Australia’s 3000 EV charging points

With a country that is almost 8 million square kilometres how many charging points are needed for EVs?

The Australian Government has now embraced EVs and is enabling their future use by the release of their Low Emissions Technology Statement 2021, where they specified ‘Enabling Infrastructure’ as a key category. Their plan is to invest in infrastructure that will allow the widespread delivery of low emission energy to the commercial and residential sectors. Currently Australia has just over 3000 EV public charging points to cover 7.692 million square kilometres and of those 2531 are AC standard and 470 are DC supercharge with most located in New South Wales. They are to service the .78 percent of new cars that are EVs. The world average is 4.2 percent, we are lagging well behind even the US has 2.3 percent. Three levels of charging stations are available in Australia.

Level 1/Mode 2: The at-home charging station

This is like plugging in any other electrical device at home, but with a special cable. It uses 10-15 Amp, single-phase power and delivers 1.4kW – 2.4kW. This will ‘top up’ any kilometres used from a small trip (10-20 km) but won’t fully charge your battery. This charging method will also be useful on destination trips if no other charging points are available.
