Hydraulic Hose Hose I.D. (inches)
Hose O.D. (inches)
Max. Oper. Pressure (psi)
Min. Burst Pressure (psi)
Min. Bend Radius (inches)
GH493–6**
.38
.79
4000
16000
5.00
.47
GH493-8
.50
.92
4000
16000
7.00
.59
GH493–10
.63
1.11
4000
16000
9.50
.69
GH493–12
.75
1.20
4000
16000
9.50
.92
GH493–16
1.00
1.48
4000
16000
12.00
1.22
GH493–20
1.25
1.83
3000
12000
16.50
1.64
GH493–24 Construction: Synthetic rubber tube, 4 spiral wire reinforcement, synthetic rubber cover. Application: Hydraulic systems service with petroleum and GH493–32 water base fluids, for general industrial service. For more information on specific fluid applications and high temperature ratings, see pages 22-26. Operating Temperature Range: –40°F to +250°F (–40°C to +121°C). For complete Agency Listings: See page 20.
1.50
2.12
2500
10000
20.00
2.10
2.00
2.64
2500
10000
25.00
2.81
FC250A08
.50
.92
4000
16000
7.00
.58
FC250A12
.75
1.20
4000
16000
9.50
.87
FC250A16
1.00
1.48
4000
16000
12.00
1.40
FC250A20
1.25
1.83
3000
12000
16.50
1.84
FC250A24
1.50
2.12
2500
10000
20.00
2.10
FC250A32
2.00
2.64
2500
10000
25.00
2.81
FC136–06**
.38
.79
.45
.50
.92
7.00
.60
FC136–10
.63
1.11
22000 16000 * 20000 16000 * 20000 16000 *
5.00
FC136–08
5500 4000 * 5000 4000 * 5000 4000 *
9.50
.67
FC136–12
.75
1.20
4000 †
16000
9.50
.90
FC136–16
1.00
1.48
4000
16000
12.00
1.19
FC136–20
1.25
1.83
3000
12000
16.50
1.60
FC136–24
1.50
2.12
2500
10000
20.00
2.01
FC136–32
2.00
2.64
2500
10000
25.00
2.93
Hose
Part Number
GH493 Four heavy spiral wire SAE 100R12
Four heavy spiral wire SAE 100R12
FC250A
Vacuum Service (in./Hg)
Wt. Per Ft. (lbs)
Construction: Synthetic rubber tube, 4-heavy spiral wire reinforcement and gray synthetic rubber cover. Application: Hydraulic system service with petroleum and water base fluids, for general industrial service. For more information on specific fluid applications and high temperature ratings, see pages 22-26. Operating Temperature Range: –40°F to +250°F (–40°C to +121°C). For complete Agency Listings: See page 20.
Four heavy spiral wire Exceeds SAE 100R12
FC136
Construction: Synthetic rubber tube, 4-heavy spiral wire reinforcement, synthetic rubber cover. Application: Hydraulic system service with petroleum and water base fluids, for general industrial service. For more information on specific fluid applications and high temperature ratings, see pages 22-26. Operating Temperature Range: –40°F to +250°F (–40°C to +121°C). For complete Agency Listings: See page 20.
*Pressure rating with TTC12 fittings. †5,000 operating pressure with 20,000 burst pressure when operating within –40°F to +200°F (–40°C to +93°C) temperature range. **Approved for 10,000 psi maximum operating pressure for static Jack Hose applications
