VPX PLUS™ Design | Test | Deploy Meritec’s VPX PLUS™ is today’s most versatile VPX MULTIGIG RT compatible cabling system, allowing users to access and expand upon the traditional VPX backplane. When bringing out VITA 46 and Open VPX I/O, developers can utilize eSATA, Display Port, USB, Serial Rapid I/O, InfiniBand, Ethernet, Meritec’s HERCULES® and other MIL-38999 connectors. Meritec’s VPX Plus System, along with its I/O capabilities, is designed for full bandwidth testing and can be adapted for deployment. The standard VPX cabling terminology applies to Meritec’s VPX Plus cabling system. Fat pipes, thin pipes, ultra-thin pipes are all available in multiple lengths as COTS products; and thanks to Meritec’s unique stacking of wafers, up to eight (8) wafers can be stacked to achieve final results, thus creating a wide variety of development options. Your link to The Xtreme High-Speed Xperts – http://meritec.com/wp-content/flipbooks/vpx-plus/
Visit our newly-designed website http://www.meritec.com for your Direct Connection to the Xtreme High-Speed Xperts!
FEATURES ĄĄ The Meritec VPX Plus is a cost effective and flexible alternative to expensive rear-transition modules. ĄĄ VPX Plus has less electrical losses than both backplane and rear-transition module circuitry. ĄĄ Provides a connection method allowing backplane circuit rerouting with small electrical losses and low investment. ĄĄ Adds functionality and flexibility to any system ĄĄ 6U and 3U housing kits allow you to maintain complete control from test to deployment. ĄĄ Deployment rails, supplied with capped screws, enhance the ruggedness and security of the system when deployed into real-world environments ĄĄ COTS and standard pricing ĄĄ Made In The USA vita.opensystemsmedia.com/p372490
Meritec
www.meritec.com
www.facebook.com/pages/Meritec/142140812492429
www.linkedin.com/company/meritec-inc.
888-MERITEC (637-4832) info@meritec.com
VPX
6U VPX – 700 Watt AC/DC Power Supply NAI’s VPX56-6 power supply supports VITA 46.0 and VITA 65 systems with an off-the-shelf solution. The 700-Watt AC/DC power supply plugs directly into a standard 6U VPX chassis with a VITA 62 power supply slot (1.0” slot).
FEATURES ĄĄ Ideal for rugged 6U VPX power applications
The conduction-cooled VPX56-6 accepts both a 3Ø AC or +270Vdc input compliant with the input transients of MIL-STD-704F. It provides six outputs and I/O per the VITA 62 standard.
ĄĄ Standard VPX-compatible connectors and I/O per VITA 62
The COTS power supply is specifically designed with NAVMAT component derating for rugged defense and industrial applications. It is also designed to meet the many harsh environmental requirements of military applications.
ĄĄ Operates at full load through the entire -40°C to +85°C
ĄĄ Supports VITA 46.0 and VITA 65 systems ĄĄ Integrated EMI filtering per MIL-STD-461F ĄĄ Input transient protection per MIL-STD-704F
ĄĄ ĄĄ ĄĄ ĄĄ
temperature range Remote error sensing BIT User programmable Current share is available
Made in the USA Certified Small Business
vita.opensystemsmedia.com/p372753
North Atlantic Industries, Inc.
www.naii.com/700-Watt-AC-DC-Power-Supply-6U-VPX/P279 www.vita-technologies.com
www.naii.com 631-567-1100
