MAINTENANCE After Initial 50 Hours of Operation Perform the following procedures after the first 50 hours of operation. • Lubricating the engine coupler • Changing the stern-drive oil
■ Lubricating the engine coupler
1
Lubricate the engine coupler every 50 hours if operated at idle for prolonged periods of time. Note: The stern-drive may be equipped with a sealed engine coupler. The sealed coupler and shaft splines can be lubricated without removing the stern-drive. Apply approximately 8 to 10 pumps of grease to the engine coupler grease fitting (1, Figure 2) to lubricate the engine coupler splines through the grease fittings, if equipped. Use a typical hand-operated grease gun to apply the grease.
039056-00X00
Figure 2 Description
Where used
Multi-purpose heavy-duty type lithium grease, NLGI #2
Coupler
Note: Lubricate the coupler on the ZT370 model every 50 hours if the vessel is operated at idle for prolonged periods of time.
■ Changing the stern-drive oil See Changing the stern-drive oil on page 41.
