

42x42mm LOSP TRIM, FIXED THROUGH CLADDING TO BATTEN

6 9

BREATHABLE SARKING TO STUD WALL

6 9

BREATHABLE SARKING TO STUD WALL

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FACTORY FITTED PACKING

FALL

BRICK HEADER COURSE UNDER WINDOW

FLEXIBLE PVC SILL FLAP

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

FALL

BRICK FLASHING

WEEPHOLE TO BRICKWORK, AS REQUIRED STUD WALL

STUD WALL

RENDERED BRICKWORK

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

MATRIX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

MATRIX CLADDING WINDOW / BRICK SILL

SHEET:

I9C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I9C - MATRIX CLADDING - WINDOW / BRICK SILL

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.

BREATHABLE SARKING TO STUD WALL INTERNAL LINING STUD WALL

FLASHING

HARDIE MATRIX CLADDING FIXED TO BATTEN HARDIE JOINT SEALANT TO JUNCTION EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION SCALE 1:5

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

BREATHABLE SARKING TO STUD WALL

HARDIE MATRIX CLADDING

HARDIE JOINT SEALANT TO JUNCTION

6 9

FALL

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

BRICK FLASHING HEADER COURSE

25 WEEPHOLE TO BRICKWORK, AS REQUIRED

RENDERED MASONRY WALL

RENDERED BRICKWORK HORIZONTAL BRICK JUNCTION

FACE BRICKWORK HORIZONTAL BRICK JUNCTION

SCALE 1:5

I9D - MATRIX CLADDING - BRICK JUNCTION DETAILS MATRIX CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

MATRIX CLADDING - BRICK JUNCTION DETAILS

SHEET:

I9D

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

STUD WALL

INTERNAL LINING STUD WALL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

BREATHABLE SARKING TO STUD WALL

HARDIE OBLIQUE CLADDING FIXED TO BATTENS

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.

42x18mm LOSP

CONTINUOUS BEAD OF JAMES HARDIE JOINT SEALANT

EXTERNAL CORNER SCALE 1:5

INTERNAL LINING STUD WALL

JAMES HARDIE 75X75 COLORBOND CORNER FLASHING

ND 50mm BRAD NAILS AT 300mm VERTICAL CENTRES, 20-50mm FROM EDGE OF PLANKS

STUD WALL

CONTINUOUS BEAD OF HARDIE JOINT SEALANT TO ALUMINIUM PROFILE

2mm CLEARANCE FROM CLADDING PLANKS TO ALUMINIUM PROFILE

HARDIE OBLIQUE CLADDING FIXED TO BATTENS HARDIE 14mm ALUMINIUM INTERNAL CORNER PROFILE

INTERNAL CORNER SCALE 1:5

OBLIQUE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

OBLIQUE CLADDING - FIXING DETAILS

SHEET:

I10A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I10A - OBLIQUE CLADDING - FIXING DETAILS

BREATHABLE SARKING TO STUD WALL HARDIE OBLIQUE CLADDING FIXED TO BATTENS 90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

HARDIE 35mm CAVITY VENT STRIP ND 50mm BRAD NAILS AT 300mm VERTICAL CENTRES, 20-50mm FROM EDGE OF PLANKS

18x42mm LOSP TRIM, FIXED THROUGH CLADDING TO BATTEN

6 20

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

FLEXIBLE PVC SILL FLAP

19x42mm LOSP TRIM, FIXED THROUGH CLADDING TO BATTEN ND 50mm BRAD NAILS AT 300mm VERTICAL CENTRES, 20-50mm FROM EDGE OF PLANKS

FLASHING OVER BREATHABLE SARKING TO STUD WALL

HARDIE OBLIQUE CLADDING FIXED TO BATTENS

INTERNAL LINING STUD WALL

WINDOW HEAD & SILL SCALE 1:5 INTERNAL LINING

METAL FLASHING

STUD WALL

90 X 35 MGP10 TIMBER BATTENS @600 CTRS MAX. BREATHABLE SARKING TO STUD WALL

HARDIE OBLIQUE CLADDING FIXED TO BATTENS

CONTINUOUS BEAD OF HARDIE JOINT SEALANT TO JUNCTION

ND 50mm BRAD NAILS AT 300mm VERTICAL CENTRES, 20-50mm FROM EDGE OF PLANKS, WITH CONTINUOUS BEAD OF HARDIE SEALANT TO BATTEN

