Operation
2.
3.
4.
To return the outboard motor to the normal running position, place the gear shift lever in neutral, then place the tilt lock lever in the lock position.
5.
Slightly tilt the outboard motor up. Slowly tilt the outboard motor down while pulling the tilt support bar lever up.
6.
Slowly lower the outboard motor to the normal position.
Place the tilt lock lever in the release position.
Slightly tilt the outboard motor up. The tilt support bar will lock automatically, supporting the outboard motor in a partially raised position.
EMU28190
Cruising in other conditions Cruising in salt water After operating in salt water, wash out the cooling water passages with fresh water to prevent them from becoming clogged with salt deposits.
NOTE: The outboard motor is equipped with 2 or 3 positions for shallow water cruising.
NOTE: For cooling system flushing instructions, see page 26.
24
