Sample Design Concepts, Research and Proposals pt2

Page 1

HASHTAG MARKETING TEAM MAIN

OFFICE

Hashtag Marketing Team is social media advertising and marketing company. It is comprised of three young entrepreneurs who started the company in their living rooms. The company has quickly grown to a near million dollar business which forces them to purchase an office space to improve productivity. Hashtag now has five employees including administration and often contracts out work.

The space will be used to conduct meetings with contractors, clients and collective team assignments, as well as smaller individualized assignments. Since social media platforms are conducive to creative content they are looking for a fresh, bold and inspiring space. The client has requested a very unique, non-traditional office design that includes bright colors and playful furniture.

Since social media freely travels with each account holder the client wants the office to embody that freedom of movement.

Paint Flooring Office Furniture
Design Presentation Board Nickeisha Mustafa
Floor Plan Model

HASHTAG MARKETING TEAM MAIN OFFICE

Hashtag Marketing Team is social media advertising and marketing company. It is comprised of three young entrepreneurs who started the company in their living rooms. The company has quickly grown to a near million dollar business which forces them to purchase an office space to improve productivity. Hashtag now has five employees including administration and often contracts out work.

The space will be used to conduct meetings with contractors, clients and collective team assignments, as well as smaller individualized assignments. Since social media platforms are conducive to creative content they are looking for a fresh, bold and inspiring space. The client has requested a very unique, non-traditional office design that includes bright colors and playful furniture.

Since social media freely travels with each account holder the client wants the office to embody that freedom of movement.

Design Presentation Board Nickeisha Mustafa
Floor Plan Model Office Furniture Paint Flooring

HASHTAG MARKETING TEAM

MAIN OFFICE

INSPIRING CREATIVE PLAYFUL UNIQUE BOLD NON-TRADITIONAL

Concept Board Nickeisha Mustafa

Nickeisha Mustafa

Design Concept

The Design concept was inspired by the Streamline Moderne architecture of Miami Beach.The whimsical curves and metallics paint the scene for a classic, all-American diner. While the bold colors and prints give a taste of tropical paradise.The wallpaper used within the design was the muse for the color palette.The Streamline Moderne buildings of Miami are still vibrant and lively, enticing people to visit which is the same culture that the client wants to cultivate.

Color Palette and Logo

Inspiration

Mood Board

Every material chosen for this design was done with durability, moisture resistance, stain resistance and fire safety in mind. The countertops are solid surfaces that mimic terrazzo. Making them non-porous, seamless, hygienic, water and fire resistant, resistant to etching and renewable. The fabrics are also created for high traffic having 100,000+ double rub ratings while being stain and moisture resistant and having a soft touch. The parquet floor is strong and durable. The wallpaper is a heavy commercial grade with low emitting paste for installation. There are also plastics and metals used in the design that have been powder coated so that the color does not fade or easily chip. All products also have none or low off gas emission. Lastly, care for these products is very simple as it is recommended to use a damp rag with mild soap for them all.

Cabinet Design

Elevation

Floor Plan

¼” = 1’-0”
Coast Cafe and Bakery

RENDERS

ENTRANCE

JUICE BAR

Solid Surface Glass Tile White Oak Paint Glass Shelving and Cabinetry Lounge Chair and Side Table

WALLPAPER INSTALLATION

Paint Window Shades Upholstery Wallpaper Countertop Barstool Table and Chairs

BANQUETTE SEATING

Model: DI-718-TEA

Furniture Specification

www.polyandbark.com $109 9 Counter Height Dining

OceanTeal Molded polypropylene, powder coated metal base and legs

36" H x

18.5" W x

17" D

11 lbs

Poly & Bark

UV-resistant (when not in use, store out of direct sunlight to preserve colorseat), easily wipeable (damp cloth), fade-resistant, indoor/outdoor use, Some light assembly required Sevelti Dining Chair SKU: 12798 Article

www.article.com $79 6- C 4-Y 4-G

Main Dining Coastal Coral (C), Daisy Yellow (Y), Aloe Green (G)

www.knoll.com $10469 4 LoungeArea Diva, Daffodil, Gold

Molded polypropylene, powder coated metal base and legs

34.5" H x

18" W x

20.5" D

UV-resistant (when not in use, store out of direct sunlight to preserve colorseat), easily wipeable (damp cloth), fade-resistant, indoor/outdoor use, Some light assembly required Platner Lounge Chair Knoll

molded fiberglass, molded latex foam cushion, yarn upholstery, plated 18K gold steel rods

10 lbs

30.25” H x

36.5” W x

25.5” D

Certified CleanAir GOLD, features a soil and stain repellent finish and can be cleaned using water-based cleaning products or mild, water-free solvents

