Application NVMe Lib
MPI
Socket Switch
User Space SuperSockets
eXpressWare PCIe Software Suite eXpressWare™ software enables Military applications to easily migrate to PCIe Networks using standard PCI Express. It supports a low level direct remote memory access API – SISCI API, a sockets API – SuperSockets™, and SmartIO technology. The SISCI API enables customers to time efficiently exploit the PCIe model. It offers a C programming API for shared/remote memory access, including reflective memory/multi-cast, peer-to-peer memory transfers, RDMA capabilities, and direct support for FPGAs, GPUs, or any combination of communication with FPGAs, CPUs, GPUs or system memory over PCIe. SuperSockets™ enables applications to benefit from a low-latency high throughput PCIe network without any modifications. It delivers maximum application performance without application changes. SuperSockets™ is a unique implementation of the Berkeley Sockets API that capitalizes on the PCIe transport to transparently achieve performance gains for existing socket-based network applications. PCIe SmartIO is a collection of software for PCI Express enabling customers to utilize standard PCIe devices in a new and flexible way. It includes capabilities to share devices and includes features for device lending, hot adding transparent devices and sharing PCIe endpoints. eXpressWare™ is a complete software suite that supports Linux, Windows and VxWorks. Dolphin supports both standard and custom designs.
SISCI - Shared Memory API
Dolphin ICS
Device Driver
SISCI SmartIO
Device Lending
TCP/IP Stack
Windows User SuperSockets
IP-Driver
IRM - Interconnect Resource Manager
IP- Driver
Ethernet Hardware
PCIe Hardware Failover Support
FEATURES Ą PCIe Gen 1, 2, 3, 4 and beyond support Ą Address based Multi-cast/reflective memory Ą Point-to-point and switched network support Ą Low latency direct memory and peer-to-peer transfers Ą Operating systems – Windows, Linux, VxWorks,
and RTX
Ą FPGA and GPU direct memory transfers Ą Microsemi, Broadcom, IDT and Intel NTB support
info@dolphinics.com
603-747-4100
www.linkedin.com/company/dolphin-interconnect-solutions
www.dolphinics.com
Communications
Managed Scalable GigE Switch The LAN35MH08HR is an 8-port 10/100/1000 Managed Ethernet switch. This switch module has a total of 10 ports: eight ports are provided to I/O connectors, one port is available to the host CPU through a x1 PCI Express GigE controller, and one port is used as a stacking switch expansion port allowing full compatibility with RTD’s managed and unmanaged StackNET® Ethernet switch family. Additionally, this allows the CPU to use the switch without the need for external cables. The LAN35MH08HR can also be used as an expandable, standalone 8-port Ethernet switch. The onboard CEServices Carrier Ethernet switching software provides a rich Layer 2 switching solution with Layer 3-aware packet processing. All of the industry-standard Managed Ethernet Switch features found in an enterprise rackmount switch are provided, such as VLANs, Spanning Tree, QoS, and SNMP. Additionally, the CEServices software provides features for carrier and timing-critical networks such as OAM, Synchronous Ethernet, and IEEE 1588. The switch may be configured via a web GUI interface, or a command-line console via USB, Telnet, or SSH.
RTD Embedded Technologies, Inc. www.rtdstacknet.com www.mil-embedded.com
FEATURES Ą -40 to +85°C operation, passively cooled Ą PCIe/104 stackable bus structure Ą Eight 1000/100/10 Mbps Ethernet ports plus one host port and one
stacking switch expansion port
Ą Onboard tri-color LED for each Ethernet Port Ą RJ-45 jacks or 10-pin right-angle headers Ą Fully-managed Layer 2 Ethernet Switch with Layer 3-aware packet
processing • Support for all major Enterprise switching features such as VLANs, Spanning Tree, QoS, and SNMP • Manageable via web GUI interface, SSH, Telnet, and Serial Console • Industry-standard CLI interface Ą Onboard PCI Express Ethernet Controller for interface to host cpuModule Ą USB Device Port for Serial Console command-line interface Ą Available in stackable, rugged enclosures
sales@rtd.com
814-234-8087
MILITARY EMBEDDED SYSTEMS Resource Guide
September 2019 55
Military Embedded Systems Resource Guide
Communications
