4 5 6 7 8 9
4 5 6 7 8 9
Battery Alarm Voltage (07x#)
This option sets the battery voltage threshold below which the general alarm will activate. The default Battery Alarm Voltage is 10.0 Volts. This alarm can be set to activate one of the relays, and is part of the General alarm. Value 0 1 2 3 4 5 6 7 8 9
11.3.4
Alarm 9.0 V 9.5 V 10.0 V 10.5 V 11.0 V 11.5 V 12.0 V 12.5 V 13.0 V 13.5 V
Technical Information
11.3.3
Input Type (11x#)
The control inputs can be inverted. Unless an input is used for a Gate switch, in which case it is always NC. Value (x) 0 1
JVA ZLM1 Manual
Input type NO Normally open NC Normally Closed
Page 45