Product Manufacturer/ Product Name and SKU-Model Representative Unit Price Quantity Project Location Color/Finish Materials Dimensions/ Weight Ratings/ Maintenance/ Notes Lola 25" Counter Stool

Furniture Specification

Product Manufacturer/ Product Name and Number Representative Unit Price Quantity Project Location Color/Finish Materials Dimensions/ Weight Ratings/ Maintenance/ Notes
SideTable
www.knoll.com $2133 2 LoungeArea Clear, gold Tempered glass, plated 18K
rods 18" H x 15.75" W
15.75" D Certified
Platner
Knoll
gold steel
x
CleanAir GOLD
Lippa 36" Round
EEI-3209-GLD-WHI Modway www.homethreads. com $605 3 Main Dining White, gold Lacquered chip resistant coated top, powder coated metal base. 28.5" H x 35.5" W x 35.5" L Assembly required.
36" Square
Wood DiningTable SKU:
Lippa
Wood DiningTable
Modway www.homethreads. com $595 4 Main Dining White, gold
28.5" H x 35.5" W x 35.5" L Assembly
Lippa 60" Rectangle
DiningTable
EEI-3256-GLD-WHI Modway www.homethreads. com $1060 2 Main Dining White, gold Lacquered chip resistant coated top, powder coated metal base. 29.5" H x 60.0" W x 35.5" L Assembly required.
SKU: EEI-3212-GLD-WHI
Lacquered chip resistant coated top, powder coated metal base.
required.
Wood
SKU:

Product Manufacturer/ Product Name and Number

Roux (1/2") Glass

Unit - 4 shelves

IronAbode

Furniture Specification

Representative Unit Price Quantity Project Location Color/Finish Materials Dimensions/ Weight Ratings/ Maintenance/ Notes

Broadway Color Cabinet SKU: MD-BROADAYCABMW-MFGSE-BGBG

Minerva Custom

Olive-LED Prudential Lighting

www.ironabode.com $1652 2 Juice Bar Light brass, clear Powder coated steel, tempered glass

74.5” H x

26” W

15.5” D

Wall mounted but stabilized on a countertop, 2 year warranty, can hold up to 200 lbs

KUSHI - Opal glass pendant lamp Kdln

www.minervabeauty. com $2699 TBA Juice Bar Matte white, brushed gold Laminate 38.5" H x

39.5" W x

24" D

1 year warranty, minor assembly required

www.prulite.com TBA 7 Main Dining White, black semi-gloss Acrylic, metal 5” H x

37” W x

37” L

5 year warranty, surface mount, monopoint mounting, adjustable aircraft cable, top-swivel stem mount

www.kdln.it TBA 9 Juice Bar, Counter Height Dining

White, black Mouth blown glass, metal 16” suspension 26” H x 16” D

220-240/120V w/ dimmer Class 1, IP20, CE, EAC, ETL

MIAW - Muuuz International Awards

Vitality Wallpaper Mural SKU: X10434

Ever Wallpaper

Textile Specification

Manufacturer/ Product Name and Number Representative Unit Price Quantity Product Location Color/Finish Materials Dimensions/ Weight Ratings/ Maintenance/ Notes
Product
$735 1 South wall of dining area Heavy 13’5” Lx 8” H Proprietary blend
Filtering
Shade
motorized Select
com Starting at $163 2- 4’ 4- 6’ 1- 8’9” 1- 11’9” All Windows Amalfi Chocolate Polyester 4’W x 6’H
www.everwallpaper. co.uk
of untoxic and recyclable content, clean with lightly wet sponge, compatible with many surfaces, glue required, easily removable Designer Light
Dual
-
Blinds www.selectblinds.
H
6’W x 6’
6’H
8’9”W x
W x 6’H
Hall Parquet Flooring
Hardwoods
$12,363 at $7.50 per sq ft 39 boxes Entire Space White Oak White Oak with mesh backing or taped face 14 1/4" x 14 1/4" 5/16thThickness Glue down method for installation
Peach
Glass
Tile SKU: TCNB88PK226A
Club www.tileclub.com $21.41 per sq ft TBD Juice Bar, Lounge Area, North Wall Peach Pink Glass 11.6” x 11.6" Thickness: 1/4" Paper facing mounting
11’9”
Haddon
PRHHAD-WO Hurst
www.hursthardwoods .com
Pearly
Squares
Pool
Tile

Everform Solid Surface 505 Formica

Textile Specification

www.formica.com TBD 5 slabs Juice Bar Food Counter

Sea Glass Laminate Juice Bar: 4’Lx 3’D

9’11”’Lx 3’D (curved)

15’8” Lx 2’D

Food Counter: 13’3’Lx 3’D

(curved)