18x42mm LOSP TRIM, FIXED THROUGH CLADDING TO BATTEN

WINDOW JAMB I10B - OBLIQUE CLADDING - WINDOW DETAILS OBLIQUE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

OBLIQUE CLADDING WINDOW DETAILS

SHEET:

I10B

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

HARDIE OBLIQUE CLADDING FIXED TO BATTENS

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

HARDIE 35mm CAVITY VENT STRIP

ND 50mm BRAD NAILS AT 300mm VERTICAL CENTRES, 20-50mm FROM EDGE OF PLANKS

6 20

BREATHABLE SARKING TO STUD WALL

6 20

BREATHABLE SARKING TO STUD WALL

19x42mm LOSP TRIM, FIXED THROUGH CLADDING TO BATTEN

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FACTORY FITTED PACKING

FLEXIBLE PVC SILL FLAP

FALL

BRICK HEADER COURSE UNDER WINDOW SECONDARY FLASHING AS PER WINDOW MANUFACTURER

SECONDARY FLASHING AS PER WINDOW MANUFACTURER BRICK FLASHING

WEEPHOLE TO BRICKWORK, AS REQUIRED

RENDERED BRICKWORK STUD WALL

STUD WALL

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE BRICKWORK SCALE 1:5

SCALE 1:5

OBLIQUE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

OBLIQUE CLADDING WINDOW / BRICK SILL

SHEET:

I10C

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I10C - OBLIQUE CLADDING - WINDOW / BRICK SILL

90 x 35 MGP10 TIMBER BATTENS @ 600CTRS MAX.

BREATH SARKING TO STUD WALL INTERNAL LINING STUD WALL

FLASHING

HARDIE OBLIQUE CLADDING FIXED TO BATTEN HARDIE JOINT SEALANT TO JUNCTION EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION SCALE 1:5

JAMES HARDIE OBLIQUE CLADDING

90 x 35 MGP10 TIMBER BATTENS @600CTRS MAX.

CAULKING TO JUNCTION

MIN. 1DEG FALL

BREATHABLE SARKING TO OUTSIDE STUD FRAME

RENDERED BRICKWORK

DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

BREATHABLE SARKING TO OUTSIDE STUD FRAME DAMP PROOF FLASHING DISCHARGING TO WEEPHOLES

WEEPHOLE

STUD WALL

HORIZONTAL BRICK JUNCTION (EXPOSED BRICKWORK)

HORIZONTAL BRICK JUNCTION (RENDERED BRICKWORK)

SCALE 1:5

I10D - OBLIQUE CLADDING - BRICK JUNCTION DETAILS OBLIQUE CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

OBLIQUE CLADDING - BRICK JUNCTION DETAILS

SHEET:

I10D

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

HEADER COURSE

UP TO 1M MAX

HEADER COURSE

UP TO 1M MAX

MIN. 1DEG FALL

INTERNAL LINING STUD WALL

NAILS FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @450CTRS MAX.

50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD 42x42mm LOSP TRIM

75X75 COLORBOND CORNER FLASHING 'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS 'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING)

INTERNAL CORNER SCALE 1:5

IMPORTANT NOTES: > ALL APPLIED COATINGS MUST BE OIL-BASED >INITIAL COATINGS OF STAIN OR PAINT MUST BE APPLIED PRIOR TO INSTALLATION, AND TO COVER ALL FACES OF BOARDS INCLUDING ANY CUT EDGES, AND BUTT/END-MATCHED JUNCTIONS. >ALL END-MATCHED JOINTS ARE TO BE SEALED WITH A SUITABLE EXTERIOR SEALANT. ANY EXCESS IS TO BE CAREFULLY REMOVED WITH A CLEAN BLADE, ONCE FULLY DRIED >ALL BOARDS TO BE CUT 2mm CLEAR OF JUNCTION WITH LOSP TRIMS, AND SEALED WITH 'INSTYLE' FOAM TAPE AND A CONTINUOUS BEAD OF SUITABLE SEALANT

'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS

90 x 35 MGP10 TIMBER BATTENS @450CTRS MAX.

BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING)

INTERNAL LINING STUD WALL

NAIL FOR BATTEN FIXING

50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

75X75 COLORBOND CORNER FLASHING

90x42mm LOSP TRIM

'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS

EXTERNAL CORNER SCALE 1:5

'INSTYLE CLASSIC' CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

'INSTYLE' CLASSIC - FIXING DETAILS

SHEET:

I11A

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I11A - 'INSTYLE' CLASSIC - FIXING DETAILS

BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING) 'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS 90 X 35 MGP10 TIMBER BATTEN @450 CTRS MAX. VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER 50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS 42x42mm LOSP TRIM

NOM. 5mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

O/A DEPTH NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

A&L FLASHING TO WINDOW 42x42mm LOSP TRIM

'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS CUT-DOWN BOARD (WHERE REQUIRED) TO BE ADHESIVE FIXED TO BATTEN 'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS

WINDOW HEAD & SILL WITH TRIM SCALE 1:5 VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING

INTERNAL LINING TO STUD FRAME NAIL FOR BATTEN FIXING

90x35mm MGP10 TIMBER BATTENS @450 CTRS MAX. BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING)

50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

42x42mm LOSP TRIM

'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS 'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS

WINDOW JAMB WITH TRIM I11B - 'INSTYLE' CLASSIC - WINDOW DETAILS 'INSTYLE CLASSIC' CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

SHEET:

'INSTYLE' CLASSIC - WINDOW I11B DETAILS AMENDMENT

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING)

'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS

90 X 35 MGP10 TIMBER BATTEN @450 CTRS MAX.

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER

50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS

42x42mm LOSP TRIM

NOM. 5mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

WINDOW HEADER FLASHING

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm FACTORY FITTED PACKING

FACTORY FITTED PACKING

BRICK SILL

BRICK HEADER COURSE UNDER WINDOW

FALL

O/A DEPTH

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

SECONDARY FLASHING AS PER WINDOW MANUFACTURER BRICK FLASHING

WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

SCALE 1:5

WINDOW ABOVE BRICKWORK

SCALE 1:5

'INSTYLE CLASSIC' CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

SHEET:

'INSTYLE' CLASSIC - WINDOW I11C / BRICK SILL AMENDMENT

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I11C - 'INSTYLE' CLASSIC - WINDOW / BRICK SILL

'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS

90 X 35 MGP10 TIMBER BATTEN @450 CTRS MAX.

'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS

90 X 35 MGP10 TIMBER BATTEN @450 CTRS MAX.

50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

'INSTYLE' STARTER STRIP, OR TONGUE CUT FROM BOARD FIXED TO LOWER EDGE OF CLADDING

NOM. 5mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE

NOM. 5mm OPEN JOINT TO ALLOW MOISTURE TO ESCAPE FALL

50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING)

HEADER COURSE

RENDERED MASONRY WALL

STUD WALL

HORIZONTAL BRICK JUNCTION

SCALE 1:5

SCALE 1:5 IMPORTANT NOTES: > ALL APPLIED COATINGS MUST BE OIL-BASED >INITIAL COATINGS OF STAIN OR PAINT MUST BE APPLIED PRIOR TO INSTALLATION, AND TO COVER ALL FACES OF BOARDS INCLUDING ANY CUT EDGES, AND BUTT/END-MATCHED JUNCTIONS. >ALL END-MATCHED JOINTS ARE TO BE SEALED WITH A SUITABLE EXTERIOR SEALANT. ANY EXCESS IS TO BE CAREFULLY REMOVED WITH A CLEAN BLADE, ONCE FULLY DRIED >ALL BOARDS TO BE CUT 2mm CLEAR OF JUNCTION WITH LOSP TRIMS, AND SEALED WITH 'INSTYLE' FOAM TAPE AND A CONTINUOUS BEAD OF SUITABLE SEALANT

INTERNAL LINING STUD WALL NAIL FOR BATTEN FIXING

90 x 35 MGP10 TIMBER BATTENS @450CTRS MAX. BREATHABLE SARKING TO STUD WALL (MIN. 20mm CLEARANCE TO REAR OF CLADDING) 50mm 12G 316 STAINLESS STEEL SCREWS TO EACH BATTEN, THROUGH COUNTERSUNK PRE-DRILLED HOLES IN TONGUE OF BOARD

