Section: 08 Ancillary Material Key B: Brass, C: Stainless Steel, CH: Chrome Plated, D: Aluminium, EN: Electroless Nickel, P: Zinc Plated Carbon Steel, T: Titanium
Fireproof Sleeve: Part No: FG900 Application : Insulation and fire retardant, 1090ºC (2000ºF) short term flame protection. Operating temp: -54ºC (-65ºF) to 260ºC (500ºF)
A silicone covered sleeve which acts as a fire retardant, an insulator and a chafe protector. Installed by inserting the hose into the sleeve prior to hose fitting assembly. The standard colour is silver, but also available in orange on request.
fg900
fireproof sleeve tube o.d size to be covered
to suit hose
FG900-03S FG900-06S
1/4
600-02/03/04
3/8
600-06/200-04
FG900-08S
1/2
200-06/08
FG900-12S
3/4
200-10/12
FG900-16S FG900-20S
1
200-16
1 1/4
710-16
Part No.
To Suit Hose : All Material: Silicone
Textalu: Part No: TEXTALU Application : Insulation and fire retardent protection, To Suit Hose : All Material: Silicone Temp: Under continuous use: Up to 220ºC (428ºF)
An insulative fibreglass sleeving with a silicone coating designed to protect components in high temperature areas where the heavier fireproof sleeving is not required. It provides suprior insulation to components that must maintain stable temperatures to assure performance efficiency. Its braided construction allows good flexibility in temperatures as low as -40ºC.
textalu
textalu Part No.
to suit hose
TEXTALU-3/8 TEXTALU-1/2
600-03 / 04
TEXTALU-5/8
200-06
TEXTALU-3/4 TEXTALU-1
200-08
200-04
200-10 / 12
Raychem Heatshrink: Part No: DR-25 Application : Heat, abrasion and chemical resistant covering, capable of withstanding temperatures from: -75ºC (-103ºF ) to 150ºC (302ºF ) To Suit Hose : 600, 200, 210, 910, 710, 811, 510 Material: Raychem Colour: Black
An insulative fibreglass sleeving with a silicone coating designed to protect components in high temperature areas where the heavier fireproof sleeving is not required. It provides superior insulation to components that must maintain stable temperatures to assure performance efficiency. Its braided construction allows good flexibility in temperatures as low as -40ºC.
DR-25
raychem Heatshrink Part No.
to suit hose
DR-25-1/4 DR-25-3/8
600-02
DR-25-1/2
200-06
DR-25-3/4
200-06/08
DR-25-1
200-10/12
DR-25-1 1/2 dr-25-2
710-12/200-16
600-03/04
any 2 inch application
Aluminized Fibreglass: Part No: TCD Application : Aluminized Fiberglass Sleeving, offers continuous temperature protection, withstanding temperatures to: 343ºC (650ºF ) and short term temperatues of 538ºC (1000ºF ) To Suit Hose : All Material: Aluminized Fiberglass
60 Street_Performance_rev.03.indd 60
Aluminized Fiberglass Sleeving, offers continuous temperature protection to 650°F and short term thermal exposure to 1000°F. The sleeve reflects 90% of radiant heat energy.
TCD
ALUMINIZED FIBREGLASS Part No.
to suit hose
TCD-206G TCD-208G
-6 GLASS LINE SLEEVE
TCD-210G
-10 GLASS LINE SLEEVE
TCD-212G
-12 GLASS LINE SLEEVE
TCD-212K TCD-216G
-12 KEVLAR LINE SLEEVE
-8 GLASS LINE SLEEVE
-16 GLASS LINE SLEEVE
