01;1 | Functional Border
A space with adaptable perimeters
A space encompassed by greenery that holds an inherent relationship with the outdoors. Elemental infrastructure trails the room’s perimeters, is open to interpretation and facilitates flexible application of space by its dwellers. This singular and continuous element alternates throughout the day and is easily substituted to become a working space - a bed - or dining space.
Advertisement
75% Boundary
01;1;1 Floor Space Dimentionality
1.1 - A minimum of 3 (m) length (L)
1.2 - A minimum of 2.5 (m) Width (W)
1.3- Height of the room is a Minimum of H>3 (m)
01.;1;2 Passage
2.1 - At least one entrance, with a visual connection to green space
2.1 - At least one face of the room should not be directly open to common space area
01.1;3 Openings
3.1 - 5% of the total wall Length (L2) adjacent to solid wall for privacy
3.2- Wall openings are adjustable and include at least two modes of operation, completely open or completely closed.
3.3 - At least 50% of the rooms floor space should have access to natural light
01.1;4 Joinery
4.1 - Horizontal Infrastructure -
4.1a - Horizontal Infrastructure includes at least one continuous segment of L1=1.8x (m)
4.1b - Continuous segment of L1=0.9(m) in width (W2)
4.1c - Infrastructure shall be attached or made up of the room perimeter
4.1d - Infrastructure shall be attached or made up of the room perimeter
4.1e- Height of horizontal infrastructure is required to be at the height H1 < window sill = Minimum of 0.6 (m) and no higher than 1 (m)
4.1f- Height of horizontal infrastructure is required to be at the height H1 < window sill = Minimum of 0.6 (m) and no higher than 1 (m)
Image a
Image a
Image b a
H’ - 600 mm
L> 3000 mm
Elevation | Adjustable opening
Image b
Refer to Ex. 1x
H’ > 3000mm b Refer to openings section 04
Image c c
H’ - 600 mm
The functional border can accoodate wet areas, in this case consider placing the joinery adjacent to a 200mm wall for service risers . To ensure that the room is sustainable, please secure the drainage for grey water recycling is connected to the functional border
The functional border can accoodate electrical appliances
Example
01;1 | Functional Border
A space with adaptable perimeters b’ a’ - Joinery with storage b’ - Sliding Window Opening c’ - Proximity to Garden
Refer to Image x Refer to Image x
The functional border can accoodate wet areas, in this case consider placing the joinery adjacent to a 200mm wall for service risers . To ensure that the room is sustainable, please secure the drainage for grey water recycling is connected to the functional border The functional border can accoodate electrical appliances
01;2 | Core
A space not confined by fixed
A space that is responsive and adaptive to the dwellers functional capacities and responds to changing environmental conditions as well as user interaction. The dweller is unlimited by the set and fixed boundaries of a room but can rather utilise the edge to create different personal domestic adaptations.
01.2;1 Floor Space
1.1 - Each room shall have a Minimum of 4 (m) length (L)
1.2 - Each room shall have a Minimum of 3 (m) Width (W)
1.3- Height of the room shall be a Minimum of H>3 (m)
1.3- 15-20% of the total Area of the room shall be designated to the essential core
01.2;2 Passage
2.1 - A minimum of one entry point and one bounding wall
01.1;3 Openings
3.1 - Minimum of one mobile and adjustable face
3.2- A Minimum of 3 elevations can expand/contract
Refer to Examples A1,2
3.3 - At least 50% of the rooms floor space should have access to natural light
01.1;4 Essential Core
2.5a- Services
2.5b- Essential Core includes all service infrastruc -ture e.g. plumbing, electricity and water
2.5c- Essential Core includes wet areas e.g. WC and, or shower and, or sink.
2.5d- Thickness of wall is minimum 150 mm
2.5e- Essential Core should not exceed a width W1 < 2m
2.5f- Essential shall be within a Maximum distance of D1 < 1.5(m) from room face
2.5f- Essential shall be within a Minimum distance of D2 > 1 (m) from remaining room faces
2.5f- Wall Thickness of Essential core shall be a Minimum of 100 (mm) to provide for acoustic quality
Image a
Image a
Image b
See Essential Core
Image b
Image c
The Core Room can accoodate wet areas, in this case consider placing the joinery adjacent to a 200mm wall for service risers . To ensure that the room is sustainable, please secure the drainage for grey water recycling is connected to the core wall Shading, or double glazing is recommended for windows facing the exterior to ensure eco concious energy preservation
A space not confined by fixed borders
In this example the room is facing the North and opens up from all four direction to a void. We provided double glazing and floor heating to ensure a low carbon footprint a’ - Joinery with storage b’ - Sliding Window Opening c’ - Proximity to Garden
Refer to Image x Refer to Image x
01;3 |Adaptable Layers
A space with interchangeable layers borders
A space that reciprocates one’s complex and varied modes of living through a system of layers that peel away or connect, and thus create different and flexible domestic opportunities within the room. Day Vs. Night, Work, Vs. Play, or perhaps a Bath Vs. a Bedroom.
01.3;1 Floor Space
1.1 - Each room shall have a Minimum of 4 (m) length (L)
1.2 - Each room shall have a Minimum of 2 (m) Width (W)
1.3- Height of the room shall be a Minimum of H>3 (m)
1.3- Min 15-20% of the total Area of the room shall be able to accommodate wet amenities, e.g. shower Min. of 2m2
Image a Image a
2.1 - The room is adjacent to green space & has immediate access to open air and natural ventilation
3.2- A minimum width of 700 mm passage between the wet and dry space
3.3 - Division between wet layer and dry layer is with fold-able / adjustable openings to allow for privacy
3.4 - At least one elevation that includes window / opening for natural light and is adjacent to the dry area
3.5 - At-least one bounding wall for privacy or a wall or equivalent to 30% of the wall total length
4.1- Water outlet to be provided adjacent to the wet area
4.2- 20% of the total wet area shall be angled at a Min. 50mm height difference with the dry area to allow for water drainage
01.3;2 Passage 01.3;3 Openings 01.3;4 Infrastructure 01.3;5 Materiality Image f
Image d Image c
5.1- A distinguished material between the dry and wet area
The Core Room can accoodate wet areas, in this case consider placing the joinery adjacent to a 200mm wall for service risers . To ensure that the room is sustainable, please secure the drainage for grey water recycling is connected to the core wall Shading, or double glazing is recommended for windows facing the exterior to ensure eco concious energy preservation
EXAMPLE 01;3 |Adaptable Layers
A space interchangeable layers a’ - Joinery with storage
Refer to Image x b’ - Sliding Window Opening c’ - Proximity to Garden d’ - Proximity to Garden