FLASHING

'INSTYLE CLASSIC' SHIPLAP TIMBER CLADDING BOARDS 'INSTYLE' FOAM TAPE AND SUITABLE SEALANT TO JUNCTIONS 42x42mm LOSP TRIM

VERTICAL BRICK JUNCTION

I11D - 'INSTYLE' CLASSIC - BRICK JUNCTION DETAILS 'INSTYLE CLASSIC' CLADDING ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

'INSTYLE' CLASSIC - BRICK JUNCTION DETAILS

SHEET:

I11D

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

STUD WALL

150 X 25 H3 T.PINE PLINTH (RIPPED TO 75MM WIDE) BATTENS @600 CTRS MAX.

FLASHING

PROPRIETARY C-CHANNEL ABOVE WHERE PERMATIMNER ABUTS A HORIZONTAL SURFACE/CEILING WATHERPROOF MEMBRANE PERMATIMBER CASTELLATED CLADDING C TRIM, ALLOW 1MM THERMAL EXPANSION GAP 75MM EPS CLADDING

VERTICAL BRICK JUNCTION SCALE 1:5

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED TO SARKING

INTERNAL LINING

150 X 25 H3 T.PINE PLINTH (RIPPED TO 75MM WIDE) BATTENS @600 CTRS MAX.

WATHERPROOF MEMBRANE

C TRIM, ALLOW 1MM THERMAL EXPANSION GAP

PERMATIMBER CASTELLATED CLADDING

PROPRIETARY C-CHANNEL ABOVE WHERE PERMATIMNER ABUTS A HORIZONTAL SURFACE/CEILING

WINDOW JAMB WITH TRIM SCALE 1:5

I12 - PERMATIMBER CLADDING

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

PERMATIMBER CLADDING

SHEET:

I12

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

Permatimber detail SCALE 1 : 5

DETAILED STONE FIXING (NOT TO SCALE)

NATURA MOSAIC STONE FACINGS FIXED OVER PROPRIETARY BACKING SHEET

BASE COMMONS BRICKWORK

TWO PART MAPEI ULTRALITE S2 ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE) AS PER MANUFACTURERS RECOMENDATIONS

MAPEI PLANITOP SMOOTH & REPAIR R4 SUBSTRATE TO CREATE FLAT AND LEVEL SURFACE FOR STONE FIXING

NOTE: 100% ADHESIVE COVERAGE TO REAR BACKING OF STONE SHEET AND SUBSTRATE ARDEX WJ 50 WIDE JOINT GROUT BETWEEN STONE FACINGS - MAX 10MM VARIABLE GROUT SPACING BETWEEN STONES

MAPEI PRIMER G OVER SUBSTRATE

NATURA STONE WALL CLADDING GROUTED INSTALLATION

DETAILED STONE FIXING (NOT TO SCALE)

NATURA MOSAIC STONE FACINGS FIXED OVER PROPRIETARY BACKING MESH

BASE COMMONS BRICKWORK

TWO PART MAPEI ULTRALITE S2 ADHESIVE APPLIED WITH FULL TILE COVERAGE, MIN 15MM THICK (RLA MULTIPURPOSE EPOXY HIGH STRENGTH ADHESIVE) AS PER MANUFACTURERS RECOMENDATIONS

MAPEI PLANITOP SMOOTH & REPAIR R4 RENDER SUBSTRATE TO CREATE FLAT AND LEVEL SURFACE FOR STONE FIXING

NOTE: 100% ADHESIVE COVERAGE TO REAR BACKING OF STONE SHEET AND SUBSTRATE

STONE FACINGS TO BE TIGHT FITTED NO GROUT IN BETWEEN SPACINGS

MAPEI PRIMER G OVER SUBSTRATE

NATURA STONE WALL CLADDING TIGHT JOINT INSTALLATION

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

NATIONAL TILES NATURA STONE EXT CLADDING

SHEET:

I13

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I13 - NATIONAL TILES NATURA STONE EXT CLADDING

STUD FRAME

35x50mm VERTICAL TIMBER BATTENS, FIXED TO STUDS VAPOUR BARRIER OVER FRAME

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS 'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

SUITABLE ADHESIVE BEAD APPLIED TO INSIDE OF BATTENS, PRIOR TO FITTING OVER BASES 'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

CTS.

