26360 & 80207 Inline
VALVES
• 3/2- & 5/2-Spool valves electromagnetic actuated, indirectly controlled
Manual override with and without detent
Technical features
• G1/4, G1/2 The solenoid valves are used in ATEXzones, resulting from Protection Class Atex-category of solenoids (see table of solenoids).
Medium: Filtered, lubricated or non-lubricated Air Operating pressure: 1 … 10 bar (14 … 145 psi); G1/4 1,5 … 10 bar (21 … 145 psi); G1/2 2 … 10 bar (29 … 145 psi); G1/2 Fluid/Ambient temperature: -10°C … +60°C (+14°F … +140°F) -20°C (-4°F) on request Depending on solenoid system.
Materials: Housing: aluminium anodized Pilot flange: plastic (POM) Seals: NBR
Air supply must be dry enough to avoid ice formation at temperatures below +2°C (+35°F)
Approval depends on magnetic system
2
30
Technical data 3/2-Way
V-32C-EM-S 1
3 2
Symbol
Model V-32C-EMH-S
1 2
For further information www.imi-precision.com
1
3 4
Port size
Operating pressure (bar)
Flow (l/min)
Manual override with detent
8020765
G1/4
1 … 10
1200
with
V-32C-EMH-S 8020865
G1/2
1,5 … 10
3000
with
Port size
Operating pressure (bar)
Flow (l/min)
Manual override with detent
G1/4
1 … 10
1200
with
2637065
G1/2
2 … 10
3000
with
2636265
G1/4
1 … 10
1200
with
G1/2
2 … 10
3000
with
*1)
3
2
*1) When ordering, please indicate solenoid, voltage and current (frequency).
V-52-EM-S
513
5/2-Way
4 4
2 2
V-52B-EM V-52-EMH-S Model
Symbol
5 51 13 3
*1)
4 4
2636065
2 2
V-52B-EMH V-52-EMH-S 5 51 13 3 4
2
513
V-52B-EMR 2637265
*1) When ordering, please indicate solenoid, voltage and current (frequency).
