Machines Italia News

BRAGONZI SpA (Lonate Pozzolo, Italy; www.bragonzi.it) TC 110 originated in a project intentionally designed with advanced systems, sized and structured to ensure the maximum production flexibility and structural rigidity, all these requirements to maintain overtime. The spindle, designed to ensure high power levels also in the low rotation speeds, keeps the production process of milling and boring to high performances.

The great removal capacity, associated to the maximum precision and rigidity, are ensured by the design, the manufacturing choices and Bragonzi’s experience and tradition, who boasts over 90 years of activity. Another topic that characterizes BRAGONZI TC 110 is the shape of the riser gantry head with thermos-symmetrical geometry BRAGONZI TC 110 is equipped with coolant liquid, inside and outside the spindle; automatic tool charger (40-120 tools); milling heads; motors and digital drives; CNC Heidenhain or Siemens (or custom). BRAGONZI TC 110 has flat guide-ways for all axes, hydrostatic table and double pinion for the recovering of accuracy.

OCMI SpA (MIlan, Italy; www.ocmigroup.com) represents nowadays one of the most important companies specialized in the field of glass processing and forming. The equipment and lines manufactured by OCMI allow to work with different types of glass, from borosilicate to soda-lime for different productions.

In North America OCMI is working with biggest groups operating in the field of pharmaceutical glass packaging in U.S.A. and Mexico, being the main machines supplier for Schott, Gerresheimer and Nipro that are the three biggest glass tube manufacturers and converters worldwide.

GALILEO—Hardness Testers Galielo, a busniess division of LTF SpA (Antegnate, Italy; www. ltf.it) features a double scale dial indicator to the state-of-the-art models of the digital range, fitted with a sophisticated software and touch screen display to control the instrument and the measuring process. Diverse hardness tester models for Standard and Superficial Rockwell tests, as well as Brinell and Vickers, equipped with indenters and test blocks, set of loads and accessories for any application need.

A renovated line of microhardness testers for measuring Vickers and Knoop microhardness, available in either optical-digital or computerized version for the automatic reading of the indentation. The latest contribution in favor of an increasingly automation of the product is the new CNC MICROHARDNESS TESTER, featuring 5 motorized axes controlled by a measuring software designed to meet the most advanced requirements in the microhardness field.

From tradition to excellence.

ODE Srl (Borgofrancone, Italy; www.ode.it) introduces a new solenoid valve series called 21ALB 2/2 way N.C., N.O. and 31ALB 3/2 way N.C. direct acting in stainless steel.

The New ALB series provides better performance for more critical applications than our similar series 21A1 and 31A1 series in brass, and the technopolymer versions 21APB and 31APB, because the valve body and internal components are manufactured entirely of AISI 316 stainless steel, including the orifice.

The main advantages of the new series are the full compatibility with any type of food grade fluid due to the total absence of lead, the resistance to extreme high and low temperatures for managing the steam and other liquids such as freon, nitrogen and ozone. These solenoid valve models are particularly versatile and suitable for sectors such as Vending, Coffee Machines, Pneumatic,, Fuel gas, Petrochemical, Refrigeration and Medical for handling aggressive fluids .

In its near hundred-year history, Italian group OCMI-OTG SpA (Milan, Italy; www.ocmigroup.com) has developed into an industry leader in its own right.

Defined by Mr Andrea Colombo, Sales Manager of the OTG division as, “two entities that coexist under the same roof, but that are completely different from one another”, OCMI and OTG are the two main components of the OCMI Group; an outstanding Italian business headquartered in Via Venezia Giulia, Milan and run by the third generation of the Gusti family.

The core business of the group is broken into two divisions: OTG specializes in manufacturing madeto-order reduction gears and overgears specifically for applications in the oil and gas industries; and OCMI - a leading manufacturer of machineries and finishing lines for the production of pharmaceutical and cosmetic glass containers from glass tubes.

The automation of cut and breakout processes was for the customer a need becoming more and more impellent. The constantly increasing glass quantities managed by the company, and the diversification of the raw materials employed in the process represented a problem for the management of the stock of raw materials. Thanks to the solution suggested by Bottero SpA (Genova, Italy; www.bottero.com), the Customer has met its needs of increasing the production capacity still keeping the flexibility required by the after-cut glass processing, and implementing the automation of the management of the stock of raw materials.

UMBRAGROUP: Innovative Momentum Great news for UmbraGroup SpA (Foligno, Italy; www.umbragroup.it/en/), world-class producer of precision mechanical products and leader in the manufacture of aeronautical ballscrews market.

