Chapter 1 Informational Data 1.1 HOIST TACKLE CHART This chart only represents the maximum permissible hoist line load per parts of line. You must refer to the proper Lift Charts for machine rated loads. Table 01 – 1
Line Parts
MAXIMUM PERMISSIBLE HOIST LINE LOAD LINE PARTS 1 2 3 4 5 6 7 8 MAXIMUM PERMISSIBLE 4375 8750 13125 17500 21875 26250 30625 35000 HOIST LINE LOAD (KG) MAXIMUM PERMISSIBLE 9645 19290 28935 38580 48226 57871 67516 77161 HOIST LINE LOAD (LBS) Wire rope: 17NAT-15*K7-IWRC-1960MPa (11/16″ROTATION RESISTANT 15×K7 COMPACTED STRAND, GRADE 1960) Weight: 139 kg/100m (0.9 LBS/FT) Minimum breaking strength: 251 kN (56.4 KIP) 1.2 TIRE INFLATION CHART Table 01 – 2 TIRE SIZE 20.50-25-28PR
Tire Inflation Chart
RECOMMENDED TIRE PRESSURE STATIONARY CREEP (1.6 KM/H) 625 kpa (91 PSI) 625 kpa (91 PSI)
RT35 Rough Terrain Crane
TRAVEL 625 kpa (91 PSI)
1-1
