Hose
Special Application Hose
Fuel and oil Fire resistant USCG/MMT, NMMA/BIA
FC234
Part Number
Hose I.D. (inches)
Hose O.D. (inches)
Max. Oper. Pressure (psi)
Min. Burst Pressure (psi)
Min. Bend Radius (inches)
Vacuum Service (in./Hg)
Wt. Per Ft. (lbs)
FC234–05
.25
.58
1500
6000
1.00
28
.22
FC234–06
.31
.68
1500
6000
1.25
28
.25
FC234–08
.41
.76
1250
5000
1.75
28
.30
FC234–10
.50
.94
1250
5000
2.25
28
.45
FC234–12
.62
1.08
750
3000
2.75
20
.48
FC234–16
.88
1.24
400
1600
3.50
16
.51
FC235–04
.25
.50
50
250
3.00
.12
FC235–05
.31
.56
50
250
3.00
.13
FC235–06
.38
.63
50
250
3.00
.13
2555–6
.38
.76
1125
4500
4.00
.20
Construction: AQP elastomer tube, brass plated steel wire reinforcement, braided refractory insulation and blue AQP elastomer cover. Application: Diesel fuel, gasoline, hot lube oil and water. Operating Temperature Range: –40°F to +300°F (–40°C to +150°C). For complete Agency Listings: See page 20.
Fuel and oil SAE 30R6 SAE 30R1
FC235
Construction: Synthetic rubber tube, textile braid reinforcement and synthetic rubber cover. Application: Air, gasoline, fuel, lubricating oils and coolants. Operating Temperature Range: –40°F to +212°F (–40°C to +100°C). For complete Agency Listings: See page 20.
Power steering
2555
Construction: Synthetic rubber tube, double textile braid reinforcement and synthetic rubber cover. Application: Power steering applications. For more information on specific fluid applications and high temperature ratings, see pages 22-26. Operating Temperature Range: –40°F to +212°F (–40°C to +100°C). For complete Agency Listings: See page 20.
78