Backsplash: 18’8” Lx 5’H

www.formica.com TBD 2 slabs Counter Height Dining

White Sparkle Laminate 13’5” Lx 1’4” D 10’6” Lx 1’4” D

10 year warranty, GreenGuard

Certificate of Compliance Gold, LEED certified, clean with damp cloth and mild soap Everform Solid Surface 778 Formica

10 year warranty, GreenGuard

Certificate of Compliance Gold, LEED certified, clean with damp cloth and mild soap Abstract Collage Fabric 7714003 Spoonflower

www.spoonflower.com $31.20 per yard

TBD Banquette Seating Multi Celosia Velvet 54" x 36” yd 9.2 oz per sq yard

Non-optic white

Estimated shrinkage: 2-3% in length and 1-2% in width

Product Manufacturer/ Product Name and Number Representative Unit Price Quantity Project Location Color/Finish Materials Dimensions/ Weight Ratings/ Maintenance/ Notes

Textile Specification

Product Manufacturer/ Product Name and Number Representative Unit Price Quantity Project Location Color/Finish Materials Dimensions/ Weight Ratings/ Maintenance/ Notes Hollywood Gold 279 Benjamin Moore www.benjaminmoore. com TBD Window sash Hollywood Gold Paint N/A LRV=40.45 Bashful Blue
www.benjaminmoore. com TBD Juice Bar Food Counter area Bashful Blue Paint N/A LRV=74.02 Warm Blush 892 Benjamin Moore www.benjaminmoore. com TBD Main Dining Ceiling Warm Blush Paint N/A
2065-70 Benjamin Moore

Systems Furniture Research, Design and Proposal

Space Plan

Open Office

Conference Room

Furniture Systems

Knoll Antenna Big Table Workstations with Storage and Interpoles to power devices (used for desk, conference and research tables)

30-84"W 18-48"D 27-30"H (Adjustable Height)

Verity Lounge Chair

(Employee Lounge)

20.75"W x 21"L x 16"H

Davenport 110" Fabric L-Corner Sofa Sectional

(Employee Lounge)

109.5"W x 118.6"D x 29.9"H

Furniture Systems

Catellani & Smith Lederam Manta S2 (Entire Office)

Herman Miller Noguchi Table (Employee Lounge)

50″W x 36″D x 15.75″H

Vesper Fabric Lounge Chair with Ottoman (Closed Offices)

29.5” L x 29.5” W x 30” H

Sabala Standard Bookcase

(Research Center)

75.50'' H X 31.5'' W X 16'' D

The design was inspired by a luscious, thriving forest. The Forest concept was captured through the rich forest green color and ample hardwood throughout. The gold features took the design in a more luxurious direction rather than a rustic style that would typically be associated with the forest. The organic shapes found in the light fixture and some furniture were also inspired by various life forms that grow on the forest floor like mushrooms. Comfort, beauty, and function were the central focus of the design. Offices are spaces where many individuals spend a large portion of their day. This realization encouraged me to create a space where people like to be and feel safe, at peace, and comfortable. Nature helps people feel well while encouraging focus, additionally, the color green is considered to be the most peaceful color. As for care and performance; microfiber is easy to clean, durable, and soft to the touch. Natural hardwood and quartz that resembles marble do not emit off-gases and does not require much upkeep. Darker hardwood on the ceiling helps to control glare that can occur from different materials like glass and metallic metals exposure to the sun in the space. Glass glazing panels were used to provide privacy in the conference room and closed offices when needed. Ample storage space is provided along the long wall in the research center. Lastly, the entire design was created with daylighting in mind to conserve energy. Every space is configured to receive ample sunlight in the hope to eliminate the need for artificial light during the day.

WINTHROP

600

FAMILYMEDICALCENTER IAD

By:

Index

Client

Inspiration

Community of Winthrop

Project Site

Concept Statement

Egress Plan

Design Process

Rendered Furniture

Plan

Interior Elevations and Perspective Drawings

FF&E Key Images

Materials Board

Specifications

Dr. Janice Rockefeller is working with the Health Resources and Service Administration (HRSA) to open a small family medical practice in Little River County,Arkansas.

DR. JANICE ROCKEFELLER

WHY

Dr. Rockefeller hopes to assist the community of Winthrop and the small town within driving distance. She is originally from Missouri and in 1960 her distant cousin, Winthrop Rockefeller, served as governor of Arkansas.

DESIRES

She desires a contemporary medical office with a feeling of comfort for her patients. “Furnishings need to reflect the competence of her practice. She admires the tall ceilings (11'-0") in the former school and does not want to destroy their character or cover them up with a lay-in ceiling. She is sensitive to glare”.

