SPECIALTY & TRUCK HOSE
2808 PTFE
Part Number
LOW & MEDIUM PRESSURE HOSE
2808-08 2808-10 2808-12 2808-16 2808-20 2808-24
Hose I.D.
mm
in
10,7 12,9 16,5 22,3 28,4 35,0
0.42 0.51 0.65 0.88 1.12 1.38
HIGH PRESSURE HOSE
Construction Extruded PTFE tube with double stainless steel braids. Operating Temperature Range –73°C to +260°C [–100°F to +500°F]
Hose O.D.
mm
14,7 17,3 20,6 27,7 34,3 41,1
in
0.58 0.68 0.81 1.09 1.35 1.62
Maximum Operating Pressure
Minimum Burst Pressure
bar
psi
bar
psi
190,0 172,0 121,0 103,0 78,0 55,0
2750 2500 1750 1500 1125 800
758,0 689,0 483,0 414,0 310,0 221,0
11000 10000 7000 6000 4500 3200
HOSE FITTINGS
Application Hot air, steam and most chemical applications. Not recommended for steam-cold water cycling. For more information on specific fluid applications and high temperatre ratings, see pages 400-404. † Steam 200 psi at +388°F max. Engineering information is available for specific critical temperature requirements. Contact Eaton.
r
Minimum Bend Radius
mm
in
117,3 4.62 139,7 5.50 165,1 6.50 187,4 7.38 279,4 11.00 355,6 14.00
‡Maximum negative pressure for -08 and larger are suitable for hose which has suffered no external damage or kinking. If greater negative pressures are required for -08 and larger hoses, the use of an internal support coil is recommended. Use of an internal support coil in -08 and larger PTFE hose is recommended for tube support where extended or continuous service at high temperature together with low or negative pressure is expected. For Complete Agency Listings See pages 397-398.
Vacuum Service
kPa
94,8‡ 94,8‡ 67,7‡ 50,8‡ 50,8‡ 50,8‡
Weight of Hose
in/Hg
Kg/m
lbs/ft
28‡ 28‡ 20‡ 15‡ 15‡ 15‡
0,30 0,39 0,45 0,65 0,85 1,04
0.20 0.26 0.30 0.44 0.57 0.70
Fitting Reference Reusable Fitting Socket Data
Page 189 65
ADAPTERS & TUBE FITTINGS
FC469 PTFE Conductive
r Part Number
ACCESSORIES & ASSEMBLY INSTRUCTIONS
FC469-06 FC469-08 FC469-10
Hose I.D.
Hose O.D.
mm
in.
mm
7,6 9,9 12,4
0.30 0.39 0.49
12,2 15,5 18,3
Construction Conductive extruded PTFE tube with stainless steel single wire braid.
HOSE ASSEMBLY EQUIPMENT
Operating Temperature Range –54°C to +204°C [–65°F to +400°F]
in.
0.48 0.61 0.72
Maximum Operating Pressure
bar
psi
280,0 4000 280,0 4000 245,0 3500
Application High pressure chemical and fluid transfer. For information on specific fluid applications and high temperature ratings, see pages 400-404. † Steam 200 psi at +388°F max. Engineering information is available for specific critical temperature requirements. Contact Eaton.
Minimum Burst Pressure
bar
Minimum Bend Radius
psi
mm
1120,0 16000 1120,0 16000 980,0 14000
63,5 73,2 82,6
in.
2.50 2.88 3.25
‡Use of an internal support coil in -06 and larger PTFE hose is recommended for tube support where extended or continuous service at high temperature together with low or negative pressure is expected.
Vacuum Service
Weight of Hose
kPa
in/Hg
Kg/m
94,8‡ 94,8‡ 94,8‡
28‡ 28‡ 28‡
0,25 0,36 0,43
lbs/ft
0.17 0.24 0.29
Contact Eaton for fitting information.
For Complete Agency Listings See pages 397-398.
APPENDICIES
Page 36 30
EATON Aeroquip Fluid Conveyance Products A-HOOV-MC001-E1 March 2011