Founded as Umbra Cuscinetti S.p.A. in Foligno (PG) in 1972, today it is a reference point for high tech markets in the industrial, energy and aerospace sectors. The Group has operations in Italy, Germany and the United States and a Research Center in Southern Italy. It employees approximately 1000 employees, and closed 2015 with a turnover of €160 million.

Antonio Baldaccini, President and CEO of UmbraGroup since 2014, strongly embraces innovative momentum. The Group is transforming itself into a cutting-edge operation, inspired by the Lean Production method whose principles have been applied to all business processes.

Titanium and titanium alloys owe their success to the high resistance/density ratio that characterizes them. Thanks to mechanical characteristics comparable to those of steel and to a specific mass which is about one and a half that of aluminum, titanium is widely used in fields that require lightweight structures capable of resisting to important stresses. According to Mandelli Sistemi SpA (Piacenza, Italy; www.mandelli.com), the ideal solution for the machining of titanium in the Aerospace sector is a 5-axis machining center with high stock removal. Starting from the Spark Line, we have developed the Spark Ti Line that, thanks to the adoption of spindles capable of generating high torque and the introduction of antivibration systems on all axes, reaches high stock removal and high quality surface finishing on a single MC.

Providing both the best and the most advanced technology, the innovative Parpas Group SpA (Padova, Italy; www.gruppoparpas. com), an Italian manufacturer of machinery tools, won the confidence of aerospace corporation Lockheed Martin (LM).

Parpas Group is the first supplier for Lockheed Martin to supply two High Precision Milling Machines to machine the front fuselage of the new F-35 strike fighter in its manufacturing plant in Fort Worth, Texas. Thanks to the success of this important project, Parpas Group subsequently obtained a new order to supply an additional four new machines which will be installed in the plant in Fort Worth over 2016.

Argos: Mist Collectors - Losma Presents a New Family of Air Filtration Systems Losma SpA (Bergamo, Italy; www.losma.com), a leading company in the design and construction of air and coolant filtration systems for the machine tool industry, presents a new cartridge filtration unit.

The new Argos series is designed to capture mist, vapor and smoke generated during machining operations. Argos units are available in 3 sizes with throughputs ranging from 2000 to 9000 ft3/ min (3.000 to 15.000 m3/h). Configurations with filtration efficiencies up to 99.97% are available. The re-condensed mist is collected in a tank, which can also be equipped with a pump to automatically discharge the tank.

Remote Control Slope Mower ICUT4 iCUT4, by FERRI Srl (Tamara, Italy; www.ferrisrl.it) the most powerful remote control slope mower in its category providing top performance in the most challenging ground conditions. An amazing reliable and consistent machine that sticks to steep gradients like a spider on a glass wall .

The latest born at Ferri’s factory is an amazingly reliable and robust remote control slope mower which ensures optimal grip and traction thanks to its cutting edge design and attention to details. ICUT4 proves to be a real slope mower that is able to work in perfect safety, with maximum comfort. • 4-cylinder engine: more power to tackle slopes and difficult terrains. • Intuitive control-box with display visualizing operations step by step. • Bigger fuel tank for greater autonomy and economy.

Facilitated Loading/Unloading Operations Italcarrelli Srl (Chiampo, Italy; www.italcarrelli.eu) has developed and patented, a revolutionary loader for the flat glass industry. The EN BOX 25 has been designed for the loading and unloading of glass in crates directly from containers. Given the continuous increase in demand of import/export of crates of flat glass, Italcarrelli has developed a machine to simplify these very laborious operations which are also, at times, risky for the glass but, above all, for operators, as loading is often carried out with “artisan” equipment that can damage the crates or, even worse, the person working. Companies often prefer to ship glass in open top containers for the higher ease of loading, but these types of containers are certainly a lot more expensive. With EN BOX 25 it is possible to load and unload a traditional container in just a few minutes with a single operator in complete safety.

Machines and equipment for meat processing are represented by the association COMACA - Meat Processing Machinery Manufacturers and ASSOFOODTEC - The Italian Association of Machinery and Equipment for the Production, Processing and Preservation Food (www.anima.it/ass/assofoodtec). The sector, according to the latest SOUL Office analysis, concludes the year 2015 with an appreciable growth of production value (+ 4.9%) compared to 2014. The prospects for the 2016 year are of further growth (+ 3%).