WINTHROP

LITTLE ROCK COUNTY

Once a thriving and continuously growing town due to the development of the railroad. Now, much of this rural area is home to many elderly citizens whom have been designated by HRSAas a Medically UnderservedArea and Population (MUA/P).Atown that desperately needs caring for. With the towns agreement to allow a small medical firm to use half of the lower portion of the old elementary school, that care will be

ARKANSAS

The Beginning

The Winthrop School building was constructed for a bustling population’s needs. It is indeed a significant piece of this town's history.The Winthrop School came at this town's most thriving moments and sustained them at its lowest moments. It is a central hub for the town.

Built in 1913

530 Spring Street PROJECT SITE

Colonial Revival Style

Listed inArkansas Register of Historic Places on 11/7/01

Details

● East wing of ground level

● West wing converted into town museum

Gross Lease Area

Approximately 1,500 sq ft.

● 11’-0AFF

● Exterior brick, must stay unchanged

● Concrete columns

CONCEPT STATEMENT

The philosopher Plato said “our need will be the real creator” which overtime has been translated into the version commonly known as “necessity is the mother of all invention”. Like the creation of the railroad which once provided a way for many to make this small town of Winthrop their home, this medical center is a space created to provide those who still call this town home with the care they deserve.The linear trajectory of the railroad is much like the linear progression of the medical system. The two keep going so that people can continue to connect. Our connections are our source of purpose much like this community’s connection to its past is what keeps the memory of Winthrop’s history alive.

The locomotive is the muse for this design, originating from Latin words meaning “from a place”, “causing motion”. I want this place, Winthrop,Arkansas to remember the motion it once caused. Clean simple lines like a pair of continuous lines formed by a track gives a nod to theArts and Crafts era. However, this design will not deny the machine but it will empower peoples' agricultural crafts and life’s work. While staying to the values of simplicity, truthfulness and modesty, which are also principles embodied through healthcare. Untouched industrial concrete columns like steam will elevate occupants' attention to the grand height of the ceilings which will be adorned with crown molding to incorporate the historic precedents. Both horizontal planes, the ceiling and floor will be kept untouched as well…

CONCEPT STATEMENT

Nature is an important aspect of this design era and in the health/healing of humans so its inclusion is vital.All considerations of fenestration lead to the floor plans layout. Every room except one restroom was designed to have an experience with the surrounding environment.The color scheme takes from earth with rich shades of brown and green. Plants will be intertwined throughout open spaces and offices. Furniture will be an infusion of nature and technology much like the expansion ofArt Deco.The use of natural materials like metals, woods, stone and leather are key to the finishes but also helps keep the facility clear of many allergens, dust and dirt.This facility is designed with the whole family and various needs in mind so accessibility was a major focus. For this reason all flooring is flush, providing smooth transitions from one room to the next. Lastly, circulation is simple and open.

The destination of this medical clinic speaks to the town's history and connectivity. It is a central hub for the community.The location where most of its residents (who are mainly elderly) received an education.The place which stores memories displayed within the museum across the lobby and a building that has stood over 100 years.This building, the railroad and this town has endured through many situations but has been resilient!As the wheels of a train rotate to push forward, the progression of healthcare and evidence-based design now present in Winthrop will hopefully keep this town and its people moving forward.

PLAN 03 02 01
Step By Step DESIGN PROCESS BASE

FINAL FLOOR PLAN

MATERIALS

INSPIRATION

EGRESS

Winthrop Family Medical Center

RENDERED FURNITURE PLAN

FURNITURE PLAN

INTERIOR ELEVATIONS AND PERSPECTIVE SKETCHES

INTERIOR ELEVATIONS AND PERSPECTIVE SKETCHES

KEY IMAGES

EXPOSED BRICK

RATTAN

MATTE BLACK TRIM

ARCHED DOORS

WOOD EARTHTONES

INDUSTRIAL CLEAN LINES

LEATHER TRANSITIONAL NATURE CONCRETE

NATURAL MATERIALS

HOME LIKE

KEY IMAGES

2-Humber 2 Seater

in Vintage Brown Leather

SKU: 5055999244662

$1,085

SKU: 377118

Executive Desk- By Orren Ellis

SKU: F6725

1-SUPER DEAL

Tier Bookcase, Floating Wall Mounted Bookshelf

Wall Wood Shelves with Industrial Pipe Metal Frame, Rustic Brown

SPECIFICATIONS
2-Ankara Black Cane Chair with Ascend, Night Cushion
$799.00
Sofa 1-Lorena Canals Machine WashableABC Round Rug
$225
4-Mitzi Jasmine Single Light 12" Wide Pendant in Copper Model:H181701S-POC $198.00 2-Hunters Point Pendant in Black
$1,990.00
1-Kidkraft Round Storage Table & 3 Chair Set - GrayAsh
$71.99
2-Rio Reversible L-Shape $1,439.99 4 Hanging $68.98