BASE

COVER

FIXING DETAILS

50 MAX.

SCALE 1:5

10mm CLEARANCE TO SOFFIT/CEILING LINING MATERIAL WITH SUITABLE EXTERIOR GRADE CAULKING TO JUNCTION BETWEEN PLYWOOD CLADDING SUBSTRATE AND SOFFIT/CEILING LINING

'DECOBATTEN ECE4040-2P' 40x40mm BATTEN END CAP NOTE: END CAPS TO BE INSTALLED PRIOR TO INSTALLATION OF BATTENS

300 NOM.

'DECOBATTEN DB03-40' 40x40mm BATTEN COVER 'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

VERTICAL 35x50mm TIMBER BATTENS FIXED TO STUDS

FIXING CENTRES

BEAD OF SUITABLE ADHESIVE APPLIED TO CLIPS ON INSIDE OF END CAPS, PRIOR TO FITTING OVER BATTEN ENDS

VAPOUR BARRIER OVER FRAME STUD FRAME

CEILING/SOFFIT ABUTMENT I14A - DECOBATTEN 40mm - FIXING DETAILS

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

DECOBATTEN 40mm - FIXING DETAILS

SHEET:

I14a

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

35x50mm VERTICAL TIMBER BATTENS, FIXED TO STUDS 70x35mm VERTICAL TIMBER BATTEN, FIXED TO STUD AT INTERNAL CORNER 2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS VAPOUR BARRIER TO STUD FRAME

SUITABLE ADHESIVE BEAD APPLIED TO INSIDE OF BATTENS, PRIOR TO FITTING OVER BASES

INTERNAL LINING

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE 'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

INTERNAL CORNER SCALE 1:5

VAPOUR BARRIER TO STUD FRAME INTERNAL LINING

35x50mm VERTICAL TIMBER BATTENS, FIXED TO STUDS

70x35mm VERTICAL TIMBER BATTEN, FIXED TO STUD AT EXTERNAL CORNER SCREW HEIGHTS AT CORNERS TO BE ADJUSTED TO AVOID CONTACT

'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

SUITABLE ADHESIVE BEAD APPLIED TO INSIDE OF BATTENS, PRIOR TO FITTING OVER BASES

EXTERNAL CORNER I14B - DECOBATTEN 40mm - CORNER DETAILS

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

DECOBATTEN 40mm CORNER DETAILS

SHEET:

I14b

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:5

STUD FRAME

VERTICAL 35x50mm TIMBER BATTENS FIXED TO STUDS

'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

VAPOUR BARRIER OVER FRAME

'DECOBATTEN ECE4040-2P' 40x40mm BATTEN END CAP NOTE: END CAPS TO BE INSTALLED PRIOR TO INSTALLATION OF BATTENS, ABOVE WINDOWS

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

SUITABLE ADHESIVE BEAD APPLIED TO CLIPS ON INSIDE OF END CAPS, PRIOR TO FITTING OVER BATTEN ENDS

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

NOM. 6mm OPEN JOINT FOR MOISTURE EGRESS VISCOURSE FLASHING AS PROVIDED BY WINDOW MANUFACTURER

WINDOW RUBBER OVER END CAP, CAULKED TO SUIT 'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

WINDOW FLASHING TO RETURN DOWN FRAME OVER VAPOUR BARRIER

VERTICAL 35x50mm TIMBER BATTENS FIXED TO STUDS

'DECOBATTEN ECE4040-2P' 40x40mm BATTEN END CAP NOTE: END CAPS TO BE INSTALLED PRIOR TO INSTALLATION OF BATTENS, ABOVE WINDOWS

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

VAPOUR BARRIER OVER FRAME

WINDOW HEAD & SILL WITH END CAPS SCALE 1:5

INTERNAL LINING VAPOUR BARRIER TO STUD FRAME

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS 'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