It is a strongly characterized by the export sector, which takes a share of nearly 70% of production. Exports during 2015 grew (+ 4.9%) and the 2016 is expected to see further growth (+ 2.8%). Employment grows in 2015 (+ 1.7%) and is expected to also increase during 2016 (+ 1.6%). investments have also increased (+ 2.5%) and are expected to also increase during 2016 (+ 1.8%). There are almost 77 million EUROS of Italian goods exported around the world. The technologies for meat processing are required by dell’EU28 countries for about 42%, followed by North America with about 17% and the remaining target areas. Compared to 2014, 2015 in the US has doubled the demand for Made in Italy for meat processing thus remaining on top of the 15 countries export markets.

The trend is improving. After a small crash in exports recorded between the 2012 and 2013 from 2013 on exports have resumed their pace, confirming the excellence of these technologies.

The MONALISA Group has once again chosen CMF TECHNOLOGY SpA (Frignano, Italy; www.cmftechnology.com), assigning to them the construction of the new production line for large sizes of tiles that is to be installed at the factory located in Foshan, China. The new accessories, which can be implemented on STONERISE press feeding carriages, were found to be the most appropriate for obtaining the product ranges developed together with leading Italian and Spanish glazes manufacturers. The functional simplicity of CMF TECHNOLOGY’s equipment, combined with the possibility of creating textural effects in both single and double charging, convinced the well-known Chinese manufacturer to reaffirm CMF TECHNOLOGY as its strategic partner.

In fact, the RECOLOR dry coloring units and the TBOX front-kiln storage systems have been used successfully for several years at MONALISA’s production facilities.

DRILL 1600: The 4 Axis Drilling CNC Machine DRILL 1600, developed by SKG Srl (Schio, Italy; www.skillglass. it), is a 4 axis drilling CNC machine designed for producing holes and countersinks on rectangular flat glass sheet with a thickness of 3-20mm. The machine is composed of four axes, X Y Z W, and 2 electro-spindles positioned opposite one another creating a dead center system that drills perfect holes.

This vertical drilling CNC is able to operate with extreme speed and precision thanks to the management of all the processes by numerical control and also thanks to the support of the double tool change of six positions.

The milling on this machine is a simple and quick operation and by using multiple tools can mill and grind an insert in just a few seconds like the polishing that can be carried out in small inserts with 50 or 30 mm grinders.

The Turning Point in the World of Spraying EPOCHAL The solution is EL.PA. Service Srl (Vicentina, Italy; www. elpaservice.com) to reduce production costs while improving quality! In a time when the global crisis is reducing profit margins, the ‘importance of curbing production costs is becoming increasingly apparent and necessary. EL.PA. Service Srl is a wellestablished company in the field of design and construction of machinery for processing technologically advanced skins.

The company recently introduced to the international market a new concept of rotary spray booth for skins: EPOCAL. And the result of a huge studio straining to get a real step forward compared to the systems available on the market today.

SANTEX RIMAR GROUP Srl (Trissino, Italy; www.santexrimar. com) has moved into the weaving machine sector for the textile industry with the official entrance among its companies of SMIT, one of the world’s leading manufacturers of weaving machines.

“SMIT technological know-how and committed human capital struggled in the past with operational problems but deserves to keep growing. We firmly believe in this restart: we have a solid plan involving our territorial district historically devoted to textile industry. We will start SMIT production in Trissino where SANTEX RIMAR GROUP headquarters are based and supplying customers throughout the world” said Ferdinando Businaro, SANTEX RIMAR GROUP President. SMIT has been a front runner in the weaving textile machine sector since 1938 and has become a key player worldwide in supplying weaving machines for a large variety of applications: the technology characterizing SMIT production includes weaving machines with rapier weft insertion for home textiles, garments and terry cloths; air-jet weft insertion machine for high production volumes and customized solutions for the production of special technical fabrics.

The Agriculture and Turf division of Papé Machinery demonstrated the Italian Monchiero (Pollenzo, Italy; www.monchiero.com) 20125 evolution harvester at America’s only hazelnut equipment show this past August. The exhibition was held during the annual Nut Growers Society of Oregon, Washington and British Columbia’s Summer Tour.

“Papé Machinery is pleased to introduce the Monchiero 20125 evolution harvester to hazelnut growers throughout the Pacific Northwest,” said Carl Laux, Regional Agriculture and Turf Sales Manager for Papé Machinery. “What sets the Monchiero 20125 apart from the competition is its ability to harvest the greatest quantity of nuts in the minimum amount of time, especially during inclement weather, when speed and accuracy are critical to maximizing yield.”

