093.30 WASTEGATE AND CONNECTIONS – L5794 LT ITEM NO.
PART NUMBER
L5774
L5794
L7044 DESCRIPTION
LT
GSI
LT
GSI GROUP 93
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
295645R 209493 214067P 199109B 214067V 214067R 21350 214067T 199111B 199111C 118566X 78208B 73413A 211954 154813T B277 21051 21181 214067G 65110Z 207147U 169013K 21052 21343 Y18813H 21189
2 1 1 2 1 1 2 1 4 4 2 2 2 1 2 4 4 4 1 2 1 1 3 1 1 1
REGULATOR, Bypass Wastegate BRACKET, Tube Support TUBE, Wastegate Water, RB TEE, 3/8” x 1/4” NPT x 3/8” TUBE, Wastegate Water Out, RB TUBE, Wastegate Water Out, RB CAPSCREW, Hex Head, 3/8”-16 x 1-3/16” TUBE, Wastegate Pressure, LB ELBOW, Male, 3/8” x 1/4” NPT ELBOW, Male, 3/8” x 3/8” NPT PIPE, 3/8” x 1” TEE, Pipe, 3/8” COCK, Drain, 3/8” SHIELD, Heat, Exhaust Tee Bypass U-BOLT, 5/16”-18 WASHER, Flat, 5/16” WASHER, Lock, 5/16” x M8 NUT, Hex, 5/16”-18 TUBE, Wastegate to Wastegate PIPE, 1/8” x 1-1/4” DECAL, Instruction CLIP WASHER, Lock, 3/8” CAPSCREW, Hex Head, 3/8”-16 x 3/4” WASHER, Flat. 3/8” NUT, Hex, 3/8”-16
PART NUMBERS ARE FOR REFERENCE ONLY. REFER TO ENGINE SPECIFICATION.
139
FORM 6302-2 © 12/2011
