Reconditioning / replacing: Engine body 11. Check the crankshaft axial play and replace the thrust washers if the clearance is too big or if the thrust washers are damaged. NOTE: Axial play is measured using a dial indicator. The thrust washers are available in a number of oversize dimensions. See “Technical data” for oversize dimensions and axial play. 12. The crankshaft thrust bearing pin is placed in the middle main bearing.
13. Use a narrow plastic or wood stick to remove the thrust bearing washers in the cylinder block bearing seat. NOTE: The thrust washers can only be placed in one position.
14. Check the axial play of the crankshaft when all main bearing caps have been torqued, see “Technical data” for specification. 15. Install bracing frame and torque as specified in “Technical data.” 16. Fit oil pump and oil suction pipe. 17. Remove the turning tool 9993590 from the flywheel casing and install the cover. 18. Fit the oil pan. Add oil and replace oil filter. Check the oil pressure. 93