TUBULAR ANTIPILLING: The Solution That Every Dyehouse Was Waiting For At Milano ITMA 2015 Corino Macchine SpA (Monticello, Italy; www.corinomacchine.com) launched TUBE-ONE™, the first machine in the world to effectively extract enzyme residues from the internal surface of tubular fabrics after bio-polish treatment in the dyeing process. Its innovative working concept gives great benefits in relationship to the other systems present on the market. In particular: it offers the best balance between cleaning effect and productivity, no requirement to reverse the fabric in its operations and can be easily operated by one technician.

Magaldi Technologies: LLC is the Newest Subsidiary Within the Magaldi Group of Companies With a successful history and promising future in the North American markets, Magaldi SpA (Salerno, Italy; www.magaldi.com), a leader in the supply of equipment and services in the world’s toughest material handling conditions, has registered Magaldi Technologies LLC, in Atlanta, Georgia. From this prominent business hub, Magaldi Te c h n o l o g i e s , LLC (MTL) will ultimately be home to all commercial and service leadership for the company’s activities in the North American marketplace. The next step in this comprehensive strategy of Magaldi’s commitment to the North American market, is to provide technical after sales personnel that will provide after sales support for its customers while having locally based spare parts available.

Over the last decade, the evolution of the Internet of Things, Big Data and the desire for ever-increasing productivity has driven the smart manufacturing movement. Today, manufacturers can see and react to the performance of their machines and integrated systems with analytics in real time.

SME-Society of Manufacturing Engineers, in collaboration with the Italian Trade Agency has conducted a survey showing how Industry 4.0 techniques integrated with Italian machinery are making life easier for North American companies. See the full results which are exclusively available in the digital version of this magazine.

The digital version also includes the interactive map of Italian machinery manufacturers’ subsidiaries in the NAFTA marketplaces many of which are featured in this publication. To gain access to this exclusive content, go to www. machinesitalia.org/ magazine.

The atmosphere in the wood machinery industry has clearly improved. Plenty of signals from several directions are generating optimism, with the additional support of hard figures: in 2015, the turnover of Italian woodworking technology amounted to 1.8 billion euros and the economic survey for the first quarter 2016 showed further positive signals, with a 22.7 percent growth driven by sustained business both in Italy and across the borders.

Although business follows specific and well-known trends during a year, if such increase continues at 10 percent on an annual basis, total 2016 turnover could exceed the 2 billion euros threshold, getting very close to 2.1 billion euros which would represent an all-time record for the industry. “We can say with confidence that a great contribution to this result was given by Xylexpo 2016, our biennial exhibition that finished in May”, said Lorenzo Primultini, President of ACIMALL - Italian Woodworking Machinery and Tools Manufacturers’ Association (www. acimall.com/en/) and of the exhibition.

FAP PE-PP Foam Sheet Extrusion Line FAP Srl (Besana Brianza, Italy; www.fapitaly.com) extrusion lines produce polyethylene (PE) and polypropylene (PP) expanded foamed by iso-butane and or normal butane gas, 100% recyclable at the lowest density that can be used in all production fields where it is necessary to insulate, package, protect (for example in building, electronic, mechanical, automotive, food industries). Extruders are fully automatic and divided in more zones to control temperatures and pressures levels, equipped with dosing units that ensure a supply of the raw materials with high precision. Accurate studies and researches on construction and implementation of the electrical equipment has led to a remarkable power saving method and thus to lower production costs. The extrusion lines are designed to work 24/7/365 and therefore built with high quality materials which have been treated for long-life use reducing to a minimum the need for maintenance. The process of extrusion by Direct Gas Injection (iso-butane / butane standard) transforms plastic granules (PE-PP) into various forms of thickness and density as required by their customers.

Founded in 1940, Helios Quartz Group has been a family-owned company with two production plants in Italy, Helios Italquartz Srl (Cambiago, Italy; www.heliosquartz.com) and Switzerland (Helios Quartz Group SA) combined with different distribution channels in the USA, South America and Asia to become a major international supplier for Quartz Glass processing and for the manufacturing of Infrared Quartz Emitters, Ultraviolet Lamps and Specialized Equipment for Industrial, Scientific and Medical applications.

Helios Quartz products are used in different areas of various applications of the Glass Industry such as laminated glass production and processing, drying screen printing and coating curing, mirror production, glass bending and fusion.

The decision to invest and open a branch in the United States comes from the awareness of the potential of the American market and the importance of being able to follow the customers locally with skilled staff on site.

Thanks to such important investment Helios Quartz is an international point of reference and it’s continuously increasing its business with the most important players of the global market which appreciate the high quality and reliability of made in Italy products.