SUITABLE ADHESIVE BEAD APPLIED TO INSIDE OF BATTENS, PRIOR TO FITTING OVER BASES

CAULKING

'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

35x50mm VERTICAL TIMBER BATTENS, FIXED TO STUDS

SCALE 1:5

I14C - DECOBATTEN 40mm - WINDOW DETAILS

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

DECOBATTEN 40mm WINDOW DETAILS

SHEET:

I14c

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

VISCOURSE FLASHING SUPPLIED BY WINDOW MANUFACTURER AND FIXED OVER VAPOUR BARRIER

WINDOW JAMB WITH TRIM

VAPOUR BARRIER OVER FRAME

VERTICAL 35x50mm TIMBER BATTENS FIXED TO STUDS

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHERRESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

STUD FRAME

'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

'DECOBATTEN ECE4040-2P' 40x40mm BATTEN END CAP NOTE: END CAPS TO BE INSTALLED PRIOR TO INSTALLATION OF BATTENS, ABOVE WINDOWS

SUITABLE ADHESIVE BEAD APPLIED TO CLIPS ON INSIDE OF END CAPS, PRIOR TO FITTING OVER BATTEN ENDS

NOM. 6mm OPEN JOINT FOR MOISTURE EGRESS

VISCOURSE FLASHING AS PROVIDED BY WINDOW MANUFACTURER

NOTE: OVERALL FACE OF WINDOW TO EDGE OF REVEAL SIZES; 70mm STUD - 143mm 90mm STUD - 163mm

FACTORY FITTED PACKING

RAKED RENDER BENEATH WINDOW SILL

FACTORY FITTED PACKING

FALL

BRICK HEADER COURSE UNDER WINDOW

FALL

10mm CLEARANCE BETWEEN FRAME AND SILL 10mm CLEARANCE BETWEEN FRAME AND SILL

SECONDARY FLASHING AS PER WINDOW MANUFACTURER

BRICK FLASHING

WEEPHOLE ON BRICK

BRICK FLASHING WEEPHOLE ON BRICK

WINDOW ABOVE RENDERED BRICKWORK

WINDOW ABOVE FACE BRICKWORK SCALE 1:5

SCALE 1:5

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

I - CLADDING

DECOBATTEN 40mm WINDOW / BRICK SILL

SHEET:

I14d

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

I14D - DECOBATTEN 40mm - WINDOW / BRICK SILL

STUD FRAME INTERNAL LINING

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE SUITABLE ADHESIVE BEAD APPLIED TO INSIDE OF BATTENS, PRIOR TO FITTING OVER BASES 'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

FLASHING

3mm GAP, BACKFILLED WITH SUITABLE EXTERIOR GRADE CAULKING TO JUNCTION BETWEEN SUBSTRATE AND BRICKWORK

35x50mm VERTICAL TIMBER BATTENS, FIXED TO STUDS 5mm (NOM.) CLEARANCE BETWEEN LAST BATTEN BASE AND FACE BRICKWORK (OR RENDER FINISH IF APPLICABLE)

EXTERNAL BRICKWORK

VERTICAL BRICK JUNCTION SCALE 1:5

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

2/6mm MARINE PLYWOOD SUBSTRATE, PAINTED WITH SUITABLE WEATHER-RESISTANT EXTERIOR PAINT PRIOR TO FIXING OF BATTENS OR BRACKETS

35x50mm VERTICAL TIMBER BATTENS, FIXED TO STUDS

'DECOBATTEN DB03-40' 40x40mm BATTEN COVER

GAP BACKFILLED WITH SUITABLE EXTERIOR GRADE CAULKING TO JUNCTION BETWEEN SUBSTRATE AND BRICKWORK

'DECOBATTEN 40mm BATTEN BASE' SCREW FIXED TO PLYWOOD SUBSTRATE

FALL

HEADER COURSE

RAKED RENDER TO TOP EDGE OF BRICKWORK

STUD FRAME

RENDERED MASONRY WALL

HORIZONTAL BRICK JUNCTION (BRICK SILL)

HORIZONTAL BRICK JUNCTION (RENDERED BRICK SILL)

SCALE 1:5

I14E - DECOBATTEN 40mm - BRICK JUNCTION DETAILS

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

I - CLADDING

DETAIL:

DECOBATTEN 40mm - BRICK JUNCTION DETAILS

SHEET:

I14e

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

STUD FRAME

BOTTOM PLATE

10mm PLASTERBOARD

92x18mm PRIMED MDF COVERPLATE TO PLASTER JOIN

J1A - STAIRCASE - PLASTERBOARD COVERPLATE SCALE 1:2

POST STRINGERS TREAD

STUD FRAMING

J1B - STAIRCASE - FRAME-OUT SCALE 1:10 ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

J - STAIRCASE

DETAIL:

STAIRCASE FRAME-OUT

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

10mm PLASTERBOARD

1980

INLET FROM DOWNPIPE 90MM PVC NOTE: INLET SIDE MAY BE INTERCHANGEABLE

EXTERNAL GPO FOR PUMP CONNECTION

500

750

2NO. WATER POINTS FOR MAINS BACKUP

TANK & PUMP ON SLAB (900MM WIDE), 100MM ABOVE HOUSE REBATE

2040

OVERFLOW TO STORMWATER

PUMP & COVER

3000

K1 - POLY WATER TANK SETUP (2000L SLIMLINE) - W 650MM X L 2040MM X H 1980MM SCALE 1:25

2000L Slimline with Pump & Cover 3200L Slimline with Pump & Cover 4000L Slimline with Pump & Cover 5000L Slimline with Pump & Cover

TANK SIZE 2040L x 650W x 1980H 2650L x 810W x 2050H 2750L x 810W x 2050H 2900L x 1000W x 2200H

ORBIT HOMES AUSTRALIA PTY. LTD.

3000L x 900W 3700L x 1100W 3700L x 1100W 3900L x 1250W

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SECTION:

K - SITE

WATER TANK - POLY

SHEET:

AMENDMENT AMM #:

CONC PAD SIZE

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

CAPACITY

INLET FROM DOWNPIPE 100MM PVC NOTE: INLET SIDE MAY BE INTERCHANGEABLE 2NO. WATER POINTS FOR MAINS BACKUP

1860

1970

EXTERNAL GPO FOR PUMP CONNECTION

TANK ON SLAB (900MM WIDE) 100MM ABOVE HOUSE REBATE

OVERFLOW TO STORMWATER

1700 2600

K2 - STEEL WATER TANK SETUP - SUBMERSIBLE PUMP (2000L SLIMLINE) - W 700MM X L 1700MM X H 1860MM SCALE 1:25

2000L Slimline with Submersible Pump 3000L Slimline with Submersible Pump 4000L Slimline with Submersible Pump 5000L Slimline with Submersible Pump

TANK SIZE 700W x 1700L x 1860H 700W x 2500L x 1860H 1000W x 2400L x 1860H 1150W x 2600L x 1860H

ORBIT HOMES AUSTRALIA PTY. LTD.

2600L x 900W 3400L x 900W 3300L x 1200W 3500W x 1350W

DETAIL BOOK DETAIL:

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

SECTION:

K - SITE

WATER TANK - STEEL

SHEET:

AMENDMENT AMM #:

CONC. PAD SIZE

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

CAPACITY

1000

CLEARANCE FROM ANY DOOR, OPENABLE WINDOW, MECHANICAL AIR INLET OR ANY OTHER OPENING INTO A BUILDING

EITHER SIDE 1000

MIN. 500 CLEAR

1500 MIN.

1000

GAS METER

MIN. 500 CLEAR

TELSTRA

100

500

EARTH STAKE

DP 100 MIN.

300 MIN

330

K3B - CLEARANCE TO EARTH, TELSTRA & D/P

K3A - CLEARANCE TO OPENINGS SCALE 1:25

SCALE 1:25

GAS METER

K3C - CLEARANCE TO ELECTRICAL METER BOX SCALE 1:25

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

K - SITE

DETAIL:

GAS METER CLEARANCES

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

300 MAX.

2100 MAX. METER BOX UPPER EDGE HEIGHT

1220 PREFERRED METER BOX LOWER EDGE HEIGHT

MIN. CLEARANCE TO BOTTOM OF METER BOX

50 0

MIN. CLEARANCE OFF WALL IF LOCATED DIRECTLY UNDER ELECTRICAL METER BOX

2000 MAX. HEIGHT OF MAIN SWITCH WITHIN METER BOX

METER BOX

AMM #:

TYPE:

SECTION:

DETAIL:

WATER TANK ROUGH IN

DRAWN:

Left hand side of tank option

K - SITE

SHEET:

AMENDMENT

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

Evolution MkIV default position is High Flow default position is 6

UNLESS SPECIFIED

600

<300

270

Varies

Mains water inlet to tank Rainwater to dwelling

I/O

Varies

PLAN VIEW TYPICAL

REFER TO PLAN

250

100mm Charge Line

380

SIDE ELEVATION TYPICAL

100mm Overflow

45o

Varies

PERSPECTIVE VIEW

Right hand side of tank option

100mm Overflow

Varies Ground level

100mm Charge Line

Drain rough ins within 300mm from edge of slab

Varies

100

Rainwater Tank Height

FRONT ELEVATION OPTION A

Evolution MkIV

100mm Overflow

100mm Charge Line

Ground level

Concrete slab

Offsets from edge of slab Single weatherproof power point Top of the slab to inlet/outlet

K4 - ROUGH IN SLIMLINE AND MODLINE TANK

250

VARIES

286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au 250

ORBIT HOMES AUSTRALIA PTY. LTD.

DETAIL BOOK

ALTERNATE METERBOX BOTTOM EDGE HEIGHTS HEIGHT ABOVE REBATE 1048mm 1134mm 1220mm 1306mm

BRICK COURSE NO. 12 13 14 15

NOTES

PREFERRED DIMENSION TOP EDGE OF METERBOX MUST NOT BE >2000mm ABOVE REBATE

NOTE: IF ALTERNATE HEIGHTS ARE SELECTED, THEY ARE TO BE IN 86mm INCREMENTS OF THE HEIGHTS NOMINATED IN THIS TABLE

TO FRONT OF HOME (FLIP DETAIL AS REQUIRED)

NBN RUN-IN TO HOME NBN PCD (LOCATION AS PER PLANS)

LINTEL ABOVE METER BOX

NBN RUN-IN TO PCD STUD FRAMING

METER BOX LOWER EDGE HEIGHT

ELECTRICAL RUN-IN TO METER BOX 1220 PREFERRED (REFER TO TABLE)

2000 MAX.

HEIGHT OF MAIN SWITCH WITHIN METER BOX

2100 MAX.

ELECTRICAL METER BOX (LOCATION AS PER PLANS)

MIN. CLEARANCE FROM GAS METER TO BOTTOM OF METER BOX

500

GROUND FLOOR FFL

METER BOX UPPER EDGE HEIGHT

ELECTRICAL RUN-IN TO HOME

GAS METER (LOCATION AS PER PLANS) GAS SERVICE INLET TO HOME (RHS OF ELECTRICAL METERING) TO ENTER FRAME ABOVE BOTTOM PLATE

FGL AT BUILDING PLATFORM/PAVING (REBATE HEIGHT)

GAS RUN-IN TO METER

SLAB REBATE

K5 - SERVICES RUN IN LOCATIONS (AT METERING)

ORBIT HOMES AUSTRALIA PTY. LTD. 286 MT ALEXANDER ROAD ASCOT VALE. 3032 TEL: (03) 9377 0000 FAX: (03) 9375 4632 www.orbithomes.com.au

DETAIL BOOK

K - SITE

DETAIL:

SERVICES RUN-IN LOCATIONS (AT METERING)

SHEET:

AMENDMENT AMM #:

SECTION:

TYPE:

DRAWN:

DATE:

DETAIL BOOK - ISSUE 004. - JUNE 2026 - PAT

SCALE 1:25

ORBITHOMES.COM.AU | 1300 ORBITHOMES | 1300 672 484

ORBIT HOMES AUSTRALIA PTY LTD • CDB –U 50505 DISCLAIMER: Images shown in this brochure may depict fixtures, finishes and features not included or supplied by Orbit Homes such as (but not limited to) upgraded flooring, feature materials, decorative lighting, artwork and furniture. Suppliers, makes and models may be changed or withdrawn at any time. For more information and full details please speak with your Orbit Homes New Homes Sales Professional.
